ETI D01 Manual de usuario
CeramicfusebaseD01D02 Dimensions [mm] Installation
Fuse link replacement Disassembly
INSTALLATION INSTRUCTION
ETI, d.o.o.
Obrezija 5
SI-1411 Izlake
Snap on DIN rail
CAUTION!
Installation by electricians only!
Unscrew the fuse carrier
Replace the fuse link
Screw back the fuse
carrier
Using a screwdriver
pull down on the metal
snap-on unit
Fuse-switchdisconnectorVLD01 Dimensions [mm] Installation
Disconnectorswitchedoff/on Disassembly
INSTALLATION INSTRUCTION
ETI, d.o.o.
Obrezija 5
SI-1411 Izlake
Snap on DIN rail.
CAUTION!
Installation by electricians only!
Using a screwdriver,
pull down on the
plastic snap-on unit.
PFBD01D02 Dimensions [mm] Installation
Fuse link replacement Disassembly
INSTALLATION INSTRUCTION
ETI, d.o.o.
Obrezija 5
SI-1411 Izlake
Snap on DIN rail
Unscrew the cap
Replace the fuse link
Screw the cap back
CAUTION!
Installation by electricians only!
Using a screwdriver
pull down on the
plastic snap-on unit
Switch-disconnector-fuseSTVD02 Dimensions [mm] Installation
Fuse link replacement Disassembly
INSTALLATION INSTRUCTION
ETI, d.o.o.
Obrezija 5
SI-1411 Izlake
Open the panel.
Push down the
fuse-link
holder.
Replace the
fuse-link.
Push back the fuse-
link holder and close
the panel.
Snap on DIN rail.
Using a screwdriver
pull down on the
plastic snap-on unit.
