Product Overview

Emerson® Avocent® SV switches are field-proven KVM and KM switching solutions. This

switching system enables you to use a single keyboard, monitor and mouse to seamlessly access

multiple computers.

Features and Benefits

The SV switching system offers several options depending on the model:

•Support for HDMI, DVI-I and DisplayPort video

•Support for USB and PS/2 keyboard and mouse

•Managed copy and paste between computers

•Audio and USB freeze to lock ports for use between computers

•Front panel USB 3.0 ports with one high charging port

2.....Emerson® Avocent® SV Switching System Installation/User Guide

Basic Operation

Although installation of your SV switching system is complete, ensure you have have one of the

following compatible operating systems:

•Microsoft®Windows®2000

•Red Hat® Linux®

•Mac OS® X v10.3 and higher

Switch Overview

The following figures show the connectors on the front and back of the switching system.

KVM Model (SV 340 Switch Shown)

Number Description Number Description

1 LED channel indicator 11 CONSOLE keyboard and mouse

USB type A ports

2 Channel selector 12

CONSOLE female video port

(varies with model: DVI-I, HDMI or

DisplayPort)

3 Channel label 13 Keyboard and mouse USB type B

port

4 Channel configuration 14 Varies with model (DVI-I, HDMI or

DisplayPort)

KVM SV 340 Switch Description

4.....Emerson® Avocent® SV Switching System Installation/User Guide

Number Description Number Description

5 USB freeze toggle 15 Microphone jack

6 Audio freeze toggle 16 Audio jack (3.5 mm stereo)

7 USB3.0 ports 17 USB type B port

8 CONSOLE system reset 18 Channel configuration

9 CONSOLE microphone jack 19 AC input (100-200 VAC)

10 CONSOLE Audio jack (3.5 mm stereo)

KM Model (SV KM140 Switch Shown)

Number Description Number Description

1 LED channel indicator 10 CONSOLE Audio jack (3.5 mm

stereo)

2 Channel selector 11 CONSOLE keyboard and mouse

USB type A ports

3 Channel label 12 Keyboard and mouse USB type B

port

4 Channel configuration 13 Microphone jack

5 Audio freeze toggle 14 Audio jack (3.5 mm stereo)

6 USB freeze toggle 15 USB type B port

7 USB3.0 ports 16 Channel configuration

8 CONSOLE system reset 17 AC input (100-200 VAC)

9 CONSOLE microphone jack

SV KM140 Switch Description

Switching between computers

After turning on the switch, the default channel is channel one. You can select which computer to

operate using front panel push-buttons.

Basic Operation.....5

To switch between computers:

Select the computer by pressing the corresponding front panel push-button on the front of the

switch. The LED number will illuminate to indicate which computer is currently selected. It will take

approximately one second for the video signal to sync after switching computers.

To switch between computers using keyboard shortcuts:

Select the computer by typing key combinations on the keyboard. To switch to another channel,

press left CTRL+ left CTRL+ <the channel number>.

NOTE: Use left control key only.

The following table details keyboard shortcut options for KMmodels.

Key Combination Description

CTRL | CTRL | F11 | r Device resets to factory defaults and all settings and configurations are

deleted.

CTRL | CTRL | F11 | f Disable cursor navigation. Switching between systems will not be

possible with mouse movement.

CTRL | CTRL | F11 | u Enable cursor navigation. Switching between systems is possible with

mouse movement.

CTRL | CTRL | F11 | + Mouse speed is increased.

CTRL | CTRL | F11 | - Mouse speed is decreased.

KM Keyboard Shortcuts

USB 3.0 port

Three front panel USB 3.0 ports, enabled by default, provide easy access and connectivity to any

external USB device to ensure quick data transfer. One port is a high charged port allowing

charging of other devices, such as tablets. The host detection USB freeze function enables the

user to switch between channels without affecting the processes performed by devices connected

to the USB port, such as file transfers. When only one computer is using the USB port function,

ensure that it is connected to channel one.

Using USB freeze

If you need to retain authentication information on one channel after switching to another, you can

freeze the USB port of the first channel.

To freeze the USB channel:

1. Select the channel you want to freeze.

2. On the front panel, switch the USBport Freeze toggle to FREEZE mode. The channel

indicator will illuminate on the selected channel and on the Freeze toggle.

6.....Emerson® Avocent® SV Switching System Installation/User Guide

NOTE: If you are on a channel that has a USB port enabled and you switch to a channel that is not using

the USB port, then you will lose the connection and the ability to freeze the information. You must switch

back to a USB-enabled channel to reactivate the feature.

Managed copy and paste

The managed copy and paste feature enables copying of files and text from one source computer

to the other for seamless integration of sources. Once the driver is installed, performing a copy from

one source stores the files or text in temporary memory. Performing the paste function on a

different source retrieves the files or text in a way that is transparent to the user.

NOTE: Two-port and four-port models support managed copy and paste of text. Four-port models also

support managed copy and paste of files.

The managed copy and paste feature requires a driver and software agent download. To download

the files, visit the product page at www.emersonetworkpower.com.

KMmulti-monitor support

The SV KM140 switch is preconfigured to support one monitor per channel. The user can use the

preset keys to configure the KM to support up to two monitors per channel. To leverage the multiple

monitor feature, the user must install the multiple monitor driver on each of the desired systems.

When using the multiple monitor configuration, the user can experience seamless switching by

moving the mouse cursor to the desired display. To download the multi-monitor display driver, visit

www.emersonnetworkpower.com.

The following images detail the different preset monitor configurations.

NOTE: In the configurations, gray indicates a single display computer and black indicates a multi-monitor

display. P indicates the primary display and S indicates a the seconday display in a multi-monitor display

configuration.
