ETIC 1400 Manual de usuario

XSLAN

SHDSL switch

_________________

User’s guide

Document reference : 9014709-02

_________________

The XSLAN SHDSL switch is manufactured by

ETIC TELECOM

13 Chemin du vieux chêne

38240 MEYLAN

FRANCE

TEL : + 33 4-76-04-20-00

FAX : + 33 4-76-04-20-01

e-mail : [email protected]

web : www.etictelecom.com

Hotline

TEL : + 33 4-76-04-20-05

FAX : + 33 4-76-04-20-01

e-mail : [email protected]

CONTENT

XSLAN SHDSL switch User’s guide ref 9014709-02 Page 3

OVERVIEW

1PRODUCTS IDENTIFICATION...........................................................................6

2PRODUCT OVERVIEW.......................................................................................7

2.1 Function..................................................................................................7

2.2 Data rate versus distance.....................................................................7

2.3 Ethernet ports........................................................................................8

2.4 VLAN.......................................................................................................8

2.5 Quality of service...................................................................................8

2.6 Serial gateway........................................................................................8

2.7 Diagnostic functions.............................................................................8

2.8 Html or DIP switches configuration....................................................8

3DATA-SHEET......................................................................................................9

INSTALLATION

1PRODUCT DESCRIPTION...............................................................................11

1.1 Leds.......................................................................................................12

1.2 Connectors...........................................................................................13

1.3 DIP switches and push-button...........................................................15

2VENTILATION...................................................................................................16

3SUPPLY VOLTAGE..........................................................................................16

4FUSE.................................................................................................................16

5ETHERNET PORTS..........................................................................................16

6RS232 (XSLAN—1220, 1230, 2220 AND -2230) .............................................17

7RS485 (XSLAN-1230 OR -2230)......................................................................17

8SHDSL LINE.....................................................................................................18

9INPUT AND OUTPUT.......................................................................................20

../..

CONTENT

Page 4 User’s guide ref 9014709-02 XSLAN SHDSL switch

DIP SWITCHES CONFIGURATION

1OVERVIEW.......................................................................................................21

2ONE TWISTED PAIR SHDSL LINE SET UP....................................................21

3TWO TWISTED PAIRS SHDSL LINE SET UP.................................................23

4TESTING THE SHDSL CONNECTION AND ADJUSTING THE DATA RATE24

HTML CONFIGURATION

1SET UP STEPS.................................................................................................25

2ENABLING HTML CONFIGURATION .............................................................26

3CONNECTING A PC TO THE XSLAN FOR CONFIGURATION.....................26

3.1 Overview...............................................................................................26

3.2 First configuration...............................................................................27

3.3 Modifying the configuration from the LAN........................................28

4REBOOTING THE XSLAN AFTER PARAMETERS CHANGES.....................28

5RECOVERING THE FACTORY LAN IP ADDRESS ........................................28

6RECOVERING THE FACTORY CONFIGURATION.......................................29

7RESTRICTING ACCESS TO THE ADMINISTRATION SERVER....................29

8RECOVERING A FREE ACCESS TO THE ADMINISTRATION SERVER......29

9ASSIGNING AN IP ADDRESS TO THE LAN INTERFACE.............................30

10 IP ROUTING AND BROADCAST FILTERING................................................30

11 ONE TWISTED PAIR SHDSL CONNECTION SET UP....................................33

11.1 Set up....................................................................................................33

11.2 Testing the SHDSL connection and adjusting the data rate...........34

12 TWO WISTED PAIRS UP SHDSL CONNECTION SET UP.............................35

12.1 SHDSL port set up...............................................................................35

12.2 Testing the SHDSL connection and adjusting the data rate...........36

../..

CONTENT

XSLAN SHDSL switch User’s guide ref 9014709-02 Page 5

… HTML CONFIGURATION

13 VLAN SET UP...................................................................................................37

13.1 Overview...............................................................................................37

13.2 VLAN set up .........................................................................................39

14 QUALITY OF SERVICE (QOS) SET UP..........................................................40

14.1 DiffServ benefits & overview..............................................................40

14.2 QoS set up............................................................................................41

15 SNMP SET UP..................................................................................................43

16 SERIAL GATEWAY SET UP............................................................................44

16.1 Modbus gateway..................................................................................45

16.2 RAW TCP gateway...............................................................................50

16.3 RAW UDP gateway ..............................................................................53

16.4 Multicast gateway................................................................................55

16.5 Unitelway gateway...............................................................................57

17 DIAGNOSTIC MENU ........................................................................................58

Appendix 1 : Data rate versus distance and cable quality

Appendix 2 : Html server description

INSTALLATION

Switch Shdsl XSLAN Notice d’utilisation ref 9014309-01 page 6

1 Products identification

XSLAN SHDSL switch 1400 1220 1230 2400 2220 2230

SHDSL ports 1 1 1 2 2 2

Maximum data rate (Mb/s) 2.3 2.3 2.3 4.6 4.6 4.6

10-100 Mb/s Ethernet ports 4 2 2 4 2 2

RS232 0 1 2 0 1 2

RS485 0 1 0 0 1 0

Basic IP routing feature Yes Yes Yes Yes Yes Yes

VLAN Yes Yes Yes Yes Yes Yes

Quality of service Yes Yes Yes Yes Yes Yes

Gateway

(Raw, telnet, modbus,

unitelway)

