Epson SC-F9200 series Guía del usuario

SC-F9200 Series Rev.A

SETUP MANUAL

SE Group Confidential (Related Staff Only)

SC-F9200 Series

SC-F9200 Series Rev.A

•Please inform the user of the next page certainly!

•Please print and pass the next page to user and

encourage the points of caution.

IMPORTANCE

SC-F9200 Series Rev.A

SC‐F‐Series

Checkinklevels

■Inkrefill

Ink level is more than 70mm:

Recommends to continue using the

printer until the ink level reaches

70mm from the bottom.

Ink level is about or less than 70mm:

Go to step 2.

Replace chip unit with

new one attached

new ink pack.

Refill ink.

-Use up all ink in the pack at a time. (No remaining)

When this message appears,

check ink level of the tank

which is indicated by .

Shake the new ink pack as shown

in the illustration horizontally for

approximately 5cm left and right

for 5seconds approximately

15times.

Important

SC-F9200 Series Rev.A

The instructions and procedures included herein are intended

for the experienced repair technicians, and attention should

be given to the precautions on the preceding page.

CHECK

AGAIN

IMPORTANCE

Symbols Used in this Manual

Indicates an operating or maintenance procedure, practice, or

condition that, if not strictly observed, could result in damage

to, or destruction of, equipment.

May indicate an operating or maintenance procedure, practice or

condition that is necessary to accomplish a task efficiently.

It may also provide additional information that is related to a

specific subject, or comment on the results achieved through

a previous action.

Indicates should be confirmed by tentative When assembling it

until the present stage. Write the check when it is possible to

confirm it.

Indicates important point about assembly.

Wear protective eyewear and gloves when performing

assembly, and maintenance.

About This Manual

C A U T I O N

CHECK

P O I N T

SC-F9200 Series Rev.A

Revision Date of Issue Description

0 April 22,2015 Temporary release for AMP unit

A July 10,2015 First release for MP unit

Revision Status

SC-F9200 Series Rev.A

1.1 Caution for Installation

Installation

Serviceman must set it up.（Not User）

1.2 Choosing a Place for the Printer

Instructions for Placing the Printer

• keep adequate room as shown.

• Choose a level and stable location that can support the

weight of the printer (about 288 kg).

1.3 Used Tools

• Phillips screwdriver, No.2 (Long driver: more than 250mm)

• Rule Scale

• Scissors

SC-F9200 Series Rev.A

1.4 Inside of carton box

Printer

Media Feeding Unit, Auto Take-up Reel Unit

Epson Genuine Ink Supply System

SC-F9200 Series Rev.A

2. Setup Flow

Assemble according to the following flow charts.

Stand

Printer Installation

Media Feeding Unit

Auto Take-up Reel Unit

Ink Supply System

Only Frame of

Media Guide Bar

(without Guide bar)

Connecting the

Power Cable

Customer

Service

engineer

Before assembling the printer, clear the work area by putting

away the removed packing materials and bundled items.

C A U T I O N

Media Guide Bar

SC-F9200 Series Rev.A

<<Stand>>

It is recommended to assemble the stand by 3persons.

CHECK

P O I N T

Remove the tapes.

Insert the strut into the stands with supporting the stands.

Tighten 4screws.

SC-F9200 Series Rev.A

Check the markings of L & R on both stands and strut.

Tighten 4screws with supporting the stands.

Tighten 1screw.

Tighten 2screws.
