Evenflo Pivot Vizor Manual de usuario

Stroller/Travel System

Poussette/Système de déplacement

Carriola/Sistema de viaje

Read all instructions before assembly and use of product.

KEEP INSTRUCTIONS FOR FUTURE USE.

Lire toutes les instructions avant d’assembler et d’utiliser le produit.

GARDER LE MODE D’EMPLOI POUR UTILISATION ULTÉRIEURE.

Lea todas las instrucciones antes de ensamblar y usar el producto.

GUARDE LAS INSTRUCCIONES PARA USO FUTURO.

STROLLER

Up to 55 lbs (25 kg)

Up to 40 in (101.6 cm)

POUSSETTE

Jusqu’à 25 kg (55 lb)

Jusqu’à 101,6 cm (40 po)

CARRIOLA

Hasta 25 kg (55 lb)

Hasta 101,6 cm (40 pulg)

ENGLISHESPAÑOL FRANÇAIS

Warnings.................................................................................................. 4

Important Information ............................................................................. 7

Identification of Parts.............................................................................. 8

Choosing Mode of Use ........................................................................... 9

Assembling Your Stroller...................................................................... 10

Using Your Stroller ............................................................................... 14

Using your Stroller with the Recommended Infant Car Seats

on your Stroller Frame ........................................................................ 23

Care and Maintenance......................................................................... 25

Limited Warranty .................................................................................. 25

• www.evenflo.com • USA: 1-800-233-5921 8 AM – 5 PM E.T.

• Canada: 1-937-773-3971 •México: 800-706-1200

Table of Contents

ENGLISH

1. Canopy

2. Canopy Window

3. Parent Handle

4. Cupholder

5. Toddler Seat

Release Button

6. Swivel Wheel

7. Lower Privacy

Cover

14. Multi-Position

Recline Handle

15. Fold Latch

16. Multi-Position

Recline Strap

17. Side Frame Lock

18. Storage Basket

19. Brakes

8. Buckle

9. Harness Covers

(only on certain models)

10. Bumper Bar/

Storage Pouch

11. Child Tray

12. Shoulder Straps

13. Upper Privacy

Cover

Holds Evenflo SafeMax™ or LiteMax™ Infant Car Seats Only

Features

WARNING! DEATH or SERIOUS

INJURY can occur.

• Only use Evenflo SafeMax™ and LiteMax™ infant car seats

with this stroller.

Other infant car seats or carriers are not designed to fit the

stroller frame and if used with this stroller may result in serious

injury to your child.

• NEVER leave child unattended. ALWAYS keep child in view

while in the stroller.

• Adult assembly required. Take care when unpacking and

assembling; contains small parts and some items with sharp

edges.

• To prevent a possible choking hazard, remove and discard

packing material before using this product.

•Avoid serious injury from falling or sliding out. ALWAYS use

waist restraint.

• DO NOT carry or roll stroller on stairs or escalators with child in

it.

• DO NOT hang items on handle bar or place them on the

canopy as they can tip stroller over and injure child.

•Be sure stroller is fully assembled and locked in unfolded

position before using.

• ALWAYS exercise care when going over curbs or steps,

and never use stroller for anything other than transporting

your child. Push stroller at a normal walking pace only; faster

strolling can cause a loss of control and injury to the child.

• DO NOT place hot liquids in cup holder. Spills can burn you or

your child.

• To avoid serious injury from child falling out of stroller, DO NOT

raise or recline seat with child in stroller.

• DO NOT use stroller if any parts are missing or broken.

• DO NOT allow child to climb on, into, out of, or around stroller.

• DO NOT allow child to stand on the footrest. Stroller may tip

over and injure child.

READ AND FOLLOW ALL WARNINGS AND INSTRUCTIONS!

FAILURE TO DO SO COULD RESULT IN

SERIOUS INJURY OR DEATH!

READ AND FOLLOW ALL WARNINGS AND INSTRUCTIONS!

FAILURE TO DO SO COULD RESULT IN

SERIOUS INJURY OR DEATH!

• DO NOT carry additional children, goods, or accessories in

or on this stroller except as advised in these instructions. The

stroller is intended for use with one child and to accommodate

only the additional weights in storage as listed in these

instructions.

• Care must be taken when folding or unfolding stroller to prevent

finger injury to you or your child in hinge areas. Make sure child

is not in the seat or near the stroller when folding or unfolding.

• NEVER leave stroller on a hill or incline, even with brakes set.

Stroller may tip, injuring the child.

• To avoid accidental rolling, ALWAYS set brakes when stroller is

not being pushed.

• AVOID STRANGULATION:

–DO NOT suspend strings or toys from the canopy.

–DO NOT place stroller anywhere near cords from window

blinds, draperies, phone, etc.

