Evenflo CLOVER Manual de usuario
Stroller/Travel System
Carriola/Sistema de viaje
ENGLISHESPAÑOL
Read all instructions before assembly and use of product.
KEEP INSTRUCTIONS FOR FUTURE USE.
Lea todas las instrucciones antes de ensamblar y usar el
producto.
GUARDE LAS INSTRUCCIONES PARA USO FUTURO.
©2020 Eveno Company, Inc. 25701587 06/2020
STROLLER
Up to 50 lbs (22.7 kg)
Up to 40 in. (101.6 cm)
CARRIOLA
Hasta 22.7 kg (50 lb)
Hasta 101,6 cm (40 pulg)
Sport
/
Table of Contents
Warnings ................................................................................................ 3
Important Information ............................................................................. 6
Identification of Parts.............................................................................. 7
Features ................................................................................................. 8
Choosing Mode of Use ........................................................................ 10
Assembling Your Stroller...................................................................... 11
Using Your Stroller ............................................................................... 15
Using your Stroller with Recommended Infant Car Seats ................... 26
Clover Use Configurations.................................................................... 28
Care and Maintenance......................................................................... 29
Limited Warranty .................................................................................. 29
3
Read and follow all warnings and instructions. Failure to do so
could result in serious injury or death.
• Only use Evenflo SafeMax™, LiteMax™ or LiteMax™
Sport infant car seats with this stroller. Other infant car
seats or carriers are not designed to fit the stroller frame and
if used with this stroller, may result in serious injury to your
child.
• NEVER leave child unattended. ALWAYS keep child in view
while in the stroller.
• Adult assembly required. Take care when unpacking and
assembling; contains small parts and some items with sharp
edges.
• To prevent a possible choking hazard, remove and discard
packing material before using this product.
• Avoid serious injury from falling or sliding out. ALWAYS use
waist restraint.
• DO NOT carry or roll stroller on stairs or escalators with child
in it.
• DO NOT hang items on handle bar or place them on the
canopy as they can tip stroller over and injure child.
• Be sure stroller is fully assembled and locked in unfolded
position before using.
• ALWAYS exercise care when going over curbs or steps,
and never use stroller for anything other than transporting
your child. Push stroller at a normal walking pace only; faster
strolling can cause a loss of control and injury to the child.
• DO NOT place hot liquids in cup holder. Spills can burn you or
your child.
• To avoid serious injury from child falling out of stroller, DO
NOT raise, recline or convert seat to Comfort Mode with child
in stroller.
• DO NOT use stroller if any parts are missing or broken.
• DO NOT allow child to climb on, into, out of, or around stroller.
• DO NOT allow child to stand on the footrest. Stroller may tip
over and injure child.
ENGLISH
WARNING! DEATH or SERIOUS
INJURY can occur.
4
• DO NOT carry additional children, goods, or accessories in
or on this stroller except as advised in these instructions. The
stroller is intended for use with one child and to accommodate
only the additional weights in storage as listed in these
instructions.
• Care must be taken when folding or unfolding stroller to
prevent finger injury to you or your child in hinge areas. Make
sure child is not in the seat or near the stroller when folding or
unfolding.
• NEVER leave stroller on a hill or incline, even with brakes set.
Stroller may tip, injuring the child.
• To avoid accidental rolling, ALWAYS set brakes when stroller
is not being pushed.
• AVOID STRANGULATION:
– DO NOT suspend strings or toys from the canopy.
– DO NOT place stroller anywhere near cords from
window blinds, draperies, phone, etc.
– DO NOT place items with a string around your child’s
neck such as hood strings or pacifier cords.
– If not properly secured, the child may slip into leg
openings and strangle.
• When making adjustments to the stroller, ALWAYS ensure
that all parts of the child’s body are clear of any moving parts
of the stroller.
• The canopy is not intended to provide UV protection.
• Sharp or heavy objects placed in pockets may cause damage
to the stroller, or injury to the child.
