Safety Instructions

Important Safety Instructions

Read all of these instructions before using your printer. Also be

sure to follow all warnings and instructions marked on the

printer.

❏Do not block or cover the openings in the printer’s cabinet.

❏Do not insert objects through the slots. Take care not to spill

liquid on the printer.

❏Use only the type of power source indicated on the printer’s

label.

❏Connect all equipment to properly grounded power outlets.

Avoidusing outlets on the same circuit as photocopiers or air

control systems that regularly switch on and off.

❏Avoid electrical outlets controlled by wall switches or

automatic timers.

❏Keeptheentirecomputersystemawayfrompotentialsources

of electromagnetic interference, such as loudspeakers or the

base units of cordless telephones.

❏Do not use a damaged or frayed power cord.

❏If you use an extension cord with the printer, make sure the

total ampere rating of the devices plugged into the extension

cord does not exceed the cord’s ampere rating. Also, make

sure the total ampere rating of all devices plugged into the

wall outlet does not exceed the wall outlet’s ampere rating.

❏Do not attempt to service the printer yourself.

Solomon

short.bk Rev. C

A5 size KAUC.FM

10/30/98 Pass 2

LProof Sign-off:

Y.Yano _______

N.Nomoto _______

K.Norum _______

❏Unplug the printer and refer servicing to qualified service

personnel under the following conditions:

The power cord or plug is damaged; liquid has entered the

printer; the printer has been dropped or the cabinet damaged;

the printer does not operate normally or exhibits a distinct

change in performance.

❏If you plan to use the printer in Germany, observe the

following:

To provide adequate short-circuit protection and over-

current protection for this printer, the building installation

must be protected by a 16 Amp circuit breaker.

Bei Anschluß des Druckers an die Stromversorgung muß

sichergestelltwerden,daßdieGebäudeinstallationmiteinem

16 A-Überstromschalter abgesichert ist.

A Few Precautions

When using the printer

❏Do not put your hand inside the printer or touch the ink

cartridges during printing.

❏Do not move the print head by hand; otherwise you may

damage the printer.

❏Always turn the printer off using the

Ppower button. When

this button is pressed, the

Ppower light flashes briefly then

goes off. Do not unplug the printer or turn off the power to

the outlet until the

Ppower light stops flashing.

❏Before transporting the printer, make sure the print head is in

the home (far right) position and the ink cartridges are in

place.

Solomon

short.bk Rev. C

A5 size KAUC.FM

10/30/98 Pass 3

Proof Sign-off:

Y.Yano _______

N.Nomoto _______

K.Norum _______

When handling the ink cartridges

❏Keep ink cartridges out of the reach of children.

❏If ink gets on your skin, wash it off with soap and water. If it

gets in your eyes, flush them immediately with water.

❏Do not shake an ink cartridge; this can cause leakage.

❏Install the ink cartridge immediately after you remove it from

its package. Leaving the cartridge unpacked for a long time

before use may result in reduced print quality.

❏Once you install an ink cartridge, do not open the clamp or

remove the cartridge except to replace it with a new one. The

cartridge may become unusable otherwise.

❏Do not use an ink cartridge beyond the date printed on the

cartridge carton. For best results, use up the ink cartridges

within six months of installing them.

❏Do not dismantle the ink cartridges or try to refill them. This

could damage the print head.

When choosing a place for the printer

❏Place the printer on a flat, stable surface that islarger than the

printer. The printer will not operate properly if it is tilted or

at an angle.

❏Avoid places subject to rapid changes in temperature and

humidity.Alsokeepitawayfromdirectsunlight,stronglight,

or heat sources.

❏Avoid places subject to shocks and vibrations.

Solomon

short.bk Rev. C

A5 size KAUC.FM

10/30/98 Pass 2

LProof Sign-off:

Y.Yano _______

N.Nomoto _______

K.Norum _______

❏Place the printer near a wall outlet where the plug can be

easily unplugged.

Note for French-speaking users:

Placez l’imprimante prèsd’une prisede contacte où lafiche peut être

débranchée facilement.

Warnings, Cautions, and Notes

wWarnings must be followed carefully to avoid bodily injury.

cCautions must be observed to avoid damage to your equipment.

Notes contain important information and useful tips on the operation

of your printer.

Solomon

short.bk Rev. C

A5 size KAUD.FM

10/30/98 Pass 3

Proof Sign-off:

Y.Yano _______

N.Nomoto _______

K.Norum _______

Setting Up Your Printer

System Requirements

For PCs

To use your printer, you need Microsoft®Windows®3.1,

Windows®95, Windows®98, Windows®NT 4.0, or DOS; and a

shielded, twisted-pair parallel cable. If you want connect your

printer to a USB port, you need a Windows 98 pre-installed PC

equipped with a USB port; and a shielded USB cable.

Your computer should also meet the following system

requirements:

Your computer dealer can help you update your system if it does

not meet these requirements.

