Epson C82324* Manual de usuario

EPSON

4001-882

EC2-00

C82324*

Ethernet Interface

Card for NetWare

User’s Guide

system, or transmitted in any form or by any means, mechanical, photocopying, recording,

or otherwise, without the prior written permission of Seiko Epson Corporation. No patent

liability is assumed with respect to the use of the information contained herein. Neither is

any liability assumed for damages resulting from the use of the information contained

herein

Neither Seiko Epson Corporation nor its affiliates shall be liable to the purchaser of this

product or third parties for damages, losses, costs, or expenses incurred by purchaser or

third parties as a result of: accident, misuse, or abuse of this product or unauthorized

modifications, repairs, or alterations to this product, or (excluding the US) failure to strictly

comply with Seiko Epson Corporation’s operating and maintenance instructions.

Seiko Epson Corporation shall not be liable against any damages or problems arising from

the use of any options or any consumable products other than those designated as

Original Epson Products or Epson Approved Products by Seiko Epson Corporation.

Epson and Epson ESC/P are registered trademarks and Epson ESC/P2 is a trademark of

Seiko Epson Corporation.

PC and PC AT are trademarks of International Business Machines Corporation.

MS-DOS is a trademark of Microsoft, Inc.

Novell and NetWare are registered trademarks of Novell, Inc.

HP, LaserJet, LaserJet Series II, LaserJet Series IID, LaserJet Series III, LaserJet Series IIID,

and PCL are trademarks of Hewlett- Packard Corporation.

PostScript is a registered trademark of Adobe Systems, Inc.

Nagano, Japan

FCC Compliance Statement

For United States Users

This equipment has been tested and found to comply with the limits for a Class A digital

device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide

reasonable protection against harmful interference when the equipment is operated in a

commercial environment. This equipment generates, uses, and can radiate radio frequency

energy and, if not installed and used in accordance with the instruction manual, may

cause harmful interference in which case the user will be required to correct the interface

at hi own expense.

This devise complies with Part 15 of the FCC Rules. Operation is subject to the following

two conditions: (1) This device may not cause harmful interference, and (2) this device

must accept any interference received, including interference that may cause undesired

operation.

For Canadian Users

This digital apparatus does not exceed the Class A limits for radio noise emissions from

digital apparatus as set out in the radio interference regulations of the Canadian

Department of Communications.

present

appareil

numerique

n’emet

pas

bruits

radioelectriques

d&passant

les

limites

applicables

aux

appareils

numeriques

Classe

prescrites

dans

reglement

sur

brouillage

radioelecfrique

edict6

par

Ministere

des

Communications

Canada.

WARNING

The connection of a non-shielded equipment interface cable to this equipment will

invalidate the FCC Certification of this device and may cause interference levels which

exceed the limits established by the FCC for this equipment. It is the responsibility of the

user to obtain and use a shielded equipment interface cable with this device. When this

equipment is attached to some printers, you should not leave cables connected to the

printers built-in connectors. See your printers user‘s manual for

details.

Changes or modifications not expressly approved by Seiko Epson Corporation, could void

the user’s authority to operate the equipment.

iii

Contents

Introduction

Ethernet Card Hardware

........................

Ethernet Card Software

.........................

Epson printers serviced by the Ethernet Card

........

About This Manual

...........................

Installation Overview

..........................

Terms and Concepts

...........................

How the Ethernet Card Works

.....................

Using the Ethernet Card as a Print Server

..........

Using the Ethernet Card as a Remote Printer

........

The Ethernet Card configuration software

..........

Chapter I

Installing the Ethernet Card

Hardware Installation

..........................

1-1

Installing the Ethernet Card in the printer

..........

1-2

Setting up the printer

......................

1-2

Connecting the network cable

.................

1-3

Using the Epson PostScript Card

...............

1-4

Ethernet Card Software Setup

.....................

1-4

Before setting up

.........................

1-5

Installing the Ethernet Card as a Print Server

........

1-5

Installing as a Remote Printer

.................

