Epson TC-1428 Manual de usuario
14" SVGA Color
Monitor
TC-1428
Customer’s Record
The serial number of this product appears on the back of the unit.
You should note this serial number in the space provided below and retain
this manual as a permanent record of your purchase to aid in identification
in the event of theft or loss.
Model number: TC-1428
Serial number:
WARNING: To reduce the risk of fire or electric shock, do not expose this
Computer Display to rain or moisture.
CAUTION
The power cord is intended to serve as the main disconnect device. Install
the socket-outlet near the equipment and in an easily accessible place.
For 120V operation, use only with power cord plug having a parallel blade,
grounding type plug, rated 125V 10A.
For 240V operation, use only with power cord plug having a tandem blade,
grounding type plug, rated 250V 5A.
VESA DPMS Compliance Product Information
NOTE: The TC-1428 has been tested and found to comply with the
requirement of VESA DPMS standard. The power management
features are as follows:
1. The monitor will enter into the power saving state with six seconds of
time delay, in the absence of any sync. signal from PC.
-1-
2. The monitor will be automatically recovered to the on state by receiving
normal sync. signals from PC.
3. The power management states are identified below:
Power Mgmt. States H-Sync. V-Sync.
LED Color
On
ON ON
Green
Stand-By OFF ON
Light Amber
Power ON
Suspend ON
OFF Light Amber
Off OFF OFF Dark Amber
Power OFF OFF OFF Off
Table of Contents
1
Introduction..
............................................................................................
.3
2.
Precautions
.............................................................................................
.3
3.
Features
..................................................................................................
.4
4.Specifications...........................................................................................
5
5.Control
Locations
and
Adjustments
........................................................
.7
6.Connections............................................................................................
.9
7. Pin
Assignments..
...................................................................................
10
8.TimingCharts.........................................................................................
11
9.Troubleshooting.....................................................................................
.13
Note: PC and VGA are trademarks of International Business Machines
Corporation.
-2-
1. Introduction
Congratulations on your purchase of a NEW ULTRA VGA monitor. One of
the most versatile monitors available today, the TC-1428 automatically
adjusts its vertical and horizontal scanning frequencies to those of your
computer’s graphics adapter or video chip sets. The TC-1428 provides
crisp text and vivid color graphic displays when used with NEW ULTRA
VGA compatible graphics adapters (see specifications).
2. Precautions
1. To prevent electric shock, do not remove screws or cover.
There are no user-serviceable parts inside the monitor. Refer servicing
to qualified service personnel.
DO NOT REMOVE THE TILT/SWIVEL BASE!
2. The input power source:
The TC-1428 is designed to be suitable for low input voltage (100-
125V) and high input voltage (200-240V) areas.
3. The monitor is equipped with a three-pronged grounding plug which will
only fit a grounded power outlet.
This is a safety feature. If you are unable to insert the plug into the
outlet, contact an electrician.
Do not remove
-3-
4.
Do not put the monitor or other heavy objects on the power supply cord.
A damaged power cord may cause fire or electric shock.
5. Do not insert sharp objects into the monitor. They may cause fire or
failure.
6. Do not allow liquids to spill into the cabinet.
7. To reduce eye fatigue, avoid using the display in direct sunlight or under
bright lighting.
8. Do not operate the monitor beyond the specified temperature and
humidity range (see specifications on page 5).
9. For proper operation, keep the monitor adequately ventilated.
10. Keep the monitor away from strong magnetic fields produced by
transformers, motors, fans, or other devices.
11. If the monitor does not operate properly, turn the power switch off and
then unplug the monitor.
12. When irregular AC Voltages is supplied, a protective circuit will turn off
the monitor (the power indicator will also be turned off). If this happens,
turn off the power switch, and wait at least 30 seconds before turning it
on again.
3. Features
1. The TC-1428 monitor automatically adapts to the vertical and horizontal
frequencies of VGA, SVGA, 8514/A, VESA VGA, UVGA, and other
compatible graphics adapters.
2. The monitor features maximum resolutions of 1024 pixels (horizontal)
and 768 lines (vertical) in non-interlaced or interlaced modes.
