V700L Managed Single Master / Slave LAN Extender USER’S MANUAL Ver. B.2

Trademarks

Other brand and product names are registered trademarks or trademarks of their respective holders.

Legal Disclaimer

The information given in this document shall in no event be regarded as a guarantee of conditions or characteristics. With respect

to any examples or hints given herein, any typical values stated herein and/or any information regarding the application of the

device, Manufacturer hereby disclaims any and all warranties and liabilities of any kind, including without limitation warranties of

non-infringement of intellectual property rights of any third party.

Statement of Conditions

In the interest of improving internal design, operational function, and/or reliability, Manufacturer reserves the right to make changes

to the products described in this document without notice. Manufacturer does not assume any liability that may occur due to the

use or application of the product(s) or circuit layout(s) described herein.

Maximum signal rate derived from IEEE Standard specifications.Actual data throughput will vary. Network conditions and

environmental factors, including volume of network traffic, building materials and construction, and network overhead, lower actual

data throughput rate. Manufacturer does not warrant that the hardware will work properly in all environments and applications, and

makes no warranty and representation, either implied or expressed, with respect to the quality, performance, merchantability, or

fitness for a particular purpose. Make sure you follow in line with the environmental conditions to use this product.

V700L Managed Single Master / Slave LAN Extender USER’S MANUAL Ver. B.2

Safety Warnings

For your safety, be sure to read and follow all warning notices and instructions before using the device.

DO NOT open the device or unit. Opening or removing the cover may expose you to dangerous high voltage points or other

risks. ONLY qualified service personnel can service the device. Please contact your vendor for further information.

Use ONLY the dedicated power supply for your device. Connect the power to the right supply voltage (110V AC used for

North America and 230VAC used for Europe. V700L supports 12 VDC power input).

Place connecting cables carefully so that no one will step on them or stumble over them. DO NOT allow anything to rest on

the power cord and do NOT locate the product where anyone can work on the power cord.

DO NOT install nor use your device during a thunderstorm. There may be a remote risk of electric shock from lightning.

DO NOT expose your device to dampness, dust or corrosive liquids.

DO NOT use this product near water, for example, in a wet basement or near a swimming pool.

Connect ONLY suitable accessories to the device.

Make sure to connect the cables to the correct ports.

DO NOT obstruct the device ventilation slots, as insufficient air flow may harm your device.

DO NOT place items on the device.

DO NOT use the device for outdoor applications directly, and make sure all the connections are indoors or have waterproof

protection place.

Be careful when unplugging the power, because it may produce sparks.

Keep the device and all its parts and accessories out of the reach of children.

Clean the device using a soft and dry cloth rather than liquid or atomizers. Power off the equipment before cleaning it.

This product is recyclable. Dispose of it properly.

V700L Managed Single Master / Slave LAN Extender USER’S MANUAL Ver. B.2

Attention:

Be sure to read this manual carefully before using this product. Especially Legal Disclaimer, Statement

of Conditions and Safety Warnings.

V700L is a Managed Single Master/Slave LAN Extender that leverages the extraordinary bandwidth promise of VDSL2 technology

(max. 100Mbps symmetric), the next step in the delivery of new high-speed Internet applications in commercial environments. Quick,

easy, economical to install and maintain, the V700L works over existing copper wire infrastructure. V700L is a Master(CO side)

device. And also can switch as Slave(CPE side) by web config menu.

V700L will allow operators worldwide to compete with cable andsatellite operators by offering services such as HDTV, VOD,

videoconferencing, high speed Internet access and advanced voice services including VoIP, over a standard copper

telephone cable. V700L is seen by many operators as an ideal accompaniment to a FTTP rollout, where for instance fiber optic is

supplied direct to an apartment block and from there copper cable is used to supply residents with high-speed VDSL2.

Caution:

The V700L is for indoor applications only. This product does not have waterproof protection, please do not use in outdoor

applications.

V700L Managed Single Master / Slave LAN Extender USER’S MANUAL Ver. B.2

Table of Contents

COPYRIGHT ......................................................................................................................................................................................................................................................... 1

1.1 CHECK LIST .................................................................................................................................................................................................................................................... 7

CHAPTER 2. INSTALLING THE MODEM ........................................................................................................................................................................................................ 7

2.1 HARDWARE INSTALLATION ............................................................................................................................................................................................................................. 8

2.2 PRE-INSTALLATION REQUIREMENTS................................................................................................................................................................................................................ 8

2.3 GENERAL RULES............................................................................................................................................................................................................................................. 8

2.4 CONNECTING THE RJ-11 /RJ-45 PORTS.......................................................................................................................................................................................................... 9