1-7

Before Running EPSETUP

Running EPSETUP

.......................

1-8

Chapter 2 Changing the Configuration

Configuration Using

EPSETUP

.....................

2-2

Change Queues Serviced by Printer

..............

2-2

Change Printer Port Configuration

..............

2-3

Change Master File Server

...................

2-4

Rename Print Server.

......................

2-5

Set Password

...........................

2-5

Set Queue Polling Time Interval

................

2-6

Reset Print Server

........................

2-6

Advanced Configuration Using EPCONFIG

.............

2-8

Using EPCONFIG

........................

2-9

Show Current Settings

.....................

2-10

Reset (Reboot) the Ethernet Card

...............

2-11

Rename Print Server

.......................

2-11

Set Password

...........................

2-12

Turn Configuration Report Off / On

..............

2-13

Set Queue Polling Interval (Print Server)

...........

2-13

Set the Ethernet Network Type

................

2-13

Restore Factory Defaults

....................

2-15

Chapter 3 Troubleshooting

Lights . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-1

Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-3

Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-3

After Installation . . . . . . . . . . . . . . . . . . . . . . . . . 3-4

Green Light On/Red On Error-Jobs Do not Print-

Cannot Print to Queue, or Incorrect Results-

Renaming Print Server

Answers to Common Questions . . . . . . . . . . . . . . . . . . . . 3-8

Avoiding Reboot with Print Server Status/Control-

Installing the Print Server on a Second File Server

Appendix

Index

Epson’s Ethernet Interface Card for NetWare®is a combination of

hardware and software that lets you connect a laser-type printer

directly to your Novell NetWare network. Just slide your Ethernet

Card into your printer’s optional interface slot (applicable models

listed on the next page), and connect it anywhere on your network.

Then use the Epson Ethernet Card software to quickly and easily

set up the interface as either a Novell print server or remote

printer.

With Epson’s Ethernet Card users can print using the same Novell

utilities they are already familiar with, including CAPTURE,

NPRINT and PCONSOLE.

In print server mode, the interface can service up to 32 print

queues on up to eight file servers.

Ethernet Card Hardware

The Ethernet Card is an interface card that plugs into an Epson

printer’s optional interface slot. It has connectors for either an

Ethernet Thin Coaxial or l0Base-T network connection.

introduction 1

The Ethernet Card software consists of two programs used to

install and configure the Ethernet Card on the network:

EPSETUP is an easy-to-use menu-driven installation and

configuration utility.

EPCONFIG is a command-line utility used to configure the

Ethernet Card’s more advanced features

Epson printers serviced by the Ethernet Card

Epson’s Ethernet Card for NetWare can be installed in the

optional interface slot in the back of the following Epson

printers:

ActionLaser II ActionLaser 1000

EPL-4000 EPL-4100

EPL-4300 EPL-5000

EPL-8000 EPL-8100

ActionLaser 1500

EPL-4200

EPL-5200

You may be able to install this interface card in other Epson printer

models. Check you printer’s user’s guide for a list of optional

interfaces that can be installed in your printer, or check with your

local Epson dealer to see if you can install the Ethernet Interface

Card for NetWare in your printer.

Caution:

You cannot use this Ethernet Interface card if the model C82605*

EPSON PostScript Card is installed in your printer.

2 Introduction

About This Manual

This manual describes how to install, configure, and use your

Ethernet Card in a Novell NetWare environment for the

following cable connections:

Ethernet Twisted-Pair (l0BASE-T)

Ethernet Thin Coaxial

Installation Overview

Installing the Ethernet Card is simple, and is described in

Chapters 1. The following steps are an overview of the installation

process.

Decide whether you want to set up the Ethernet Card as a print

server or as a remote printer. (See How the Ethernet Card

Works, later in this chapter.)

Install the Ethernet Card in your Epson printer and connect it

to the network.

If installing as a remote printer, complete preliminary

configuration using PCONSOLE.

Use EPSETUP to set up your Ethernet Card.

Introduction 3
