www.ener-j.co.uk
• Before Installation make sure that the mains power supply
is disconnected in order to avoid accidental power surge or
shocks.
• Make sure that the electrical circuit that powers this Wi-Fi
CCT LED Ceiling Panel Light is equipped with adequate
protection (fuse).
• Never attempt to install a damaged product. If there is any
physical damaged, please return the unit back to the point
of purchase.
• Connect with mains cable (Live, Neutral and Earthing) in
the terminal cord as per the markings (See Pic below). Blue
Cable: Neutral, Brown Cable: Live and Grounding Cable:
Green or yellow.
• Close the Back cover. There is space for the cables in the
cover so it can be closed easily when the connection is
done.
• Place the Wi-Fi CCT LED Ceiling Panel Light in desired
ceiling hole and keep the springs of the Wi-Fi CCT LED
Ceiling Panel Light inside the ceiling and Ring part outside
the ceiling. Please adjust till it gets fitted properly.
Instructions for Installation
1. DOWNLOAD AND INSTALL OUR APP
Install “ENERJSMART” in your Smartphone or Tablet
devices through Google Play or iOS Play Store. Alternatively,
please scan below QR code’s.
REGISTER OR SIGN IN APP
• Select Location.
• Enter Email Address or Mobile Number.
• Verify Mobile Number or Email Address through Text
Message or our Email.
• Follow the screen instructions to login in APP.
ADD DEVICE
Before Adding Device, please Switch on/ Switch off the
light 3 times (time interval should not exceed 5 seconds).
Once you have lights blinking rapidly it means the device
is in Pairing Mode.Also make sure that your Wi-Fi router is
switched on and working ne. Need 2.4GHz Wi-Fi access to
pair this device. 5G is not supported. If you have a Wi-Fi Hub
please go in settings of your providers Hub APP and grant
2.4GHz Access
• Tap “+” located on Top Right corner.
• Select ‘Lighting Device’ from the devices in the list.
• Conrm light blinks rapidly.
• Select your Wi-Fi and put your Wi-Fi password.
• Conrm.
• Wi-Fi LED Panel Light will be added under your Devices.
2. CONTROL DEVICE
A: You can have a quick control of our ENERJSMART
LED Panel Light from the Device screen where you could
Switch on/off, Adjust the Brightness and Change the
Colour temperature from White to Warm White.
B: If you select ENERJSMART LED Panel Light then you can
access full Control Panel where there are more functions.
White Mode: Touch and get to your desired Colour you
want of your LED Panel Light. There is Brightness levels from
1% to 100%.
Left Time: This acts like a countdown. If your LED Panel
Light is switched on and you want it to get switched off
after particular time then this option is perfect.
Schedule: You can add multiple schedules in APP for
How to Pair the product to the APP
the LED Panel Light to get switched on or Switched off a
particular time of that day or every day.
C: Scene Mode: You can select Pre-Saved Scenes or Create
new.
Please click on top right corner (Pen sign) to check more
functions listed in the app.
D: Create Group: If you have 2 or more such devices (Same
model) then select this option to synchronize and
control all devices together. The Group will be created in
your Home Screen to control all devices together.
E: Share Device: You can share the device with your
friends and family. Simply click on Add and enter their
ENERJSMART APP login mobile number or email address.
They will get notication and the device will be shared
with them once they conrm it from their ENERJSMART
Account.
3. Note
1. Only Supports WLAN in 2.4 GHz, Android 4.1 and above,
iOS 8.0 and above. 5GHz Wi-Fi not supported.
2. When you connect multiple Wi-Fi Lamps, please try
and keep enough space (Advisable 15 cms) in between
the lamps as it may cause signal interference.
3. If Wi-Fi signal is weak then Wi-Fi Extender or Repeaters
will be required.