0 2 2 0 2 2

Line cable * 1 1 1 2 2 2

Χ The product is delivered with Cable ref. CAB614 for

connection to the line (Qty 1 or 2)

INSTALLATION

2 Product overview

2.1 Function

The XSLAN shdsl switch enables to extend an Ethernet network over

kilometers using one or two simple voice-grade twisted pairs (telephone

lines).

The XSLAN-1400 or 1220 or 1230 come with one SHDSL interface; they

can be connected to a one twisted pair line.

They feature up to 2.3 Mb/s.

One pair operation

up to 2.3 Mb/s

XSLAN-1400

XSLAN-1220

XSLAN-1230

The XSLAN-2400 or 2220 or 2230 come with two SHDSL interfaces; they

can be connected to a two twisted pair line.

They feature up to 2.3 Mb/s.

Two pairs operation

up to 4.6 Mb/s

XSLAN-2400

XSLAN-2220

XSLAN-2230

2.2 Data rate versus distance

Each interface features an adaptive data rate from 128 Kb/s up to 2.3

Mb/s.

The data rate is a function of the cable quality and the distance with the

next SHDSL switch. For instance, the maximum distance between 2

switches through a line is 13 Km (8 miles) with a 0.9 mm wire diameter

cable.

The table in appendix 1 gives the data rate which can be expected over a

line versus the length of the line.

XSLAN SHDSL switch User’s guide ref 9014709-02 Page 7

INSTALLATION

Page 8 User’s guide ref 9014709-02 XSLAN SHDSL switch

2.3 Ethernet ports

The XSLAN provides 2 or 4 Ethernet RJ45 interfaces (depending on the

product reference).

2.4 VLANs

The XSLAN features VLAN per port :

Each Ethernet port can be assigned to a particular VLAN. A device

connected to an Ethernet port belonging to a particular VLAN can

communicate only with devices connected to Ethernet ports belonging to

the same one.

2.5 Quality of service

The product provides “DiffServ” quality of service functionality to give

transmission priority to critical applications.

Devices TCP ports and IP addresses are classified in 4 priority classes.

A minimum and a maximum bandwidth is allocated to each class.

2.6 Serial gateway

The XSLAN –1220, -1230, -2220 or –2230 feature a 2 ports serial

gateway.

The gateway features raw TCP client and server, raw UDP, modbus

client and server, telnet and multicast.

2.7 Diagnostic functions

The XSLAN html server provides diagnostic pages giving the guarantee

the transmission quality is what it has to be.

2.8 Html or DIP switches configuration

The XSLAN can be configured either with an html browser if advanced

functions are necessary (QoS, RS gateway, diagnostic …).

It can be configured with a few DIP switches for simple unmanaged

applications.

INSTALLATION

XSLAN SHDSL switch User’s guide ref 9014709-02 Page 9

3 Data-sheet

Dimensions 137 x 48 x 116 mm (h, l, d)

C.E.M EN50082-2

Electrical safety EN 60950

Lightning EN61000-4 et –5

Supply voltage XSLAN-1400 or –2400 or –1230 or –2230 : 9 to 60 VDC

XSLAN-1220 –2220 : 9 to 30 VDC

Consumption 4W

Operating T° -20°/ + 60°C non condensing

SHDSL ITU-T G.991.2, 802.3ah : 2BaseTL (EFM)

Data rate : 128 kb/s to 2.3 Mb/s with 2 wires

Latency : 4 ms

Ethernet 10/100 Mb/s Half / Full duplex Auto MDI/MDIX

Switch Store and forward – 1024 MAC @

IP Routing Static routes

RIP V2

QoS DiffServ compliant with RFC 2474, 2475, 2597, 2598

4 priority levels (premium, gold, silver, bronze)

SNMP SNMP V2 – MIBII and traps

VLAN Per port

RS232-RS485 1200 to 115200 kb/s parity E/O/N

Raw TCP client and server

Raw UDP

Multicast

Modbus client and server

Unitelway

Telnet

Logs 300 events (date & time)

Configuration Managed mode : HTML browser

Unmanaged mode : DIP switches
