Essick 4D7-300 Manual

“The

right

humidifier for

every decor & budget”

Home Comfort

ESSICK AIR PRODUCTS

Humidifiers

Accessories

Humidifiers

Accessories

Essick Air Products

5800 Murray Street

Little Rock, AR. 72209

1-800-826-2665 ◊Fax 501-562-9485

email: [email protected]

www.essickair.com

Essick Air Products has been a leader in

helping people improve their home environment for years. With the

new emphasis on Indoor Air Quality (IAQ), our products are more in

demand than ever.

From our evaporative humidifiers and 2in-1air purifiers,

to our high quality air filters and humidifier wicks, we

at Essick Air take great pride in offering a variety of

superior products that enhance your health and

improve your home enviroment.

Modelo #1051

Para Usar Con Los Humidificadores

Serie 400, 600, H12 y ED11

De Bemis Y Essick

Este filtro electros y con carbón:

•

Atrapa el polen irritante

•

Elimina las partículas de polvo del aire

•

Reduce el humo dañino

•

Reduce el olor de las mascotas del hogar

REPLACEMENT FILTER

Model #1051

For use with Bemis & Essick

400, 600, H12 & ED11

Series Humidifiers

During winter, extra moisture in the home has many benefits, including

reducing energy bills, lessening cold symptoms and diminishing static

electricity. Additionally, several of our humidifiers have optional air

filters to further enhance the air quality and comfort of your home.

Our wicks have been proven to outperform the competition.

Legend

Whole-house

Multi-room

Single-room

These symbols indicate

the area a specific humidifier

is appropriate to cover

In scientifically conducted tests, our SuperWicks® performed 107% to

527% better than our three biggest competitors. After 30, 60 and even

90 days, the superiority of our patented SuperWicks became more

and more apparent. And SuperWicks® are more economical than

the competition: SuperWicks® require less running time, fewer

replacements, and less energy consumption.

†Tests conducted to AHAM

test standard HU-1-1997 by

Intertek Testing Services.

Essick Air Humidifers

come with a one year

warranty

†

EssickAir Holmes RPS Honeywell

30 Days 60 Days 90 Days

2.5

2.0

1.5

1.0

0.5

output: gallons per day

Product Shpping Specifications

Product Specifications ◊

◊

Shipping Information

Page 2 Page 11

Outputper24hr 12gallons 45.4Liters Outputper24hr 13Gallons 49.2L Outputper24hr 5Gallons 19L

Coverage 2500sqfeet Coverage 2700sqft Coverage 2700sqft

Capacity 5.2gallons 19.7Liters Capacity 5.5gallons 20.8L Capacity 3gallons 11.4L

UnitDimensionsin/cm 295/8x147/8x253/8 75.25x37.8x64.45 UnitDimensionsin/cm 28x13¾x22 71x34.9x55.9 UnitDimensionsin/cm 17¾x9¼x13¾ 45x23.5x34.9

Unitweight 29lbs 13kg Unitweight 33lbs 15kg Unitweight 33lbs 15kg

Electricals

ecs: Electricals

ecs:

ElectricalListing UL CUL ElectricalListing UL CUL ElectricalListing UL CUL

CartonQty 1 CartonQty 1 CartonQty 1

UPSReship YES UPSReship YES UPSReship YES

CartonSizein/cm 30x16x287/8 76.2x40.6x73.3 CartonSize 28x137/8x223/8 71x13.8x56.8 CartonSize 19¾x11x163/8 50x28x41.6

CartonWeight 34lbs 15.4kg CartonWeight 33lbs 15kg CartonWeight 10.8lbs 4.9kg

CartonCube 6.62 CartonCube 5.03cuft CartonCube 5.03cuft

Nat.FreightClass 62273 Nat.FreightClass 62273 Nat.FreightClass 62273

LTLFreightClass 150 LTLFreightClass 100 LTLFreightClass 100

Outputper24hr 12gallons 45.4L Outputper24hr 11gallons 41.6 Outputper24hr 11gallons 41.6

Coverage 2500sqft Coverage 2300sqft Coverage 2300sqft

Capacity 5gallons 19 L Capacity 3gallons 11.4L Capacity 2gallons 7.6L

UnitDimensionsin/cm 24x13½x22 61x34.3x55.9 UnitDimensionsin/cm 24x15¾x17¾ 61x38x45 UnitDimensionsin/cm 16¼x10x11½ 41.3x25.4x29.2

Unitweight 22.5lbs 10.2kg Unit weight 20.4 9.25 Unitweight 20.4 9.25

Electricalspecs: Electricalspecs: Electricalspecs: 120VDC/60Hertz/160

ElectricalListing UL CUL ElectricalListing ETLtoULstandards ElectricalListing ETLtoULstandards

