1
Thank You....................
for purchasing this Emerson AM/FM Stereo Clock Radio with Compact Disc
Player. In addition to waking to a buzzer alarm, or your favorite AM or FM Stereo
stations, you can also wake to the music of your favorite artists on compact disc.
There are dual alarms that can be set and used independently, a sleep to music
timer that controls both the radio and the CD player, and a Sure Alarm battery
back up system that will wake you to radio or buzzer, even if the power is out at
the wake up time. The large green LED display shows the time, alarm settings,
and CD track numbers, and it can be seen from anywhere in your room. The two
3” dynamic speakers provide excellent sound for such a compact unit. All major
controls are right on the top panel for simple, user-friendly operation.
Please read this manual completely to familiarize yourself with all the features of
your new CD clock radio, and save this manual for future reference. Your
warranty is on the back page of this manual.
The serial number of your unit can be found on the bottom of the cabinet. We
suggest that you record the serial number in the space provided below in case
this information is ever needed at a future date.
Model Number: CKD9908
Serial Number _______________________________________
WARNING: TO PREVENT FIRE OR SHOCK HAZARD, DO NOT EXPOSE
THIS UNIT TO RAIN OR MOISTURE.
DANGER:
Invisible and hazardous laser radiation when open and
interlock failed or defeated. Avoid direct exposure to beam.
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE
COVER (OR BACK). NO USER-SERVICEABLE PARTS INSIDE. REFER
SERVICING TO QUALIFIED SERVICE PERSONNEL.
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
DANGEROUS VOLTAGE
Uninsulated Dangerous Voltage, that may be of sufficient
magnitude to constitute a risk of electric shock to persons is
present within this product’s enclosure.
ATTENTION
The Owner’s Manual contains important operating and
maintenance instructions.
For your safety, it is necessary to refer to the manual.
CKD9908 O/M.QXD 1/29/01 2:43 PM Page 1
2
INFORMATION
This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to Part 15 of the FCC Rules. These limits
are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates, uses,
and can radiate radio frequency energy and, if not installed and used in
accordance with instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will
not occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct
the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to
which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
SAFETY PRECAUTIONS
FCC WARNING:
This equipment may generate or use radio frequency energy. Changes
or modifications to this equipment may cause harmful interference
unless the modifications are expressly approved in the instruction
manual. The user could lose the authority to operate this equipment if
an unauthorized change or modification is made.
LASER SAFETY: This unit employs a laser. Only qualified service
personnel should attempt to service this device due to possible eye
injury.
CAUTION: USE OF CONTROLS, ADJUSTMENTS OR
PERFORMANCE PROCEDURE HEREIN MAY RESULT IN
HAZARDOUS RADIATION EXPOSURE.
CKD9908 O/M.QXD 1/29/01 2:43 PM Page 2
3
LOCATION OF CONTROLS
2
130
28
24
23
22
21
17
18
19
16
20
25
26
29
27
6
7
9
8
10
13
14
15
11
12
4
3
5
1. CD Compartment Door
2. WAKE (MUSIC/BUZZER)
Switch
3. ALARM1 (OFF/ON) Switch
4. Battery Compartment (bottom
of unit)
5. ALARM2 (OFF/ON) Switch
6. ALM.1 SET Button
7. ALM.2 SET Button
8. SLEEP Indicator
9. CLOCK Button
10. SLEEP Button
11. POWER Button
12. POWER Indicator
13. AM Indicator
14. ALM.1 Indicator
15. FM STEREO Indicator
16. AM/FM Dial Scale and Pointer
17. ALM.2 Indicator
18. Display
19. SNOOZE Button
20. PLAY/PAUSE ( ) Button
21. SKIP/Search/MINUTE ( )
Button
22. SKIP/Search/HOUR ( )
Button
23. STOP (■) Button
24. TUNING Control
25. PROG (Program) Indicator
26. PROG (Program) Button
27. REPEAT Indicator
28. FUNCTION (FM ST./AM/CD)
Switch
29. REPEAT Button
30. VOLUME Control
CKD9908 O/M.QXD 1/29/01 2:43 PM Page 3
4
INSTALLATION
Unravel the AC cord and connect it to a conveniently located AC outlet having
120V and 60Hz only. The Clock Display will illuminate and “12:00” will appear in
the display.
NOTE: If the AC plug does not fit into a nonpolarized outlet, do not file or cut the
wide blade.