2.5 POINT TO POINT APPLICATION.................................................................................................................................................................................................................... 10

CHAPTER 3. HARDWARE DESCRIPTION ................................................................................................................................................................................................... 12

3.1 FRONT PANEL................................................................................................................................................................................................................................................ 13

3.2 FRONT INDICATORS....................................................................................................................................................................................................................................... 14

3.3 REAR PANEL ............................................................................................................................................................................................................................................... 15

CHAPTER 4. CONFIGURE THE V700LVIAWEB MANAGEMENT MENU............................................................................................................................................ 17

4.1 BASIC SETUP ............................................................................................................................................................................................................................................ 18

4.1.1 Login Webpage............................................................................................................................................................................................................................... 19

4.1.2 Display status.................................................................................................................................................................................................................................. 19

4.2 SELECT THE MENU LEVEL.......................................................................................................................................................................................................................... 20

4.3 SYSTEM ....................................................................................................................................................................................................................................................... 21

4.3.1 Configuration Backup................................................................................................................................................................................................................... 22

4.3.2 Configuration Restore................................................................................................................................................................................................................... 23

V700L Managed Single Master / Slave LAN Extender USER’S MANUAL Ver. B.2

4.3.3 Update Software............................................................................................................................................................................................................................. 24

4.3.4 Account Management ................................................................................................................................................................................................................... 25

4.3.5 Log Level.......................................................................................................................................................................................................................................... 26

4.3.6 Service Control ............................................................................................................................................................................................................................... 27

4.3.7 CWNP (TR-069 Settings)............................................................................................................................................................................................................... 29

4.3.8 Internet Time.................................................................................................................................................................................................................................... 30

4.3.9 Restore Default ............................................................................................................................................................................................................................... 31

4.4 STATUS SETUP............................................................................................................................................................................................................................................ 32

4.4.1 LAN Network.................................................................................................................................................................................................................................... 33

4.4.2 Ethernet ............................................................................................................................................................................................................................................ 34

4.4.3 WAN(Line) Statistics...................................................................................................................................................................................................................... 35

4.4.4 LAN Statistics.................................................................................................................................................................................................................................. 36

4.4.5 ARP .................................................................................................................................................................................................................................................... 37

4.5 XDSL SETUP............................................................................................................................................................................................................................................... 38

4.5.1 Master/Slave mode & profile Config.......................................................................................................................................................................................... 39

4.5.1.1 VDSL Config Overview .............................................................................................................................................................................................................. 40

4.6 LAN SETUP................................................................................................................................................................................................................................................. 41

4.6.1 IPv4 Configuration ......................................................................................................................................................................................................................... 42

4.6.2 IPv6 Configuration:........................................................................................................................................................................................................................ 43

4.6.3 IPv6Static Route ............................................................................................................................................................................................................................. 44

4.6.4 Ethernet Mode................................................................................................................................................................................................................................. 46

4.7 QOS SETUP................................................................................................................................................................................................................................................. 47

4.7.1 Qos Queue ....................................................................................................................................................................................................................................... 48

4.8 APPLICATIONS............................................................................................................................................................................................................................................. 49

V700L Managed Single Master / Slave LAN Extender USER’S MANUAL Ver. B.2

4.8.1 Telnet Service Setup(for Security)............................................................................................................................................................................................. 50

4.8.2 SSH Service(Telnet Encryption)................................................................................................................................................................................................. 51

4.8.3 Printer Sharing................................................................................................................................................................................................................................ 52

4.8.4 Multimedia Sharing........................................................................................................................................................................................................................ 53

4.8.5 UPnP.................................................................................................................................................................................................................................................. 54

4.8.6 Multicast IGMP................................................................................................................................................................................................................................ 55

4.8.7 Multicast MLD (IPv6)...................................................................................................................................................................................................................... 56

4.8.8 SNMP................................................................................................................................................................................................................................................. 57

4.9 USB SETUP................................................................................................................................................................................................................................................. 60

4.9.1 Storage Device Info ....................................................................................................................................................................................................................... 61

4.9.2 Samba Service ................................................................................................................................................................................................................................ 62

4.9.3 FTP Server........................................................................................................................................................................................................................................ 63

4.9.4 FTP Client......................................................................................................................................................................................................................................... 64

4.9.5 TFTP Server..................................................................................................................................................................................................................................... 68

APPENDIX A: CABLE REQUIREMENTS ...................................................................................................................................................................................................... 69

APPENDIX B: PRODUCT SPECIFICATION.................................................................................................................................................................................................. 72

APPENDIX C: TROUBLESHOOTING ............................................................................................................................................................................................................ 76

APPENDIX E: COMPLIANCE INFORMATION............................................................................................................................................................................................ 84

WARRANTY......................................................................................................................................................................................................................................................... 87

CHINESE SJ/T 11364-2014............................................................................................................................................................................................................................... 88

V700L Managed Single Master / Slave LAN Extender USER’S MANUAL Ver. B.2

Chapter 1. Unpacking Information

1.1 Check List

Thank you for choosing V700L Before installing the router, please verify the contents inside the package.