7D6 Shipping

CartonQty 1 CartonQty 1 CartonQty 1

UPSReship YES UPSReship YES UPSReship YES

CartonSizein/cm 26x15¼x23½ 66x38.7x59.7 CartonSize in/cm 26¼x18½x201/2 66.7x47x52.1 CartonSize in/cm 26¼x18½x20½ 66.7x47x52.1

CartonWeight 27lbs 12.24kg CartonWeight 24 lbs 10.9kg CartonWeight 24lbs 10.9kg

CartonCube 5.37 CartonCube 5.5 CartonCube 5.5

Nat.FreightClass 62273 Nat.FreightClass 62270-04 Nat.FreightClass 62270-04

LTLFreightClass 110 LTLFreightClass 150 LTLFreightClass 150

Outputper24hr 9gallons 34L Outputper24hr 8gallons 34L Outputper24hr 6gallons 22.7L

Coverage 1900sqft Coverage 1700sq.ft Coverage 2300 sq ft

Capacity 6gallons 22.7 L Capacity 6 gallons 22.7 L Capacity 3 gallons 11.4 L

UnitDimensionsin/cm 18x12½x21 45.7x30.5x53.3 UnitDimensionsin/cm 18x12½x21 45.7x30.5x53.3 UnitDimensionsin/cm 15x10x26½ 38x25.4x67.3

Unitweight 17 12.2kg Unit weight 17 12.2kg Unitweight 14.33 6.5

Electricalspecs: Electricalspecs: Electricalspecs:

ElectricalListing UL CUL ElectricalListing UL CUL ElectricalListing

CartonQty 1 CartonQty 1 CartonQty 1

UPSReship YES UPSReship YES UPSReship YES

CartonSizein/cm 19¾x14¾x23 50x37.5x58.4 CartonSizein/cm 19¾x14¾x23 50x37.5x58.4 CartonSize in/cm 17¾x12¾x29 45x32.4x73.7

CartonWeight 17.64lbs 12.24kg CartonWeight 17.64lbs 12.24kg CartonWeight 17.64lbs 8kg

CartonCube 3.3 CartonCube 3.3 CartonCube 5

Nat.FreightClass 62270-04 Nat.FreightClass 62270-04 Nat.FreightClass 62270-04

LTLFreightClass 150 LTLFreightClass 150 LTLFreightClass 150

Outputper24hr 3.3gallons 19L Outputper24hr 3.5 13.25 Outputper24hr 3.5 13.25

Coverage 1100sqft Coverage 800sqft Coverage 800sqft

Capacity 3.5gallons 11.4L Capacity 2gallons 7.6L Capacity 2gallons 7.6L

UnitDimensionsin/cm 19½x12x13¼ 49.5x30.5x33.7 UnitDimensionsin/cm 11x11x10¼ 28x28x26 UnitDimensionsin/cm 11x11x10¼ 28x28x26

Unitweight 13lbs 5.9 Unitweight 8.5 3.86 Unitweight 8.5 3.86

Electricalspecs: Electricalspecs: Electricalspecs:

ElectricalListing ElectricalListing ElectricalListing

CartonQty 1 CartonQty 4 CartonQty 4

UPSReship YES UPSReship YES UPSReship YES

CartonSizein/cm 17¾x12¾x29 45x32.4x73.7 CartonSizein/cm 27½ x27½x13½ 70x70x34.3 Carton Sizein/cm 27½ x27½x13½ 70 x70 x34.3

CartonWeight 17.64lbs 8kg CartonWeight 36lbs 16.3kg CartonWeight 36lbs 16.3kg

CartonCube 5 CartonCube 5.9 Carton Cube 5.9

Nat.FreightClass 62270-04 Nat.FreightClass 62270-03 Nat.FreightClass 62270-03

LTLFreightClass 150 LTLFreightClass 150 LTLFreightClass 150

B23 810 Tabletop Style

120VDC/60Hertz/60Watts

ETLtoULstandards

B23Shipping

UL ETLtoULstandards

DP3-200Shipping 336500 Shipping

DP3 200 Tabletop 2-in-1 Unit 336 500 Tabletop

120VDC/60Hertz/65Watts 120VDC/60Hertz/60Watts

ETLtoULstandards

D46-720Shipping800Series–Shipping 800Series–Shipping

7D6-100 Tabletop Style

5D6 -700 – Mini Console

120VDC

60Htz

135Watts

5D6Shipping

600 Series – Traditional Credenza 400 Series – Traditional Console

120VDC

60Hertz

Watts135 120VDC

60Htz

135Watts

600Series-Shipping 400SeriesShipping

ED-11 Euro – Console StyleH12 Series – Console Style

120VDC/60Hertz/160Watts

ED-11ShippingH12Series–Shipping

120VDC/60Hertz/170Watts

821-000 Spacesaver 826-00 – Spacesaver

120VDC/60Hertz/90Watts 120VDC/60Hertz/90Watts

D46 720 Tower Style

120VDC/60Hertz/65Watts

2500 sq. ft; 12 gal. per day ◊◊Traditional-Style

Whole-House Credenza Style Humidifiers

Whole-house humidification is provided in the clean, classic lines of this wood grain styled credenza.