If the AC cord is disconnected or if there is a power failure,
this electronic clock is designed to continue operating
internally (without showing the time on the Clock Display)
with a 9 volt battery (not included). To install the battery,
remove the battery compartment cover and connect the
battery to the terminals of the battery snap inside the
compartment (use of an alkaline battery is recommended)
and install the battery compartment cover back into place.
Be sure to check the condition of the battery periodically by disconnecting the AC
cord and connecting it again 2 or 3 minutes later. The preset times should
continue operating. If the present time resets to “12:00”, it indicates the battery is
dead or not connected properly. A fresh 9 volt battery will keep the internal times
accurately for approximately 30 minutes. If the power is restored after 30 minutes,
the times may need to be reset.
AC Plug
AC Outlet
9V
BATTERY PRECAUTIONS
Follow these precautions when using batteries in this device:
1. Use only the size and type of batteries specified.
2. Be sure to follow the correct polarity when installing the batteries as indicated in the
battery compartment. Reversed batteries may cause damage to the device.
3. If the device is not to be used for a long period of time, remove the batteries to prevent
damage or injury from possible battery leakage.
4. Do not try to recharge batteries not intended to be recharged; they can overheat and
rupture. (Follow battery manufacturer’s directions.)
CKD9908 O/M.QXD 1/29/01 2:43 PM Page 4
5
OPERATION
Press and hold the CLOCK button and
the time will blink in the Display.
1
While holding the CLOCK button ❶,
press the SKIP/Search/MINUTE
button ❷ to advance the minute and
the SKIP/Search/HOUR button ❸
to advance the hour until the desired
time is shown on the display.
13
2
2
TO SET OR RESET THE ACTUAL TIME
Press and hold the desired Alarm
switch (ALM.1 or ALM.2)
and the
selected alarm time will blink in the
Display.
1
While holding the desired ALM button
button ❶, press the SKIP/Search/
MINUTE button ❷ to advance the
minute and the SKIP/Search/HOUR
button ❷ to advance the hour until
the desired alarm time is shown on the
display.
1
1
3
2
2
TO SET OR RESET THE ALARM TIME(S)
AM (TIME) LED INDICATOR
In the upper left corner of the Display is the AM LED indicator. When the AM LED
indicator is lit, the actual or alarm time shown in the Display is AM hours. When
the indicator is not lit, the time shown is PM hours.
CKD9908 O/M.QXD 1/29/01 2:43 PM Page 5
6
OPERATION
Set the alarm time as previously
instructed. Turn the unit on and slide
the FUNCTION switch ❶ to the FM
ST. or AM position. Select a radio
station and make sure the VOLUME ❷
is set as desired. Slide the desired
ALARM switch (ALARM1 or ALARM2)
❸ to the ON position.
3
31
2
1
Turn the unit off and slide the WAKE
switch to the MUSIC position. When
the actual time matches the selected
preset alarm time(s), the unit
automatically turns on.
To shut off the alarm, see TO SHUT
THE ALARM OFF section on the
following page.
2
TO SET THE ALARM TO WAKE TO RADIO
Set the alarm time as previously
instructed. Insert a CD into the CD
player, turn the unit on and slide the
FUNCTION switch ❶ to the CD
position. Make sure the VOLUME ❷ is
set as desired. Slide the desired
ALARM switch (ALARM1 or ALARM2)
❸ to the ON position.
3
31
2
1
Turn the unit off and slide the WAKE
switch to the MUSIC position. When
the actual time matches the selected
preset alarm time(s), the unit
automatically turns on and the CD
begins to play.
To shut off the alarm, see TO SHUT
THE ALARM OFF section on the
following page.
2
TO SET THE ALARM TO WAKE TO CD
CKD9908 O/M.QXD 1/29/01 2:43 PM Page 6
7
OPERATION
Set the alarm time as previously
instructed. Slide the desired ALARM
switch (ALARM1 or ALARM2) ❶ to the
ON position. Slide the WAKE switch ❷
to the BUZZER position.
1
1
2
1
When the actual time matches the
selected preset alarm time(s), the unit
automatically turns on. To shut off the
alarm, see TO SHUT THE ALARM OFF
section below.
2
2
1
1
2
TO SET THE ALARM TO WAKE TO BUZZER
To shut the alarm off, press the
POWER button ❶ once and the alarm
time will be reset for the next day.
Slide the desired ALARM switch ❷ to
the OFF position to turn off the alarm
and not set it for the next day.
2
2
1
1
1
TO SHUT THE ALARM OFF
The alarm can be temporarily turned
off manually by pressing the
SNOOZE button; the alarm will turn
back on automatically 6 minutes
later.
