DS-K1100 Series Card Reader
User Manual
DS-K1100 Series Card Reader
iii
Regulatory Information
Please take attention that changes or modification not expressly approved
by the party responsible for compliance could void the user’s authority to
operate the equipment.
FCC compliance: This equipment has been tested and found to comply with
the limits for a Class A digital device, pursuant to part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against harmful
interference when the equipment is operated in a commercial environment.
This equipment generates, uses, and can radiate radio frequency energy and,
if not installed and used in accordance with the instruction manual, may
cause harmful interference to radio communications. Operation of this
equipment in a residential area is likely to cause harmful interference in
which case the user will be required to correct the interference at his own
expense.
FCC Conditions
This device complies with part 15 of the FCC Rules. Operation is subject to
the following two conditions:
1. This device may not cause harmful interference.
2. This device must accept any interference received, including interference
that may cause undesired operation.
EU Conformity Statement
This product and - if applicable - the supplied
accessories too are marked with "CE" and
comply therefore with the applicable
harmonized European standards listed under
the RE Directive 2014/53/EU, the EMC Directive
2014/30/EU, the LVD Directive 2014/35/EU, the RoHS
Directive 2011/65/EU.
DS-K1100 Series Card Reader
iv
2012/19/EU (WEEE directive): Products marked
with this symbol cannot be disposed of as
unsorted municipal waste in the European Union.
For proper recycling, return this product to your
local supplier upon the purchase of equivalent
new equipment, or dispose of it at designated
collection points. For more information see:
www.recyclethis.info.
2006/66/EC (battery directive): This product
contains a battery that cannot be disposed of as
unsorted municipal waste in the European Union.
See the product documentation for specific
battery information. The battery is marked with
this symbol, which may include lettering to
indicate cadmium (Cd), lead (Pb), or mercury (Hg).
For proper recycling, return the battery to your supplier or to a designated
collection point. For more information see: www.recyclethis.info.
Industry Canada ICES-003 Compliance
This device meets the CAN ICES-3 (A)/NMB-3(A) standards requirements.
Use only power supplies listed in the user instructions:
Model
Manufacturer
Standard
TS-A018-120015Ec
Shenzhen Transin
Technologies Co., Ltd
CEE
Safety Instruction
These instructions are intended to ensure that user can use the product
correctly to avoid danger or property loss.
The precaution measure is divided into Warnings and Cautions:
DS-K1100 Series Card Reader
v
Warnings: Neglecting any of the warnings may cause serious injury or
death.
Cautions: Neglecting any of the cautions may cause injury or equipment
damage.
Warnings
All the electronic operation should be strictly compliance with the
electrical safety regulations, fire prevention regulations and other related
regulations in your local region.
Please use the power adapter, which is provided by normal company. The
power consumption cannot be less than the required value.
Do not connect several devices to one power adapter as adapter overload
may cause over-heat or fire hazard.
Please make sure that the power has been disconnected before you wire,
install or dismantle the device.
When the product is installed on wall or ceiling, the device shall be firmly
fixed.
If smoke, odors or noise rise from the device, turn off the power at once
and unplug the power cable, and then please contact the service center.
If the product does not work properly, please contact your dealer or the
nearest service center. Never attempt to disassemble the device yourself.
(We shall not assume any responsibility for problems caused by
unauthorized repair or maintenance.)
Cautions
Do not drop the device or subject it to physical shock, and do not expose
it to high electromagnetism radiation. Avoid the equipment installation on
Warnings Follow these
safeguards to prevent
serious injury or death.
Cautions Follow these precautions to
prevent potential injury or material
damage.
DS-K1100 Series Card Reader
vi
vibrations surface or places subject to shock (ignorance can cause
equipment damage).
Do not place the device in extremely hot (refer to the specification of the
device for the detailed operating temperature), cold, dusty or damp
locations, and do not expose it to high electromagnetic radiation. The
appropriate temperature is -20Ԩto 65Ԩ.
The device cover for indoor use shall be kept from rain and moisture.
Exposing the equipment to direct sun light, low ventilation or heat source
such as heater or radiator is forbidden (ignorance can cause fire danger).
Do not aim the device at the sun or extra bright places. A blooming or
smear may occur otherwise (which is not a malfunction however), and
affecting the endurance of sensor at the same time.
Please use the provided glove when open up the device cover, avoid direct
contact with the device cover, because the acidic sweat of the fingers may
erode the surface coating of the device cover.
Please use a soft and dry cloth when clean inside and outside surfaces of
the device cover, do not use alkaline detergents.
Please keep all wrappers after unpack them for future use. In case of any
failure occurred, you need to return the device to the factory with the
original wrapper. Transportation without the original wrapper may result
in damage on the device and lead to additional costs.
Improper use or replacement of the battery may result in hazard of
explosion. Replace with the same or equivalent type only. Dispose of used
batteries according to the instructions provided by the battery
manufacturer.
Preventive and Cautionary Tips
To guarantee the card reader works properly, please read and obey the
notes below.
If the card reader is powered by the controller, the power supply
distance is recommended to be no longer than 100m. If the distance is
longer than 100m, you are advised to power the card reader by
external 12V (range: -%10 ~ +%10) DC power supply, which is
nonswitched and linear.
To guarantee the communication between the controller and the card
DS-K1100 Series Card Reader
vii
reader, you must use RVVP cable above 0.5 to connect them.
If the card reader is installed outside or in environment easy to
permeable, it is advisable to install a waterproof shield.
If you need to install several card readers, the distance among them
must over 30cm.
To reduce the noise in long distance transmission, the shield of cable
should connect to the GND of both controller and card reader
terminal.
DS-K1100 Series Card Reader
viii
Content
Chapter 1 Introduction........................................................ 1
1.1 Front View.....................................................................1
1.2 Rear V iew ......................................................................3
1.3 Slide View......................................................................5
Chapter 2 Installation.......................................................... 7
2.1 Installing PSAM Card .....................................................7
2.2 Introduction for DIP Switch ...........................................7
2.3 Definition of Cable.........................................................8
2.4 Wiring Cables ................................................................9
2.5 Installing Card Reader..................................................11
Chapter 3 Sound Prompt and Indicator.............................. 13
DS-K1100 Series Card Reader
1
Chapter 1 Introduction
DS-K1100 series card reader is a kind of high-performance
product, with a 32 bit high-speed processor. It communicates with
access controller via either RS-485 protocol or Wiegand protocol.
And a build-in tamper-proof module helps to protect card reader
from malicious damage. As to the physical appearance, the
PC+ABS material makes water proof and dust proof possible in
poor environment.
1.1 Front View
The front view of DS-K1101 series card reader is shown below:
Figure 1-1 DS-K1101MK/DS-K1101CK
Figure 1-2 DS-K1101M/DS-K1101C
DS-K1100 Series Card Reader
2
The front view of DS-K1102 series card reader is shown below:
Figure 1-3 DS-K1102MK/DS-K1102CK
Figure 1-4 DS-K1102M/DS-K1102C
The front view of DS-K1103 series card reader is shown below:
Figure 1-5 DS-K1103MK/DS-K1103CK
Figure 1-6 DS-K1103M/DS-K1103C
DS-K1100 Series Card Reader
3
The front view of DS-K1104 series card reader is shown below:
Figure 1-7 DS-K1104MK/DS-K1104CK
Figure 1-8 DS-K1104M/DS-K1104C
1.2 Rear View
The rear view of card reader is shown below:
1
2
3
4
5
Figure 1-9 Rear View of DS-K1101 Series