Holding over 5 gallons, this handsome unit boasts 12 gallons output per day,

effectively humidifying up to 2,500 square feet.

◊Automatic humidistat allows you to set a

target humidity, and the unit will maintain

the selected humidity

◊Variable speed motor with quiet

nighttime setting

◊Separate left and right refill bottle indicators

◊Automatic shutoff

◊Easy-fill dual water bottles w/refill hose

◊5.2 Gallon Total Water Capacity

◊Uses patented Super Wick #1041

◊Accomodates 2-Stage AirCare® Filter

(standard on 697-500; optional on 696-400)

◊Measures 29 5/8”x 14” 7/8x 25 3/8”

697-500 Cherry

UPC 043129-12107-2

696-400 Light Oak

UPC 043129-05061-7

Replaceable SuperWick # 1041

High output, long-lasting

Easy-fill dual

water bottles

with refill hose

2-Stage AirCare®

Filter #1051

Traps airborne impurities

Prolongs life of wick

E-Z Roll

Casters

Makes moving

the unit easy

Parts & Accessories Page 10 Page 3

HIGHLOW

LOW HIGH

LEFT BOTTLE

REFILL

RIGHT BOTTLE

OFF

MODEL/

UPC DESCRIPTION MSTR

PAK/

WT/

CUBE

SGL1040

0 43129 05776-0

Replacement wick - Single Pack

(1 tabletop wick per carton)

xFits 300, 500, 700, DP3,

5D6, 7D6

4.0 lbs/

0.543

1040

0 43129 04467-8

Replacement wick – Twin Pack

(2 table top wicks per carton)

xFits 300, 500, 700 DP3,

D46 and B23 Series

5.5 lbs/

0.891

1041

0 43129 04468-5

Replacement Console Wick

xFits 400, 500, 600 and

ED-11 Series

17.1 lbs/

3.15

1043

0 43129 06259-7

Replacement Space Saver Wick

xFits 800 Series

5.2 lbs/

1.14

3398020GRYP Wick frame only for 1043

xFits 800 Series

3 lbs/

0.53

1044

0 43129 07487-3

Replacement Tabletop wick

xFits 900 Series

3 lbs/

0.53

1045

0 43129 09206-8

Replacement Console Wick

xFits H12 series

9.52 lbs/

1.83

1050

0 43129 03462-4

AirCare®Filter – Tabletops – Two

stage air cleaning filter removes dust,

pollen, smoke and odors

xFits 500 Series

1.9 lbs/

0.27

1051

0 43129 04466-1

AirCare®Filter - Two stage air

cleaning filter removes dust, pollen,

smoke and odors

xFits 400 and 600 Series

xFits H and E Series

5.5 lbs/

0.91

MODEL/

UPC DESCRIPTION MSTR

PAK/

WT/

CUBE

1101

0 43129 08187-1

Replacement HEPA Air Purifier Filter

xFits Model 200 001

17.2 lbs/

0.97

1103

0 43129 09821-3

Replacement HEPA Air Purifier Filter

xFits model 127 001

4.2 lbs/

0.36

1104

0 43129 09888-6

Replacement Carbon Prefilter for

HEPA Air Filter

xFits Model 127 001

3 lbs/

0.23

1202

0 43129 09647-9

Replacement Air Purifier Filter

xFits model DP3 200 2 in 1 3

4.6 lbs/

0.91

1301

0 43129 10757-1

Replacement MEGA Air Purifier Filter

xFits model 129 900 3

2.6 lbs/

0.39

1960

0 43129 01127-4

1 Quart Water Treatment

xPrevents Lime scale

build-up

xKeeps water smelling clean

xFor Water Wheel units

28.9 lbs/

1.02

1970

0 43129 04629-0

32 oz. Bacteria Treatment – EPA

registered. Only treatment required for

evaporative humidifiers

xHelps control bacteria and

algae buildup.

