Introduction
Modulation effects are sort of like spices, used tastefully they can
elevate a dish into flavour country. With the Nebulus you get it all,
9 different spices that will cater to just about any modulation meal
you're after.
Along with the sonic versatility, we've included 8 presets for the
most demanding live sets. A hybrid of analog and digital, the
Nebulus harnesses the best of both domains. The Advanced
Configuration mode lets you tailor the functionality to meet your
needs in any situation.
It's musical, it's lush, it's Nebulus!
- Jason Fee
Quick Start
Basic chorus: a smooth swirling chorus
Tremolo chorus: chorus and tremolo, together at last...
Quick Start ...continued
Vibe: the classic vibe sound
Rotary: offers up the delicious warble of a rotary speaker
60s Flanger: a big sweeping flanger
Thru zero flanger : often misunderstood, but oh so musical!
The Modes
Chorus A - Basic Chorus Mode: By basic we mean that this chorus is
basically perfect sounding: lush, beautiful, deep, you get the idea.
The special switch allows you to get rid of some of the low
frequency throb that is often associated with chorus effects.
Chorus B - Multi Chorus Mode: This mode offers a rich and thick
multi-tap chorus sound. Again, the special switch allows you to roll
out some of that low frequency throb.
Chorus C - Tremolo Chorus: A blend of chorus & tremolo together.
It's a unique effect that has a great feel. The depth knob controls
the tremolo depth and the special switch controls the chorus.
Vibe A - Single Vibe: This is reminiscent of some of those classic
vibe sounds with some added versatility. In this mode the special
switch controls the resonance intensity.
Vibe B - Classic Vibrato: This is a full featured vibrato that will give
you more warble than you'll ever need. The special switch adds
compression to the vibrato sound which is a match made in heaven.
Hint, if you just want to use the compressor, turn the width to 0.
Now you've got a 10th mode....but who's counting.
Vibe C - Rotary:This mode gives you the Doppler spin and
amplitude modulation of a rotating speaker cab. The special switch
pumps up the horn volume to give you a bit more of that driving
whirl.
Flanger A - 60's Tape Flange: Smooth, wide, and deep. Try it with
the warm tone, and with your favourite overdrive in front of it. The
special switch brings up the regeneration.
Flanger B - 70's Flanger: It inverts the phase of the feedback for a
more aggressive sound. Again, the special switch brings up the
regeneration.
Flanger C - Thru-Zero Flanger: The delayed signal actually passes
right through the dry signal and goes back in time, defying the laws
of physics, and giving you a really cool flange sound. Again, the
special switch brings up the regeneration.
Controls at a Glance
Power: 9V - 12V DC negative
tip 2.1mm jack. 280mA or greater
-
+
Submode: Select the type of eect from the chart below.
Mix: Controls the level between the dry signal and the
wet signal. Counterclockwise is 100% dry, and turning
clockwise will increase the amount of eect in the signal.
Mode: Select between chorus, vibrato and anger.
Chorus has a smooth, rich shimmering quality adding
dimension to your sound.
Vibe is a pitch modulation eect that adds a warbly feel.
Flanger is a wide sweeping phase eect that adds a
sense of air and movement.
Rate: Adjusts how quickly the eect will modulate.
Preset Stompswitch: Press to scroll through presets. Each LED color
represents a dierent preset. When the LED is white, the Nebulus will
use the settings currently indicated by knobs and switches.
chorus
mode
special
vibe flanger
a
basic multi w/ trem uni vibrato rotary 60s 70s
regenerationhorncompdepthLF throb regen
b c a b c a b c
thru 0
Controls at a Glance
Power: 9V - 12V DC negative
tip 2.1mm jack. 280mA or greater
Bypass Stompswitch: When the LED is shining, the eect is applied to the
signal. When o, the pedal is being bypassed.
When scrolling through presets, the bypass LED will blink indicating the preset is
ready to load. Press the bypass switch to engage the new preset.
Output: Sets the overall output level (volume) of the pedal.
Depth: Adjusts the width of the modulation.
Special: Modies the eect. Performs a dierent function
for each mode. See the chart at the upper left to
reference the functionality in each mode.
Tone: Changes the tonal character of the eect.
Warm will darken the sound.
Clean will leave the signal unaected.
Bright will add some high end.
chorus
mode
special
vibe flanger
a
basic multi w/ trem uni vibrato rotary 60s 70s
regenerationhorncompdepthLF throb regen
b c a b c a b c
thru 0
Advanced Configuration
Entering the advanced configuration: Unplug the power from the
Nebulus. Plug the power back in while holding down both the
preset and bypass stompswitches. The bypass LED should blink
twice to confirm that you are in the advanced configuration.
Modifying the advanced configuration: Each toggle controls a
configuration parameter. When a parameter is modified, the preset
LED will blink to confirm that a change has been made.
Exiting the advanced configuration: Hold down both the preset and
bypass stompswitches. The bypass LED will blink twice to confirm
that the Nebulus has exited the advanced configuration.
Factory reset: While in the advanced configuration, press the
following stompswitches in order: preset, bypass, preset, bypass.
The LEDs will do a little dance to confirm that the Nebulus has been
reset to its factory settings. Please note that this overwrites the
current presets with the factory presets.
