INSTRUCTIONS MANUAL

EW 524 T

146 1241 04 GB

WASHINGMACHINE

CONTENTS

For the user

Safety instructions 4/5

Description of the appliance 6

Use of your appliance 7

Operating instructions 8/9

Programme chart 10/11

Hints & Tips 12-14

Cleaning and maintenance 15

If something doesn't work 16/17

Service 18

For the installer

Technical information 19

Installation

Unpacking 19

Installation 20

Levelling 20

Moving of the appliance 20

Water connection 21

Electrical connection 21

Guide to use the instruction

The following symbols will be found in the text to guid you

throughout the instructions :

Safety instructions

Hints and tips

Environmentalinformation

You must read the whole of this instruction book

before you use the appliance. Follow the advice

carefully.Keep thebook forfuture reference.If you

sell or give away the appliance, make sure that the

book is passed to the new owner.

The following warnings are provided in the interest

of overall safety. You must read them before the

appliance is installed or used.

Use

This appliance is designed to be used by

adults. Children should not be allowed to touch

the controls or play with the product.

It is dangerous to modify the specifications of

this appliance in any way.

Always unplug the appliance and turn off the

water after use.

Only wash fabrics with are designed to be

machine washed. If in doubt, follow the instruc-

tions you find on the label of the item itself.

Place small metal rings or edged plastic rings

in a net or bag.

Make sure that all pockets are empty. Hard,

sharp objects such as coins, safety pins, nails,

screwsor stones can cause extensivedamage.

Do not machine wash fabrics which are

saturated with petroleum products. If volatile

cleaning fluids have been used, make sure

that they are thoroughly removed from the

fabrics before they are placed in the appliance.

Small and delicate objects (e.g. baby socks,

stockings) can be easily washed inside a small

pillowcase with a zip fastener or in larger

socks.

Use only the recommended quantities of fabric

conditioner.

Beforecleaning,care and maintenance,ensure

that the machine is unplugged.

Installation

Any electrical work required to install this

appliance should be carried out by a qualified

electrician or competent person.

Any plumbing work required to install this

appliance should be cariied out by a qualified

plumber or competent person.

Make sure that the appliance does not stand

on its electrical supply cable.

This appliance is heavy. Care should be taken

when moving it.

Allpackaging and transitbolts mustbe removed

before the appliance is used. Serious damage

may occur if this is not done.

If your washing machine is in a room subject to

temperatures below freezing, the water must

be removed from the machine. So, the danger

of freezing should be expected.

SAFETY INSTRUCTIONS

Read all instructions before using

the appliance and save them for

future reference.

Safeties

Lid : your washing machine is equipped with

asafety avoidingthe switching of theappliance

when the flapdoors of the drum are opened ;

the closure of the lid is so impossible. An

electromechanic safety prohibits the opening

of the lid when the washing machine works and

2 minutes after the end of the programme.

Washing motor : in case of mechanic

overloading, overvoltage, a thermic safety

protects automatically the motor.

Heating : the heating can only begin when

the water quantity necessary for the washing

is in the tub. This safety is useful when there is

a water break-up or if you forget to open the

water inlet hose.

Environmental information

All materials marked by the symbol are

biodegradable. They can be disposed of without

danger or burnt in rubbish incinerators.

In order to realize water and energy savings and to

act in an environmentally conscious manner, we

advice to follow the below instructions :

Use if possible the appliance with full loads

instead of partial loads. Take care to do not

overload the drum.

Use only the programmes with prewash for very

soiled laundry.

Savings on detergent and for the environment

may also be achieved if with medium to hard

water you add sufficient detergent for soft water

andthenadd separately asoftener. This relieves

our waters of a certain amount of chemicals.

When disposing of the machine in a proper

manner, destroy the door lock and cut off the

power supply cord.

DESCRIPTION OF THE APPLIANCE

1234

Detergent dispenser

Symbols

()Washing powder for programmes with

prewash (1).

()Washing powder or liquid detergent for

the main wash (2).

()Bleach compartment (3).

()Liquid additives (fabric softener and

conditioner...) (4).

(5) Overflow orifice

Control panel

Lid

Handle for opening lid

Trap door for lint filter

Lever for castors

Pushbuttons

Programme selector Temperature selector

Light

USE OF YOUR APPLIANCE

The control panel

1ON/OFF pushbutton " "

Press the ON/OFF pushbutton, the programme

starts : the control lamp lights on.

