Electrolux ESF5521LOX Manual de usuario

ESF5521LOX

EN Dishwasher User Manual

CONTENTS

1. SAFETY INFORMATION....................................................................................3

2. SAFETY INSTRUCTIONS..................................................................................4

3. PRODUCT DESCRIPTION................................................................................ 5

4. CONTROL PANEL ............................................................................................ 6

5. PROGRAMMES................................................................................................. 7

6. SETTINGS..........................................................................................................8

7. OPTIONS..........................................................................................................10

8. BEFORE FIRST USE....................................................................................... 11

9. DAILY USE....................................................................................................... 12

10. HINTS AND TIPS........................................................................................... 14

11. CARE AND CLEANING..................................................................................15

12. TROUBLESHOOTING....................................................................................17

13. TECHNICAL INFORMATION......................................................................... 20

WE’RE THINKING OF YOU

Thank you for purchasing an Electrolux appliance. You’ve chosen a product that

brings with it decades of professional experience and innovation. Ingenious and

stylish, it has been designed with you in mind. So whenever you use it, you can

be safe in the knowledge that you’ll get great results every time.

Welcome to Electrolux.

Visit our website for:

Get usage advice, brochures, trouble shooter, service information:

www.electrolux.com/webselfservice

www.registerelectrolux.com

Buy Accessories, Consumables and Original spare parts for your appliance:

www.electrolux.com/shop

CUSTOMER CARE AND SERVICE

Always use original spare parts.

When contacting our Authorised Service Centre, ensure that you have the

following data available: Model, PNC, Serial Number.

The information can be found on the rating plate.

Warning / Caution-Safety information

General information and tips

Environmental information

Subject to change without notice.

www.electrolux.com2

1. SAFETY INFORMATION

Before the installation and use of the appliance, carefully

read the supplied instructions. The manufacturer is not

responsible for any injuries or damages that are the

result of incorrect installation or usage. Always keep the

instructions in a safe and accessible location for future

reference.

1.1 Children and vulnerable people safety

•This appliance can be used by children aged 8 years

and above and by persons with reduced capabilities

provided that they have been given instruction and/or

supervision regarding the safe use of the appliance

and understand the potential hazards involved.

•Do not let children play with the appliance.

•Keep detergents away from children.

•Keep children and pets away from the appliance door

when it is open.

•Children shall not carry out cleaning and user

maintenance of the appliance without supervision.

1.2 General Safety

•This appliance is intended to be used in household

and similar applications such as:

–farm houses; staff kitchen areas in shops, offices

and other working environments;

–by clients in hotels, motels, bed & breakfast and

other residential type environments.

•Do not change the specification of this appliance.

•The operating water pressure (minimum and

maximum) must be between 0.5 (0.05) / 8 (0.8) bar

(Mpa)

•Obey the maximum number of 13 place settings.

•If the supply cord is damaged, it must be replaced by

the manufacturer, its Authorised Service Centre or

similarly qualified persons in order to avoid a hazard.

ENGLISH 3

•Put knives and cutlery with sharp points in the cutlery

basket with the points down or in a horizontal position.

•Do not keep the appliance door open without

supervision to prevent to fall on it.

•Before any maintenance operation, deactivate the

appliance and disconnect the mains plug from the

socket.

•Do not use high pressure water sprays and/or steam

to clean the appliance.

•The ventilation openings in the base (if applicable)

must not be obstructed by a carpet.

•The appliance is to be connected to the water mains

using the new supplied hose-sets. Old hose sets must

not be reused.

2. SAFETY INSTRUCTIONS

2.1 Installation

• Remove all the packaging and the

transit bolts.

• Do not install or use a damaged

appliance.

• Do not install or use the appliance

where the temperature is less than 0

°C.

• Follow the installation instruction

supplied with the appliance.

2.2 Electrical connection

WARNING!

Risk of fire and electrical

shock.

• The appliance must be earthed.

• Make sure that the electrical

information on the rating plate agrees

with the power supply. If not, contact

an electrician.

• Always use a correctly installed

shockproof socket.

• Do not use multi-plug adapters and

extension cables.

• Make sure not to cause damage to

the mains plug and to the mains

cable. Should the mains cable need to

be replaced, this must be carried out

by our Authorised Service Centre.

