Epson 410W - PowerLite WXGA LCD Projector Manual del sistema

INSTALLATION HANDBOOK

Remote Control Information

Epson PowerLite 410W

Using the Remote Control

The remote control lets you access your projector’s features from

anywhere in the room—up to 20 feet (6 m) away. For example, you

can turn the projector on and o, freeze the presentation, zoom in on

a portion of your image, and accessthe menu system. (The projector

menus let you adjust many projector settings; see Chapter 4.)

When using the remote control, stand within 20 feet (6 m) of the

projector. Point the remote control either at the front or back of the

projector or at the screen (the projector’s front sensor can detect

signals bounced o the screen). Press the button for the function you

want to use.

This chapter covers the following information:

Controlling the picture and sound

Replacing the remote control batteries

Controlling the Picture and Sound

You can use the remote control to select your source, adjust the colors,

temporarily turn o the picture and sound, freeze the action, or zoom

in on the picture. Make sure you have set up your projector and

connected any equipment asdescribed in Chapter 1.

Switching Between Picture Sources

If you’ve connected your projector to more than one computer and/or

video source, you can use the Source Search button on the projector

or remote control to switch between the dierent sources.

After you select a source, the screen goes dark for a moment before the

image appears. The name of the selected source (such as Computer1

or S-Video)appears briey on the screen.

Source Search

button

INSTALLATION HANDBOOK

Remote Control Information

Epson PowerLite 410W

Adjusting the Color Mode

You may want to adjust the color mode to select a dierent setting

that isappropriate for the image you’re projecting and the

environment in which you’re projecting it. Press the Color Mode

button on the remote control.

If you’re projecting computer or RGB video images, the default color

mode is Presentation, which is appropriate for full-color

presentations in bright rooms.

The following table lists the color modes available.

You can also use the projector menu system to change the color mode

in the Image menu

Color mode Description

Dynamic Use for projecting the brightest picture.

Presentation Use when you’re projecting a full-color presentation in

a bright room.

Theatre Use when projecting movies in a dark room.

Photo Best for projecting still images with vivid color in a

bright room (computer input only).

Sports Best for projecting TV programs in a bright room

(component, composite, or S-Video input only).

sRGB Use when projecting computer images conforming to

the sRGB color standard.

Blackboard Choose thisfixed color mode when you need to

project against a green blackboard.

Whiteboard Choose this fixed color mode when you need to

project against a whiteboard.

Color

Mode

button

Turning Off the Picture and Sound

Press the A/V Mute button on the remote control to turn o the

image and sound and darken your screen. This is useful if you want to

temporarily re-direct your audience’s attention without the distraction

of a bright screen.

To turn o the picture and sound, press the A/V Mute button. The

screen goes dark.

To turn the image and sound back on, press the button again.

You can create an image, such as a company logo or a picture, to

display on the screen whenever you press the A/V Mutebutton.

A/V Mute

button

INSTALLATION HANDBOOK

Remote Control Information

Epson PowerLite 410W

Stopping Action

Press the Freezebutton to stop the action in your video or computer

image and keep the current image on the screen. The sound will

continue, however. Also, because the source continues to transmit

signals, you won’t resume the action from the point you paused it.

To restart the action, press the Freezebutton again. Freeze

button

Zooming Your Image

Follow these steps to zoom in on a portion of the image:

1. Press the E-Zoom + button on the remote control.

You see a crosshair indicating the center of the zoom-in area.

2. Use the four “arrow” buttons on the remote control to position

the crosshair in the area you want to enlarge.

3. Continue pressing the E-Zoom + button to enlarge the selected

area up to4 times.

4. While the image is enlarged, you can:

Use the arrow buttons to pan about.

Press the E-Zoom – button to zoom out.

5. When you’re done, press the ESC button to return to the original

size.

Changing the Image’s Aspect Ratio

You can use the Aspect button on the remote control to change the

aspect (width to height) ratio, depending on the input signal.

Auto (video images only)

Automatically sets the aspect ratio according to the input signal.

4:3 ratio images display at 4:3, squeeze-recorded signals display at

16:9, andletterbox signals display at Zoomratio (described

below).

Normal

Displays images using the full projection area and maintains the

aspect ratio of the image. 4:3 ratio images project with black

bands on the sides, 16:9 images project with black bands on the

top and bottom, and 16:10 images use the entire projection area.

16:9

Converts the aspect ratio of the image to 16:9. 4:3 ratio images

are elongated horizontally to t.

E-Zoom

buttons

Arrow

buttons

Aspect

button

INSTALLATION HANDBOOK

Remote Control Information

Epson PowerLite 410W

Zoom

Displays images using the full width of the projection area and

maintains the aspect ratio of the image. 4:3 ratio images are cut

o on the top and bottom.

Full

Displays images using the full width of the projection area, but

does not retain the aspect ratio. 4:3 ratio images are elongated

horizontally.

Through

Displays images as is (aspect ratio and resolution are maintained).

Black bands appear if the resolution is 1280 × 800 or less; images

are cut o if the resolution is over 1280 × 800.

Press the Aspect button repeatedly tocycle through the available

options.

You can also change the aspect ratio using the projector’s Signal

menu.

INSTALLATION HANDBOOK

Remote Control Information

Epson PowerLite 410W

Replacing the Batteries

The remote control uses two AA alkaline batteries. Follow these steps

when you need to replace them:

1. Press in the tab to remove the battery cover.

2. Remove the old batteries, then insert the new ones as shown.

3. Replace the battery cover. (It should click into place.)

caution

When replacing batteries,

take the following

precautions:

Replace the batteries as

soon as they run out. If a

battery leaks, wipe away

battery uid with a soft

cloth. If uid gets on your

hands, wash them

immediately.

Do not expose batteries to

heat or ame.

Dispose of used batteries

according to local

regulations.

Remove the batteries if

you won’t be using the

remote control for a long

period of time.

note

The remote control

automatically shuts o when

it detects a button being

pressed more than

30 seconds. This conserves

battery life. It can be

helpful, for example, when

the remote is in a carrying

case and the PPower

button is accidentally

pushed.