3. Universal 100~240 Vac full-range power supply.
4. Power management complies with VESA DPMS standard, operating
states distinguished by the triple color power indicator.
5. Full scan capability allows the use of entire screen as display area.
6. The monitor compatible with the VESA DDC (Data Display Channel)
standard with DDC1 and DDC2b functionality (optional).
7. This monitor can be equiped with a built-in amplifier and stereo speakers
for multimedia environment applications (optional).
-4-
4. Specifications
Power Source:
Power Consumption:
Power Management:
Picture Tube:
Resolutions
l Horizontal:
* Vertical:
Input Signals
* Video:
* Separate Sync:
Synchronization
* Horizontal:
* Vertical:
Display Colors
* ANALOG Input:
Active Display Area
* Horizontal:
* Vertical:
Dimension
* (W)x(H)x(D):
VESA DDC Standard:
(Optional)
Environmental Conditions
* Operating Temperature:
* Operating Humidity:
* Storage Temperature:
* Storage Humidity:
Interfaces (Optional)
* Audio Input:
* Audio Output:
AC 90~264V, 50/60Hz
75W Maximum
VESA DPMS (<5W)
14 inches, 90° deflection, 0.28mm dot pitch
Viewable size 13.1 inches.
1024 pixels (interlaced)
768 lines (interlaced)
Analog 0.7 Vp-p / 75 ohm Positive
TTL Level
Horizontal . . . . . . . . . . . Positive/Negative
Vertical
. . . . . . . . . . . . . . . Positive/Negative
31.5KHz/35KHz/38KHz
50Hz~100Hz continuous
Infinite colors (262, 144 color range)
250mm typical (varies by signal timing)
188mm typical (varies by signal timing)
370mm(14.6”)x355mm(14”)x394mm(15.5”)
DDC1, DDC2b
0°C~+35°C
10%-80% (non-condensing)
-40°C~+65°C
5%~95%
Audio input port
Headphone jack
-5-
Low Radiation:
* X-ray radiation: < 100n Gylh
* Magnetic field:
Band I (5KHz-2KHz): < 250nT.
Band II (2KHz-400KHz): < 25nT.
Tilt and Swivel Operation:
The swivel range is normally limited to a range of 45 degrees to the right or
left of the front position (marked by a small molded pip on the top front
bottom of the base).
The tilt range is normally limited at an angle of -5 degrees forwards and +
15 degrees backwards. This allows you to set the screen angle to the
viewing position most comfortable to you.
Note: *When this display is operated with the vertical frequency under
55Hz, the image on the screen may flicker.
-6-
5. Control Locations and Adjustments
Note: The numbers indicate the control item whose description is found on
the following page.
-7-
Adjustments
1. POWER Switch Push to turn the display on, and push again
to turn off.
The power indicator will light when the
display is on.
2. BRIGHTNESS Control Adjusts the display to the desired brightness
level. (factory preset at the center detent of
the control knob)
3. CONTRAST Control Adjusts the display to the desired contrast
level.
4. H. WIDTH Control Adjusts the display to the desired horizontal
width. (factory preset at the center detent of
the control knob)
5. H. POSITION Control Adjusts the display to the desired horizontal
position.
6. V. HEIGHT Control Adjusts the display to the desired vertical
height. (factory preset at the center detent of
the control knob)
7. V. POSITION Control Adjusts the display to the desired vertical
position.
-8-
6. Connections
Your monitor has two connecting cables: a Power Supply Cord, which
connects to a wall outlet, surge protector or other power source, and a
Signal Cable, which connects to the graphics adapter of your computer. To
insure safety and correct operation, always follow these four steps when
connecting the monitor:
1. Disconnect the power supply cords from your computer and monitor.
2. Connect the signal cable from the monitor to the graphics adapter of
your computer. The connector is shaped so that it will only fit when
properly aligned.
3. Secure the connection by tightening the two screws on the connector.
4. Plug the power supply cords of the computer and monitor into an AC
outlet.
Power Supply Cord
-9-
Signal Cable
