Electro-Voice XS212 Manual de usuario

Key Features:

•Dual DVX3120 12”Transducers

•136 dB, 1000W Continuous

•Very Compact, Lightweight

•Simple, Quick Integrated Rigging

•Versatile Integration in Main Arrays

•LAPS Aiming and Flying Software

XS212

Dual 12” Side-Firing

Very Compact

Line-Array Bass Element

General Description:

The XS212 is designed for high-level low frequency

extension to 42 Hz. It uses two new generation DVX 3120

forced air-cooled 12" transducers capable of long, linear

excursion and high power. A unique configuration allows

side firing transducers to match the XLD281’s horizontal

coverage and provide smaller arrays. XS212 are designed

to be used with a ratio of four XLD281 full range systems for

each XS212 sub woofer.

EV engineers have defined a new group of Very Compact

line array elements, XLVC. It is comprised of the models;

XLD281 full range, XLE181 full range, and the XS212 sub

woofer. Most applications using flown very compact

elements require subwoofers integrated into the same array

as the full range systems. XLVC provides two methods to

conveniently do this. The XS212 sub woofer module has

the same rigging foot print as the XLD281 allowing it to be

directly arrayed above, or below XLD281 full range systems.

Where vertical space is limited sub woofer arrays can be

created and flown behind the XLD281 full range array using

an additional grid and EV’s CBEAM (Coupler Beam). LAPS

modeling software quickly provides array configurations and

rigging information. XS212 sub woofers can also be used

as the base for groundstack applications, or by using EV’s

XGS-4 Groundstack Kit for XLVC.

XLVC delivers unprecedented performance in applications

ranging from live reinforcement to performing arts venues,

to houses of worship.

Technical Specifications:

esnopseR.qerF

2,1

:)Bd3-(zH45

egnaR.qerF

2,1

:)Bd01-(zH74

LPSdetaluclaCxaM

3,2

:kPBd431,.tnoCBd821

:egarevoClacitreVelbanifeDerawtfoS,tnadnepeDyarrA

:gniggiR,stnemercni°1,munimulAevitpa

CylluF rotcaFytefaS1ot8htiwstnemele8

:gnildnaHrewoPkaePW0004,.tnoCW0001

ytivitisneS

3,2

:Bd89

qerFssaphgiH

:zH94

revossorCdednemmoceR qerF

:zH001

:dnabssaPFL :reifilpmAdednemmoceR smho4,0213XVD"21x2 S0003PCVE

:srotcennoC8LNx2

:lairetaMerusolcnEtaoC

VE/wdoowylphcriB

:ellirGtniaptaocredwophtiwleetsdetalpcniZ

:cepSlatnemnorivnE018LIM,42PI925CEI

:)DxWxH(miD"09.41x"85.82x"00

.02 )mm873x627x805(

:thgieWteN)gk8.04(sbl09

:thgieWgnippihS)gk1.34(sbl59

1 Half Space Measurement.

2 Use EV or KT Signal Processing or Download Presets from Electro-Voice Website.

3 Half Space Measurement. SPL Adjusted for 1W at 63 Hz at 1m.

BlockDiagram:

DimensionDrawings (inches/metric):

Performance Match:

• XLD281 - Dual 8” 3-Way Line Array Element

• CP3000S - Precision SeriesTM Power Amplifier

• P3000RL - Precision SeriesTM Remote Control Power Amplifier

• Dx38 - Digital Sound System Controller

• DN9848-DigitalSoundController

• XLVC Series Grid - Grid for Hanging XLVC Line-Arrays

• CBEAM - Coupler Beam for XLD281/XLE181 to XS212 Arrays

• XGS-4 - Groundstack Kit for XLVC Line-Arrays

12000 Portland Avenue South, Burnsville, MN 55337

Phone:952/884-4051, Fax:952/884-0043

www.electrovoice.com

Part Number 38110-432 Rev A

U.S.A. and Canada only. For customer orders, contact Customer Service at:

800/392-3497 Fax: 800/955-6831

Europe, Africa, and Middle East only. For customer orders, contact Customer Service at:

+ 49 9421-706 0 Fax: + 49 9421-706 265

Other International locations. For customer orders, contact Customer Service at:

+ 1 952 884-4051 Fax: + 1 952 736-4212

For warranty repair or service information, contact the Service Repair department at:

800/685-2606

For technical assistance, contact Technical Support at: 866/78AUDIO

Specifications subject to change without notice.

SideFront

Top

Impedance:

Connections

Pins 1: LF

Pins2,3, 4: PassThrough

Frequency Response, Full and Half Space:

Beamwidth:

XS212 Part Number:

• XS212 - 301791-001

Grid Drawing:
