Electro-Voice Sx250 Manual de usuario

Key Features:

• Small-format 15-inch two-way full-range

speaker system

• 18 mm plywood enclosure

• EVCoatTM finish is rugged and weather-

resistant

• DH2010A pure titanium compression driver

coupled to an 80ox 55oConstant-directivity

horn

• EV 15-inch cast-frame woofer

• 50 Hz usable bass response

• Metal stand mount built in

• Suspendable using optional SK-1 kit

Sx250

Compact Sound

Reinforcement Speaker For:

Live Sound, Speech, Playback,

DJ, A/V, Institutional Venues

General Description:

TheSx250isthenewestmemberoftheworld’smostpopular

line of high-performance professional speakers. The Sx250

has all of the characteristics of Sx systems, including

tremendous use flexibility, easy portability, light weight and

high acoustic output capability.

Thanks to its unique multi-angle enclosure, the Sx250 can

be used as a floor monitor, as a pole-mounted “PA system”

and safely suspended using the optional SK-1 kit.

The Sx250’s enclosure is made of 18mm plywood that is

finished in EVCoatTM, a sprayed on polyurethane finish that

is resistant to damage, naturally weather resistant and can

be easily painted. Sx250’s components are protected from

damage by an 16-gauge steel grille with cloth backing for a

polished, professional look.

The Sx250 uses components that have toured the world in

EVconcertsystemsincludingtheD2010A1.25-inch diameter

pure titanium compression driver and the DL15BFH 15-inch

cast frame woofer. The Sx250 uses an 80ox 55oConstant-

directivity horn with EV’s patented TimePathTM phase plug

forwidedispersion, yet with better controlandprojectionthan

90ohorns.

The Sx250 also has EV’s Ring-Mode Decoupling (RMDTM)

technology for pure, clean vocals and detailed mids over a

wide range of SPLs. The Sx250’s sound is very accurate

with full-range fidelity that has high intelligibility for either

voice or music reproduction.

Technical Specifications:

:)Bd01-(esnopseR.qerFzHk02-zH05

-hgiHdednemmoceR ycneuqerFssaP zH54

)m1/W1LPS(ytivitisneSBd99

:LPSdetaluclaCxaMBd031

rewoPmreT-gnoL gnildnaH sttaw053

rewoPmreT-trohS gnildnaH sttaw004,1

:egarevoClatnoziroH°08

:egarevoClacitreV°55

:recudsnarTFLhcni-51emarFtsaCHFB51LDVE refooW

:recudsnarTFHmuinatiTeruPhcni-52.1A0102HDVE revirD

:ycneuqerfrevossorCzH006,1

:ecnadepmilanimoNsmho8

:srotcennoctupnIs'4LNnokaepSkirtueN)2(

:)DxWxH(miD"0.31x"0.71x"6.42 )mm033xmm134xmm526(

:)hcae(thgieWteN)gk7.22(sbl9.94

:thgieWgnippihS)gk0.62(sbl5.75

250

Block Diagram: Frequency Response:

Dimension Drawings: Beamwidth:

Directivity:

PerformanceMatch:

• P-Series Amplifiers

• Q66 Amplifier

• AC One Audio Controller

• SB180 Subwoofer

• QRx118 Subwoofer

AvailableAccessories:

• SK1 Rigging Hardware

• 100BK Tripod Stand

Sx250 Part Number

• 301253-001

12000 Portland Avenue South, Burnsville, MN 55337

Phone:952/884-4051, Fax:952/884-0043

www.electrovoice.com

PartNumber38110-097 RevD

U.S.A. and Canada only. For customer orders, contact Customer Service at:

800/392-3497 Fax: 800/955-6831

Europe, Africa, and Middle East only. For customer orders, contact Customer Service at:

+ 49 9421-706 0 Fax: + 49 9421-706 265

Other International locations. For customer orders, contact Customer Service at:

+ 1 952 884-4051 Fax: + 1 952 887-9212

For warranty repair or service information, contact the Service Repair department at:

800/685-2606

For technical assistance, contact Technical Support at: 866/78AUDIO

Specifications subject to change without notice.
