Eureka NER E10s Manual de usuario
ROBOT VACUUM CLEANER
INSTRUCTION
MANUAL
Please read the manual before use
NER E10s
CONTENTS
Safety instructions
Technical data
What comes in the box
How to identify parts of
your robot
Assembling and charging
robot
How to use your robot
03
08
09
10
11-12
13
How to set up app, connect
the device and use app
How to maintain your robot
How to maintain brushroll 16
14
15
Other routine maintenance 17-18
Troubleshooting 19
TRADEMARKS, COPYRIGHTS
AND LEGAL STATEMENT 21
02
SAFETY INSTRUCTIONS
Warning for the machine
This appliance is not intended for use by persons (including children) with
reduced physical, sensory or mental capabilities, or lack of experience and
knowledge, unless they have been given supervision or instruction concerning
use of the appliance by a person responsible for their safety.
Children should be supervised to ensure that they do not play with the
appliance.
Plug must be removed from the socket-outlet before cleaning or maintaining
If the supply cord is damaged, it must be replaced by the manufacturer, its
service agent or similarly qualified persons in order to avoid a hazard.
WARNING: For the purposes of recharging the battery, only use the detach-
able supply unit provided with this Appliance.
Use only with BS2302 supply unit.
This Appliance contains batteries that are only replaceable by skilled
persons.
Do not bring the smart robot close to heat source, radiation or burning
cigarette butts. It is strictly forbidden to vacuum the following objects:
1) All liquids such as water and solvents;
2) Lime, cement dust and other construction dust and garbage;
3) Heat generating objects, such as unextinguished carbon butts, cigarette
butts;
4) Sharp fragments, such as glass, etc.;
5) Flammable and explosive items, such as gasoline and alcohol products.
Before using, please remove all fragile items from the ground (such as
glasses, lamps, etc.), and items that may be tangled with the side brush,
Roller brush and drive wheels(such as wires, curtains and other easily-entan-
gled materials).
Please pay attention to your hair and avoid entanglement on wheels or roller
brushes when using, cleaning and maintaining the robot.
Do not use this product at an altitude of more than 2000m.
1.
2.
3.
4.
5.
6.
7.
8.
9.
03
10.
11.
12.
13.
Correct Disposal of this product.
This marking indicates that this product should not be
disposed of with other household wastes throughout the EU.
To prevent possible harm to the environment or human health
from uncontrolled waste disposal, recycle it responsibly to
promote the sustainable reuse of material resources. To return
your used device, please use the return and collection systems
or contact the retailer where the product was purchased. They
can take this product for environmentally safe recycling.
Warranty Information
The manufacturer provides warranty in accordance with the legislation of the
customer's own country of residence, with a minimum of 1 year (Germany: 2
years), starting from the date on which the Appliance is sold to the end user.
The warranty only covers defects in material or workmanship.
The repairs under warranty may only be carried out by an authorized service
centre. When making a claim under warranty, the original bill of purchase (with
purchase date) must be submitted.The warranty will not Apply in cases of:
- Normal wear and tear
- Incorrect use, e.g. overloading of the Appliance, use of non-Approved
accessories
- Use of force, damage caused by external influences
- Damage caused by non-observance of the user
manual, e.g. connection to an unsuitable mains supply or non-compliance with
the installation instructions
- Partially or completely dismantled Appliances
Wireless network: 2400-2483.5MHz, MAX POWER:20dBm.
BLUETOOTH MAX POWER:10dBm
To satisfy RF exposure requirements, a separation distance of 20 cm or more
should be maintained between the antenna of this device and persons during
device operation. To ensure compliance, operations at closer than this
distance is not recommended.
CLASS 1 LASER PRODUCT
INVISIBLE LASER RADIATION
SAFETY INSTRUCTIONS
04
1.
2.
3.
4.
5.
6.
7.
“IMPORTANT SAFETY INSTRUCTIONS – SAVE THESE INSTRUCTIONS" and
"DANGER – TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, CARE-
FULLY FOLLOW THESE INSTRUCTIONS".
This appliance can be used by children aged from 8 years and above and
persons with reduced physical, sensory or mental capabilities or lack of
experience and knowledge if they have been given supervision or instruction
concerning use of the appliance in a safe way and understand the hazards
involved.
