Brief Operating Instructions

iTEMP TMT86

Dual-input temperature transmitter

PROFINET® protocol

These Instructions are Brief Operating Instructions; they are

not a substitute for the Operating Instructions pertaining to

the device.

For detailed information, refer to the Operating Instructions

and other documentation.

Available for all device versions via:

• Internet: www.endress.com/deviceviewer

• Smart phone/Tablet: Endress+Hauser Operations App

KA01529T/09/EN/01.21-00

71562442

2021-11-30

iTEMP TMT86

2 Endress+Hauser

Order code:

Ext. ord. cd.:

Ser. no.:

www.endress.com/deviceviewer Endress+Hauser

Operations App

XXXXXXXXXXXX

XXXXX-XXXXXX

XXX.XXXX.XX

Serial number

A0023555

iTEMP TMT86 Table of contents

Endress+Hauser 3

Table of contents

1 About this document .............................................................. 3

1.1 Symbols used ......................................................................... 3

1.2 Tool symbols ..........................................................................4

1.3 Registered trademarks .................................................................. 4

2 Safety instructions ................................................................ 4

2.1 Requirements for personnel .............................................................. 4

2.2 Intended use .......................................................................... 5

2.3 Workplace safety ...................................................................... 5

2.4 Operational safety ......................................................................5

2.5 Product safety ......................................................................... 5

2.6 IT security ............................................................................ 5

3 Incoming acceptance and product identification ................................... 6

3.1 Incoming acceptance .................................................................... 6

3.2 Product identification ................................................................... 6

3.3 Certificates and approvals ................................................................ 7

3.4 Storage and transport ................................................................... 7

4 Installation ....................................................................... 7

4.1 Mounting requirements ................................................................. 7

4.2 Mounting the measuring device ............................................................8

4.3 Post-mounting check ................................................................... 9

5 Electrical connection .............................................................. 9

5.1 Connection requirements ................................................................ 9

5.2 Connecting the measuring device ......................................................... 10

5.3 Connecting the sensor cables ............................................................. 12

5.4 Ensuring the degree of protection ......................................................... 14

5.5 Post-connection check ..................................................................15

6 Operation options ............................................................... 16

6.1 Overview of operation options ............................................................ 16

6.2 Access to operating menu via web browser .................................................. 18

6.3 Access to the operating menu via operating tools .............................................. 18

7 Commissioning .................................................................. 18

7.1 Post-installation check ................................................................. 18

7.2 Switching on the device ................................................................. 18

7.3 Configuring the device ................................................................. 18

8 Maintenance .................................................................... 19

1 About this document

1.1 Symbols used

1.1.1 Safety symbols

DANGER

This symbol alerts you to a dangerous situation. Failure to avoid this situation will result in

serious or fatal injury.

Safety instructions iTEMP TMT86

4 Endress+Hauser

WARNING

This symbol alerts you to a dangerous situation. Failure to avoid this situation can result in

serious or fatal injury.

CAUTION

This symbol alerts you to a dangerous situation. Failure to avoid this situation can result in

minor or medium injury.

NOTICE

This symbol contains information on procedures and other facts which do not result in

personal injury.

1.2 Tool symbols

Symbol Meaning

A0011219

Phillips head screwdriver

1.3 Registered trademarks

PROFINET®

Registered trademark of the PROFIBUS User Organization, Karlsruhe, Germany

2 Safety instructions

2.1 Requirements for personnel

The personnel for installation, commissioning, diagnostics and maintenance must fulfill the

following requirements:

‣Trained, qualified specialists must have a relevant qualification for this specific function

and task.

‣Personnel must be authorized by the plant owner/operator.

‣Be familiar with federal/national regulations.

‣Before starting work: personnel must read and understand the instructions in the manual

and supplementary documentation as well as the certificates (depending on the

application).

‣Personnel must follow instructions and comply with general policies.

The operating personnel must fulfill the following requirements:

‣Personnel are instructed and authorized according to the requirements of the task by the

facility's owner-operator.