• Connect the mains plug to the mains

socket only at the end of the

installation. Make sure that there is

access to the mains plug after the

installation.

• Do not pull the mains cable to

disconnect the appliance. Always pull

the mains plug.

• This appliance complies with the

E.E.C. Directives.

• Only for UK and Ireland. The

appliance has a 13 amp mains plug. If

it is necessary to change the fuse in

the mains plug, use fuse: 13 amp

ASTA (BS 1362).

2.3 Water connection

• Do not cause damage to the water

hoses.

• Before connection to new pipes, pipes

not used for a long time, where repair

work has been carried out or new

devices fitted (water meters, etc.), let

the water flow until it is clean and

clear.

• Ensure that there are no visible water

leaks during and after the first use of

the appliance.

www.electrolux.com4

• The water inlet hose has a safety

valve and a sheath with an inner

mains cable.

WARNING!

Dangerous voltage.

• If the water inlet hose is damaged,

immediately disconnect the mains

plug from the mains socket. Contact

the Authorised Service Centre to

replace the water inlet hose.

2.4 Use

• Do not sit or stand on the open door.

• Dishwasher detergents are

dangerous. Obey the safety

instructions on the detergent

packaging.

• Do not drink and play with the water in

the appliance.

• Do not remove the dishes from the

appliance until the programme is

completed. There can be detergent on

the dishes.

• The appliance can release hot steam

if you open the door while a

programme operates.

• Do not put flammable products or

items that are wet with flammable

products in, near or on the appliance.

2.5 Disposal

WARNING!

Risk of injury or suffocation.

• Disconnect the appliance from the

mains supply.

• Cut off the mains cable and discard it.

• Remove the door catch to prevent

children and pets to get closed in the

appliance.

3. PRODUCT DESCRIPTION

10 9

11 67

1Worktop 2Upper spray arm

ENGLISH 5

3Lower spray arm

4Filters

5Rating plate

6Salt container

7Air vent

8Rinse aid dispenser

9Detergent dispenser

10 Cutlery basket

11 Lower basket

12 Upper basket

4. CONTROL PANEL

2 3 4 5

678

1On/off button

2Program button

3Programme indicators

4Display

5Delay button

6Start button

7Indicators

8Option button

4.1 Indicators

Indicator Description

Washing phase. It comes on when the washing phase operates.

Drying phase. It comes on when the drying phase operates.

XtraDry indicator.

Rinse aid indicator. It is always off while the programme operates.

Salt indicator. It is always off while the programme operates.

Hygiene indicator.

www.electrolux.com6

5. PROGRAMMES

Programme Degree of soil

Type of load

Programme pha‐

ses

Options

1) • Normal soil

• Crockery and

cutlery

• Prewash

• Wash 50 °C

• Rinses

• Dry

• Hygiene

• XtraDry

2) • All

• Crockery, cut‐

lery, pots and

pans

• Prewash

• Wash from 45 °C

to 70 °C

• Rinses

• Dry

• Hygiene

• XtraDry

3) • Heavy soil

• Crockery, cut‐

lery, pots and

pans

• Prewash

• Wash 70 °C

• Rinses

• Dry

• XtraDry

• Light soil

• Crockery and

cutlery

• Wash 50 °C or

55 °C

• Rinses

• Hygiene

• XtraDry

4) • Fresh soil

• Crockery and

cutlery

• Wash 60 °C or

65 °C

• Rinses

• Hygiene

• XtraDry

5) • All • Prewash

1) With this programme you have the most efficient use of water and energy consumption

for crockery and cutlery with normal soil. (This is the standard programme for test institutes).

2) The appliance senses the degree of soil and the quantity of items in the baskets . It auto‐

matically adjusts the temperature and the quantity of water, the energy consumption and the

programme duration.

3) This programme has a high temperature rinsing phase for better hygiene results. During

the rinsing phase, the temperature stays at 70 °C for at least 10 minutes.

4) With this programme you can wash a load with fresh soil. It gives good washing results in

a short time.

5) With this programme you can quickly rinse dishes to prevent remains of food to bond on

dishes and odours to form in the appliance. Do not use detergent with this programme.