Children shall not play with the appliance.
Cleaning and user maintenance shall not be made by children without
supervision.
Plug must be removed from the socket-outlet before cleaning or maintaining
the Appliance.
If the supply cord is damaged, it must be replaced by the manufacturer, its
service agent or similarly qualified persons in order to avoid a hazard.
Docking base is only Applicable to the product NER E10s. (Battery pack
type : Li-ion, DC 14.4 V, 5200 mAh)
The Docking base will automatically start charging after Robot Vacuum
Cleaner returned to the base.
Warning: The battery charger (Docking station) is not intended to charge
non-rechargeable batteries.
CAUTION: In order to avoid a hazard due to inadvertent resetting of the
thermal cut-out, this Appliance must not be supplied through an external
switching device, such as a timer, or connected to a circuit that is regularly
Warning for docking station
SAFETY INSTRUCTIONS
05
before removing the battery.
Please note that do not disassemble the battery by yourself.
If you need to replace it, please contact the after-sales service center.
Please dispose of used battery according to local laws and regulations
Do not dismantle, open or shred the battery.
Do not expose batteries to heat or fire. Avoid storage in direct sunlight.
Do not short-circuit a battery.
Do not store batteries haphazardly in a box or drawer where they may
short-circuit each other or be short-circuited by other metal objects.
Do not subject batteries to mechanical shock.
In the event of a leaking, do not allow the liquid to come in contact with
copious amounts of water and seek medical advice.
Do not use any charger other than that specifically provided for use with
the equipment.
Do not use any battery which is not designed for use with the equipment.
Keep batteries out of the reach of children.
Seek medical advice immediately if the battery has been swallowed.
Keep batteries clean and dry.
Do not leave a battery on prolonged charge when not in use.
After extended periods of storage, it may be necessary to charge and
discharge the batteries several times to obtain maximum performance.
The batteries give their best performance when they are operated at
normal room temperature (20 °C ± 5 °C).
Retain the original product literature for future reference.
The battery may be irreversibly damaged if the battery is in low power for
before storage.
1.
2.
3.
4.
5.
6.
7.
8.
9.
10.
11.
12.
13.
14.
15.
16.
17.
18.
19.
20.
21.
Warning for battery
SAFETY INSTRUCTIONS
06
[symbol IEC 60417-5957
( 2004-12 )]
[symbol ISO 7000-0790
( 2004-01 )]
[symbol IEC 60417-5031
( 2002-10 )]
[symbol IEC 60417-5032
( 2002-10 )]
[symbol IEC 60417-5172
( 2003-02 )]
time-lag miniature fuse-link where X is the symbol for the
time/current characteristic as given in IEC 60127
for indoor use only
read operator's manual
direct current
alternating current
class II equipment
SAFETY INSTRUCTIONS
07
TECHNICAL DATA
Product Model: NER E10s
Host Charging Voltage: 16.7V
Host Rated Voltage: 14.4V
Host Rated Power: 55W
Docking Station Model: BS2302
Docking Station Input: 220-240V~, 50-60Hz, 850W
Docking Station Output: 16.7V , 1A
Battery Model: BP14452C
Battery Rated Voltage: 14.4V
Battery Capacity: 5200mAh 74.88Wh
Charging Limit Voltage: 16.8V
1.
2.
3.
4.
5.
6.
7.
8.
9.
10.
11.
08
Note: You can also view the instructions on the App.
Parts and Components
What comes in the box
350mm
350mm
97mm
Robot Vacuum
Side Brush x2 Instruction Manual
244mm
178mm
445mm
Self-Emptying Base
Cleaning Brush
09
Instruction
Manual
How to identify parts of your robot
Power Cable
Slot
Dust Cup
Indicator Light
Release Button
Self-empty
Inlet
Charging
Contacts
Carpet Detection
Sensor
Auto-lifting Mop
Assembly
Omni-directional
Wheel
Side Brush
Main Wheel
Cover Plate of
Main Brush
Charging Contacts
Main Brush
Edge Sensor
Power Button
Network / Spot
Cleaning Button
Bumper
LiDAR Sensor
Recharging Button
Dustbin /
Water Tank
Dustbin Release
Button
Release Button of
Auto-lifting Mop
Reset Button
10
