Electro-Voice EVID-S10.1DW Manual de usuario

EVID-S Surface Mount Dual 10” Subwoofers

EVID-S10.1DB | EVID-S10.1DW

en | Installation manual

Table of contents

1Safety 4

1.1 Suspension 4

1.2 Notices 4

2Short information 5

3Introduction 6

3.1 System features 6

3.2 Packing list 7

3.3 Product information 8

4Installation 9

4.1 Suspending the subwoofer 9

4.2 Replacing the logo 10

4.3 Installing the IP65 port covers 11

4.4 Installing the U-bracket - optional accessory 12

4.5 Installing the transformer input panel - optional accessory 12

4.6 Installing the crossover input panel - optional accessory 14

5Wiring 15

5.1 Standard input panel 15

5.1.1 Mono operation 15

5.1.2 Stereo operation 16

5.2 Transformer input panel - optional accessory 17

5.2.1 Mono operation 17

5.2.2 Stereo operation 19

5.3 Crossover input panel - optional accessory 20

5.3.1 Mono operation 20

5.3.2 Stereo operation 21

6Troubleshooting 23

7Technical data 24

7.1 Dimensions 25

7.2 Frequency response and impedance 25

8U-bracket dimensions - optional accessory 27

en 3

Electro-Voice Installation manual 2017.08 | 01 | F.01U.345.359

Safety

Suspension

Warning!

Suspending any object is potentially dangerous and should only be attempted by individuals

who have a thorough knowledge of the techniques and regulations of suspending objects

overhead. Electro-Voice strongly recommends all loudspeakers be suspended taking into

account all current national, federal, state, and local laws and regulations. It is the

responsibility of the installer to ensure all loudspeakers are safely installed in accordance

with all such requirements. When loudspeakers are suspended, Electro-Voice strongly

recommends the system be inspected at least once per year or as laws and regulations

require. If any sign of weakness or damage is detected, remedial action should be taken

immediately. The user is responsible for making sure the wall, ceiling, or structure is capable

of supporting all objects suspended overhead. Any hardware used to suspend a loudspeaker

not associated with Electro-Voice is the responsibility of others.

Safety point

As an added safety measure, it is suggested the user install an extra suspension point back to

the building structural supports. This safety point should have as little slack as possible (less

than 1-inch is preferable).

Notices

Old electrical and electronic appliances

Electrical or electronic devices that are no longer serviceable must be collected separately and

sent for environmentally compatible recycling (in accordance with the European Waste

Electrical and Electronic Equipment Directive).

To dispose of old electrical or electronic devices, you should use the return and collection

systems put in place in the country concerned.

any means, electronic, mechanical, photocopying, recording, or otherwise, without the prior

written permission of the publisher. For information on getting permission for reprints and

excerpts, contact Electro-Voice.

The content and illustrations are subject to change without prior notice.

1.1

1.2

EVID-S Surface Mount Dual 10” Subwoofers

2017.08 | 01 | F.01U.345.359 Installation manual Electro-Voice

Short information

The following table lists products in a family, with CTN (Commercial Type Number) and

identifying product name DESCRIPTION.

CTN Description

EVID-S10.1DB Cabinet subwoofer 2x10" black

EVID-S10.1DW Cabinet subwoofer 2x10" white

UB-10DB U-bracket for 10" subwoofer black

UB-10DW U-bracket for 10" subwoofer white

IP-10D-TB Transformer input 10" subwoofer bk

IP-10D-TW Transformer input 10" subwoofer wh

IP-10D-CB Crossover input 10" subwoofer bk

IP-10D-CW Crossover input 10" subwoofer wh

en 5

Electro-Voice Installation manual 2017.08 | 01 | F.01U.345.359

Introduction

The EVID-S10.1D subwoofer, from Electro-Voice, is a compact, high-performance, dual woofer

loudspeaker with outstanding performance for the most demanding professional and

commercial sound applications. Designed and engineered for use in background and

foreground music, and sound reinforcement applications, the EVID-S10.1D subwoofer is the

ideal solution for indoor and outdoor applications, such as restaurants, bars, patios, retail,

fitness clubs, hospitality, theme parks, leisure venues, and others. Ease of installation, and

flexible options for mounting solutions and weather resistance, the EVID-S10.1D subwoofer is

the perfect solution for a wide variety of surface mount applications.

The EVID-S10.1D subwoofer has been carefully engineered to resist outdoor environments,

without compromising on performance for indoor applications. The subwoofer is IP54 rated,

and its weather-proofing is complemented with exceptional cabinet and grille resistance

against sun, salt and moisture. For the toughest weather conditions, the IP rating of the EVID-

S10.1D subwoofer can be upgraded to IP65, using the included port plug accessory.

Read through this manual to familiarize yourself with the safety information, features, and

applications before you use these products.

System features

▪Two 10 inch high-excursion woofers

▪Carefully engineered for outdoor environments (IP54 and IP65), without compromising

performance

▪400 W power handling provides for 120 dB maximum SPL (126 dB peak)

▪70/100 V transformer input panel accessory available

▪Crossover input panel accessory available

3.1

EVID-S Surface Mount Dual 10” Subwoofers

2017.08 | 01 | F.01U.345.359 Installation manual Electro-Voice

Packing list

Quantity Component

A 1 Subwoofer

B 5 Mounting point covers

C 1 Logo (spare)

D 1 Allen wrench

E 1 Weather input cover

F 8 Screws for weather input cover

G 2 IP65 port covers

H 12 IP65 port cover screws

I 1 Installation manual

Table 3.1: Components list

A (x 1) C

EF (x 8) G (x 2) H (x 12)

B (x 5)

Figure 3.1: Components

3.2

en 7

Electro-Voice Installation manual 2017.08 | 01 | F.01U.345.359

Product information

Figure 3.2: Product information (subwoofer on the right is shown upside down)

Item Description

A Grille

B U-bracket mounting points

C M8 flying points

D M8 safety point

E Input panel

F Subwoofer feet

G Weather input cover

Table 3.2: Product information

3.3

EVID-S Surface Mount Dual 10” Subwoofers

2017.08 | 01 | F.01U.345.359 Installation manual Electro-Voice

Installation

For safety, ensure the mounting surface supports more than the weight of the speaker. Use

only industry-accepted fasteners and mounting methods when mounting the loudspeaker.

Consult an expert if you are unsure.

Caution!

It is the installer's responsibility to determine and use the proper mounting hardware for

the wall construction type.

Disregarding this caution could result in damage to the product and personal injuries may

occur.

Safety point

As an added safety measure, it is suggested the user install an extra suspension point back to

the building structural supports. This safety point should have as little slack as possible (less

than 1-inch is preferable).

Suspending the subwoofer

To suspend the subwoofer, do the following:

1. Turn the subwoofer upside down.

2. Remove the two subwoofer feet with the supplied Allen wrench.

3. Attach the mounting point covers on the U-bracket mounting points.

4. Rotate the logo by replacing it, as shown in the Replacing the logo section.

4.1

en 9

Electro-Voice Installation manual 2017.08 | 01 | F.01U.345.359

5. Install four 8-mm rated forged eyebolts (not included) into the threaded fly points.

6. Install an 8-mm rated forged eyebolt (not included) into the safety point.

7. Suspend the subwoofer from the eyebolts using rated fittings and steel cable.

8. Secure the subwoofer from the safety eyebolt using rated fittings and steel cable.