‣Personnel follow the instructions in this manual.

iTEMP TMT86 Safety instructions

Endress+Hauser 5

2.2 Intended use

The device is a universal and user-configurable temperature transmitter with either one or

two sensor inputs for a resistance thermometer (RTD), thermocouples (TC), resistance and

voltage transmitters. The head transmitter version of the device is intended for mounting in a

terminal head (flat face) as per DIN EN 50446. The device is also optionally available in a

version that is integrated into a field housing. It is also possible to mount the device on a DIN

rail using the optional DIN rail clip.

If the device is used in a manner not specified by the manufacturer, the protection provided by

the device may be impaired.

The manufacturer is not liable for damage caused by using the device incorrectly or for

purposes for which it was not intended.

2.3 Workplace safety

When working on and with the device:

‣Wear the required personal protective equipment as per national regulations.

2.4 Operational safety

‣Operate the device only if it is in proper technical condition, free from errors and faults.

‣The operator is responsible for ensuring trouble-free operation of the device.

Hazardous area

To eliminate a danger for persons or for the facility when the device is used in the hazardous

area (e.g. explosion protection or safety equipment):

‣Based on the technical data on the nameplate, check whether the ordered device is

permitted for the intended use in the hazardous area. The nameplate can be found on the

side of the transmitter housing.

‣Observe the specifications in the separate supplementary documentation that is an integral

part of these instructions.

Electromagnetic compatibility

The measuring system complies with the general safety requirements and EMC requirements

of the IEC/EN 61326 series and the APL EMC Test Specification.

2.5 Product safety

This product is designed in accordance with good engineering practice to meet state-of-the-

art safety requirements and has been tested and left the factory in a condition in which it is

safe to operate.

2.6 IT security

Our warranty is valid only if the device is installed and used as described in the Operating

Instructions. The device is equipped with security mechanisms to protect it against any

inadvertent changes to the settings.

Incoming acceptance and product identification iTEMP TMT86

6 Endress+Hauser

IT security measures, which provide additional protection for the device and associated data

transfer, must be implemented by the operators themselves in line with their security

standards.

3 Incoming acceptance and product identification

3.1 Incoming acceptance

1. Unpack the temperature transmitter carefully. Are the contents or packaging

undamaged?

 Do not install damaged components, as otherwise the manufacturer cannot

guarantee the material resistance or ensure compliance with the original safety

requirements, and therefore cannot be held responsible for any resulting damage.

2. Is the delivery complete or is anything missing? Check the scope of delivery against your

order.

3. Does the nameplate match the order information on the delivery note?

4. Are the technical documentation and all other necessary documents provided? If

applicable: are the Safety Instructions (e.g. XA) for hazardous areas provided?

If one of these conditions is not met, please contact the manufacturer's sales office.

3.2 Product identification

The following options are available for identification of the device:

• Nameplate specifications

• Extended order code with breakdown of the device features on the delivery note

• Enter the serial number from the nameplate in the W@M Device Viewer

(www.endress.com/deviceviewer): all data relating to the device and an overview of the

Technical Documentation supplied with the device are displayed.

• Enter the serial number on the nameplate into the Endress+Hauser Operations App or scan

the 2-D matrix code (QR code) on the nameplate with the Endress+Hauser Operations App:

all the information about the device and the technical documentation pertaining to the

device is displayed.

Approval in hazardous areas: Ensure that the information on the nameplate matches the

enclosed Ex documentation (XA...).

3.2.1 Name and address of manufacturer

Name of manufacturer: Endress+Hauser Wetzer GmbH + Co. KG

Model/type reference: TMT86

Address of manufacturer: Obere Wank 1, D-87484 Nesselwang or www.endress.com

iTEMP TMT86 Installation

Endress+Hauser 7

3.3 Certificates and approvals

For certificates and approvals valid for the device: see the data on the nameplate

Approval-related data and documents: www.endress.com/deviceviewer → (enter the

serial number)

3.4 Storage and transport

Storage temperature: –52 to +100 °C (–61.6 to +212 °F)

Humidity

• Condensation permitted with head transmitter

• Max. rel. humidity: 95 % as per IEC 60068-2-30

Pack the device for storage and transportation in such a way that it is reliably protected

against impact and external influences. The original packaging provides optimum

protection.

