EnGenius ETR9350 Especificaciones técnicas
ETR9350
802.11b/g/n SOHO Router
2.4 GHz 300Mbps 11N Pocket size AP/Router
* Theoretical wireless signal rate based on IEEE standard of 802.11a, b, g, n chipset used. Actual throughput may vary. Network conditions and environmental factors lower actual
throughput rate.
** All specifications are subject to change without notice.
11/9/2009
PRODUCT DESCRIPTION
ETR9350 is a 2T2R Wireless Single chip 11N Travel AP/Router that delivers
up to 6x faster speeds than 802.11g devices. ETR9350 drives superior
performance and unparalleled wireless range. With easy to use on the WPS
function, it helps users to connect to wireless device with just one push button.
Just leave power adapter behind and enjoy the convenience that embedded
power brings. Device can be slipped into your pocket easily and build Wireless
Networks somewhere you want. With Clear LED indicator user can identify
running operation mode painless
PACKAGE CONTENT
1*802.11n Pocket AP (ETR9350)
1*QIG
1*CD (User’s Manual)
1*AC cord
TECHNICAL SPECIFICATION
> HARDWARE SPECIFICATION
WAN/LAN: One 10/100 Fast Ethernet RJ-45
Power Jack
WPS (WiFi Protected Setup)
Physical Interface
USB port for 3G
Operation Mode
Power Status
WAN (Internet connection)
WLAN(Wireless connection)
WPS
LEDs Status
USB port
Power Requirements Power Board embedded
ETR9350
802.11b/g/n SOHO Router
2.4 GHz 300Mbps 11N Pocket size AP/Router
* Theoretical wireless signal rate based on IEEE standard of 802.11a, b, g, n chipset used. Actual throughput may vary. Network conditions and environmental factors lower actual
throughput rate.
** All specifications are subject to change without notice.
11/9/2009
> TOP PANEL LED
Operation Mode 1 (AP/Router/CB variant mode will display variant color)
Power 1 ( Link-> blue static on)
WAN 1 ( Link-> blue static on, traffic->blink)
WLAN 1 ( Link-> blue on, traffic->blink)
WPS 1 (Link-> Associate Done, Processing->blink)
USB 1 (Link blue static on)
> RF SPECIFICATION
Frequency Band 2.400～2.484 GHz
Modulation Technology OFDM BPSK, QPSK, 16-QAM, 64-QAM
DBPSK, DQPSK, CCK
Operating Channels 11 for North America, 14 for Japan, 13 for Europe
Wireless Setting Wireless Mode – 11b/ 11g /11n
Channel Selection (Setting varies by Country)
Channel Bandwidth (Auto, 20Mhz, 40Mhz)
Transmission Rate
-11g: Best. 54, 48, 36, 24, 18, 12, 11, 9, 6, 5.5, 2, 1 in Mbps
Guard Interval 800ns Guard Interval 400ns
MCS
Index 20MHz 40MHz 20MHz 40MHz
06.5 13.5 7.2 15
113 27 14.4 30
219.5 40.5 21.7 45
326 54 28.9 60
439 81 43.3 90
552 108 57.8 120
658.5 121.5 65 135
765 135 72.2 157.5
813 27 14.4 30
926 54 28.9 60
10 39 81 43.3 90
11 52 108 57.8 120
12 78 162 86.7 180
13 104 216 115.6 240
14 117 243 130 270
15 130 270 144.4 300
ETR9350
802.11b/g/n SOHO Router
2.4 GHz 300Mbps 11N Pocket size AP/Router
* Theoretical wireless signal rate based on IEEE standard of 802.11a, b, g, n chipset used. Actual throughput may vary. Network conditions and environmental factors lower actual
throughput rate.
** All specifications are subject to change without notice.
11/9/2009
Receive Sensitivity (Typical)
IEEE802.11n
MCS0@ -79dBm
MCS7@ -61dBm
IEEE802.11g
6Mbps@ -90dBm
54Mbps@ -70dBm
IEEE802.11b
1Mbps@ -90dBm
Mbps@ -87dBm
Available transmit power
IEEE802.11N
MCS7@ 14dBm
IEEE802.11g
6~54 Mbps@ 14dBm
IEEE802.11b
1~11Mbps@ 17.5dBm
Antenna *2 Peak Gain = 2 dBi embedded ANT
> SOFTWARE FEATURES
Router and Gateway
Topology Infrastructure
Operation Mode AP/Router/CB
LAN
DHCP Server
Static Routing Table
UPNP
WAN PPTP
PPPoE
Static IP
Router NAT/ NAPT
Static Routing
Dynamic Route
ETR9350
802.11b/g/n SOHO Router
2.4 GHz 300Mbps 11N Pocket size AP/Router
* Theoretical wireless signal rate based on IEEE standard of 802.11a, b, g, n chipset used. Actual throughput may vary. Network conditions and environmental factors lower actual
throughput rate.
** All specifications are subject to change without notice.
11/9/2009
Firewall Blocking Ping
DoS(Blocking Ping, Port scan, Sync Flood)
MAC / IP Filtering
ICMP Blocking
SPI (Stateful Packet Inspection)
DMZ (Demilitarized Zone) Host
Policy Based Parental Controls
- Port Range / Service Filtering
- Internet Domain Restriction
- Dynamic URL Filtering (OEM subscription service)
VPN VPN pass-through (PPTP, L2TP, IPSEC)
Wireless Power saving(Green technology)
64/128 bit WEP Encryption
WPA Personal (WPA-PSK using TKIP or AES)
WPA Enterprise (WPA-EAP using TKIP)
802.1x Authenticator
Hide SSID in beacons
Wi-Fi Protection Setup (WPS)
ACL control
Best channel selection
Speed/Bandwidth monitor
QoS WMM
Application base
- Priority Queue
- Bandwidth Allocation
Management
Configuration Web-based configuration (HTTP)
Firmware Upgrade Via webpage upgrade
Auto recovery once firmware upgrade fail
Administrator Setting Administrator password change
Idle time out
ETR9350
802.11b/g/n SOHO Router
2.4 GHz 300Mbps 11N Pocket size AP/Router
* Theoretical wireless signal rate based on IEEE standard of 802.11a, b, g, n chipset used. Actual throughput may vary. Network conditions and environmental factors lower actual
throughput rate.
** All specifications are subject to change without notice.
11/9/2009
Reset Setting (WPS button) 5sec Reset
10sec Reset to Default
System monitoring Speed and Bandwidth monitoring
Scheduling Enable power saving
Easy access User can type model name and access the main page.
Install wizard Guide user to set-up Router smoothly
ENVIRONMENT & PHYSICAL
Temperature Range 0 to 40° C - Operating, -10 to 70 ° C - Storage
Humidity (non-condensing) 15%～95% typical
Dimensions 90mm (L) x 63mm (W) x 31mm (H)