xKeeps water smelling clean

28 lbs/

1.02

1980

0 43129 10756-4

Bottle Cap Replacement Pack –

Contains two caps

xFits 400, 600, and H12

Series bottles

3 lbs/

0.22

1990

0 43129 09491-8

Digital Hygrometer/Thermometer

xDigitally measures humidity

and temperature

xMin/Max memory

xFahrenheit/Centigrade

switch

1.55 lbs/

1.99

4400

0 43129 25646-0

Universal Fill Tube

x44 inches total length

xFits most faucet heads

Whole-House Console Humidifiers

400 Series

◊Automatic humidistat allows you to set a

target humidity, and the unit will maintain

the selected humidity

◊Variable speed motor with quiet

nighttime setting

◊Separate left and right refill bottle indicators

◊Automatic shutoff

◊Easy-fill dual water bottles w/refill hose

◊5.5 Gallon Total Water Capacity

◊Uses patented Super Wick #1041

◊Includes 2-Stage AirCare® Filter

◊Measures 28”x 13

7/8

”x 22

3/8

”

427 300 Oak Burl

UPC 043129-04613-9

4D7 300 Light Oak

UPC 043129-25547-0

2700 sq. ft; 13 gal. per day ◊

◊

Console-Style

Replaceable

SuperWick # 1041

High output, long-lasting

Easy-fill dual

water bottles

with refill hose

Traps airborne impurities.

E-Z Roll

Casters for

moving the unit

This console stlye humidifier provides maximum humidification for the whole house in a

contemporary cabinet. The 4D7 series is capable of servicing a 27oo sq. ft house with an output

of 13 gallons per day. The 427 unit humidifies 2100 sq ft and delivers 10 gallons per day.

4D7-800 White

UPC 043129-12106-5

Stage

AirCare® Filter #

1051

Same features as above,

except for the following:

◊2-speeds

◊10 gallons output

◊2100 sq. ft. coverage

Two-in-One Purifier/Humidifier

DP3 200 Tabletop Unit

1100 sq. ft; 5 gal. per day

◊

Tabletop Style

750 sq. ft; 3.3 gal. per day

◊

Tabletop Style

This tabletop unit performs double duty: humidifying and purifying the air. The DP3 200

is capable of purifying the air in a 12’ x 14’ room every 15 minutes, and humidifies 750 sq. ft.

This unit can be used as a stand-alone air purifier when the humidifier function is not required.

◊Automatic humidistat

◊3-speed motor with quiet

nighttime setting

◊3.3 gallon output per day

◊3.5 Gallon Total Water Capacity

◊Lock-on feature allows air purifier (only)

to run continuously

◊Uses Dual Super Wicks #1040

◊Uses electrostatic air purifying filter, #1202

◊C.A.D.R. : Pollen 110; Dust 125; Smoke 90

◊Measures approx. 191/2”x 12”x 13

1/4

”

◊Automatic humidistat

◊3-speed motor with quiet

nighttime setting

◊5 gallons output per day

◊3.5 Gallon Total Water Capacity

◊Uses Dual Super Wicks #1040

◊Measures 191/2”x 12”x 13

1/2

”

336 500 Tabletop Multi-room Humidifier

DP3-200 Granite, Blue

UPC 043129-09188-7

336-500 Granite, Smoke

UPC 043129-11279-7

Although small enough to place on a table, the dual wicks in this unit provide coverage

to a surprisingly large area, 1100 sq. ft.,

with 5 gallons output per day.

Replaceable

Dual SuperWick #1040

Long lasting,

Electrostatic

Air filter #1202

Dual

SuperWicks

# 1040

Page 4 Page 9

H-12 Series Console Style Humidifiers

2300 sq. ft; 11 gal. per day ◊◊Euro-console Style

2500 sq. ft; 12 gal. per day ◊Console Style

Although this is a midsize unit, it is sufficient to humidify an entire 2500 sq. ft. house. It also

accomodates an optional air filter to increase indoor air quality.

◊Automatic humidistat

◊3-speed motor

◊12 gallon output per day

◊5 Gallon Total Water Capacity

◊E-Z Roll Casters for easy movement

◊Uses Super Wick #1041

◊Measures 24”x 131/2”x 22”

◊Automatic humidistat & built-in hygrometer

◊3-speed motor with quiet nighttime setting

◊11 Gallons output per day

◊3 Gallon Total Water Capacity

◊Uses Super Wick #1041

◊Optional 2-Stage AirCare®Filter #1051

◊Measures 241/2”x 15

3/4

”x 17

3/4

”

ED11 Euro-Console Style Humidifiers

H12-300

UPC 043129-09193-1

Light Oak

These stylish European-inspired console units offer whole-house humidification.

Replaceable

SuperWick # 1041

Optional 2-Stage

AirCare®Filter #1051

Easy-fill single

water bottle

with refill hose

H12-400

UPC 043129-098008-8

Oak Burl

Replaceable

SuperWick # 1041

Optional 2-Stage

AirCare®Filter #1051

Easy-fill Side

Reservoir

ED11-910

UPC 043129-25594-4

Charcoal, Titanium

ED11-800

UPC 043129-25595-1

Khaki, Linen

B23-810 Tabletop Humidifier

800 sq. ft; 3.5 gal. per day ◊Tabletop Style

This unique model is easily portable, and the built-in nitelight makes it

perfect for children’s bedrooms. The dishwasher-safe base makes this unit very low maintenance.

