Baumann™24000F Wafer Control Valve

Contents

Introduction 1...................................

Scope of Manual 1.............................

Safety Precautions 2...........................

Maintenance 2.................................

Installation 3..................................

Air Piping 3...................................

Disassembly 4................................

Lapping the Metal Seat 5.......................

Replacing Packing 5...........................

Actuator and Valve Body Reassembly 6...........

Parts Ordering 6................................

Dimensions and Weights 15......................

Figure 1. 24000F Control Valve

24000F with

Baumann 32

Dual-Stop Actuator

24000F with Baumann 32 Actuator

and FIELDVUEtDVC2000

Digital Valve Controller

W9762-1 W9763-1

Introduction

The Baumann 24000F Wafer Body Control Valve (figures 1) mates with ASME and EN line flange connections and is

designed to control a wide range of process liquids, gases and vapors. This compact package provides the connection

integrity of flanged body globe valves while being significantly lighter and easier to install.

Scope of Manual

This instruction manual includes installation, maintenance, and parts information for the Baumann 24000F wafer body

control valve.

Do not install, operate, or maintain Baumann 24000F control valves without being fully trained and

qualified in valve, actuator, and accessory installation, operation, and maintenance. To avoid personal

injury or property damage, it is important to carefully read, understand, and follow all the contents of

this manual, including all safety cautions and warnings. If you have any questions about these

instructions, contact your Emerson sales office before proceeding.

Instruction Manual

D103358X012

24000F Valves

February 2021

Instruction Manual

D103358X012

24000F Valves

February 2021

WARNING

Always wear protective gloves, clothing and eyewear when performing any installation operations to avoid personal

injury.

Personal injury or property damage caused by sudden release of pressure or bursting of pressure retaining parts may result

if service conditions exceed those for which the product was intended. To avoid injury or damage, provide a relief valve for

over pressure protection as required by government or accepted industry codes and good engineering practices.

Check with your process or safety engineer for any additional measures that must be taken to protect against process

media.

If installing into an existing application, also refer to the WARNING at the beginning of the Maintenance section in this

instruction manual.

CAUTION

This valve is intended for a specific range of pressures, temperatures and other application specifications. Applying

different pressures and temperatures to the valve could result in parts damage, malfunction of the control valve or loss of

control of the process. Do not expose this product to service conditions or variables other than those for which the product

was intended. If you are not sure what these conditions are you should contact your Emerson sales office for more

complete specifications. Provide the product serial numbers (shown on the nameplate) and all other pertinent information.

WARNING

If you move or work on an actuator installed on a valve with loading pressure applied, keep your hands and tools away

from the stem travel path to avoid personal injury. Be especially careful when removing the stem connector to release all

loading on the actuator stem whether it be from air pressure on the diaphragm or compression in the actuator springs.

Likewise take similar care when adjusting or removing any optional travel stop. Refer to the relevant actuator Maintenance

Instructions.

If hoisting the valve, take care to prevent people from being injured in case the hoist or rigging slips. Be sure to use

adequate sized hoists and chains or slings to handle the valve.

WARNING

Personal injury could result from packing leakage. Valve packing is tightened before shipment; however, the packing

might require some readjustment to meet specific service conditions.

Maintenance

WARNING

Avoid personal injury and property damage from sudden release of process pressure or bursting of parts. Before

performing any maintenance operations:

Instruction Manual

D103358X012

24000F Valves

February 2021

D Do not remove the actuator from the valve while the valve is still pressurized.

D Always wear protective gloves, clothing, and eyewear when performing any maintenance operations.

D Disconnect any operating lines providing air pressure, electric power, or a control signal to the actuator. Be sure the

actuator cannot suddenly open or close the valve.

D Use bypass valves or completely shut off the process to isolate the valve from process pressure. Relieve process pressure

on both sides of the valve. Drain the process media from both sides of the valve.

D Depending on the actuator construction, it will be necessary to manage the pneumatic actuator spring

pre-compression. It is essential to refer to the relevant actuator instructions in this manual to perform safe removal of

the actuator from the valve.

D Use lock‐out procedures to be sure the above measures stay in effect while you work on the equipment.

D The valve packing box may contain process fluids that are pressurized, even when the valve has been removed from the

pipeline. Process fluids may spray out under pressure when removing the packing hardware or packing rings, or when

loosening the packing box pipe plug.