Package Contents:

1 x VDSL2 CO Modem

1 x QR code for user’s

manual hyperlink.

Accessory Kit : 1 x Ethernet Cable, 1 x Phone wire , 1 x

DC12V Power Adapter

Notes:

1. Please inform your dealer immediately for any missing or damaged parts. If possible, retain the carton including the

original packing materials. Use them to repack the unit in case there is a need to return for repair.

2. Do not use sub-standard power supply. Before connecting the power supply to the device, be sure to check

compliance with the specifications. The V700L uses a DC12V/1A or above Switching power supply.

Chapter 2. Installing the Modem

V700L Managed Single Master / Slave LAN Extender USER’S MANUAL Ver. B.2

2.1 Hardware Installation

This chapter describes how to install the modem, and establish the network connections. The V700L may be installed

on any level surface (e.g. a table or shelf). However, please take note of the following minimum site requirements

before you begin. The V700L has 2 pre-installed rubber feet.

2.2 Pre-installation Requirements

Before you start the actual hardware installation, make sure you can provide the right operating environment, including

power requirements, sufficient physical space, and proximity to other network devices that are to be connected.

Verify the following installation requirements:

Power requirements: DC 12 V / 1A

The modem should be located in a cool dry place, with at least 10cm/4in of space at the front and back for

ventilation.

Place the modem away from direct sunlight, heat sources, or areas with a high amount of electromagnetic

interference.

Check if the network cables and connectors needed for installation are available.

Do not install phone lines strapped together with AC power lines, or telephone office line with voice signal.

Avoid installing this device with radio amplifying stations nearby or transformer stations nearby.

2.3 General Rules

Before making any connections to the modem, please note the following rules:

V700L Managed Single Master / Slave LAN Extender USER’S MANUAL Ver. B.2

Ethernet Port interface : RJ-45

All network connections to the modem Ethernet port must be made using Category 5 UTP/STP or above for

100 Mbps, Category 3, 4 UTP for 10Mbps.

No more than 100 meters of cabling may be use between the MUX or HUB and an end node.

VDSL2 Port interface : RJ-11 & Terminal block combo

All network connections to the RJ-11/ terminal block(sharing port) must use 24~26 gauge with single

twisted pair phone wire.

We do not recommend the use of the 28 gauge phone wire or above.

The RJ-11 is an 6P2C connector, two of which are wired. The modem uses the center two pins. The pin out

assignment for these connectors is presented below.

Please note that the line port is no polarity, therefore user can reverse the two wires of the phone cable

when installed. RJ-11 Pin out Assignments

Pin#

MNEMONIC

FUNCTION

Unused

DSL

Used

DSL

Used

Unused

2.4 Connecting the RJ-11 / RJ-45 Ports

The line port have 1 connector: RJ-11 . It is used to connect with V700L Master side over a single pair phone wire to V700L

Tabla de contenidos

Manuales populares de Extensor de otras marcas

SY HDBT-60T Manual de usuario

Appsys ProAudio

Appsys ProAudio ADX-16 Manual de usuario

Atlona

Atlona RS232 Manual de usuario

IDK

IDK OPF-TH1000-A Manual de usuario

Enable-IT

Enable-IT 824WP Manual de usuario

Worx

Worx Landroid RadioLink WA0864 Hoja de especificaciones

TP-Link

TP-Link TL-WA730RE Manual de usuario

Camplex

Camplex CMX-HDMI-SFPL Manual de usuario

SC&T

SC&T HE03-4K Manual de usuario

Marmitek

Marmitek MegaView70 Manual de usuario

Samsung

Samsung SCS-26UC4 Manual de usuario

Foxun

Foxun SX-GES24 Manual de usuario

MuxLab

MuxLab 500771 Manual de usuario

foxunhd

foxunhd SX-AEX01 Manual de usuario

TERK Technologies

TERK Technologies LFIRX2 Manual de usuario

Devolo

Devolo Audio Extender Manual

Edimax

Edimax EW-7438RPn V2 Manual de usuario

Shinybow USA

Shinybow USA SB-6335T5 Manual de usuario