◊Analog hygrometer

◊2-speed motor

◊3.5 gallon output per day

◊2 Gallon Total Water Capacity

◊Uses Super Wick #1040

◊Measures 11”x 11”x10

1/2

”

◊Digital humidistat & built-in hygrometer

◊4-speed motor with quiet nighttime setting

◊Humidifies 700 sq. ft.

◊3 Gallons output per day

◊2 Gallon Total Water Capacity

◊Uses Super Wick #1041

◊Measures 161/4” x 10” x 11

1/2

”

7D6-100 Tabletop Humidifier

This single-room humidifier makes maintaining proper room moisture easier than ever.

Small enough to take with you on trips, with easy bottle fill and dishwasher-safe base.

Replaceable

SuperWick # 1040 B23 810, White

UPC 043129-25592-0

Replaceable

SuperWick # 1040

7D6-100 Gray, Midnight Blue

UPC 043129-25598-2

Water level

Window

with Nitelight

Bucket fill

and easy

dishwasher

cleaning

700 sq. ft; 3 gal. per day ◊Tabletop Style Page 8 Page 5

800 Series Spacesaver Humidifier

821 000 Warm Gray

UPC 043129-11603-0

Uses

Super Wick # 1043

for High Output.

Our spacesaver units provide whole-house humidification in

a compact cabinet that fits easily into a corner.

Easy Pour-in Reservoir

1700 - 1900 sq. ft; 8 - 9gal. per day ◊

◊

Spacesaver Style

826 800 Warm Gray

UPC 043129-07515-3

◊8Gallons output per day

◊Humidifies 1700 sq. ft.

◊Two speeds

◊Refill light and

Auto shutoff

◊Humidistat provides

precise humidity control

◊Measures 18”x 12

1/2

”x 21 ”

◊9 Gallons output per day

◊Humidifies 1900 sq. ft.

◊Digital Control

◊Refill light and

Auto shutoff

◊Hygrometer measures

precise room humidity

◊Measures 18”x 12

1/2

”x 21 ”

Mini-Console Humidifier

5D6-700

◊5 Gallons output per day

◊Automatic humidistat allows you to set a

target humidity, and the unit will maintain

the selected humidity

◊4-speed motor with quiet nighttime setting

◊Built-in hygrometer

◊Refill light & automatic shutoff

◊Easy pour-in fill method

◊3 Gallon Total Water Capacity

◊Uses two patented Super Wicks #1040

◊Accomodates 2-Stage AirCare® Filter # 1050

◊Measures 17

3/4

”x 9

1/4

”x 13

3/4

”

5D6 700 Warm Gray

UPC 043129-25597-5

1100 sq. ft; 5 gal. per day

◊

Mini-Console-Style

Uses Dual

SuperWick # 1040

High output, long-lasting

Traps airborne impurities.

Prolongs life of wick

This midsize humidifier offers good looks, compact design and maximum

humidification for up to 1100 sq. ft. The digital control panel provides precise

humidity monitoring and control. The easy pour-in design makes refilling worry-free.

Optional

2-Stage

AirCare®

Filter #1050

Easy Pour-in

reservoir

◊Automatic humidistat

◊4-speed motor with

quiet nighttime setting

◊Built-in hygrometer

◊6 gallons output per day

◊Humidifies 1300 sq. ft.

◊Dual Water Tanks

◊3Gallon Total Water Capacity

◊Measures 15”x 10”x 26

1/2

”

D46-720 Tower Humidifier

This atttractive tower unit is capable of humidifying multiple

rooms while taking up minimal space. Its digital controls

offers precise humidity monitoring and control.

Uses Dual

SuperWick # 1040

High output, long-lasting

D46-720 Charcoal, Titanium

UPC 043129-25599-9

Easy-fill Dual

Water Tanks

with handles and

locking clips

1300 sq. ft; 6 gal. per day

◊

Tower-Style

Page 6 Page 7

E-Z Roll

Casters for

moving the unit

800 Series Spacesaver Humidifier

821 000 Warm Gray

UPC 043129-11603-0

Uses

Super Wick # 1043

for High Output.

Our spacesaver units provide whole-house humidification in

a compact cabinet that fits easily into a corner.

Easy Pour-in Reservoir

1700 - 1900 sq. ft; 8 - 9gal. per day ◊

◊

Spacesaver Style

826 800 Warm Gray

UPC 043129-07515-3

◊8Gallons output per day

◊Humidifies 1700 sq. ft.