• To ensure safety for your baby, please refer to the
manufacturer’s instructions for the use of your recommended
infant car seats and keep all instructions available for
reference.
• To avoid stroller instability and tip-overs, DO NOT load child
tray with over 1 lb (0.45 kg), parent tray with over 2 lbs (0.90
kg) and the main cargo basket with over 10 lbs (4.5 kg).
• DO NOT lift stroller by using the infant car seat handle when
installed on stroller.
WARNING! DEATH or SERIOUS
INJURY can occur.
5
• Make sure the infant car seat is securely snapped onto the car
seat mounts.
• DO NOT use Comfort Mode with a child over 6 months of age.
• ALWAYS remove child tray when using stroller in Comfort
Mode.
• ALWAYS thread lower harness strap under webbing when
child is in Comfort Mode.
• NEVER attach infant car seat with child in Comfort Mode.
• NEVER use seat in the Comfort Mode position unless the
seat is set up in Comfort Mode as per the instructions.
• NEVER use the stroller in any configuration other than what is
shown in the instruction manual.
If unable to securely attach the infant car seat to this stroller,
remove the car seat and contact Evenflo ParentLink at
1-800-233-5921 (U.S.A.), 1-937-773-3971 (Canada), or
01-800-706-12-00 (Mexico).
WARNING! DEATH or SERIOUS
INJURY can occur.
6
Important Information
Child Requirements
• Maximum weight: 50 lbs (22.7 kg), Maximum height: 40 inches
(101.6 cm)
• Comfort Mode: Intended for a child up to 6 months of age.
• Stroller Mode (in upright position): Intended for a child who is
capable of sitting upright unassisted.
IMPORTANT: Read instructions carefully before use. Save these
instructions for future reference. It is very important to assemble the
stroller according to these instructions. If you are missing parts, do not
use stroller and call Evenflo ParentLink at 1-800-233-5921 (U.S.A.),
1-937-773-3971 (Canada), or 01-800-706-12-00 (Mexico) to order
replacement parts.
For future reference, record the Model Number and Date of
Manufacture below. You can find this information on one of the rear
stroller legs.
Model Number: ________________________________
Date of Manufacture: ___________________________
Registration Information
Please register this product so we can reach you if there is a safety alert
or recall. We will not sell, rent, or share your personal information. To
register your product, please complete and mail the card that came with
it or visit our online registration at www.evenflo.com/registerproduct.
7
Identication of Parts
One Rear Wheel
(Unassembled)
Rear Axle Assembly
(1 Wheel Pre-Assembled)
Rear Wheel Hub Caps
(1 Cap Pre-Assembled)
Child Tray
Frame
Front Wheel (2)
8
Features
1. Canopy
2. Parent’s Handle
3. Adjustable Handle Buttons*
4. Harness Covers
5. Buckle
6. Canopy Visor*
7. Shoulder Straps
*Not all features are available on all models. Styles may vary.
1
11
13
12
2
3
4
5
6
7
8
9
10
FRONT
8. Child Tray
9. Child Tray Release levers
10. Buckle Cover*
11. Footrest
12. Swivel Wheel
13. Leg Rest
14. Comfort Mode Flaps
14
9
Features
15. Canopy Window
16. Cell Phone Holder*/
Covered Storage*
17. Parent Tray*
18. Fold Release Levers
19. Multi Position Recline
Strap
15
16
17
18
19
21
22
REAR
20. Side Frame Lock
21. Storage Basket
22. Brakes
20
10
Choosing Mode of Use
Stroller ModeComfort Mode
Your stroller can be used in two different
modes: Comfort Mode or Stroller Mode.
Your stroller is shipped in Stroller Mode. You will need to
follow the instructions completely to make sure you set up
your stroller in your preferred mode of use.
After the frame and the wheels have been assembled, you
can choose to set the stroller up in Comfort Mode
(see p. 22) or Stroller Mode (see p. 24).