2Control lamp

The control lamp lights on when the appliance is

working (on/off pushbutton " " pressed). It lights

off when the on/off pushbutton " " is pressed out.

3Half load pushbutton " "

This pushbutton allows to wash small quantity of

linen not much soiled (2,5 kg) only on the cotton

programmes.

4Spinning suppression push-

button " "

This pushbutton allows to end the cotton program-

mes without spinning. They finish then only by a

draining.

Never turn the programme selector when the appliance is working.

5Programme selector

It enables to select the most adapted programme

to the nature and degrees of soil of your laundry.

Turn the programme selector clockwise to select

the chosen programme.

The programme selector indicates each pro-

gramme phase as it takes place.

At the end of the programme, the appliance stops

automatically on a position "I" for cotton program-

mes or on a position rinse hold " " for synthetics

programmes.

Neverturn the programme selector anticlockwise.

6Temperature selector

Itenablestochoosethemostaadaptedtemperature

between cold ( ) and 90°C.

Choosethe temperaturewhich correspondsto the

chosen programme, with the help of the indica-

tions or the programme table, according to the

fibers and the fastness of the colours.

2 3 4156

OPERATING INSTRUCTIONS

1. Place the laundry in the drum

lift up the lid of the machine.

open the drum with your two hands by pressing

the button Aand the two flapdoors till they

disengage.

introduce the laundry into the drum ; close the

drum and the lid of the machine.

Becareful :before closing thelid of your machine,

make sure that the drum flapdoors are correctly

closed :

the two flapdoors fastened,

the button Apressed out.

2. Measure out the detergent

Measure out the amount of detergent

recommended by the manufacturer in the main

wash compartment ( ).

Ifyou wish to carry out a prewash, pour the amount

required into the prewash compartment ( ).

3. Add the bleach agent, if required

You may use a bleach agent on cotton program-

mes.However,makesurethat the fabric withstands

the treatment. Bleach is automatically washed

down into the drum. Pour 1/4 to 1 glass of 12° chl

bleach into compartment marked ( ) before

switching the machine on.

4. Add the fabric softener

Pourthesoftener, ifrequired, into thecompartment

marked ( ). Do not exceed the MAX level.

Your washing machine has been conceived in

order to save water and detergent products.

Pleasetakecarethefilling levelofthedetergent

productsdonotexceed theMAXmarks located

near the display window of your detergent

dispenser.

5. Press the half load pushbutton

""or/and the spinning suppres-

sion pushbutton " " if required.

Liquiddetergent

only compartment

Powder detergent

Compartment

(prewash)

Compartment

(wash)

Before using your appliance for the first time, we recommend that you do a

preliminarywash withthe machineempty, as aprecaution toclean the drum, the tub

and the detergent dispenser.

1. Pour a dose of detergent in the “washing” compartment.

2. Select the "whites 90°C" program without prewash.

3. Press the on/off button " ". The cycle starts.

6. Select the temperature

Choosethe temperaturewhich correspondsto the

chosen programme, with the help of the indica-

tions or the programme table, according to the

fibers and the fastness of the colours.

7. Select the programme

Choose the programme according to the nature

and the degree of soil of the laundry.

Turn the programme selector clockwise to select

the chosen programme.

8. Starting of the programme

The ON/OFF pushbutton " " enables to switch

on your machine. The control lamp lights on and

the programme begins.

9. At the end of the programme

When the selected programme is over, the ma-

chine stops automatically. The timer knob stops

on the position "I" for the cotton programmes.

The synthetics programmes end by a rinse hold

"" in order to avoid the formation of creases. You

can finish these programmes by a spinning (pro-

gramme G) or by a draining (programme N).

Depress the on/off pushbutton " " before doing

your choice.

After each wash, depress the on/off pushbutton

"". Press off the pushbuttons if necessary ;

unplug the machine from the wall socket ; turn off

the water tap.

PROGRAMMES CHART

Programmes for cotton/linen

Maximum load : 5,0 kg (cotton)

Programmes description Temperatures

(°C)

Water

consumption

in liters

Time in

minutes

(2)

White with prewash

White ( )

Coloured

Short programme

Rinsing

Spinning

60 - 90

40 - 60

30 - 40

Detergent

dispensers

to use

(1)

() recommended program for comparisons based on standard IEC 456. Thermostat at 60°.