– DO NOT place items with a string around your child’s neck

such as hood strings or pacifier cords.

– If not properly secured, the child may slip into leg openings

and strangle.

•When making adjustments to the stroller, ALWAYS ensure that

all parts of the child’s body are clear of any moving parts of the

stroller.

• The canopy is not intended to provide UV protection.

• Sharp or heavy objects placed in pockets may cause damage

to the stroller, or injury to the child.

• To ensure safety for your baby, please refer to the

manufacturer’s instructions for the use of your recommended

infant car seats and keep all instructions available for reference.

• DO NOT lift stroller by using the infant car seat handle when

installed on stroller.

ENGLISH

WARNING! DEATH or SERIOUS

INJURY can occur.

READ AND FOLLOW ALL WARNINGS AND INSTRUCTIONS!

FAILURE TO DO SO COULD RESULT IN

SERIOUS INJURY OR DEATH!

• If unable to securely attach the infant car seat to this stroller,

remove the car seat and contact Evenflo ParentLink at

1-800-233-5921 (USA), 1-937-773-3971 (Canada),

or 800-706-1200 (México).

• To avoid stroller instability and tip-overs, DO NOT load cup

holder with over 1 lb (0.45 kg) , and the main cargo basket with

over 10 lbs (4.5 kg).

• NEVER use the toddler seat without the canopy attached.

• NEVER lift or carry the toddler seat by the bumper bar.

• NEVER use the stroller frame without the toddler seat or car

seat attached.

• NEVER use toddler seat in a motor vehicle or use it as a

booster seat.

• To avoid falls, never remove toddler seat from the stroller with

child in it.

• To avoid falls, always make sure the toddler seat or car seat

is securely attached into the seat mounts on both sides of the

stroller before placing child in the seat.

• When stroller seat is in carriage mode, it is intended for a

child up to 6 months of age.

• NEVER use seat in the carriage mode position unless the

straps under the seat are unbuckled and the seat is set up in

carriage mode as per the instructions.

• To avoid overheating, make sure to open the canopy window

when using privacy cover in toddler seat mode or carriage

mode.

• To avoid serious injury or death, DO NOT use privacy cover

when installing Infant Car Seat in vehicle rear facing without

the base.

WARNING! DEATH or SERIOUS

INJURY can occur.

Child Requirements - When stroller is in carriage mode, it is

intended for a child up to 6 months of age. Only use the stroller in the

upright position with a child who is capable of sitting upright

unassisted.

• Maximum weight: 55 lbs (25 kg)

• Maximum height: 40 inches (101.6 cm)

IMPORTANT:Read instructions carefully before use. Save these

instructions for future reference. It is very important to assemble the

stroller according to these instructions. If you are missing parts, do

not use stroller and call

Evenflo ParentLink at 1-800-233-5921

(U.S.A.)

, 1-937-773-3971 (Canada), or 800-706-1200 (México) to

order replacement parts.

For future reference, record the Model Number and Date of

Manufacture below. You can find this information on one of

the rear stroller legs.

Model Number: _____________________________

Date of Manufacture: ________________________

Registration Information

Please register this product so we can reach you if there is a safety

alert or recall. We will not sell, rent, or share your personal

information. To register your product, please complete and mail the

card that came with it or visit our online registration at

www.evenflo.com/registerproduct.

ENGLISH

Important Information

Cupholder (1)

Front Wheel Assembly (2)

Rear Wheel (2)

Frame

Toddler Seat

Bumper Bar, Storage Pouch

and Upper Privacy Cover

Lower Privacy Cover

(Stores in Bumper Bar

Storage Pouch)

Child’s Tray

Identication of Parts

YOUR STROLLER SEAT CAN BE USED IN TWO DIFFERENT

MODES.

TODDLER SEAT MODE OR CARRIAGE MODE.

Your stroller seat is shipped in carriage mode with the buckles

unfastened under the footrest. You will need to follow the

instructions completely to make sure you set up your stroller in

your preferred mode of use.

After the frame and the wheels have been assembled, you can

choose to set the stroller up in Carriage Mode or Toddler Seat

Mode by following instructions on pages 12 - 16.

Toddler Seat Mode Carriage Mode

ENGLISH

Choosing Mode of Use

Grab the parent’s handle and

pull upward until the stroller

opens fully with an audible

click.

Make sure the stroller is

locked in the open position by

pushing down on the parent’s

handle.

1To protect ooring, place a

protective covering (carton)

beneath the stroller during

assembly.

Unlatch side frame lock.

Continue holding the lock

open while unfolding the

stroller.

CLICK!

Side Frame Lock

Care must be taken when folding or unfolding stroller

to prevent finger injury in hinge areas.

WARNING! DEATH or SERIOUS

INJURY can occur.

Assembling Your Stroller - Frame
