Electro-Voice R300 Manual de usuario

R300 UHF Wireless MicropHone

USER GUIDE

EZsync ClearScan

Electro-Voice

300

SET

SYNC

TAB LE oF contents

1. Quick System Setup

 •Receiver.................................................................................................................4

 •Transmitter.............................................................................................................5

 •SystemsOperation..............................................................................................6

2.DetailedComponentDescriptions

 •Receiver.......................................................................................................... 7-14

 •HandheldTransmitter .................................................................................15-16

 •BodypackTransmitter................................................................................. 17-19

3.GuidelinesForBestPerformance.............................................................................20-21

4.TroubleshootingGuide................................................................................................22-23

5.Specications ...............................................................................................................24-25

6.Certications....................................................................................................................... 26

7. ServiceandWarranty ........................................................................................................ 27

8.ComponentsandAccessories........................................................................................ 28

9.AppendixACompatibleChannelGroups...............................................................29-31

01QUICK SETUP: receiver

1.Donotconnectthereceivertoanyotherequipmentyet!

2.ConnectthetwoAntennastothereceiver.

3.Installthebladesintothepowersupply,plugitintothebackofthereceiver,

andintoanoutlet.

4.PressthePOWERswitch.Displaywilllightup.

5.Pressandholdthe buttonuntilCLEARSCANscrollsacrossthescreen.

6.WhenCLEARSCANstops,thereceiverwillbesettotheclearestchannel.

7.Turnthereceiveroffandconnectthemixerorotheraudiosystemtothereceiver

XLRConnectororthe¼inchLineLevelJack.

8.Settheaudiomixerorothersysteminputleveltominimum.

9.PressthePowerswitchbuttoninagain.

Receiver “Quick Set-up” is complete.

QUICK SETUP: transMitter

1.WiththePowerswitchonthetransmitterOFF,installtwofreshAAbatteriesintothetransmitter.

2.PressthetransmitterPowerSwitchuntilthedisplaycomeson.

3.HoldthetransmitterwiththeEZsyncPortfacingthereceiver,aboutafoot(30cm)away.

4.PresstheSYNCButtononthereceiver,SYNCwillshowinthedisplay.

5.Oncethechannelissetinthetransmitter,thedisplaywillswitchtothemain

displayandshowRFandAudioLevels.

Transmitter “Quick Set-up” is complete.

R300

EZsync Clear

SYNC

EZsync

R300 ClearScan

SET

QUICK SETUP: systeMs operation

1.Setthemixer/ampgain.

2.Talkorsingintothemicrophoneorplaytheguitaratanormalvolume.You

shouldhearaudiocomingoutofthesystem.

3.Youmayhavetoadjustthegain(viathecontrolnexttotheconnectoronthe

receiverbackpanel)toprovidethebestinputvolumeforyourmixer/amp.

“Quick Set-up” is now complete. Please enjoy your R300 system.

SYNC

R300

EZsync Clear

SET

EZsync ClearScan

Electro-Voice

300

ANTENNA B ANTENNA A12V .500mA

MIN MAX

VOLUME

LEVEL

-10dB 0dB

BALANCED OUT UNBALANCED OUT

DETAILED coMponent descriptions

2.1 |R300 Receiver

RECEIVER CONTROLS, CONNECTORS

1.PowerON/OFF

2.SYNCDataTransferButton

3.InfraredEZsyncWindow

4.GraphicalDisplay

 a.ChannelorFrequencyDisplay

 b.DiversityIndicator

 c.RFStrengthMeter

 d.AudioLevelMeter

 e.LockIndicator

 f.SquelchLevelIndicator

5.ScrollDownandUp( and )ControlButtons

6.SETControlButton

7.ClearScanControl(pressandhold button)

8.TNCAntennaInputConnectors(2)

9.BalancedOutputVolumeControl

10.XLRBalancedOutputConnector

11.¼InchUnbalancedLineLevelAudioOutputConnector

12.UnbalancedOutputLevelSwitch(-10dBor0dB)

13.DCPowerConnector(12VDC,500mA)

14.PowerCordRetainer

8 89 10 11 12 13 14

DETAILED coMponent descriptions

2.1 |Receiver Setup & Operation

1.Placethereceiverandantennaswherethereisaclearlineofsighttotheareawherethetransmitter

willbeused.Rotatetheantennastoseparatethemby90degrees.

2. Install the appropriate power connection blades into the power supply and connect the

power supplycordtothereceiver.PlugthepowersupplyintoanACoutlet.Pushthepower

buttontoturnthereceiveronandconrmthatitisonbycheckingthemaindisplayscreen.

3. Manual Channel Change

  a.The and buttonsallowyoutoscrollthroughtheChannels.WhentheChannel

youdesireisdisplayed,stopscrolling.

  b.After2secondsthedisplayedchannelnumberwillstarttoash.

  c.Thenumberwillstopashingandthenewchannelisinstalled.

  d.TurnonthetransmitterandholdtheEZsyncportfacingthereceiverEZSyncport,

aboutafoot(50cm)away.

ANTENNA B ANTENNA A12V .500mA

MIN MAX

VOLUME

LEVEL

-10dB 0dB

BALANCED OUT UNBALANCED OUT

e.PresstheSYNCbuttononthereceivertotransferthechannelinformation.

f.ThereceiverwilldisplaySYNCuntilthedataistransferred,thenreturntothemainscreen.

g.Thetransmitterdisplayscreenwillnowshowthenewchannelandfrequency.

h.Ifthechanneldatawasnottransferredtothetransmitterafter5seconds,thereceiver

willdisplayERROR.BecertainthatthetransmitterisOnandtheEZsyncportisfacingthereceiver

andtryagain.

i.Ifthedatastilldoesnottransfer,trynewbatteries,ormovetheunittoashadedareaawayfrom

directsunlightbeforetryingagain.

R300

EZsync Clear

SYNC

EZsync

R300 ClearScan

SET

R300

EZsync Clear

SYNC

EZsync

R300 ClearScan

SET

DETAILED coMponent descriptions

4. ClearScan: Thisfeatureautomatestheprocessofndingaclearchannel.

  a.Toscanfortheclearestchannelinagroup,pressandhold untilCLEARSCAN

appearsinthedisplay,thenreleasethebutton.

  b.Whenthescaniscomplete,thedisplaywillshowtheclearestavailablechannel.

  c.UsetheSYNCbuttontotransferthenewchannelasinstep3.

5.DuringsetupmakesurethemixeroramplierinputusedfortheR300ismutedor

turneddowntoaminimumlevel.

6.Pluganaudiocable(notsupplied)intothe3pinXLRor¼inchoutputoftheR300.

Note:TheXLRconnectoristhepreferredconnectionsincetheoutputisbalancedandwillbe

moreimmunetonoiseforlongerrunsofcablealthougheithercanbeusedwithgoodresults.

Setthebalancedoutputlevelonthebackpanelto12o’clock(midwayintherange)tostartand

adjustlaterifnecessary.Ifthe¼inchunbalancedoutputisused,startwithadjustmentswitchin

the-10dBsetting.