5.1 Consumption values

Programme 1) Water

(l)

Energy

(kWh)

Duration

(min)

11 1.050 195

7 - 12 0.6 - 1.4 40 - 150

ENGLISH 7

Programme 1) Water

(l)

Energy

(kWh)

Duration

(min)

13 - 15 1.5 - 1.6 150 - 170

8 - 9 1.1 - 1.3 55 - 65

9 0.8 30

4 0.1 14

1) The pressure and the temperature of the water, the variations of the mains supply, the

options and the quantity of dishes can change the values.

5.2 Information for test

institutes

For all the necessary information for test

performance, send an email to:

[email protected]

Write down the product number (PNC)

that is on the rating plate.

6. SETTINGS

6.1 Programme selection mode

and user mode

When the appliance is in programme

selection mode it is possible to set a

programme and to enter the user mode.

In user mode, the following settings

can be changed:

• The level of the water softener

according to the water hardness.

• The activation or the deactivation of

the acoustic signal for end of

programme.

• The activation or deactivation of the

rinse aid empty notification.

These settings will be saved until you

change them again.

How to set the programme

selection mode

The appliance is in programme selection

mode when the programme indicator

is on and the display shows the

programme duration.

When you activate the appliance, usually

it is in programme selection mode.

However, if this does not happen, you

can set the programme selection mode

in the following way:

Press and hold simultaneously Program

and Option until the appliance is in

programme selection mode.

6.2 The water softener

The water softener removes minerals

from the water supply, which would have

a detrimental effect on the washing

results and on the appliance.

The higher the content of these minerals,

the harder your water is. Water hardness

is measured in equivalent scales.

The water softener should be adjusted

according to the hardness of the water in

your area. Your local water authority can

advise you on the hardness of the water

in your area. It is important to set the

right level of the water softener to assure

good washing results.

www.electrolux.com8

Water hardness

German de‐

grees (°dH)

French de‐

grees (°fH)

mmol/l Clarke de‐

grees

Water softener

level

47 - 50 84 - 90 8.4 - 9.0 58 - 63 10

43 - 46 76 - 83 7.6 - 8.3 53 - 57 9

37 - 42 65 - 75 6.5 - 7.5 46 - 52 8

29 - 36 51 - 64 5.1 - 6.4 36 - 45 7

23 - 28 40 - 50 4.0 - 5.0 28 - 35 6

19 - 22 33 - 39 3.3 - 3.9 23 - 27 5 1)

15 - 18 26 - 32 2.6 - 3.2 18 - 22 4

11 - 14 19 - 25 1.9 - 2.5 13 - 17 3

4 - 10 7 - 18 0.7 - 1.8 5 - 12 2

<4 <7 <0.7 < 5 1 2)

1) Factory setting.

2) Do not use salt at this level.

If you use multi-tablets containing salt

and the hardness of your water is lower

than 21°dH, you can set the lowest water

softener level. It deactivates the salt refill

indicator.

If you use standard detergent or multi-

tablets without salt, set the proper

water hardness level to keep the salt

refill indicator active.

How to set the water softener

level

The appliance must be in programme

selection mode.

1. To enter the user mode, press and

hold simultaneously Delay and Start

until the indicators ,

and start to flash and

the display is blank.

2. Press Program.

• The indicators and

go off.

• The indicator continues to

flash.

• The display shows the current

setting: e.g. = level 5.

3. Press Program again and again to

change the setting.

4. Press the on/off button to confirm the

setting.

6.3 The rinse aid empty

notification

When rinse aid chamber is empty, the

rinse aid indicator is turned on notifying

to refill rinse aid. If you are using multi-

tabs containing rinse aid and you are

satisfied with the drying result, you can

deactivate the notification for refilling

rinse aid. However, we recommend that

you always use rinse aid for best drying

performance.

If you use standard detergent or multi-

tablets without rinse aid, activate the

notification to keep the rinse aid refill

indicator active.

ENGLISH 9

How to deactivate the rinse aid

empty notification

The appliance must be in programme

selection mode.

1. To enter the user mode, press and

hold simultaneously Delay and Start

until the indicators ,

and start to flash and

the display is blank.

2. Press Option.

• The indicators and go

off.

• The indicator

continues to flash.

• The display shows the current

setting.

– = rinse aid empty

notification activated.

– = rinse aid empty

notification deactivated.

3. Press Option to change the setting.

4. Press the on/off button to confirm the

setting.