D Check with your process or safety engineer for any additional measures that must be taken to protect against process

media.

Note

Whenever a gasket seal is disturbed by removing or shifting gasketed parts, install a new gasket during reassembly. This provides a

good gasket seal because the used gasket may not seal properly.

WARNING

Avoid personal injury or property damage by thoroughly cleaning the line of all dirt, welding chips, scale, oil or grease, and

other foreign material. Failure to do so could result in damage to the seating and sealing surfaces of the valve and result in

damage to the valve and release of process materials.

Installation

1. Before installing the valve in the pipeline, thoroughly clean the line of all dirt, welding chips, scale, oil or grease, and

other foreign material.

2. Install the valve so the controlled fluid will flow through the valve body in the direction indicated by the arrow cast

on the valve body.

3. A three-valve bypass must be used to permit removal of the control valve from the line without shutting down the

system.

4. In case of a heat-insulated installation, insulate the valve body only, not the bonnet.

WARNING

To avoid personal injury or property damage, do not attempt to do any work on a valve while the system is in operation.

The valve must be isolated 100% from the active system and the isolated line voided of pressure and/or hazardous fluids.

Air Piping

1. For an air-to-extend actuator (air-to-close action), connect the actuating air pressure line to the 1/4 NPT opening in

the upper diaphragm case. For an air-to-retract actuator (air-to-open action) connect the actuating air pressure line

to the 1/4 NPT in the lower diaphragm case.

Instruction Manual

D103358X012

24000F Valves

February 2021

2. Use 6.4 mm (1/4 inch) O.D. tubing or equivalent for all air lines. If air line exceeds 8 m (25 ft) in length, 9.5 mm (3/8

inch) tubing is preferred. Air lines must not leak. Air pressure not to exceed 2.5 bar (35 psig).

Disassembly

WARNING

If there is evidence of process fluid under pressure leaking from the joint, retighten the valve body/joint nuts. Return to the

Warning at the beginning of the Maintenance section to ensure proper steps have been taken to isolate the valve and

relieve process pressure.

CAUTION

D When assembling or disassembling the valve, do not turn the valve stem while the plug is touching the valve seat. This

will damage the valve's seating surfaces.

D When adjusting the valve stem, do not grip the stem directly with pliers or a wrench. This will damage the surface of the

stem, and cause damage to the packing in the valve. Instead, counter-tighten the two locknuts (key 27) on the stem

(key 5). This will allow you to turn the stem by turning the locknuts (key 27) with a wrench.

D When placing the valve in a vise, do not clamp the rounded sides of the valve. This will distort the shape of the casting,

and will ruin the valve.

Actuator Removal

Access to the internal components of the valve body can be accomplished with the actuator removed. For actuator

maintenance see the following instruction manual (D103352X012).

Air-to-Close Actuators

1. Disconnect the air supply to the actuator and remove the air tubing.

2. Loosen the drive nut (key 9) and then remove the plug and stem (keys 4 and 5) assembly by holding the actuator

stem still while unthreading the plug and stem assembly counterclockwise.

3. Remove the stem locknuts (key 27), travel indicator (key 58), and yoke drive nut (key 9).

4. Remove the actuator from the valve.

Air-to-Open Actuators

1. Using flexible tubing, apply sufficient air pressure to the actuator to lift the plug off the seat.

2. Loosen the drive nut (key 9) and then remove the plug and stem (keys 4 and 5) assembly by holding the actuator

stem still while unthreading the plug and stem assembly counterclockwise.

3. Remove the stem locknuts (key 27), travel indicator (key 58), and yoke drive nut (key 9).

4. Remove the actuator from the valve.

5. Disconnect the air supply to the actuator and remove the air tubing.

Valve Body Disassembly

1. After removing the actuator, unscrew the bonnet (key 8), and plug and stem (keys 4 and 5) from valve body (key 1).

A new body gasket (key 49) should be installed each time the valve is disassembled.

Instruction Manual

D103358X012

24000F Valves

February 2021

2. Loosen the packing spring load by removing the packing follower (key 10).

Remove the plug and stem assembly by pulling it out through the bottom of the bonnet (key 8) while rotating the

stem (key 5). This will help prevent damage to the packing components.