◊Two speeds

◊Refill light and

Auto shutoff

◊Humidistat provides

precise humidity control

◊Measures 18”x 12

1/2

”x 21 ”

◊9 Gallons output per day

◊Humidifies 1900 sq. ft.

◊Digital Control

◊Refill light and

Auto shutoff

◊Hygrometer measures

precise room humidity

◊Measures 18”x 12

1/2

”x 21 ”

Mini-Console Humidifier

5D6-700

◊5 Gallons output per day

◊Automatic humidistat allows you to set a

target humidity, and the unit will maintain

the selected humidity

◊4-speed motor with quiet nighttime setting

◊Built-in hygrometer

◊Refill light & automatic shutoff

◊Easy pour-in fill method

◊3 Gallon Total Water Capacity

◊Uses two patented Super Wicks #1040

◊Accomodates 2-Stage AirCare® Filter # 1050

◊Measures 17

3/4

”x 9

1/4

”x 13

3/4

”

5D6 700 Warm Gray

UPC 043129-25597-5

1100 sq. ft; 5 gal. per day

◊

Mini-Console-Style

Uses Dual

SuperWick # 1040

High output, long-lasting

Traps airborne impurities.

Prolongs life of wick

This midsize humidifier offers good looks, compact design and maximum

humidification for up to 1100 sq. ft. The digital control panel provides precise

humidity monitoring and control. The easy pour-in design makes refilling worry-free.

Optional

2-Stage

AirCare®

Filter #1050

Easy Pour-in

reservoir

◊Automatic humidistat

◊4-speed motor with

quiet nighttime setting

◊Built-in hygrometer

◊6 gallons output per day

◊Humidifies 1300 sq. ft.

◊Dual Water Tanks

◊3Gallon Total Water Capacity

◊Measures 15”x 10”x 26

1/2

”

D46-720 Tower Humidifier

This atttractive tower unit is capable of humidifying multiple

rooms while taking up minimal space. Its digital controls

offers precise humidity monitoring and control.

Uses Dual

SuperWick # 1040

High output, long-lasting

D46-720 Charcoal, Titanium

UPC 043129-25599-9

Easy-fill Dual

Water Tanks

with handles and

locking clips

1300 sq. ft; 6 gal. per day

◊

Tower-Style

Page 6 Page 7

E-Z Roll

Casters for

moving the unit

H-12 Series Console Style Humidifiers

2300 sq. ft; 11 gal. per day ◊

◊

Euro-console Style

2500 sq. ft; 12 gal. per day

◊

Console Style

Although this is a midsize unit, it is sufficient to humidify an entire 2500 sq. ft. house. It also

accomodates an optional air filter to increase indoor air quality.

◊Automatic humidistat

◊3-speed motor

◊12 gallon output per day

◊5 Gallon Total Water Capacity

◊E-Z Roll Casters for easy movement

◊Uses Super Wick #1041

◊Measures 24”x 131/2”x 22”

◊Automatic humidistat & built-in hygrometer

◊3-speed motor with quiet nighttime setting

◊11 Gallons output per day

◊3 Gallon Total Water Capacity

◊Uses Super Wick #1041

◊Optional 2-Stage AirCare®Filter #1051

◊Measures 241/2”x 15

3/4

”x 17

3/4

”

ED11 Euro-Console Style Humidifiers

H12-300

UPC 043129-09193-1

Light Oak

These stylish European-inspired console units offer whole-house humidification.

Replaceable

SuperWick # 1041

Optional 2-Stage

AirCare®Filter #1051

Easy-fill single

water bottle

with refill hose

H12-400

UPC 043129-098008-8

Oak Burl

Replaceable

SuperWick # 1041

Optional 2-Stage

AirCare®Filter #1051

Easy-fill Side

Reservoir

ED11-910

UPC 043129-25594-4

Charcoal, Titanium

ED11-800

UPC 043129-25595-1

Khaki, Linen

B23-810 Tabletop Humidifier

800 sq. ft; 3.5 gal. per day

◊

Tabletop Style

This unique model is easily portable, and the built-in nitelight makes it

perfect for children’s bedrooms. The dishwasher-safe base makes this unit very low maintenance.

◊Analog hygrometer

◊2-speed motor

◊3.5 gallon output per day

◊2 Gallon Total Water Capacity

◊Uses Super Wick #1040

◊Measures 11”x 11”x10

1/2

”

◊Digital humidistat & built-in hygrometer

◊4-speed motor with quiet nighttime setting

◊Humidifies 700 sq. ft.

◊3 Gallons output per day

◊2 Gallon Total Water Capacity

◊Uses Super Wick #1041

◊Measures 161/4” x 10” x 11

1/2

”

7D6-100 Tabletop Humidifier

This single-room humidifier makes maintaining proper room moisture easier than ever.

