Electrolux ECT9281G Manual de usuario

ECT9281G

ECT6281G

ECT9281G

ECT6281G

Fig.4

ECT9281G

ECT6281G

Chimney

Oil cup

Aluminum pipe

Hood mounting bracket

5Mounting screws(ST 5X 50MM)

5Drywall Anchors

DamperDamper

set

276

279

545

505

598/898

83Flue cover fixing screws(ST 3.9X 100MM)

92Magnet

1Duct fixing tape

1User manual

700

286mm

190

62mm

Min.565

Install the wall bracket with screws to the wall as

marked(Fig.6) .

Hang the hood on the wall bracket(Fig.7).

Range hood

mounting points

Auxiliary mounting

points

6.Install two additional hood body mounting screws

into the auxiliary mounting holes to secure the

hood body in place.(Fig.8)

Mounting screws

Fig.5

Fig.6

Fig.7

Fig.8

Fig.9

(Fig.5)

(Fig.9)

tapes

Self-clean

Self-clean instruction

1.Remove the metal grease filter.

2.Reassemble the flue cover onto the hood body and

use supplied screws to fix it on the correct position.

1. Remove the grease filter by unscrewing 2pcs screws.

This will disengage the filter from the hood. Tilt the filter

downward and remove(Fig.11).

2，Wash the filter, taking care not to bend them. Allow

them to be dry before refitting.

3. To install the grease filter, push filter into position

and release. Rescrew two screws .Make sure the filter

is securely engaged after assembly.

1.Extract the guard by levering it off with a small screwdriver

or similar tools.

2.Replace the damaged LED, only use. LED DC12V,2W Max.

WARNING:

1. Always switch off the electrical supply before carrying

out any operation on the appliance.

2. Only a qualified and trained service technician can

undertake the work of bulbs replacement and servicing.

NOTE:We recommend only using lamps of the same

specification as the ones being replaced.

Fig.10

Fig.11

Fig.12

(Fig.10)

(Fig.12)

This product is equipped with self-clean technology.

The self-clean function will be automatically triggered

after the motor works for 15hours.

User also can tap the self-clean button to trigger the

self-clean function.

The red indicator will start glowing during the cleaning

process.

The time period for Self-clean is 10 to 15 minutes. The

product can be used during self-clean.

Philippines

Consumer Care Center Toll Free:

1-800-10-845-CARE(2273)

Consumer Care Hotline:(+63 2)845-CARE(2273)

Electrolux Philippines,lnc.

Unit B 12F Cyber Sigma Bldg, Lawton Avenue,

McKinley West,Taguig, Philippines 1634

Trunkline:+63 2 737-4757

Website:www.electrolux.com.ph

Email:wecare@electrolux.com

Vietnam

Consumer Care Center Toll Free

1800-58-88-99

Tel: (+84 28) 39105465

Electrolux Vietnam Ltd.

Unit 1&2, 10F Sofic Tower, #10 Mai Chi Tho

Street,

Thu Thiem Ward, Thu Duc City, Ho Chi

Minh City, Vietnam
