Emotron EMX-B Manual de usuario
Emotron EMX-B
Drive system
for rotary heat exchangers
Instruction manual
English
Emotron EMX-B
Drive system
Instruction manual
Valid from software version 3.0
Document number: 01-6048-01
Edition: r3
Date of release: 2019-03-27
© Copyright CG Drives & Automation Sweden AB 2015-2019
CG Drives & Automation retain the right to change
specifications and illustrations in the text, without prior
notification. The contents of this document may not be copied
without the explicit permission of CG Drives & Automation
Sweden AB.
The product is protected as follows:
Patents: US 6 628 100; SE 9902821-9
SE 0100814-3; SE 0100814-3; EP 1 366 346; US 7 083 544
Registered design: US 462 937; DE 400 05 393.4; SE 66 630
Patent pending for UltraRotoSenseTM: EP17171733.3
CG Drives & Automation 01-6048-01r3 1
Safety instructions
Instruction manual
Read this instruction manual before installing and running the drive system.
The following symbols can appear in this manual. Always read these first before
continuing:
Users
This instruction manual is intended for:
• installation engineers
• maintenance engineers
•operators
• service engineers
Handling the drive system
Installation, commissioning, demounting, taking
measurements, etc, of or on the drive system may only be carried out by
personnel technically qualified for the task. The installation must be carried out
in accordance with local standards.
NOTE: Additional information as an aid to avoid problems.
CAUTION! Failure to follow these instructions can result in malfunction
or damage to the drive system.
WARNING! Failure to follow these instructions can result in serious
injury to the user in addition to serious damage to the drive system.
!
2CG Drives & Automation 01-6048-01r3
Opening the control unit
Always take adequate precautions before opening the control unit. Although the
connections for the control signals and the switches are isolated from the mains
voltage, do not touch the control board when the drive system is switched on.
Precautions to be taken with a connected motor
If work must be carried out on a connected motor or on the driven machine,
the mains voltage must always be disconnected from the drive system first.
Earthing
The control unit must always be earthed via the mains safety earth connection.
EMC Regulations
In order to comply with the EMC Directive, it is absolutely necessary to follow
the installation instructions. All installation descriptions in this manual follow
the EMC Directive.
Voltage tests (Megger)
Do not carry out voltage tests (Megger) on the motor, before all the motor
cables have been disconnected from the drive system.
Condensation
If the control unit is moved from a cold (storage) room to a room where it will
be installed, condensation can occur. This can result in sensitive components
becoming damp. Do not connect the mains voltage until all visible dampness
has evaporated.
Incorrect connection
The control unit is not protected against incorrect connection of the mains
voltage, and in particular against connection of the mains voltage to the motor
outlets R, Y and B. The control unit can be damaged in this way.
WARNING! Always switch off the mains voltage before opening
the control unit.
Wait at least 5 minutes before starting work.
CG Drives & Automation 01-6048-01r3 3
Transport
To avoid damage, keep the drive system in its original packaging during
transport. This packaging is specially designed to absorb shocks during
transport.
4CG Drives & Automation 01-6048-01r3
CG Drives & Automation 01-6048-01r3 5
Contents
Safety instructions................................................................... 1
Contents ................................................................................ 5
1. Description ............................................................................ 7
1.1 Introduction................................................................................................. 7
1.2 Delivery and unpacking.............................................................................. 8
1.3 Warranty ...................................................................................................... 8
1.4 General description .................................................................................... 9
1.5 Operating indicators ............................................................................... 10
2. Mounting and installation ..................................................... 13
2.1 Basic mounting ........................................................................................ 13
2.2 External sensor for rotation monitor (optional) ..................................... 14
2.3 Cable connections ................................................................................... 15
2.4 Control board ........................................................................................... 16
2.5 Select type of control signal.................................................................... 22
3. Built-in functions .................................................................. 23
3.1 Holding torque ......................................................................................... 23
3.2 Automatic purging.................................................................................... 23
3.3 Rotation monitor (DIP switch 6).............................................................. 24
3.4 Protection of the control unit .................................................................. 26
3.5 Defrosting................................................................................................. 27
3.6 Manual control using a 10 kOhm potentiometer .................................. 27
3.7 Test Switch ............................................................................................... 27
3.8 Cooling recovery....................................................................................... 27
3.9 DIP switches............................................................................................. 28
3.10 Communication through Modbus........................................................... 32
3.11 Built-in configurable non-linearity........................................................... 39
4. Troubleshooting ................................................................... 41
4.1 Trip conditions, causes and remedial action......................................... 41
6CG Drives & Automation 01-6048-01r3
5. Maintenance........................................................................ 46
5.1 Motor diagnosis........................................................................................ 46
6. Technical Data..................................................................... 47
6.1 Dimensions ............................................................................................... 48
6.2 Part numbers ............................................................................................ 51
7. Appendix ............................................................................. 53
7.1 Connection label....................................................................................... 53
7.2 Front label................................................................................................. 54
Tabla de contenidos
Otros manuales de Unidad de control de Emotron
