ESAB PowerCut 1300 Manual de usuario

Valid for serial no. 034-xxx-xxxx0449 551 001 GB 20120905

Powercutä1300/ 1600

Instruction manual

- 2 -

- 3 -

TOCe

Rights reserved to alter specifications without notice.

1 SAFETY 4...........................................................

2 INTRODUCTION 6...................................................

2.1 Equipment 6................................................................

3 TECHNICAL DATA 6.................................................

4 INSTALLATION 7....................................................

4.1 Delivery check and location 8.................................................

4.2 Mains power supply 9........................................................

4.3 Input air connection 9........................................................

4.4 Connection for return cable 10.................................................

4.5 Connection of torch 11........................................................

5 OPERATION 12.......................................................

5.1 Connections 12..............................................................

5.2 Control devices 13...........................................................

5.2.1 Symbol key 14..........................................................

5.3 Cutting 15...................................................................

6 MAINTENANCE 16....................................................

6.1 Inspection and cleaning 16....................................................

7 FAULT TRACING 17..................................................

7.1 Fault codes 18...............................................................

8 ORDERING SPARE PARTS 19.........................................

DIAGRAM 20............................................................

ORDER NUMBER 22.....................................................

ACCESSORIES 23.......................................................

- 4 -

bp16ea

1 SAFETY

Users of ESAB equipment have the ultimate responsibility for ensuring that anyone who works on or

near the equipment observes all the relevant safety precautions. Safety precautions must meet the

requirements that apply to this type of equipment. The following recommendations should be ob

served in addition to the standard regulations that apply to the workplace.

All work must be carried out by trained personnel well-acquainted with the operation of the equip

ment. Incorrect operation of the equipment may lead to hazardous situations which can result in in

jury to the operator and damage to the equipment.

1. Anyone who uses the equipment must be familiar with:

Sits operation

Slocation of emergency stops

Sits function

Srelevant safety precautions

Swelding and cutting

2. The operator must ensure that:

Sno unauthorised person is stationed within the working area of the equipment when it is

started up.

Sno-one is unprotected when the arc is struck

3. The workplace must:

Sbe suitable for the purpose

Sbe free from drafts

4. Personal safety equipment

SAlways wear recommended personal safety equipment, such as safety glasses, flame-proof

clothing, safety gloves.

SDo not wear loose-fitting items, such as scarves, bracelets, rings, etc., which could become

trapped or cause burns.

5. General precautions

SMake sure the return cable is connected securely.

SWork on high voltage equipment may only be carried out by a qualified electrician.

SAppropriate fire extinquishing equipment must be clearly marked and close at hand.

SLubrication and maintenance must not be carried out on the equipment during operation.

- 5 -

bp16ea

WARNING

Read and understand the instruction manual before installing or operating.

Arc welding and cutting can be injurious to yourself and others. Take precautions when welding and

cutting. Ask for your employer's safety practices which should be based on manufacturers' hazard

data.

ELECTRIC SHOCK - Can kill

SInstall and earth the unit in accordance with applicable standards.

SDo not touch live electrical parts or electrodes with bare skin, wet gloves or wet clothing.

SInsulate yourself from earth and the workpiece.

SEnsure your working stance is safe.

FUMES AND GASES - Can be dangerous to health

SKeep your head out of the fumes.

SUse ventilation, extraction at the arc, or both, to take fumes and gases away from your breathing zone

and the general area.

ARC RAYS - Can injure eyes and burn skin.

SProtect your eyes and body. Use the correct welding screen and filter lens and wear protective

clothing.

SProtect bystanders with suitable screens or curtains.

FIRE HAZARD

SSparks (spatter) can cause fire. Make sure therefore that there are no inflammable materials nearby.

NOISE - Excessive noise can damage hearing

SProtect your ears. Use earmuffs or other hearing protection.

SWarn bystanders of the risk.

MALFUNCTION - Call for expert assistance in the event of malfunction.

PROTECT YOURSELF AND OTHERS!

WARNING

Do not use the power source for thawing frozen pipes.

CAUTION

Class A equipment is not intended for use in residential locations where

the electrical power is provided by the public low-voltage supply system.

There may be potential difficulties in ensuring electromagnetic

compatibility of class A equipment in those locations, due to conducted

as well as radiated disturbances.

CAUTION

This product is solely intended for plasma cutting.

CAUTION

Read and understand the instruction manual before

installing or operating.