Note

Handle the parts carefully to avoid damaging the seating and guiding surfaces. Wipe the parts with a clean soft cloth and examine

for signs of wear or damage.

3. To remove the seat ring (key 2), use a 5/8 inch socket wrench. Clean the seat ring thoroughly and examine for signs

of wear or damage.

4. Low Flow Trims:

a. For Baumann 151 trim (figure 5) unscrew the seat subassembly. When reassembling, hand tighten the

subassembly (key 51) and then rotate 1/8 of a turn with the 5/8 inch socket to lock in place.

Note

If changing to Baumann 151 trim, for correct flow characteristics, be sure the valve is reversed in the pipeline so that flow direction

is flow-to-close.

b. For Baumann 177 trim (figure 6) unscrew the retainer nut (key 24) using a 3/4 inch socket wrench. Remove the

gland (key 23) and insert (key 25). Replace the insert (key 25), making sure that the tapered portion faces up. If

replacement of the housing (key 26) is required, use a 5/8 inch socket wrench.

Lapping the Valve Seat

If valve seat leakage becomes excessive, it may be necessary to lap the valve seat.

Lapping is the process of mating the valve plug to the seat ring, with an abrasive to produce a close fit. When valve seat

leakage becomes excessive, lapping becomes necessary. The plug and seat ring seating surfaces should be free of

large scratches or dents and the contact surface of the seats should be as narrow as possible.

1. Disassemble the valve body and remove the plug and stem assembly (keys 4 and 5) as directed in the previous Valve

Body Disassembly section in this instruction manual.

2. Use a good quality lapping compound with a mixture that contains 280 to 600 grit. Apply at several spots around

the plug seating surface. Replace the plug and stem carefully in the bonnet.

3. Install the bonnet (key 8) into the valve body, without gasket and hand tighten. The bonnet will serve as a guide

during the lapping operation.

4. Lap the valve by applying a slight pressure on the stem and rotate the stem in short oscillating strokes

approximately 8 to 10 times or until you see an even and complete lap line. The plug should be intermittently lifted

and turned 90 degrees while lapping to keep the plug and seat ring concentric.

5. Clean the valve seat and plug (key 4) thoroughly when lapping is complete, removing all traces of lapping

compound.

6. For the NPS 1 integral seat body, inspect internal seating surface for wear or damage and replace if necessary.

Replacing Packing

Refer to figure 2 and the standard and optional packing constructions (figures 7, 8, and 9) to determine the packing

that has been preinstalled in your valve.

Instruction Manual

D103358X012

24000F Valves

February 2021

1. Disassemble the valve as directed earlier. Remove the locknuts (key 27) and indicator disk (key 58), and turn the

plug stem (key 5) out through the packing box. Remove the packing follower (key 10). Push out the old packing

(key 14) by working from the underside of the bonnet (key 8).

2. Standard Spring Loaded PTFE V-Ring Packing (figures 2 and 7): Carefully insert each piece in exact order shown in

figure 7. Turn the packing follower (key 10) until it shoulders on the bonnet (key 8). This will compress the packing

spring (key 6) to enable constant stem sealing throughout packing life.

3. Molded Graphite Ribbon Packing (figure 8): Carefully insert each piece in exact order shown in figure 8. Hand

tighten the packing follower (key 10). Use a wrench to increase tightness by turning the follower an additional 60

degrees.

4. ENVIRO-SEAL™Packing (figure 9): Carefully insert each piece in exact order as shown in figure 9. Tighten the

packing follower (key 10) until the Belleville springs are compressed. This will be signaled by a significant increase in

resistance. Back off the follower 1/8 to 1/4 turn. A gap of approximately 1.5 mm (1/16 inch) between the packing

follower and the bonnet will ensure the packing is seated properly.

Actuator and Valve Body Reassembly

1. Insert a new valve body gasket (key 49) and install the bonnet assembly (key 8).

2. Place the actuator yoke over the stem (key 5). While tilting the actuator back, drop the yoke drive nut (key 9) over

the stem (key 5). Run the locknuts (key 27), and the travel indicator (key 58), down as far as possible and counter

tighten the locknuts (key 27) to lock.

3. Carefully position the actuator over the stem (key 5), lift the plug stem (key 5) and turn the plug stem (key 5) into

the actuator stem as far as it will go before adjusting the bench range.

