Electrolux T4900 Manual de usuario

Service manual

Tumble dryers

T4900, T41200

TD100, TD135

Type N4...

Dryer type T4900/TD100 from serial number: 00900/0100000

Dryer type T41200/TD135 from serial number: 01200/0100000

Original instructions

487 05 46 91/EN

2015.02.03

Additional safety instructions and warnings

WARNING. Never stop a tumble dryer before the end of the drying cycle unless all items

are quickly removed and spread out so that the heat is dissipiated.

This appliance is not intended for use by young children or inrm persons unless they

have been adequately supervised by a responsible person to ensure that they can use the

appliance safely.

Young children should be supervised to ensure that they do not play with the appliance.

The tumble dryer is not to be used if industrial chemicals have been used for

cleaning.

The lint trap has to be cleaned frequently, if applicable.

Lint must not to be allowed to accumulate around the tumble dryer (not applicable for

appliances intended to be vented to the exterior of the building).

The exhaust air must not be discharged into a ue which is used for exhausting fumes

from appliances burning gas or other fuels.

Fresh air ventilation openings shall not be blocked and/or sealed.

Servicing shall be carried out only by authorized personnel.

Contact authorized service personnel if abnormal operation is recognized.

THIS APPLIANCE SHALL NOT BE USED TO DRY OFF SOLVENTS OR DRY-CLEANING

FLUIDS.

DO NOT USE OR STORE FLAMMABLE MATERIALS IN THE APPLIANCE STORAGE

DRAWER OR NEAR THIS APPLIANCE.

DO NOT SPRAY AEROSOLS IN THE VICINITY OF THIS APPLIANCE WHILE IT IS IN

OPERATION.

DO NOT MODIFY THIS APPLIANCE.

For parts, service and technical assistance please contact:

Electrolux Laundry Systems

5-7 Keith Champbell Crt Scoresby Victoria 3179

Service

manual

Additional safety instructions and warnings

To minimize the risk of re in a tumble dryer, the following should be observed:

• Items that have been spotted or soaked with vegetable or cooking oil

constitute a fire hazard and should not be placed in a tumble dryer.

• Oil-affected items can ignite spontaneously, especially when exposed to

heat sources such as in a tumble dryer. The items become warm, causing

an oxidation reaction in the oil. Oxidation creates heat. If the heat cannot

escape, the items can become hot enough to catch fire. Piling, stacking or

storing oilaffected items can prevent heat from escaping and so create a

fire hazard.

If it is unavoidable that fabrics that contain vegetable or cooking oil or have

been contaminated by hair care products be placed in a tumble dryer they

should first be washed in hot water with extra detergent - this will reduce,

but not eliminate, the hazard. The ’cool down’ cycle of tumble dryers

should be used to reduce the temperature of the items. They should not be

removed from the tumble dryer or piled or stacked while hot.

• Items that have been previously cleaned in, washed in, soaked in or

spotted with petrol/gasoline, dry-cleaning solvents or other flammable or

explosive substances should not be placed in a tumble dryer.

Highly flammable substances commonly used in domestic environments

include acetone, denatured alcohol, petrol/gasoline, kerosene, spot

removers (some brands), turpentine, waxes and wax removers.

• Items containing foam rubber (also known as latex foam) or similarly

textured rubber. like materials should not be dried in a tumble dryer on a

heat setting.

Foam rubber materials can, when heated, produce fire by spontaneous

combustion.

• Fabric softeners or similar products should not be used in a tumble dryer

to eliminate the effects of static electricity unless this practice is

specifically recommended by the manufacturer of the fabric softener or

product.

• Undergarments that contain metal reinforcements should not be placed in a

tumble dryer.

Damage to the tumble dryer can result if metal reinforcements come loose

during drying. When available a drying rack could be used for such items.

• Plastic articles such as shower caps or babies’ waterproof napkin covers

should not be placed in a tumble dryer.

• Rubber-backed articles, clothes fitted with foam rubber pads, pillows,

galoshes and rubber-coated tennis shoes should not be placed in a tumble

dryer.

