Electrolux ELM 5400 Manual de usuario

•EN •

ELM5400/ELM5400MR/ELM5400S/ELM5400K

EN Instruction book ..................3–13

Before using the appliance for the

rst time, please read the safety

advice on page 4.

Components

A. ON/OFF button

B. Espresso button

C. Espresso Lungo button

D. Cappuccino button

E. Latte button

F. Lever

G. Capsule compartment

H. Water tank

J. Cup support rack

K. Drip tray

L. Waste water indicator

M. Used capsules container

N. Power cord & plug

O. Motor unit

P. Lid

Q. Steam spout

R. Whisker

S. Removable whisking

spiral

T. Milk glass

U. Motor release button

Safety advice

Read the following instruction care-

time.

•This appliance is not intended for use

by persons (including children) with

reduced physical, sensory or mental

capabilities, or lack of experience

and knowledge, unless they have

been given supervision or instruction

concerning use of the appliance by a

person responsible for their safety.

•Children should be supervised to

ensure that they do not play with the

appliance.

•The appliance may only be connected

to a power supply whose voltage and

tions on the rating plate!

•Never use or pick up the appliance if

– the supply cord is damaged,

– the housing is damaged.

•The appliance must only be connected

to an earthed socket. If necessary an

extension cable suitable for 10 A can

be used.

• If the appliance or the supply cord is

damaged, it must be replaced by the

manufacturer, its service agent or simi-

hazard.

•Always place the appliance on a

level surface.

•Never leave the appliance unattended

while connected to the supply mains.

•The appliance and accessories become

hot during operation. Use only des-

ignated handles and knobs. Allow to

cool down before cleaning or storage.

•The mains cable must not come into

contact with any hot parts of the ap-

pliance.

•Do not immerse the appliance in wa-

ter or any other liquid.

•Do not exceed the maximum

volume as indicated on the appliances.

•Fill the water tank only with cold wa-

ter, never with milk or other liquids.

•Do not use the appliance if the water

•Do not use the appliance without the

drip tray or the drip grid.

•This appliance is intended for domes-

tic use only. The manufacturer cannot

accept any liability for possible dam-

age caused by improper or incorrect

use.

•Do not carry machine by the handle.

•This machine can only be used with

Lavazza A MODO MIO capsules. Do not

in the capsule compartment. The cap-

sules can be used only once.

•The motor unit is not waterproof and

cannot be immersed into the water.

• To avoid steam leakage during

frothing, the frothing function shall be

run with a capsule inserted.

Getting started

1. -

face

drinkable and non sparkling water.

(The machine must not be used with

empty tank!) Plug the power cord

into the mains and press the ON

button. The machine is ready to use

when the cup indicator lights stop

and become steady.

2. When starting the machine for

Place a glass under

pressing the Espresso Lungo but-

ton. Run also the Latte function

one time by pressing the Latte

button with water in the milk glass.

3. The machine must not be used

with empty tank!

coming out during brewing try to

prime it. To prime the circuit, run

the Latte function one time by

pressing the Latte button with

water in the milk glass. Once this

is complete, place a glass under

the coee spout and run also the

fresh water through the coee

spout by pressing the Espresso

Lungo button.

Other functions

1. for

it down or pushing it up.

The machine is equipped with an

energy saving function that auto-

of inactivity.

EN Light. The machine is equipped

with a lamp which lights up the cup

support rack. The light will be on

during the brewing time and will

cup is ready.

Preparing coee

2. Lift the lever, insert a capsule in

the compartment. Close the lever

and press either Espresso or Espres-

ready, lift the lever and the capsule

falls down into the used capsules

container.

Place a cup on the cup support

rack. Press and hold the Espresso

or Espresso Lungo button. Release

reached. The programmed quantity

is memorized by the machine.

1. LAVAZZA A MODO MIO capsules.

Only suitable Lavazza “A MODO

MIO” capsules should be placed in

the capsule compartment. Single

dose capsules brew a single coee/

product. DO NOT use the capsules

more than once. Inserting 2 or

more capsules can cause the

machine to malfunction.

Preparing Cappuccino/Latte

1. Frothing milk for Cappuccino

and Latte: Fill the glass of the milk

frother with fresh milk (standard

fridge temperature of 4-8 degrees)

exactly to the level for the

Cappuccino or Latte line (do not

exceed the line). Place the lid on

top of the glass, plug the motor

into the machine and then slide

the glass under the motor. You

can select hot and cold frothing.

2. Warm frothing: Press the Cappuc-

cino or Latte button, the amber

light will start ashing. The frothing

process will start in 30 sec. The

process will stop automatically

when the milk is prepared (you can

stop it manually as well by press-

ing it again). Approximate time for

warm frothing is 75 sec (Cappuc-

cino) to 110 sec (Latte).

3. Cold frothing: Press the Cappuc-

cino or Latte button for more than

2 sec. The LED light buttons will

start ashing and turn blue and

only the whisker will be working

(no steam function). Approximate

time for cold frothing is 45 sec.

4. Preparing Cappuccino: Froth

the milk as described in previous

3 steps. Prepare an Espresso in a

Cappuccino cup and then pour the

frothed milk on top of the Espresso.

5. Preparing Latte: Froth the milk as

described in previous 3 steps.

When the frothing process stops,

pour the frothed milk into a latte

glass. Place the glass under the

coee spout and prepare an

Espresso.

Cleaning and care

EN 1.

cord and let the machine cool

down. Wipe all outer surfaces with

a damp cloth. Rinse the water tank

once a day.

2. is

visible above the grid, the drip

tray must be emptied. Lift out grid,

tray and waste container. Empty,

rinse, dry and put back in place.

This procedure should be carried

out every two or three days or after

dishwasher proof (paint can be

damaged).

3. The milk frother glass, lid, whisker

and steam spout can be washed in

dishwasher. The motor unit is

not waterproof and cannot be im-

mersed into the water. Please use

the soft damp cloth for cleaning.
