Emerson PACSystems RX3i Manual de usuario

QUICK START GUIDE

GFK-2939A

Sep 2019

PACSystems™ RX3i

ENERGY PACK

(IC695ACC402)

Quick Start Guide Contents
GFK-2939A Sep 2019
Contents i

Table of Contents
1. Overview ........................................................2
Ordering Information .......................................................4
2. Hardware Installation......................................5
Mounting the Energy Pack on a DIN Rail ........................6
Mounting the Energy Pack Directly on a Panel................7
Installation Location ........................................................8
3. Cable Connections.........................................11
Connecting to the Energy Pack ..................................... 11
Connecting the Energy Pack to the Controller............... 12
4. Grounding..................................................... 13
5. Power-Up...................................................... 14
6. LED Indications.............................................. 15
7. Firmware Updates.........................................16
LED Indications for Firmware Updates .......................... 16
8. Replacing the Cap Pack Module ..................... 17
9. Additional Information.................................. 19
General Contact Information ......................................... 20

Quick Start Guide Cautions and Warnings

GFK-2939A Sep 2019

Warnings and Cautions ii

Caution, Warnings & Danger Notes

as Used in this Publication

Warning

Warning Notices are used in this publication

to emphasize that hazardous voltages,

currents, temperatures, or other conditions

that could cause personal injury exist in this

equipment or may be associated with its use.

In situations where inattention could cause

either personal injury or damage to

equipment, a Warning notice is used.

arning

Caution

Caution notices are used where equipment

might be damaged if care is not taken.

arning

Note: Notes merely call attention to information that is

especially significant to understanding and operating the

equipment.

These instructions do not purport to cover all details or

variations in equipment, nor to provide for every possible

contingency to be met during installation, operation,

and maintenance. The information is supplied for

Quick Start Guide Cautions and Warnings

GFK-2939A Sep 2019

Warnings and Cautions iii

informational purposes only, and Emerson makes no

warranty as to the accuracy of the information included

herein. Changes, modifications, and/or improvements

to equipment and specifications are made periodically

and these changes may or may not be reflected herein. It

is understood that Emerson may make changes,

modifications, or improvements to the equipment

referenced herein or to the document itself at any time.

This document is intended for trained personnel familiar

with the Emerson products referenced herein.

Emerson may have patents or pending patent

applications covering subject matter in this document.

The furnishing of this document does not provide any

license whatsoever to any of these patents.

Emerson provides the following document and the

information included therein as-is and without warranty

of any kind, expressed or implied, including but not

limited to any implied statutory warranty of

merchantability or fitness for particular purpose.

Emerson Terms and Conditions of Sale are available

upon request. The Emerson logo is a trademark and

service mark of Emerson Electric Co. All other marks are

the property of their respective owners.

Quick Start Guide Chapter 1

GFK-2939A Sep 2019

Overview 2

1. Overview

The ACC402 Energy Pack is used exclusively with the

CPE330 RX3i CPU. It preserves user memory in the

Controller during power fluctuations or outages.

If system power is lost, the Energy Pack maintains power

long enough for the connected CPE330 to write its user

memory contents to non-volatile memory. When system

power is restored, the user memory is restored if the

CPE330 is configured to power up from RAM.

The ACC402 Energy Pack is connected to the

IC695CPE330 CPU via a dedicated cable IC695CBL002

(shown above). This arrangement allows the Energy Pack

to source power from the RX3i backplane in order to

charge its circuitry. The cable also allows the CPU to

monitor the status of the Energy Pack. Upon loss of

backplane power, the CPU automatically switches over

to the Energy Pack power source, ensuring an orderly

power-down sequence.

Quick Start Guide Chapter 1

GFK-2939A Sep 2019

Overview 3

Figure 1.1: Connection Diagram

Quick Start Guide Chapter 1

GFK-2939A Sep 2019

Overview 4

Ordering Information

IC695ACC402

CPE330-compatible Energy Pack.

Includes Base, Cap Pack module, CPU

connecting cable & ground strap.

IC695ACC412

Replacement Cap Pack module.

IC695CBL002

Replacement 1m (36”) CPU connecting

cable.

Quick Start Guide Chapter 2

GFK-2939A Sep 2019

Hardware Installation 5

2. Hardware Installation

The ACC402 Energy Pack may be mounted on a standard

EN50022 DIN rail or directly on an equipment panel. It is

designed to be mounted adjacent to the CPE330

Controller and connected to the Controller using the 1m

cable provided (IC695CBL002).

Heat dissipation: A minimum clearance of 25mm (1 inch)

needs to be provided on all four sides of the unit (right,

left, top and bottom).

Quick Start Guide Chapter 2

GFK-2939A Sep 2019

Hardware Installation 6

Mounting the Energy Pack on a

DIN Rail

The Energy Pack snaps easily onto the DIN rail. No tools

are required.

Figure 2.1: Mounting on to DIN-Rail

Quick Start Guide Chapter 2

GFK-2939A Sep 2019

Hardware Installation 7

Mounting the Energy Pack

Directly on a Panel

Recommended fasteners:

The baseplate accommodates four M4-0.7 machine

screws (8-36 UNF). Minimum length of 25mm (or 1”) is

recommended. Secure with matching nuts.