- 6 -

bp16ea

Dispose of electronic equipment at the recycling facility!

In observance of European Directive 2002/96/EC on Waste Electrical and Electronic

Equipment and its implementation in accordance with national law, electrical and/or

electronic equipment that has reached the end of its life must be disposed of at a

recycling facility.

As the person responsible for the equipment, it is your responsibility to obtain

information on approved collection stations.

For further information contact the nearest ESAB dealer.

ESAB can provide you with all necessary cutting protection and accessories.

2 INTRODUCTION

The plasma power source Powercut 1300/1600 and the plasma cutting torch PT-38

are a complete and safe plasma cutting system for manual cutting and gouging. It

delivers cutting power for severing materials up to 45 mm thickness.

ESAB's accessories for the product can be found on page 23.

2.1 Equipment

The power source is supplied with:

Smains cable, 3 m

Sinstruction manual

Sreturn cable incl clamp

Splasma cutting torch, 7.5 m, supplied according to the denomination on page 22.

3 TECHNICAL DATA

Powercut 1300 Powercut 1600

Mains voltage 3400 V $10 % 50/60 Hz 3400 V $10 % 50/60 Hz

Mains supply Ssc min. 4.0 MVA

Zmax. 0.04 

Ssc min. 4.0 MVA

Zmax. 0.04 

Setting range 20 – 70 A 20 – 90 A

Permitted load

60 % duty cycle

100 % duty cycle

90 A / 115 V

70 A / 115 V

90 A / 115 V

70 A / 115 V

Efficiency at maximum current 89 % 89 %

Open-circuit voltage U0208 V 280 V

Operating temperature –10 to 40 °C –10 to 40 °C

Transportation temperature –20 to 55 °C –20 to 55 °C

Sound pressure at no load < 70 db (A) < 70 db (A)

Dimensions, l x w x h 706 x 322 x 379 mm 706 x 322 x 379 mm

Weight 41 kg 41 kg

Insulation class transformer H H

Enclosure class IP 23 IP 23

- 7 -

bp16ea

Mains supply, Ssc min

Minimum short circuit power on the network in accordance with IEC 61000-3-12

Mains supply, Zmax

Maximum permissible line impedance of the network in accordance with IEC 61000-3-11.

Duty cycle

The duty cycle refers to the time as a percentage of a ten-minute period that you can weld or cut at

a certain load without overloading. The duty cycle is valid for 40°C.

Enclosure class

The IP code indicates the enclosure class, i. e. the degree of protection against penetration by solid

objects or water. Equipment marked IP23 is designed for indoor and outdoor use.

4 INSTALLATION

The installation must be carried out by a professional.

Correct installation is very important for trouble-free operation and good cutting

results. Carefully read and follow each step in this chapter.

WARNING

ELECTRIC SHOCKS CAN KILL Take precautionary measures against electric

shocks. Ensure that all power supplies are disconnected –switch off the switch at

the wall socket and pull out the equipment's power cable from the socket before

making any electrical connections in the power source.

WARNING

It is very important that the chassis is connected to the approved electric protective

earth, to prevent electric shocks and electrical accidents. Ensure that protective

earth is not connected to any phase conductors by mistake.

WARNING

Poor connections or failure to connect the return cable to the workpiece can result

in fatal electric shock.

WARNING

Air filter devices may not be used –installation or mounting of any form of air filter

device prevents the cold air flow and causes a risk of overheating. The warranty is

invalidated if any type of air filter is used.

- 8 -

bp16ea

WARNING

Do NOT start the equipment with the cover removed.

Do NOT connect the equipment under tension or when you are holding it or

carrying it.

Do NOT touch any of the torch's parts when the power supply is on.

CAUTION

This product is intended for industrial use. In a domestic environment this product may

cause radio interference. It is the user's responsibility to take adequate precautions.

CAUTION

Place the power source at least 3 metres from the cutting area as sparks and slag spray

can damage the power source

4.1 Delivery check and location

1. Remove the packaging. Inspect the equipment for damage that was not

immediately apparent upon reception of the delivery. Immediately report any

damage to the delivery company.

2. Check for any loose parts in the packaging. Check that the air ducts in the

cover's rear panel are not blocked with packaging material that can prevent the

air flow through the power source.

The power source has a lifting eyelet and can be lifted easily. Check that the

lifting equipment that is to be used can withstand the weight of the power source.

The weight is stated in the table TECHNICAL DATA, see chapter 3.

