COMPACT DISC PLAYER
with STEREO CLOCK RADIO
CKD9907
OWNERS MANUAL
Visit our web site at www.emersonradio. om
CKD9907_ib.p65 2001/4/17, PM 12:1916
1
Thank You..........
for purchasing this CD Cruiser Stereo Clock Radio with Compact Disc Player from
Emerson. This compact unit will wake you up to an electronic bu er alarm, the
AM/FM radio, or your favorite artists on compact disc. It also features a sleep to
music timer that lulls you to sleep to the radio or CD player and then switches the
power off automatically. The battery back up system maintains the correct time
and alarm settings in the event of a power interruption. Two dynamic speakers
provide excellent sound for such a compact si e unit, and all of the important controls
are top mounted for the most user friendly operation.
The serial number of your unit can be found on the bottom of the cabinet. We
suggest that you record the serial number in the space provided below in case
this information is ever needed at a future date.
Model Number: CKD9907
Serial Number: ________________________________
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK,
DO NOT REMOVE COVER (OR BACK). NO USER
SERVICEABLE PARTS INSIDE. REFER SERVICING TO
QUALIFIED SERVICE PERSONNEL.
DANGEROUS VOLTAGE
Uninsulated Dangerous Voltage, that may be of sufficient
magnitude to constitute a risk of electric shock to persons is present
within this product's enclosure.
ATTENTION
The Owner's Manual contains important operating and maintenance
instructions.
For your safety, it is necessary to refer to the manual.
CLASS 1 LASER PRODUCT
CLASS 1 LASER PRODUCT
APPAREIL Á LASER DE CLASSE 1
PRODUCTO LASER DE CLASE 1
CAUTION
INVISIBLE LASER RADIATION
WHEN OPEN AND INTERLOCKS
DEFEATED.
AVOID EXPOSURE TO BEAM
This product contains a low power Laser Device.
CKD9907_ib.p65 2001/4/17, PM 12:191
2
IMPORTANT NOTES
WARNING: TO PREVENT FIRE OR SHOCK HAZARD,
DO NOT EXPOSE THIS UNIT TO RAIN OR MOISTURE.
FCC INFORMATION
This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses, and can radiate radio frequency
energy and, if not installed and used in accordance with the instructions, may
cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television reception, which
can be determined by turning the equipment off and on, the user is encouraged to
try to correct the interference by one or more of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.
This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions:
(1) This device may not cause harmful interference, and
(2) This device must accept any interference received, including interference
that may cause undesired operation.
Do not attempt to clean this unit with
chemical solvents as this might
damage the finish. Use a clean dry
cloth.
Operate controls and switches as
described in the manual.
Store your CDs in a cool area to
avoid damage from heat.
Places exposed to direct sunlight or
close to heat radiating appliances
such as electric heaters, on top of
other stereo equipment that radiates
too much heat, places lacking
ventilation or dusty areas, places
subject to constant vibration and/or
humid or moist areas.
Avoid installing the unit in locations desc ibed below :
CKD9907_ib.p65 2001/4/17, PM 12:192
3
PREPARATION FOR USE
UNPACKING AND SET UP
Remove the unit from the carton and remove all packing material from the unit.
Remove any descriptive labels or stickers from the top or front of the cabinet.
Do not remove any labels or stickers from the back or bottom of the cabinet.
Press the CD Open button to open the CD door. Remove the white transit card
from the CD compartment, if applicable. This card is used to prevent the laser
pick up from moving during shipment. It must be removed from the CD
compartment before you insert a disc.
Remove the twist tie from the AC power cord and extend the cord to its full
length.
Unwind the lead wire FM antenna and extend it to its full length.
Place the radio on a level surface such as a stand, desk, table or shelf, convenient
to an AC outlet, and away from direct sunlight or sources of excess heat, humidity,
moisture, dust or vibration.
BATTERY BACK UP SYSTEM
This clock radio has a battery back up system that will maintain the time and alarm
settings in the event of a temporary power interruption. The system requires one
9-volt battery, not included.
Open the battery door on the bottom of the cabinet and connect a 9-volt battery to
the battery terminals inside the compartment. It can only be connected one way.
Push the battery into the battery compartment and replace the battery door.
If the power is interrupted the clock display goes off and the unit will not operate.
However the battery will maintain the time and alarm settings, and when the power
is restored the time and alarm settings will be correct.