Minimum system Recommended system

i386/25 MHz processor for Windows 3.1

i486/25 MHz for Windows 95 and NT 4.0

i486/66 MHz for Windows 98

Pentium or higher

processor

16MB RAM 32MB RAM or more for

Windows 3.1, 95 and 98

64MB or more for

Windows NT 4.0

10MB hard disk space for Windows 95 and 98

20MB for Windows 3.1 and NT 4.0

50MB or more free disk

space for Windows 3.1,

95, and 98

100MB or more for

Windows NT 4.0

VGA monitor VGA or better monitor

Solomon

short.bk Rev. C

A5 size KAUD.FM

10/30/98 Pass 2

LProof Sign-off:

Y.Yano _______

N.Nomoto _______

K.Norum _______

For Macintosh computers

To use this printer, your Apple®Macintosh®must meet the

following system requirements. You also need a standard Apple

System Peripheral-8 cable (8-pin mini-circular connector) or

equivalent.

Applicable computer models (as of April 1, 1998)

Macintosh LC475, LC575, LC630

Macintosh Quadra Series

Macintosh Centris Series

Macintosh PowerBook™ Series (PowerBook 190, 520, 540, 550

or later)

Macintosh PowerBook Duo 280, 2300c/100

Macintosh Performa 475, 575, 588, 630, 5210 or later

Power Macintosh Series

Environment

Minimum system Recommended system

System 7.5.1 System 7.6 or later

5MB of available memory

10MB of available memory when

background printing is turned on.

12MB or more of available

memory

21MB of available memory when

background printing is turned on.

Solomon

short.bk Rev. C

A5 size KAUD.FM

10/30/98 Pass 3

Proof Sign-off:

Y.Yano _______

N.Nomoto _______

K.Norum _______

Note:

❏Theamountofavailablememoryvariesaccordingtothenumberand

kind of applications that are open. To see how much memory is

available, choose About This Macintosh

from the Apple menu and

refer to the memory size (listed in kilobytes) under “Largest Unused

Block” (1,024K=1MB).

❏The memory requirements above are for printing on Letter size

paper. These requirements may vary depending on the size of the

paper, the type of application you are using, and the complexity of

the document you want to print.

In addition to these system and memory requirements, you also

need 10MB of free harddisk space to install your printer software.

To print, you need extra hard disk space amounting to about

double the size of the file you want to print.

Solomon

short.bk Rev. C

A5 size KAUD.FM

10/30/98 Pass 2

LProof Sign-off:

Y.Yano _______

N.Nomoto _______

K.Norum _______

Printer Parts and Functions

sheet feeder

edge guides

output tray extension

output tray

printer cover

paper support

ink cartridge clamps

adjust lever

Buttons and lights

Otros manuales para 740 Series

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Impresora de Epson

Epson

Epson TM-T81 Manual de usuario

Epson

Epson Stylus 1000 Manual de usuario

Epson

Epson RP-U420 Series Manual de usuario

Epson

Epson XP-302 Manual de instrucciones

Epson

Epson Stylus Pro 7600 Manual de usuario

Epson

Epson TM950 - B/W Dot-matrix Printer Manual de usuario

Epson

Epson Stylus SX200 series Instrucciones de montaje

Epson

Epson Stylus C120 Series Manual de operación y mantenimiento

Epson

Epson SureColor T-7270 Manual de usuario

Epson

Epson LQ 590 Manual de usuario

Epson

Epson Stylus C66 Manual de usuario

Epson

Epson R320 - Stylus Photo Color Inkjet Printer Manual de usuario

Epson

Epson EPL-7000 Manual de usuario

Epson

Epson LFP C Guía del usuario

Epson

Epson RX690 Series Manual de usuario

Epson

Epson WorkForce Pro WF-6090 Series Manual de instrucciones

Epson

Epson 7800 - Stylus Pro Color Inkjet Printer Manual de usuario

Epson

Epson ET-5800 Series Manual de usuario

Epson

Epson Stylus Photo 900 Guía de configuración

Epson

Epson Stylus C84 Manual de usuario

Epson

Epson Stylus C50 Manual de usuario

Epson

Epson Expression Photo XP-750 Guía del usuario

Epson

Epson Stylus color 600 Manual de usuario

Epson

Epson WorkForce 60 Guía de referencia

Manuales populares de Impresora de otras marcas

Lexmark

Lexmark 1400 Series Manual

Canon

Canon i70 Series Manual de usuario

Evolis

Evolis Elypso Manual de usuario

Kyocera

Kyocera FS-9530DN Manual de usuario

Canon

Canon LASER SHOT LBP-1210 Manual de usuario

Samsung

Samsung BIXOLON SRP-350plusF Manual de usuario

Canon

Canon PIXMA PRO-1 Series Manual de usuario

Canon

Canon PIXMA G3560 Guía de configuración

Dell

Dell Color Laser Printer 2130cn Manual de usuario

Tektronix

Tektronix Phaser 840 Manual de usuario

Canon

Canon CLBR 460ps Manual de usuario

Eltron

Eltron P210 Guide Manual de usuario

Ricoh

Ricoh MD-P1 Manual de usuario

Canon

Canon imagePASS-A2 Manual de usuario

Canon

Canon S820D Manual de usuario

IRA3D

IRA3D POETRY4 Manual de usuario

Ricoh

Ricoh Aficio AP400 Manual de usuario

BIXOLON

BIXOLON SRP-352plusV Manual de usuario