1
1
SNOOZE
CKD9908 O/M.QXD 1/29/01 2:43 PM Page 7
8
OPERATION
Press the POWER button ❶ to turn
the unit on (the POWER indicator will
light). Slide the FUNCTION switch ❷
to
the desired band (FM. ST or AM).
1
2
1
Tune a station by turning the TUNING
control
❶
. When a strong FM stereo
signal is received while listening to FM,
the FM ST. indicator will light.
Adjust the VOLUME control
❷
as
desired.
1
2
2
LISTENING TO THE RADIO
Hints for Better Reception
FM - Make sure the FM Antenna wire is uncoiled and extended to its full length.
You may have to vary the direction of the wire to find the strongest signal for each
FM station.
AM - The AM ferrite bar antenna is located inside the cabinet. It may be
necessary to turn the unit slightly so that the internal antenna is pointing in the
direction of the AM transmitter. You may have to experiment to find the position
that provides the strongest reception for each of your favorite AM stations.
CKD9908 O/M.QXD 1/29/01 2:43 PM Page 8
9
OPERATION
Press the POWER button ❶ to turn
the unit on (the POWER indicator will
light). Slide the FUNCTION switch ❷
to the CD position.
1
2
1
Press the OPEN/CLOSE area of the
CD compartment door and place a CD
on the center spindle, with the printed
label side facing up. Close the CD
compartment door; the total number of
tracks will briefly appear in the Display.
2
PLAYING COMPACT DISCS - NORMAL PLAYBACK
Remove the paper card from the CD Compartment before inserting a CD.
Press the PLAY/PAUSE () button
❶
to start playback.
Adjust the VOLUME control ❷ as
desired.
2
1
3
When the disc is through playing, it will
stop. Press the STOP (■) button to
stop the disc before it is finished.
4
NOTES:
• This unit is capable of playing standard CDs or 3” singles; no adapter is
required.
• If a disc is inserted incorrectly, dirty, damaged or not present at all, “no” will
appear in the display.
• To remove the disc, press the OPEN/CLOSE area on the CD Compartment
door, hold the edge of the CD and lift it out.
• The maximum time of a CD is 74 minutes for this unit.
CKD9908 O/M.QXD 1/29/01 2:43 PM Page 9
10
OPERATION
During CD playback, if you wish to
pause the disc momentarily, press the
PLAY/PAUSE () button
again.
Playback stops but the disc continues
to spin and the track number flashes
in the Display.
1
Press the
PLAY/PAUSE () button
again to release Pause and resume
normal CD playback. The sound
returns and the track number in the
Display stops flashing.
2
CD PAUSE CONTROL
After you insert the disc into the CD
player and the total number of tracks
appear on the display, you may press
either the SKIP/Search ( ) or
SKIP/Search ( ) buttons to select a
specific track for playback.
1
When the desired track number
appears in the display, press the CD
PLAY/PAUSE () button
. Playback
will begin on the track you selected.
2
TO BEGIN PLAYBACK FROM A SPECIFIC TRACK
CKD9908 O/M.QXD 1/29/01 2:43 PM Page 10
Tabla de contenidos
Otros manuales de Radio reloj de Emerson
Emerson
Emerson CK5888 Manual de usuario
Emerson
Emerson CK5029 Manual de usuario
Emerson
Emerson CKD3810 Manual de usuario
Emerson
Emerson GirlPower GP815 Manual de usuario
Emerson
Emerson SmartSet CKS1900 Manual de usuario
Emerson
Emerson SmartSet CKS1500 Manual de usuario
Emerson
Emerson SmartSet CKD9917BK Manual de usuario
Emerson
Emerson SmartSet ER100103 Manual de usuario
Emerson
Emerson SmartSet CKSW0555 Manual de usuario
Emerson
Emerson CKD2300 Manual de usuario
Emerson
Emerson CKD3630 Manual de usuario
Emerson
Emerson CKD2020 Manual de usuario
Emerson
Emerson CK5052 Manual de usuario
Emerson
Emerson CK9902 Manual de usuario
Emerson
Emerson CKD1100, CKD1100BL, CKD1100GN, Manual de usuario
Emerson
Emerson CK5048 Manual de usuario
Emerson
Emerson cK5027 Manual de usuario
Emerson
Emerson SmartSet ER100202 Manual de usuario
Emerson
Emerson SmartSet ER100104 Manual de usuario
Emerson
Emerson CK5038 Manual de usuario