Small enough to take with you on trips, with easy bottle fill and dishwasher-safe base.

Replaceable

SuperWick # 1040 B23 810, White

UPC 043129-25592-0

Replaceable

SuperWick # 1040

7D6-100 Gray, Midnight Blue

UPC 043129-25598-2

Water level

Window

with Nitelight

Bucket fill

and easy

dishwasher

cleaning

700 sq. ft; 3 gal. per day

◊

Tabletop Style Page 8 Page 5

Whole-House Console Humidifiers

400 Series

◊Automatic humidistat allows you to set a

target humidity, and the unit will maintain

the selected humidity

◊Variable speed motor with quiet

nighttime setting

◊Separate left and right refill bottle indicators

◊Automatic shutoff

◊Easy-fill dual water bottles w/refill hose

◊5.5 Gallon Total Water Capacity

◊Uses patented Super Wick #1041

◊Includes 2-Stage AirCare® Filter

◊Measures 28”x 13

7/8

”x 22

3/8

”

427 300 Oak Burl

UPC 043129-04613-9

4D7 300 Light Oak

UPC 043129-25547-0

2700 sq. ft; 13 gal. per day ◊◊Console-Style

Replaceable

SuperWick # 1041

High output, long-lasting

Easy-fill dual

water bottles

with refill hose

Traps airborne impurities.

E-Z Roll

Casters for

moving the unit

This console stlye humidifier provides maximum humidification for the whole house in a

contemporary cabinet. The 4D7 series is capable of servicing a 27oo sq. ft house with an output

of 13 gallons per day. The 427 unit humidifies 2100 sq ft and delivers 10 gallons per day.

4D7-800 White

UPC 043129-12106-5

Stage

AirCare® Filter #

1051

Same features as above,

except for the following:

◊2-speeds

◊10 gallons output

◊2100 sq. ft. coverage

Two-in-One Purifier/Humidifier

DP3 200 Tabletop Unit

1100 sq. ft; 5 gal. per day ◊Tabletop Style

750 sq. ft; 3.3 gal. per day ◊Tabletop Style

This tabletop unit performs double duty: humidifying and purifying the air. The DP3 200

is capable of purifying the air in a 12’ x 14’ room every 15 minutes, and humidifies 750 sq. ft.

This unit can be used as a stand-alone air purifier when the humidifier function is not required.

◊Automatic humidistat

◊3-speed motor with quiet

nighttime setting

◊3.3 gallon output per day

◊3.5 Gallon Total Water Capacity

◊Lock-on feature allows air purifier (only)

to run continuously

◊Uses Dual Super Wicks #1040

◊Uses electrostatic air purifying filter, #1202

◊C.A.D.R. : Pollen 110; Dust 125; Smoke 90

◊Measures approx. 191/2”x 12”x 13

1/4

”

◊Automatic humidistat

◊3-speed motor with quiet

nighttime setting

◊5 gallons output per day

◊3.5 Gallon Total Water Capacity

◊Uses Dual Super Wicks #1040

◊Measures 191/2”x 12”x 13

1/2

”

336 500 Tabletop Multi-room Humidifier

DP3-200 Granite, Blue

UPC 043129-09188-7

336-500 Granite, Smoke

UPC 043129-11279-7

Although small enough to place on a table, the dual wicks in this unit provide coverage

to a surprisingly large area, 1100 sq. ft.,

with 5 gallons output per day.

Replaceable

Dual SuperWick #1040

Long lasting,

Electrostatic

Air filter #1202

Dual

SuperWicks

# 1040

Page 4 Page 9

2500 sq. ft; 12 gal. per day ◊

◊

Traditional-Style

Whole-House Credenza Style Humidifiers

Whole-house humidification is provided in the clean, classic lines of this wood grain styled credenza.

Holding over 5 gallons, this handsome unit boasts 12 gallons output per day,

effectively humidifying up to 2,500 square feet.

◊Automatic humidistat allows you to set a

target humidity, and the unit will maintain

the selected humidity

◊Variable speed motor with quiet

nighttime setting

◊Separate left and right refill bottle indicators

◊Automatic shutoff

◊Easy-fill dual water bottles w/refill hose

◊5.2 Gallon Total Water Capacity

◊Uses patented Super Wick #1041

◊Accomodates 2-Stage AirCare® Filter

(standard on 697-500; optional on 696-400)

◊Measures 29 5/8”x 14” 7/8x 25 3/8”