(1) if the laundry can withstand the bleaching treatment.

(2) Program times given in the above table are provided as a guide and may vary depending on the water

supply temperature and pressure, and your electricity power supply mains voltage.

The temperatures given in the programs table are provided as a guide. You can vary them using the

thermostat knob on your washing machine. Always scrupulously respect the temperature shown on the

label on each item of washing.

BE CAREFUL :

THE LID CAN ONLY BE OPENED 2 MINUTES AFTER THE MACHINE HAS STOPPED.

150

135

110

Programmes for synthetics/delicates/wool

Maximum loads : 2,5 kg (synthetics), 1 kg (wool).

Synthetics

with prewash

Synthetics

Delicate

Wool

Rinsing

Drain

40 - 60

30 - 40

- 40

Programmes description Temperatures

(°C)

Water

consumption

in liters

Time in

minutes

(1)

Detergent

dispensers

to use

(1) Program times given in the above table are provided as a guide and may vary depending on the

water supply temperature and pressure, and your electricity power supply mains voltage.

The temperatures given in the programs table are provided as a guide. You can vary them using the

thermostat knob on your washing machine. Always scrupulously respect the temperature shown on the

label on each item of washing.

BE CAREFUL :

THE LID CAN ONLY BE OPENED 2 MINUTES AFTER THE MACHINE HAS STOPPED.

Tabla de contenidos

Otros manuales de Arandela de Electrolux

Electrolux

Electrolux EWF 890 Manual de usuario

Electrolux

Electrolux washing machine Manual de usuario

Electrolux

Electrolux EWT 805 Manual de usuario

Electrolux

Electrolux Rex RWP 86109 W Manual de usuario

Electrolux

Electrolux EA2F6820CF Manual de usuario

Electrolux

Electrolux EWF 10240 W Manual de usuario

Electrolux

Electrolux EWB 76210 W Manual de usuario

Electrolux

Electrolux EWF 1145 Manual de usuario

Electrolux

Electrolux EW 1100 F Guía rápida

Electrolux

Electrolux STAR-EFLS210TIW Manual de usuario

Electrolux

Electrolux EIFLW55HIW - 27" Front-Load Washer Manual de instrucciones

Electrolux

Electrolux WH6-8CV Manual de usuario

Electrolux

Electrolux EW6F328WU Manual de usuario

Electrolux

Electrolux EWF 1274BW Manual de usuario

Electrolux

Electrolux EWF 169542 W Manual de usuario

Electrolux

Electrolux EWF 12780 W Manual de usuario

Electrolux

Electrolux EWT 1367 EDW Manual de usuario

Electrolux

Electrolux EWF 1476 GDW Manual de usuario

Electrolux

Electrolux LAVAMAT 42230 Manual de usuario

Electrolux

Electrolux EWF 12270W Manual de usuario

Electrolux

Electrolux EW 1077 F Manual de usuario

Electrolux

Electrolux EWF 1220 Manual de usuario

Electrolux

Electrolux EWF12935S Manual de usuario

Electrolux

Electrolux EWFLS70J IW Guía de inicio rápido

Manuales populares de Arandela de otras marcas

Tricity Bendix

Tricity Bendix AW 1000 W Guía del producto

Panasonic

Panasonic NA-F60L5WRB Manual de usuario

GE WSLP1500 Manual

Bosch

Bosch WAN2829BSN Manual de usuario

LG TV2516DV3B Manual de usuario

LG TH2517DSAV Manual de usuario

VESTEL

VESTEL CMH-XL 7510 TE Manual de usuario

AEG

AEG 74335 Manual de operación

Johnson

Johnson JWF721A Manual de usuario

Beko

Beko WTE7604XLW0 Manual de usuario

Danby

Danby DTT100A1WDB Instrucciones de montaje

Amica

Amica WA 14 Ex Manual de usuario

Daewoo

Daewoo DWD-F1222 Manual de usuario

Bosch

Bosch WAS28461AU Manual de usuario

Miele

Miele PW 6080 Vario Manual de usuario

Finlux

Finlux FLX108CF220 Manual de usuario

Whirlpool

Whirlpool 3LBR5132AN0 Manual de usuario

Beko

Beko WKB 51231 PTMA Manual de usuario