WARNING

The product must be lifted as follows:

3. Position the power source so that its cooling air inlets and outlets are not

obstructed. Minimum permitted distance to wall or other obstruction is 30 cm.

4. An air source that gives clean and dry air, at least 236 l/m at 6.2 bar (90 psig), is

required for cutting. The cutting air pressure must not exceed 10.3 bar

(150 psig), which is the maximum inlet pressure for the filter regulator that is

included in the delivery.

- 9 -

bp16ea

4.2 Mains power supply

Make sure that the power source is connected to the correct supply voltage and that

it is protected by the correct fuse rating. The outlet shall have a protectiv earth

connection.

Rating plate with supply connection data

Recommended fuse sizes and minimum cable area

Powercut 1300 Powercut 1600

Mains voltage 400 V, 50 Hz 400 V, 50 Hz

Mains cable area mm 24 G 6 4 G 6

Phase current I1eff 18 A 20 A

Fuse, anti-surge 25 A 30 A

NOTE! The mains cable areas and fuse sizes as shown above are in accordance with Swedish

regulations. Use the power source in accordance with the relevant national regulations.

WARNING

Make sure the power source is switched off before removing the fuse.

4.3 Input air connection

Connect your air supply to the inlet connection of the filter.

- 10 -

bp16ea

4.4 Connection for return cable

Clamp the return cable to the workpiece. Be sure the workpiece is connected to an

approved earth ground with a properly sized ground cable.

Otros manuales para PowerCut 1300

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Sistema de soldadura de ESAB

ESAB

ESAB EMP 215ic Manual de usuario

ESAB

ESAB EPP-360 Manual de usuario

ESAB

ESAB Aristotig 405 AC/DC Manual de usuario

ESAB

ESAB TXH Series Manual de usuario

ESAB

ESAB Aristo FeedMech 4804 Manual de usuario

ESAB

ESAB Heliarc 353iAC/DC Manual de usuario

ESAB

ESAB Aristotig 255 AC/DC Manual de usuario

ESAB

ESAB Aristo Origo Feed 3004 Manual de usuario

ESAB

ESAB Powercut 900 Manual de usuario

ESAB

ESAB A6 Mastertrac Manual de usuario

ESAB

ESAB DTB 250 Manual de usuario

ESAB

ESAB HandyPlasma 50 Manual de usuario

ESAB

ESAB ET180i Manual de usuario

ESAB

ESAB Origo Tig 3000i Manual de usuario

ESAB

ESAB OrigoFeed 30-2 Manual de usuario

ESAB

ESAB AristoMig U500 Manual de usuario

ESAB

ESAB Warrior 500i CC Manual de usuario

ESAB

ESAB Aristo Mig 5000i Manual de usuario

ESAB

ESAB PowerCut-550 Manual de usuario

ESAB

ESAB Origo Mig L305 Manual de usuario

ESAB

ESAB ARC 601i Manual de usuario

ESAB

ESAB Cutmaster 100 Manual de usuario

ESAB

ESAB AristoFeed 30- 4 Manual de usuario

ESAB

ESAB MIG 301i Manual de usuario

Manuales populares de Sistema de soldadura de otras marcas

Berner

Berner PLASMACUT 54 Manual de usuario

Pro Spot

Pro Spot PR-155 Manual de usuario

Forney

Forney 210 Manual de usuario

Thermal Arc

Thermal Arc 400S Manual de usuario

Lincoln Electric

Lincoln Electric HANDYMIG 170I Manual de usuario

GYS

GYS PROTIG 201 AC/DC Manual de usuario

TAFA

TAFA 30*8B35 Manual de usuario

Lincoln Electric

Lincoln Electric INVERTEC V350-PRO CE Manual de usuario

CIGWELD

CIGWELD 636804 Guía rápida

Red-D-Arc

Red-D-Arc DC-400 Manual de usuario

Hobart Welding Products

Hobart Welding Products Spool Gun DP 3035-10 Manual de usuario

Elettro

Elettro HI-MIG 3000 SYNERGIC Manual de usuario

WIA

WIA Weldmatic 270 CP132-2 Manual de usuario

Sonics

Sonics H520T Manual de usuario

Miller

Miller Big Blue 400D Manual de usuario

NewArc

NewArc RT2000 Guía de inicio rápido

Hypertherm

Hypertherm powermax1000 Manual de usuario

Lincoln Electric

Lincoln Electric POWER WAVE I400 Manual de usuario
