5. Navigate to Resolution (rSoL) and press
ENTER/TARE.
Set the resolution value with the possible
values (1, 2, 5, 10, 20, 50 and 100). E.g., ‘2’.
6. Navigate to Cal. Zero (CAL-0) and press
ENTER/TARE.
Remove any load on load cell. LED displays
ADC counts corresponding to the cal. Zero
value.
Press ENTER/TARE to set Cal. Zero.
When you calibrate Cal. Zero and Cal.
Span, wait for LED to display stable
raw ADC counts.
7.
Navigate to Cal. Span (LoAd) and press
ENTER/TARE.
AUTO
Place a reference weight on the load cell, the LED
displays ADC count corresponding to the weight.
E.g., ‘6081’.
MANUAL:
User need to enter Known weight count
(without zero count) as span count.
Press ENTER/TARE to set Cal. Span.
Cal. Span counts should be greater than
Cal. Zero + 50.
8. Navigate to load Capacity (L-CAP) and press
ENTER/TARE.
Enter the reference weight that is used while
calibrating Cal Span using up and left key. The
range should be (0.01 to Max Capacity). E.g.,
‘001.00’
System asks to take calibration backup
(ConF?). If you want take backup then press
ENTER/TARE otherwise press MENU/ESC
thencome out from menu.