6.4 Acoustic signals

Acoustic signals sound when a

malfunction of the appliance occurs. It is

not possible to deactivate these acoustic

signals.

There is also an acoustic signal that

sounds when the programme is

completed. By default this acoustic signal

is deactivated but it is possible to

activate it.

How to activate the acoustic

signal for the end of

programme

The appliance must be in programme

selection mode.

1. To enter the user mode press and

hold simultaneously Delay and Start

until the indicators ,

and start to flash and

the display is blank.

2. Press Delay

• The indicators and

go off.

• The indicator continues to

flash.

• The display shows the current

setting:

– = Acoustic signal off.

– = Acoustic signal on.

3. Press Delay to change the setting.

4. Press the on/off button to confirm the

setting.

7. OPTIONS

Desired options must be

activated every time before

you start a programme.

It is not possible to activate

or deactivate options while a

programme is running.

Not all options are

compatible with each other.

If you have selected non

compatible options, the

appliance will automatically

deactivate one or more of

them. Only the indicators of

the options still active will

stay on.

7.1 Hygiene

With this option you have better hygiene

results. During the last rinsing phase, the

temperature stays at 70 °C for at least 10

minutes.

How to activate Hygiene

Press Option until the indicator

comes on.

If the option is not applicable to the

programme, the related indicator does

not come on or it flashes quickly for a few

seconds and then goes off.

The display shows the updated

programme duration.

www.electrolux.com10

Tabla de contenidos

Otros manuales de Lavavajillas de Electrolux

Electrolux

Electrolux EEM69300IX Manual de usuario

Electrolux

Electrolux 66 Manual de usuario

Electrolux

Electrolux FDB1050RE 2005 Manual de usuario

Electrolux

Electrolux EIDW6305GB - Semi-Integrated Dishwasher Manual de usuario

Electrolux

Electrolux FAVORIT 88990 VI Manual de usuario

Electrolux

Electrolux KECA7305L Manual de usuario

Electrolux

Electrolux EIDW5905JB0A Manual de usuario

Electrolux

Electrolux ESF8635ROW Manual de usuario

Electrolux

Electrolux ESF4513LOX Manual de usuario

Electrolux

Electrolux ESI 63020 Manual de usuario

Electrolux

Electrolux ESL 43010 Manual de usuario

Electrolux

Electrolux EHT8G Manual de usuario

Electrolux

Electrolux BW3100 Manual de instrucciones

Electrolux

Electrolux ESF 4160 Manual de usuario

Electrolux

Electrolux ESL 66022 Manual de usuario

Electrolux

Electrolux KECA7300L Manual de usuario

Electrolux

Electrolux ESF 43011 Manual de usuario

Electrolux

Electrolux Green&Clean 504228 Manual de usuario

Electrolux

Electrolux ESL7540RO Manual de usuario

Electrolux

Electrolux ESC87311UW Manual de usuario

Electrolux

Electrolux AEG FAVORIT 64080 VIL Manual de usuario

Electrolux

Electrolux GA554IF Manual de usuario

Electrolux

Electrolux ESF6768KXA Manual de usuario

Electrolux

Electrolux FAVORIT 50777 Manual de usuario

Manuales populares de Lavavajillas de otras marcas

KitchenAid

KitchenAid KUDB230B Manual de usuario

Brandt

Brandt BDJ424DB Manual de usuario

Asko

Asko DSD767UXXL.AU Manual de usuario

Beko

Beko DFN26210W Manual de usuario

NEFF

NEFF S153ITX00E Hoja de especificaciones

Midea

Midea SV 4.45 wi Manual de usuario

LG LDF7932 Manual de usuario

Gorenje

Gorenje GV63214 Manual de usuario

Hotpoint

Hotpoint HDA1100ZWH Manual de servicio

Blomberg

Blomberg LDFN2240W Manual de usuario

AEG

AEG FFB83836PM Manual de usuario

Cylinda

Cylinda DM3220RFD Manual de usuario

Atag

Atag DW8214MB Manual de usuario

GE GLD8000 Series Manual de usuario

Siemens

Siemens SN23HI02KE Hoja de especificaciones

Omega

Omega ODW717X Manual de usuario

BORETTI

BORETTI BVW-683 Manual de usuario

Siemens

Siemens SN 56N591 Manual de usuario
