Epson 1715C - PowerLite XGA LCD Projector Manual del sistema

INSTALLATION HANDBOOK

Remote Control Information

Epson PowerLite 1715c

Using the Remote Control

Follow these tips for using the remote control:

Point the remote control at the front of the projector or at the

screen.

Stand within 20 feet of the projector.

Avoid using the remote under bright fluorescent lamps or in

direct sunlight, or the projector may not respond properly.

Replacing the Batteries

Replace the batteries as described below:

1. Turn the remote control over.

2. Press down on the tab on the

battery cover as you lift the cover

off.

3. Install two AAA batteries,

inserting the +and –ends as

shown.

4. Position the cover as shown, then

press down until it snaps into

place.

note

If a button is pressed longer

than 30 seconds, the remote

control stops operating to

conserve power. When you

release the button, normal

operation resumes.

caution

When replacing batteries,

take the following

precautions:

Replace the batteries as

soon as they run out. If the

batteries leak, wipe away

battery fluid with a soft

cloth. If fluid gets on your

hands, wash immediately.

Do not expose batteries to

heat or flame.

Dispose of used batteries

according to local

regulations.

Remove the batteries if

you won’t be using the

projector for a long period of

time.

INSTALLATION HANDBOOK

Remote Control Information

Epson PowerLite 1715c

Controlling the Picture and Sound

You can use the remote control to preview and select your picture

sources, temporarily turn off the picture and sound, freeze the action,

zoom in on the picture, and adjust the volume.

Switching Between Picture Sources

If your projector is connected to more than one computer and/or

video source, you can switch between the different sources:

The easiest way to select your source is to press the Search button

on the remote control (or the Source Search button on the

projector) repeatedly until you see the image you want on the

screen.

On the remote control, there are four Source buttons. Use them

to switch between equipment connected to the port identified on

each button, or to use EasyMP.

After you select a source, the screen goes dark for a moment before the

image appears.

INSTALLATION HANDBOOK

Remote Control Information

Epson PowerLite 1715c

Turning Off the Picture and Sound

You can use the A/V Mute button on the remote control to turn off

the image and sound. This does the same thing as the A/V Mute slide

and is useful if you want to temporarily redirect your audience’s

attention.

To turn off the picture and sound, press the A/V Mute button.

The screen turns black.

To turn the image and sound back on, press the button again.

You can have the screen turn blue when you press the A/V Mute

button. You can also have an image, such as a company logo, display

on the screen (see page 124).

Stopping Action

You can use the remote control to stop the action in your video or

computer image.

To stop the action and keep the current image on the screen, press

the Freeze button. The sound continues.

To restart it, press the Freeze button again.

note

This function pauses the

image, but not the sound.

Also, because the source

continues to transmit

signals, you won’t resume

the action from the point

you stopped it.

INSTALLATION HANDBOOK

Remote Control Information

Epson PowerLite 1715c

Zooming Part of Your Image

You can zoom in on a portion of the image using the E-Zoom buttons

on the remote control.

1. Press the E-Zoom button on the remote control.

You see a crosshair indicating the center of the zoom-in area.

2. Use the pointer button to position the crosshair.

3. Continue pressing the E-Zoom button to enlarge the selected

area up to 4 times.

4. While the image is enlarged, you can:

Use the pointer button to move around the screen.

Press the E-Zoom button to zoom out.

5. When done, press the ESC button to return the image to its

original size.

Controlling the Volume

To change the volume, press the or button on the remote

control or projector.

You can also adjust the volume using the projector’s menu system. See

page 120.

note

To temporarily shut off the

sound and picture, press the

A/V Mute button or close

the A/V Mute slide.

INSTALLATION HANDBOOK

Remote Control Information

Epson PowerLite 1715c

Resizing Video Images

You can use the Resize button on the remote control to adjust how

an image fits into the display area.

For video images, press Resize to switch the aspect ratio between 4:3

and 16:9, (and Normal for computer images). This lets you play

certain digital video images or movies recorded on certain DVDs in

16:9 widescreen format.

For computer images, resizing is normally unnecessary, since the

projector automatically resizes the image to make the best use of the

display area. If you press the Resize button on the projector or remote

control, the projector displays the image at the output resolution of

the computer (which makes the image larger or smaller, depending on

its resolution). If the resolution of the image is the same as the

projector’s (1024 ×768), pressing Resize has no effect.

Adjusting the Color Mode

You can use the Color Mode button on the remote control to adjust

the color, brightness, and other aspects of your image.

Press the button repeatedly to select from the following settings:

Photo: For vivid, high-contrast still images in a bright room.

Sports (video, S-video, or composite video only): For vivid TV

images projected in a bright room.

Presentation: For computer presentations (the default when

projecting from a computer with analog video).

Theatre: For optimizing movie images with increased contrast.

Game: For increased brightness when playing video games or

watching TV in a bright room. Emphasizes dark gradations.

sRGB: For matching the color palette of standard sRGB computer

displays

Blackboard: For projecting accurate colors on a green chalkboard

(adjusts the white point).

INSTALLATION HANDBOOK

Remote Control Information

Epson PowerLite 1715c

Operating Your Computer with the

Remote Control

If you connect a computer to the projector with a USB cable, as

described on page 38, then select Link21L for the USB Type B setting

in the Extended menu (see page 128), you can use the remote control

in place of your computer’s mouse. This gives you more flexibility

when delivering slideshow-style presentations, since you won’t have to

stand next to the computer to change slides.

Use the Up and Down buttons to move through a

slideshow.

Use the pointer button to move the cursor on the screen.

Press the Enter button once to left-click, or press it twice to

double-click. Press the Esc button to right-click.

To drag-and-drop, hold down the Enter button. Then use the

pointer button to drag the object. When it’s where you want it,

press Enter to release it.

Page up or down

to change slides

in PowerPoint

Right-click

Left-click

INSTALLATION HANDBOOK

Remote Control Information

Epson PowerLite 1715c

Highlighting Your Presentation

You can display a pointer to call out important information on the

screen. If you want to customize the pointer tool, you can choose from

three alternative shapes.

Using the Pointer Tool

1. To activate the pointer tool, press the Pointer button on the

remote control. A pointer appears on the screen.

If you prefer to use a different style of pointer, see the instructions

in the next section.

2. Use the pointer button on the remote control to position the

pointer on the screen.

3. When you’re done using the pointer, press Esc to clear the screen.

Customizing the Pointer Tool

You can change the appearance of the pointer by choosing from three

alternative shapes.

1. Press the Menu button on the remote control, highlight the

Settings menu, highlight Pointer Shape, and press Enter. You

can select one of the pointer shapes shown at the left.

2. Select the shape you want and press Enter.

3. Highlight Return and press Enter.

4. Press Menu to exit from the menu system.

Pointer