Avoid the following environmental influences during storage and transport:

• Direct sunlight

• Vibration

• Aggressive media

4 Installation

4.1 Mounting requirements

4.1.1 Mounting location

Head transmitter:

• in the terminal head, flat face, as per DIN EN 50446, direct mounting on insert with cable

entry (middle hole 7 mm)

• in the field housing, separated from the process

• with DIN rail clip on DIN rail as per IEC 60715, TH35

For use in hazardous areas, the limit values specified on the certificates and approvals must be

observed (see Ex Safety Instructions).

4.1.2 Important ambient conditions

• Operating height: up to 4000 m (4374.5 yards) above mean sea level

• Overvoltage category: overvoltage category II

• Pollution degree: 2

• Insulation class: class III

• Ambient temperature: –40 to +85 °C (–40 to 185 °F);

Optional –50 to +85 °C (–58 to 185 °F), –52 to +85 °C (–61.6 to 185 °F)

• Head transmitter climate class: C1 (–5 to +45 °C (23 to 113 °F), 5 to 95 % r.h.) as per IEC

60654-1

Installation iTEMP TMT86

8 Endress+Hauser

• Condensation permitted with head transmitter

• Max. rel. humidity: 95 % as per IEC 60068-2-30

• Degree of protection:

• Head transmitter with screw terminals: IP00, with push-in terminals: IP30. When

installed, the degree of protection depends on the terminal head or field housing used.

• When installing in field housing TA30x: IP IP66/68 (NEMA Type 4x encl.)

4.2 Mounting the measuring device

A Phillips head screwdriver is required to mount the device:

• Maximum torque for securing screws = 1 Nm (¾ foot-pound), screwdriver: Pozidriv Z2

• Maximum torque for screw terminals = 0.35 Nm (¼ foot-pound), screwdriver: Pozidriv Z1

4.2.1 Head transmitter mounting

1 2 3 4 5 1234

120 mm

(4.72 in)

120 mm

(4.72 in)

Item A Item B

Item C

A0048481

 1 Head transmitter mounting (three versions)

iTEMP TMT86 Electrical connection

Endress+Hauser 9

Mounting typical of North America

12 3 456

A0008520

 2 Head transmitter mounting

NOTICE

The terminal head cover must be secured properly to meet the requirements for

explosion protection.

‣After wiring, securely screw the terminal head cover back on.

4.3 Post-mounting check

After installing the device, run the following final checks:

Device health and specifications Notes

Is the device undamaged (visual inspection)? -

Do the ambient conditions match the device specification (e.g. ambient temperature,

measuring range, etc.)?

→  7

5 Electrical connection

5.1 Connection requirements

A Phillips head screwdriver is required to wire the head transmitter with screw terminals. No

tools are required for the version with push-in terminals.

Electrical connection iTEMP TMT86

10 Endress+Hauser

LCAUTION

‣Switch off the power supply before installing or connecting the device. Non-compliance

may result in the destruction of parts of the electronics.

‣When connecting Ex-certified devices, please take special note of the instructions and

connection schematics in the Ex-specific supplement to these Operating Instructions.

‣Do not occupy the display connection. An incorrect connection can destroy the electronics.

‣Before connecting the power supply, connect the potential equalization line to the external

ground terminal.

‣The device may only be powered by a power unit with an energy-limited circuit in

accordance with UL/EN/IEC 61010-1, Section 9.4 and the requirements of Table 18.