697-500 Cherry

UPC 043129-12107-2

696-400 Light Oak

UPC 043129-05061-7

Replaceable SuperWick # 1041

High output, long-lasting

Easy-fill dual

water bottles

with refill hose

2-Stage AirCare®

Filter #1051

Traps airborne impurities

Prolongs life of wick

E-Z Roll

Casters

Makes moving

the unit easy

Parts & Accessories Page 10 Page 3

HIGHLOW

LOW HIGH

LEFT BOTTLE

REFILL

RIGHT BOTTLE

OFF

MODEL/

UPC DESCRIPTION MSTR

PAK/

WT/

CUBE

SGL1040

0 43129 05776-0

Replacement wick - Single Pack

(1 tabletop wick per carton)

xFits 300, 500, 700, DP3,

5D6, 7D6

4.0 lbs/

0.543

1040

0 43129 04467-8

Replacement wick – Twin Pack

(2 table top wicks per carton)

xFits 300, 500, 700 DP3,

D46 and B23 Series

5.5 lbs/

0.891

1041

0 43129 04468-5

Replacement Console Wick

xFits 400, 500, 600 and

ED-11 Series

17.1 lbs/

3.15

1043

0 43129 06259-7

Replacement Space Saver Wick

xFits 800 Series

5.2 lbs/

1.14

3398020GRYP Wick frame only for 1043

xFits 800 Series

3 lbs/

0.53

1044

0 43129 07487-3

Replacement Tabletop wick

xFits 900 Series

3 lbs/

0.53

1045

0 43129 09206-8

Replacement Console Wick

xFits H12 series

9.52 lbs/

1.83

1050

0 43129 03462-4

AirCare®Filter – Tabletops – Two

stage air cleaning filter removes dust,

pollen, smoke and odors

xFits 500 Series

1.9 lbs/

0.27

1051

0 43129 04466-1

AirCare®Filter - Two stage air

cleaning filter removes dust, pollen,

smoke and odors

xFits 400 and 600 Series

xFits H and E Series

5.5 lbs/

0.91

MODEL/

UPC DESCRIPTION MSTR

PAK/

WT/

CUBE

1101

0 43129 08187-1

Replacement HEPA Air Purifier Filter

xFits Model 200 001

17.2 lbs/

0.97

1103

0 43129 09821-3

Replacement HEPA Air Purifier Filter

xFits model 127 001

4.2 lbs/

0.36

1104

0 43129 09888-6

Replacement Carbon Prefilter for

HEPA Air Filter

xFits Model 127 001

3 lbs/

0.23

1202

0 43129 09647-9

Replacement Air Purifier Filter

xFits model DP3 200 2 in 1 3

4.6 lbs/

0.91

1301

0 43129 10757-1

Replacement MEGA Air Purifier Filter

xFits model 129 900 3

2.6 lbs/

0.39

1960

0 43129 01127-4

1 Quart Water Treatment

xPrevents Lime scale

build-up

xKeeps water smelling clean

xFor Water Wheel units

28.9 lbs/

1.02

1970

0 43129 04629-0

32 oz. Bacteria Treatment – EPA

registered. Only treatment required for

evaporative humidifiers

xHelps control bacteria and

algae buildup.

xKeeps water smelling clean

28 lbs/

1.02

1980

0 43129 10756-4

Bottle Cap Replacement Pack –

Contains two caps

xFits 400, 600, and H12

Series bottles

3 lbs/

0.22

1990

0 43129 09491-8

Digital Hygrometer/Thermometer

xDigitally measures humidity

and temperature

xMin/Max memory

xFahrenheit/Centigrade

switch

1.55 lbs/

1.99

4400

0 43129 25646-0

Universal Fill Tube

x44 inches total length

xFits most faucet heads

Este manual sirve para los siguientes modelos

Tabla de contenidos

Manuales populares de Humidificador de otras marcas

Boneco

Boneco H300 Manual de usuario

Bionaire

Bionaire CM1 Manual

Air-O-Swiss

Air-O-Swiss AOS 7131 Manual

KING

KING K 5002 Rainbow Manual de usuario

Crane

Crane EE-6902 Manual de usuario

Glaziar

Glaziar Ness Manual de usuario

Philips

Philips DreamStation Go Dimensiones

Honeywell

Honeywell MISTMATE HUL520BC Manual de usuario

Stadler Form

Stadler Form Hera Manual de usuario

Hunter

Hunter 31206 Manual de usuario

TaoTronics

TaoTronics TT-AH004 Manual de usuario

adorini

adorini Cigar Heaven Manual de usuario

Lanaform

Lanaform Aroma Manual de usuario

Aprilaire

Aprilaire 800 Series Manual de usuario

Pyle

Pyle SereneLife PHUMDIF8 Manual de usuario

Trotec

Trotec B 200 Manual de usuario

Pure Humidifier

Pure Humidifier EC Series Manual de usuario

Crane

Crane EE-864 Manual de usuario