Service

manual Additional safety instructions and warnings

Service

manual

Contents

SafetyPrecautions.....................................7

Technicaldata........................................9

Descriptionofprincipalcomponents. . . . . . . . . . . . . . . . . . . . . . 15

Periodicmaintenance.................................21

Errorcodes(seeSelectaControlServiceManual)

Control.............................................31

Sensorsandoverheatingthermostats. . . . . . . . . . . . . . . . . . . . . 41

Doorswitchandlintfilterswitch . . . . . . . . . . . . . . . . . . . . . . . . . 49

Motor..............................................57

Heating............................................ 65

Drumwithbearing....................................77

SlidingDoor.........................................89

Gassystem.........................................99

RMC..............................................105

Safety Precautions

Service

manual

This appliance can be used by children aged from 8 years and

above and persons with reduced physical, sensory or mental

capabilities or lack of experience and knowledge if they have

been given supervision or instruction concerning use of the

appliance in a safe way and understand the hazards involved

Children shall not play with the appliance.

Cleaning and user maintenance shall not be made by children

without supervision.

Children of less than 3 years should be kept away unless

continuously supervised.

The machine is not to be used if industrial chemicals have

been used for cleaning.

Do not dry unwashed items in the machine.

Items that have been soiled with substances such as cooking

oil, acetone, alcohol, petrol, kerosene, spot removers,

turpentine, waxes and wax removers should be washed in hot

water with an extra amount of detergent before being dried in

the machine.

Items such as foam rubber (latex foam), shower caps,

waterproof textiles, rubber backed articles and clothes or

pillows ﬁtted with foam rubber pads should not be dried in the

machine.

Fabric softeners or similar products should be used as

speciﬁed by the fabric softener instructions.

The ﬁnal part of a drying cycle occurs without heat (cool down

cycle) to ensure that the items are left at a temperature that

ensures that the items will not be damaged.

Remove all objects from pockets such as lighters and

matches.

Safety Precautions

Service

manual

WARNING. Never stop the machine before the end of the

drying cycle unless all items are quickly removed and spread

out so that the heat is dissipated.

Adequate ventilation has to be provided to avoid the back

ﬂow of gases into the room for appliances burning other fuels,

including open ﬁres.

Exhaust air must not be discharged into a ﬂue which is used

for exhausting fumes from appliances burning gas or other

fuels.

The machine must not be installed behind a lockable door, a

sliding door or a door with a hinge on the opposite side to that

of the machine in such a way that a full opening of the machine

is restricted.

If the machine has a lint trap this has to be cleaned frequently.

The lint must not be accumulated around the machine.

DO NOT MODIFY THIS APPLIANCE.

Servicing shall be carried out only by authorized personnel.

Only authorized spare parts shall be used.

When performing service or replacing parts, the power must

be disconnected.

In accordance with the wiring rules: mount a multi-pole switch

prior to the machine to facilitate installation and service

operations.

Safety Precautions

Service

manual

Gas heated tumble dryer:

Before installation, check that the local distribution conditions,

nature of gas and pressure and the adjustment of the

appliance are compatible.

The machine is not to be installed in rooms containing cleaning

machines with perchloroethylene, TRICHLOROETHYLENE or

CHLOROFLUOROCONTAINING HYDROCARBONS as cleaning

agents.

CAUTION: This appliance shall not be installed where the

public has access.

If you can smell gas:

• Do not switch on any equipment

• Do not use electrical switches

• Do not use telephones in the building

• Evacuate the room, building or area

• Contact the person responsible for the machine

In order to prevent damage to the electronics (and other parts) that may occur as

the result of condensation, the machine should be placed in room temperature for 24

hours before being used for the ﬁrst time.