See the following instruction manual (Baumann Actuator Instructions, D103352X012) for reassembly and bench

range adjustment.

CAUTION

When assembling or disassembling the valve, do not turn the valve stem while the plug is in contact with the valve seat.

This can damage the seating surface very quickly.

WARNING

To avoid personal injury or equipment damage due to possible sudden shifting or falling of the valve assembly, do not lift

the valve assembly by the handwheel.

Parts Ordering

When corresponding with your Emerson sales office about this equipment, always mention the valve serial number.

When ordering replacement parts, also specify the key number, part name, and desired material using the following

parts tables.

WARNING

Use only genuine Fisher™replacement parts. Components that are not supplied by Emerson should not, under any

circumstances, be used in any Fisher valve, because they may void your warranty, might adversely affect the performance

of the valve, and could cause personal injury and property damage.

Instruction Manual

D103358X012

24000F Valves

February 2021

Figure 2. Baumann 24000F Valve Body with Standard Bonnet and NPS 1 Integral Seat

E1278

Instruction Manual

D103358X012

24000F Valves

February 2021

Figure 3. Baumann 24000F Valve Body with Extension Bonnet and Screwed-In Seat Ring

E1279

Instruction Manual

D103358X012

24000F Valves

February 2021

Table 1. Baumann 24000F Common Parts(1,2)

KEY

NO. QTY DESCRIPTION REMARKS

VALVE SIZE

DN 15 (NPS 1/2) DN 20 (NPS 3/4) DN 25 (NPS 1)

Part Number Part Number Part Number

1 1 Valve Body Screwed Seat 24511 24518 24524

Integral Seat N/A N/A 24521

4* 1 Plug (Metal Seat) See table 2

Plug (Soft Seat) See table 3

8 1 Bonnet Standard 24516-3 24516-3 24522-3

Extension 24856 24856 24529

9 1 Yoke Drive Nut 011757-003-153 011757-003-153 011757-003-153

10 1 Packing Follower 24490-1 24490-1 24490-1

14 1 Packing Kit (standard) 24494T001

Packing Kit (optional) See page 13

27 2 Lock Nut 971514-002-250 971514-002-250 971514-002-250

49* 1 Body Gasket 24513 24513 24156

24513-1 24513-1 24156-1

58 1 Travel Indicator 24299 24299 24299

1. Contact your Emerson sales office for part number, price, and delivery on optional valve and trim materials (N10276, N08020, and N04400).

2. For valves made before 2005, the common parts numbers above may not apply. Please notify your Emerson sales office if the valve is prior to 2005 so the appropriate parts can be ordered.

For Extension Bonnet Construction

Substitute -104 for -101

-105 for -102

*Recommended spare parts

Instruction Manual

D103358X012

24000F Valves

February 2021

Table 2. Plug and Seat Ring for Metal Seat

KEY

NO. DESCRIPTION PLUG TYPE PLUG

NO.

ORIFICE

DIAMETER

mm (Inch)

CvKv

VALVE SIZE

DN 15 (NPS 1/2) DN 20 (NPS 3/4) DN 25 (NPS 1)

4* Plug & Stem

Assy

Metal Seat,

Micro Trim

(Linear)

102 6.3 (0.25)

0.02(1) 0.017(1) GE46385X012

0.05(1) 0.043(1) GE46386X012

0.1(1) 0.086 GE46387X012

0.2(1) 0.17(1) GE46388X052

Metal Seat

(Equal %)

548

(416 SST)

6.3 (0.25)

0.2(1) 0.17(1) GE46393X012

0.5(1) 0.43(1) GE46394X012

1.0 0.86 GE46392X012

9.5 (0.375)

1.5 1.29 24634-6-101-548

2.0 1.72 24171-12-101-548 ---

2.5 2.15 --- --- 24171-12-101-548

20.6

(0.8125)

4 3.44 --- --- 24185-6-101-548

6.5 5.59 --- --- 24061-5-101-548

Metal Seat

(Equal %) 588

6.3 (0.25)

0.2(1) 0.17(1) GE46390X012

0.5(1) 0.43(1) GE46391X012

1.0 0.86 GE46389X012

9.5 (0.375)

1.5 1.29 24634-101-588

2.0 1.72 24171-101-588 ---

2.5 2.15 --- --- 24171-101-588

20.6

(0.8125)