CKD9907_ib.p65 2001/4/17, PM 12:193
4
POWER FAILURE INDICATION
If the battery is exhausted, or there is no battery installed and the power is interrupted,
the time and alarm settings will be lost. When power is restored the clock display
will return to its default setting 12:00 and begin counting forward from that point. If
you notice that the time on the display is incorrect, check your alarm settings as
well. If they are also incorrect this indicates that the power was interrupted and the
battery is exhausted. Replace the battery with a new one and reset both the time
and alarm settings.
POWER SOURCE
This radio is designed to operate on 120V 60H AC house current only. Attempting
to operate this radio from any other power source may cause damage to the unit,
and such damage is not covered by your warranty.
Be sure that the AC outlet you use is always live. Do not connect this unit to an
outlet that is controlled by a wall switch.
This unit has a polari ed AC plug with one wide
blade and one narrow blade. This plug will only
fit into a matching polari ed AC outlet. This is a
safety feature to reduce the possibility of electric
shock. If this plug will not fit in your AC outlet,
you probably have an outdated non-polari ed
outlet. You should have your outdated outlet
changed by a qualified, licensed electrician. Do
not file the wide blade on the plug, or use an
adapter to make the plug fit into your outlet. This
defeats the safety feature and could expose you
to electric shock.
CKD9907_ib.p65 2001/4/17, PM 12:194
5
LOCATION OF CONTROLS
1. POWER On/Off Button.
2. Power On Indicator.
3. SLEEP Button.
4. VOL ME Control.
5. DISPLAY Mode Button.
6. RANDOM Button.
7. ALARM (SET/ON/OFF) Switch.
8. CLOCK Adjust Button.
9. CD Door.
10. AC Power Cord.
11. FM Wire Antenna.
12. Battery Compartment (at bottom cabinet).
13. F NCTION (CD/AM/FM/B ZZER) Switch.
14. CD PROG (Program) Button.
15. CD REPEAT Button.
16. CD SKIP + / HO R Button.
17. T NING Control.
18. CD SKIP / MIN TE Button.
19. CD PLAY/PA SE Button.
20. CD Door OPEN Button.
21. SNOOZE Button.
22. CD STOP Button.
23. Tuning Dial.
24. Speakers.
25. ALARM On Indicator.
26. AM Indicator.
27. LED Display.
28. FM STEREO Indicator.
29. CD RANDOM On Indicator.
30. SLEEP On Indicator.
31. CD REPEAT On Indicator.
32. CD PROG (Program) On Indicator.
'
&%
$
#
"
!
!
"
#
% &
'
$
$
#
"
%
&
"
! ! ! '
!
CKD9907_ib.p65 2001/4/17, PM 12:195
6
OPERATING INSTRUCTIONS
SETTING THE CLOCK
When the unit is first connected to the AC outlet the display will show 12:00 and
will begin counting forward from that point. If no back up battery is installed the
display will revert to this 12:00 default setting every time the AC plug is removed
from the outlet, or whenever the power is interrupted.
To set the display to the co ect time:
1. Depress and hold the CLOCK button. The time display begins to flash.
2. While holding the CLOCK button, depress the SKIP + / HOUR button to adjust
the display to the correct hour. Release the button when the correct hour appears.
NOTE: Be sure to set the clock to the correct AM or PM hour by observing the
AM indicator in the upper left corner of the display. If the AM indicator is On
the time displayed is AM. If the AM indicator is Off, the time displayed is PM.
3. Depress the CLOCK and SKIP / MINUTE buttons to adjust the display to the
correct minute, and then release the buttons. The display stops flashing and the
clock begins to run.
Setting The Wake Up Time
The ALARM switch (SET-ON-OFF) is located on the left side of the cabinet.
1. Slide the ALARM switch to the SET position. The clock display changes from
the correct time to the wake up time and begins to flash.
2. Depress the SKIP + / HOUR button to adjust the display to the desired wake up
hour, AM or PM, then release the button.
3. Depress the SKIP / MINUTE button to adjust the display to the desired wake
up minute, and then release the button.
4. Confirm that the wake up time flashing in the display is correct and then slide
the ALARM switch to either the ON or OFF position.
CKD9907_ib.p65 2001/4/17, PM 12:196
7
LISTENING TO THE RADIO
The FUNCTION selector (CD-AM-FM-BUZZER) is located on the right side of
the cabinet.
1. Slide the FUNCTION selector to either the AM or FM position.
2. Press the POWER button to turn the radio On.
3. Rotate the TUNING control to find the desired station.
NOTE: If you tune to an FM station that is broadcasting in stereo, the FM
STEREO indicator will come On.
4. Adjust the VOLUME control as desired.
5. When you are finished listening, press the POWER button to turn the radio
Off.
Antenna Info mation
AM
The AM antenna is located inside the cabinet.
