Element One CONMIC FLAP Manual de usuario

Installation and Operating Instructions (EN)

CONMIC FLAP

CONMIC FLAP Extended

Installation and Operating Instructions CONMIC FLAP / CONMIC FLAP Extended (EN)

Explanation of symbols

Important Note

Caution

Ban

Installation and Operating Instructions CONMIC FLAP / CONMIC FLAP Extended (EN)

Dear Customer,

thank you very much for purchasing our

product.

Please read this installation and operating

instructions carefully and keep them in a safe

place.

In this manual we have endeavored to

provide you with all the necessary information

to enable you to have most success with the

products.

Ralf Küchel

Technical Manager / CTO

Installation and Operating Instructions CONMIC FLAP / CONMIC FLAP Extended (EN)

Table of Contents

Table of Contents ......................................................................................................................................................... 2

Commissioning Date .................................................................................................................................................... 3

Notes ........................................................................................................................................................................ 3

Description ................................................................................................................................................................... 5

Features ....................................................................................................................................................................... 5

Dimensions ................................................................................................................................................................... 6

Safety Instructions ....................................................................................................................................................... 7

Installation ................................................................................................................................................................... 8

Commissioning ........................................................................................................................................................... 10

General Information .............................................................................................................................................. 10

CONMIC FLAP | CONMIC FLAP Extended .............................................................................................................. 11

Operation ................................................................................................................................................................... 13

General Information .............................................................................................................................................. 13

Raising .................................................................................................................................................................... 13

Microphone operation ........................................................................................................................................... 14

Retracting ............................................................................................................................................................... 14

Service function DIRECT AXLE ACCESS (DAA) ......................................................................................................... 15

Care Instructions ........................................................................................................................................................ 16

TCP/IP - Control and Status request .......................................................................................................................... 17

Control via a Media Control System with 9-pin d-sub Remote Interface .................................................................. 18

Firmware Update (Authorized Personnel only) ........................................................................................................ 18

Technical Specification ............................................................................................................................................... 19

Safety Standards ........................................................................................................................................................ 20

Declaration of Conformity ......................................................................................................................................... 20

Warranty .................................................................................................................................................................... 21

Installation and Operating Instructions CONMIC FLAP / CONMIC FLAP Extended (EN)

Commissioning Date

Date:

Serial No.:

Keep this document for future reference.

Pass on this document when you pass on the device.

Notes

Installation and Operating Instructions CONMIC FLAP / CONMIC FLAP Extended (EN)

Scope of Supply

 CONMIC FLAP | CONMIC FLAP Extended

 Table Power Supply - Input: 100-240V AC, 50 / 60Hz. 1.5A; Output: 12V 60W

 MAX 5.A (Cable Length DC ~ 140cm)

 Power Cable 1.5m

 Installation and Operating Instructions / Manual

 [A microphone is not included in the standard scope of delivery].

Installation and Operating Instructions CONMIC FLAP / CONMIC FLAP Extended (EN)

Description

The CONMIC FLAP system includes an electromotive retractable microphone carrier with a mounting

frame for installation in a horizontal furniture surface.

In the starting position (retracted), the system is level to the furniture surface and covered by a

closing flap. By pressing a button, the microphone (not included in the standard scope of delivery)

drives into the working position (extended). By pressing again the button, the retraction is

triggered. Both movements can be paused by a short push of a button.

The sturdy frame and high-quality mechanical elements ensure smooth running without jerks or

vibrations.

To prevent personal injury and damage, CONMIC FLAP has been equipped with a safety control

system. If counterforces of 20 N or more occur during extension or retraction, an acoustic signal

sounds and the process is interrupted, and a countermovement is initiated for approx. 1 sec.

Features

 Compact housing dimensions

 Lightweight-Design

 Brushed stainless steel mounting frame and closure flap

 LowNoiseDesign & LowEnergy Design

 RJ 45 Interface for TCP/IP Remote conrol

 9-pin dSub interface for remote control via potential-free switch

 DirectAxleAccess for optional, manual movement

 Digital stepper motor 12V motor, toothed belt drive

 German precision mechanism

 Electronic & Acoustic Diagnostic System

 Durable HighFlex cables

 Integrated universal mounting rails

 All-aluminum housing

 Convenient cable & connection position

 EMC + EMI protected

Installation and Operating Instructions CONMIC FLAP / CONMIC FLAP Extended (EN)

Dimensions

Installation and Operating Instructions CONMIC FLAP / CONMIC FLAP Extended (EN)

Safety Instructions

= Important Note

= Caution

= Ban

The device may only be opened by authorized personnel when it is disconnected from the

power supply!

Let damage and defects be repaired immediately by authorized specialists.

Do not operate this device with any accessories other than the supplied ones.

Gehäuse niemals gewaltsam öffnen oder schließen!

In the event of damage caused by third-party accessories, e.g. power supply unit, or

unauthorized attachments or modifications, any warranty and liability claims are excluded.

Remove all transport locks before start-up. We recommend that you keep them.

To avoid signal transmission errors, use only high-quality cables.

Do not slide sharp or hard objects over the surface, it may be damaged.

Immediately remove any liquids spilled on the surface with a cloth.

Do not load the device with more than 1.0 kg when closed.

Installation and Operating Instructions CONMIC FLAP / CONMIC FLAP Extended (EN)

Installation

= Important Note

= Caution

= Ban

Make sure that your furniture has sufficient load-bearing capacity and strength against

deflection and warping even after it has been weakened by the cut-out!

Stresses on the mechanics due to tension, pressure or shock can lead to damage or

malfunctions. Therefore, ELEMENT ONE devices should not be transported in their installed

state!

In the case of mandatory transport in the installed state, the following conditions must be

observed:

 Retract microphone carrier | Close device

 Transport and store devices vertically, i.e. according to the installation position

 Do not tilt furniture with built-in appliances

 Secure devices against slipping and falling out

 observe the permissible load on the device, do not stack it.

ELEMENT ONE units are held in the furniture by means of the decorative/holding frame. The

optionally supplied clamping holders to be attached at the side are intended for horizontal

alignment and fastening in the furniture. Please note that these may only be applied lightly

(risk of damage to the furniture or tensioning of the device mechanics and thus possible

malfunction of the movement mechanics).

For customer´s mounting, ELEMENT ONE will provide an installation drawing upon request.

The table cutout must be milled or sawn out before mounting the unit and according to the

installation drawings (see dimensions)

It is recommended to install the device with two people.