4 3.44 --- --- 24185-101-588

6.5 5.59 --- --- 24061-101-588

Metal Seat

(Linear)

648

(416 SST)

6.3 (0.25) 0.5 0.43 GE46398X012

1.0 0.86 GE46397X012

9.5 (0.375)

1.5 1.29 24669-1-101-648

2.0 1.72 24671-2-101-648 ---

2.5 2.15 --- --- 24671-2-101-648

20.6

(0.8125)

4 3.44 --- --- 24757-5-101-648

6.5 5.59 --- --- 24717-3-101-648

Metal Seat

(Linear) 688

6.3 (0.25) 0.5 0.43 GE46396X012

1.0 0.86 GE46395X012

9.5 (0.375)

1.5 1.29 24669-101-688

2.0 1.72 24671-101-688 ---

2.5 2.15 --- --- 24671-101-688

20.6

(0.8125)

4 3.44 --- --- 24757-101-688

6.5 5.59 --- --- 24717-101-688

2* Seat Ring 9.5 mm (0.375 in) Orifice Diameter, 316 SST 24167

9.5 mm (0.375 in) Orifice Diameter, 416 SST 24167-3

1. Matching seat ring (key 2) must be furnished with replacement plug orders.

*Recommended spare parts

Tabla de contenidos

Otros manuales de Unidad de control de Emerson

Emerson

Emerson KTM VIRGO E Series Manual

Emerson

Emerson Enardo ES-665-HF Manual de usuario

Emerson

Emerson Fisher G101 Series Manual de usuario

Emerson

Emerson 8323G0 Series Instrucciones de instalación y funcionamiento

Emerson

Emerson Yarway 9200 Series Manual de usuario

Emerson

Emerson Bettis XTE3000 Manual de usuario

Emerson

Emerson Rosemount Analytical NGA2000 CLD Manual de usuario

Emerson

Emerson Fisher 3582i Manual de usuario

Emerson

Emerson IC200UEM001 Manual de usuario

Emerson

Emerson AVENTICS 501 Series Manual de usuario

Emerson

Emerson SI-PROFIBUS Manual de usuario

Emerson

Emerson Fisher Baumann 87000 Manual de usuario

Emerson

Emerson Clarkson series Manual de usuario

Emerson

Emerson Fisher 63EGLP Series Manual de usuario

Emerson

Emerson Baumann 25000 Lo-T Series Manual de usuario

Emerson

Emerson YARWAY 9100 ARC Series Manual

Emerson

Emerson Fisherr D2 FloPro Manual de usuario

Emerson

Emerson Neotecha Sapro Guía de configuración

Emerson

Emerson Daniel 700 Series Guía de inicio rápido

Emerson

Emerson Fisher EU Manual de usuario

Emerson

Emerson Fisher Vee-Ball SS-84PSV4 Manual de usuario

Emerson

Emerson FRM-2 Manual

Emerson

Emerson Fisher Types N480 Manual de usuario

Emerson

Emerson Fisher HS Manual de usuario

Manuales populares de Unidad de control de otras marcas

Festo

Festo Compact Performance CP-FB6-E Manual de lista de piezas

Elo TouchSystems

Elo TouchSystems DMS-SA19P-EXTME Manual de usuario

JS Automation

JS Automation MPC3034A Manual de usuario

JAUDT

JAUDT SW GII 6406 Series Guía rápida

Spektrum

Spektrum Air Module System Manual de usuario

BOC Edwards

BOC Edwards Q Series Manual de usuario

KHADAS

KHADAS BT Magic Manual de usuario

Etherma

Etherma eNEXHO-IL Manual de usuario

PMFoundations

PMFoundations Attenuverter Manual de usuario

GEA

GEA VARIVENT Manual de usuario

Walther Systemtechnik

Walther Systemtechnik VMS-05 Manual de usuario

Altronix

Altronix LINQ8PD Instrucciones de montaje

Eaton

Eaton Powerware Series Manual de usuario

WAGO

WAGO 750-407/040-000 Manual de usuario

Sony

Sony CCU-590 Manual de usuario

Graco

Graco 25D614 Manual de usuario

Task Force Tips

Task Force Tips YE-RF-900 Manual de programación

Shini

Shini SPV-U Series Manual de usuario