CAUTION

Caution

Read the instructions before using the machine

Symbols

Caution, hot surface

Technical data

Service

manual

Contents

Technicaldata-typeT4900.................................10

Technicaldata-typeT41200. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

Technicaldata-typeTD100.................................12

Technicaldata-typeTD135.................................13

Technical data Service

manual

Technical data - type T4900

Heating Gas Steam Electric

Drum volume: 900 litres 900 litres 900 litres

Weight net: Basic: Standard door 545 kg 545 kg 545 kg

Basic: Sliding Door 599 kg 599 kg 599 kg

Heating unit 39 kg 50 kg 42 kg

Motors: Effect: Fan (3-phase) 1.1 kW 1.1 kW 1.1 kW

RPM: 50 Hz 2800 rpm 2800 rpm 2800 rpm

RPM: 60 HZ 3400 rpm 3400 rpm 3400 rpm

Effect: Drum (3-phase) 1.5 kW 1.5 kW 1.5 kW

RPM: 50 Hz 1440 rpm 1440 rpm 1440 rpm

RPM: 60 Hz 1730 rpm 1730 rpm 1730 rpm

Drum: Diameter 1240 mm 1240 mm 1240 mm

Depth 770 mm 770 mm 770 mm

Revolutions per minute 38 rpm 38 rpm 38 rpm

Capacity: 45 kg 45 kg 45 kg

Heat effect: Gas heating 64 kW

Steam heating Depending upon

steam pressure

Electric heating 48 / 60 kW

Air consumption: Max. 2300 m3/h Max. 2300 m3/h Max. 2300 m3/h

Piping: Exhaust duct Ø 315 mm Ø 315 mm Ø 315 mm

Gas connection ISO 7/1 - Rp 1

Steam in ISO 228/1 - G1

Steam out ISO 228/1 - G1

Pressure drop: max. 100 Pa max. 100 Pa max. 100 Pa

Gas pressure: See page regarding

pressure in the installation

manual supplied with the

dryer

Sound pressure level: < 70 dB (A) < 70 dB (A) < 70 dB (A)

Otros manuales para T4900

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Secadora de Electrolux

Electrolux

Electrolux EDE 67550W Manual de usuario

Electrolux

Electrolux EDE 5130 Manual de usuario

Electrolux

Electrolux FEQ1442ES Manual de usuario

Electrolux

Electrolux EDE 56160W Manual de usuario

Electrolux

Electrolux EDP2074PDW Manual de usuario

Electrolux

Electrolux EDH903R9WB Manual de usuario

Electrolux

Electrolux QuickDry N1130 Manual de usuario

Electrolux

Electrolux EDH3686GDE Manual de usuario

Electrolux

Electrolux EIMED55I MB Manual de usuario

Electrolux

Electrolux EDC 5470 Manual de operación

Electrolux

Electrolux EFME617SIW Instrucciones de instalación

Electrolux

Electrolux TK SL 3E Manual de usuario

Electrolux

Electrolux EDC 5366 Manual de operación

Electrolux

Electrolux EDI 96150 W Manual de usuario

Electrolux

Electrolux T5130 Manual de usuario

Electrolux

Electrolux EDE5100 Manual de usuario

Electrolux

Electrolux WT31RT Manual de instrucciones

Electrolux

Electrolux EDP2074PDW Manual de usuario

Electrolux

Electrolux EIMGD55I Manual de usuario

Electrolux

Electrolux DC6-14 Manual de usuario

Electrolux

Electrolux EDE 425 M Guía rápida

Electrolux

Electrolux EDC 3150 Manual de usuario

Electrolux

Electrolux EDH3488GDE Manual de usuario

Electrolux

Electrolux EDP2074PEW Manual de usuario

Manuales populares de Secadora de otras marcas

Bosch

Bosch WTA79200GB Manual de usuario

Amana

Amana W10233410A Manual de usuario

Miele

Miele TWH 780 WP Manual de usuario

Asko

Asko T760 Manual de usuario

Alliance Laundry Systems

Alliance Laundry Systems 25 Series Manual de usuario

Bosch

Bosch Logixx 10 WTB76556GB Hoja de especificaciones

STIEBEL ELTRON

STIEBEL ELTRON Ultronic S Manual de instrucciones

Beko

Beko DS8433RX1M Manual de usuario

Dawlance

Dawlance Spinner DS 6000 C Manual de usuario

AEG

AEG TR838P4OB Manual de usuario

Indesit

Indesit IDV 75 Manual de usuario

Infiniton

Infiniton SD-DG85C Manual de usuario

BOMANN

BOMANN WT 5019 Manual de usuario

Alliance Laundry Systems

Alliance Laundry Systems TMB795C Manual de usuario

Asko

Asko T793C Manual de usuario

Kenmore

Kenmore 8041 - 5.8 cu. Ft. Capacity Electric Dryer Manual de usuario

Frigidaire

Frigidaire CAQE7077KW0 Manual del propietario

Bosch

Bosch WTX8HKM9SN Manual de usuario