If AM reception is weak try changing the position
of the cabinet until you find the position that
provides the best reception.
FM
Make sure that the FM lead wire is fully
extended. If FM reception is weak try changing
the position and direction of the antenna until
you find the position that provides the best
reception.
CKD9907_ib.p65 2001/4/17, PM 12:197
8
CD OPERATION
NORMAL PLAYBACK
1. Slide the FUNCTION selector to the CD position.
2. Press the POWER button to turn the unit On.
3. Press the CD door OPEN button. Place
your disc on the center spindle with the
printed label side facing up and gently press
down on the disc near the center hole to make
sure that it is firmly locked in place on the
spindle.
4. Close the CD door, pressing down on the right
side marked CLOSE to make sure that the
door locks properly. The disc will spin as the
player reads the Table of Contents on the
disc. The disc stops and the display shows
the total number of tracks for about 5 seconds
and then returns to the correct time display.
5. Press the PLAY/PAUSE button to begin playback. The display shows 01
and playback begins on track 1. After 5 seconds the display returns to the
correct time. Playback continues until all tracks have been played. To see the
track number during playback presses the DISPLAY button. The track number
appears for 5 seconds and then the correct time reappears.
6. When all tracks have been played the player stops. To stop playback before
the disc ends press the STOP button at any time.
7. Press the CD door OPEN button to open the door. Remove your disc and
close the door. Return your disc to its protective storage case.
8. Press the POWER button to turn the power Off.
PAUSE OPERATION
To pause momentarily press the PLAY/PAUSE button during playback. The
sound stops but the disc continues to spin. The track number flashes for 5 seconds
and then the correct time reappears. Press PLAY/PAUSE button again to
cancel pause and resume normal playback.
CKD9907_ib.p65 2001/4/17, PM 12:198
9
SKIP TRACK AND MUSIC SEARCH FUNCTIONS
To begin playback from a specific track
After inserting your disc press the SKIP + / HOUR or SKIP / MINUTE button
until the desired track number appears on the display, then press the PLAY/
PAUSE button to begin playback on that track.
To skip tracks during playback
Press the SKIP + / HOUR or SKIP / MINUTE button repeatedly during playback
until the desired track number appears on the display, then release the button.
The player moves ahead or back to the beginning of the desired track.
To search for a specific part of a track
During playback depress and hold the SKIP + / HOUR or SKIP / MINUTE
button. The player searches rapidly forward or backward through the track and
the track number appears on the display. When you reach the desired point on
the track release the buttons. Normal playback resumes at that point and the
display returns to the correct time.
REPEAT PLAYBACK
To repeat a single track
Select the track to be repeated with the SKIP + or SKIP buttons, then press the
REPEAT button once. The REPEAT indicator flashes. Press PLAY/PAUSE
to begin playback. The selected track will be repeated continuously.
To repeat the entire disc
Press the REPEAT button twice. The REPEAT indicator remains On. Press
PLAY/PAUSE button to begin playback. The entire disc will be repeated
continuously.
NOTE: The repeat function can be activated while the disc is playing or while
the disc is stopped.
To cancel repeat playback
Press the STOP button or press the REPEAT button until the REPEAT
indicator goes Off.
CKD9907_ib.p65 2001/4/17, PM 12:199
Otros manuales para Cd Cruiser CKD9907
1
Tabla de contenidos
Otros manuales de Reproductor de CD de Emerson
Emerson
Emerson CD Cruiser HD2700 Manual de usuario
Emerson
Emerson SpongeBob Squarepants SB250 Manual de usuario
Emerson
Emerson SpongeBob Squarepants SB280 Manual de usuario
Emerson
Emerson PD6900 Manual de usuario
Emerson
Emerson PD6559BL Manual de usuario
Emerson
Emerson PD3500RD Manual de usuario
Emerson
Emerson HD8118 Manual de usuario
Emerson
Emerson HD8120 Manual de usuario
Emerson
Emerson SpongeBob Squarepants SB220 Manual de usuario
Emerson
Emerson PD5812 Manual de usuario
Emerson
Emerson PD6513 Manual de usuario
Emerson
Emerson SpongeBob SquarePants SB260 Manual de usuario
Emerson
Emerson PD6810 Manual de usuario
Emerson
Emerson HD7098 Manual de usuario
Emerson
Emerson PD5098 Manual de usuario
Emerson
Emerson HD7295 Manual de usuario
Emerson
Emerson HD8100R Manual de usuario
Emerson
Emerson HD7998 Manual de usuario
Emerson
Emerson PD6871 Manual de usuario
Emerson
Emerson PD6920 Manual de usuario