5.2 Connecting the measuring device

Head transmitter:

RD (BK)

WH (YE)

A0046019

 3 Assignment of terminal connections for head transmitter

A Sensor input 1, RTD and Ω, 4-, 3- and 2-wire

B Sensor input 1, TC and mV

C Sensor input 2, RTD and Ω, 3- and 2-wire

D Sensor input 2, TC and mV

E Display connection, service interface

F Bus terminator and power supply

NOTICE

‣ ESD - Electrostatic discharge. Protect the terminals from electrostatic discharge. Non-

compliance may result in the destruction or malfunction of parts of the electronics.

5.2.1 Fieldbus connection

Devices can be connected to the fieldbus in two ways:

Otros manuales para iTEMP TMT86

Tabla de contenidos

Otros manuales de Transmisor de Endress+Hauser

Endress+Hauser

Endress+Hauser tmt142 Instrucciones de instalación

Endress+Hauser

Endress+Hauser CM14 Manual de usuario

Endress+Hauser

Endress+Hauser Liquisys M CLM223 Manual de usuario

Endress+Hauser

Endress+Hauser iTEMP TMT162 Manual de usuario

Endress+Hauser

Endress+Hauser iTEMP TMT85 Manual de usuario

Endress+Hauser

Endress+Hauser Prosonic S FMU95 Instrucciones de funcionamiento e instalación

Endress+Hauser

Endress+Hauser Liquisys M CPM253 Manual de usuario

Endress+Hauser

Endress+Hauser Liquisys M CXM 223 Manual de usuario

Endress+Hauser

Endress+Hauser RMA42 Especificaciones técnicas

Endress+Hauser

Endress+Hauser deltabar S PMD 25 K Manual de usuario

Endress+Hauser

Endress+Hauser CM14-AAK Manual de usuario

Endress+Hauser

Endress+Hauser Liquisys M CPM223 Manual de usuario

Endress+Hauser

Endress+Hauser iTEMP TMT162 Manual de usuario

Endress+Hauser

Endress+Hauser Proline 300 Especificaciones técnicas

Endress+Hauser

Endress+Hauser Mycom S CLM 153 Manual de usuario

Endress+Hauser

Endress+Hauser mycom COM 121 Manual de usuario

Endress+Hauser

Endress+Hauser Liquisys M CPM 223 Manual de usuario

Endress+Hauser

Endress+Hauser Cerabar S PMC71 Manual de usuario

Endress+Hauser

Endress+Hauser iTEMP Instrucciones de instalación

Endress+Hauser

Endress+Hauser RMA42 Especificaciones técnicas

Endress+Hauser

Endress+Hauser Memograph CVM40 Especificaciones técnicas

Endress+Hauser

Endress+Hauser Liquisys M CCM223 Manual de usuario

Endress+Hauser

Endress+Hauser FHX50 Manual de usuario

Endress+Hauser

Endress+Hauser Deltabar S FMD76 Manual de usuario

Manuales populares de Transmisor de otras marcas

NIVELCO

NIVELCO EasyTREK SCA-300 Series Manual del propietario

Honeywell

Honeywell 5816WMBR Manual de usuario

Kamstrup

Kamstrup READy MTU Instrucciones de funcionamiento

Omega

Omega ZW Series Manual de usuario

ABB

ABB Field 264H Guía

Alinco

Alinco DJ-V17T Manual de usuario

Dejero

Dejero EnGo 3x Manual de usuario

Rosemount

Rosemount 4600 Manual de usuario

Speaka Professional

Speaka Professional 2342740 Manual de usuario

trubomat

trubomat GAB 1000 Manual de usuario

Teledyne Analytical Instruments

Teledyne Analytical Instruments LXT-380 Manual de usuario

Rondish

Rondish UT-11 Manual de usuario

MG 10JRE Manual de usuario

Burkert

Burkert 8177 Manual de usuario

Firetide

Firetide HotPort 3203 Manual

Tele Radio

Tele Radio T9-02 Manual de usuario

Rotronic

Rotronic HygroFlex HF3 Series Manual de usuario

Jamara

Jamara FCX6 Pro Tel Manual de usuario

Endress+Hauser iTEMP TMT86 Especificaciones técnicas

Manuales populares de Transmisor de otras marcas
