Electralog Fireplace Compact Manual de usuario
Owner’s Manual
Model
20" Compact
7207250100R07
IMPORTANT SAFETY INFORMATION: Always read this manual rst
before attempting to install or use this replace. For your safety, always
comply with all warnings and safety instructions contained in this manual
to prevent personal injury or property damage.
2 www.dimplex.com
Table of Contents
Always use a qualied techni-
cian or service agency to repair
this stove.
!NOTE: Procedures and
techniques that are considered
important enough to empha-
size.
CAUTION: Procedures and
techniques which, if not care-
fully followed, will result in
damage to the equipment.
WARNING: Procedures and
techniques which, if not care-
fully followed, will expose the
user to the risk of re, serious
injury, or death.
Welcome & Congratulations .................3
IMPORTANT INSTRUCTIONS ...............4
Installation ...............................7
Operation ................................8
Maintenance ............................11
Warranty ...............................13
Replacement Parts ........................15
3
Welcome & Congratulations
Thank you and congratulations for choosing to purchase an electric
replace from Electralog, the world leader in electric replaces.
Please carefully read and save these instructions.
CAUTION: Read all instructions and warnings carefully before
starting installation. Failure to follow these instructions may result in a
possible electric shock, re hazard and will void the warranty.
Please record your model and serial numbers below for future
reference: model and serial numbers can be found on the Model and
Serial Number Label.
NO NEED TO RETURN TO THE STORE
Questions with operation or assembly? Require Parts Information?
Product Under Manufacturer’s Warranty?
Contact us at: www.dimplex.com/customer_support
For Troubleshooting and Technical Support
OR Toll-Free 1-888-346-7539
Monday to Friday 8:00 a.m. to 4:30 p.m. EST
Please have your model number and product serial
number ready. (See above)
S E R IAL No.
MODE L
MOD.
4 www.dimplex.com
IMPORTANT INSTRUCTIONS
When using electrical appliances,
basic precautions should always
be followed to reduce the risk of
fire, electric shock, and injury to
persons, including the following:
①Read all instructions before
using the electric replace.
②This heater is hot when in use.
To avoid burns, do not let bare
skin touch hot surfaces. The trim
around the heater outlet becomes
hot during heater operation. Keep
combustible materials, such
as furniture, pillows, bedding,
papers, clothes, and curtains at
least 3 ft (0.9 m) from the front of
the heater and keep them away
from the sides and rear.
③ Extreme caution is neces-
sary when any heater is used by
or near children or invalids and
whenever the unit is left operating
and unattended.
④ Always unplug the heater when
not in use.
⑤Do not operate any heater
after it malfunctions. Disconnect
power at the service panel and
have the heater inspected by a
reputable electrician before reus-
ing.
⑥ Do not operate any unit with
a damaged cord or plug, or if the
heater has malfunctioned, or if
the electric replace has been
dropped or damaged in any man-
ner, contact Technical Service at
1-888-346-7539.
⑦ Do not use outdoors.
⑧ This heater is not intended for
use in bathrooms, laundry ar-
eas and similar indoor locations.
Never locate this heater where
it may fall into a bathtub or other
water container.
⑨ Do not run cord under carpet-
ing. Do not cover cord with throw
rugs, runners, or the like. Arrange
cord away from trafc area and
where it will not be tripped over.
⑩ To disconnect heater, turn
controls to off, then remove plug
from outlet.
⑪ Do not insert or allow foreign
objects to enter any ventilation
or exhaust opening as this may
cause an electric shock or re, or
damage the heater.
⑫ To prevent a possible re, do
not block air intakes or exhaust in
any manner.
⑬ All electrical heaters have
5
SAVE THESE INSTRUCTIONS
IMPORTANT INSTRUCTIONS
hot and arcing or sparking parts
inside. Do not use in areas where
gasoline, paint, or ammable
liquids are used or stored.
⑭ Do not modify the heater.
Use it only as described in this
manual. Any other use not recom-
mended by the manufacturer may
cause re, electric shock, or injury
to persons.
⑮ To reduce the risk of electric
shock, this heater has a polarized
plug (one blade is wider than the
other). This plug will t in a polar-
ized outlet only one way. If the
plug does not t fully in the outlet,
reverse the plug. If it still does not
t, contact a qualied electrician
to install the proper outlet. Do not
change the plug in any way.
⑯Always plug heaters directly
into a wall outlet/receptacle.
Never use with an extension cord
or relocatable power tap (outlet/
power strip).
⑰ Do not burn wood or other ma-
terials in the Compact Fireplace.
⑱ Do not strike the front glass.
⑲ Always use a certied electri-
cian should new circuits or outlets
be required.
⑳ Always use properly grounded,
fused and polarized outlets.
㉑ Disconnect all power supply
before performing any cleaning,
maintenance or relocation of the
heater.
㉒ When transporting or storing
the heater and cord, keep in a
dry place, free from excessive
vibration and store so as to avoid
damage
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
NO USER-SERVICABLE PARTS INSIDE
6 www.dimplex.com
IMPORTANT INSTRUCTIONS
!NOTE: This equipment has been
tested and found to comply with
the limits for Class B digital device,
pursuant to part 15 of the FCC
Rules. These limits are designed to
provide reasonable protection against
harmful interference in a residential
installation. This equipment
generates, uses and can radiate
radio frequency energy and, if not
installed and used in accordance with
the instructions,may cause harmful
interference to radio or television
reception, which can be determined
by turning the equipment off and
on, the user is encouraged to try to
correct the interference by one or
more of the following measures:
• Reorient or relocate the receiving
antenna.
• Increase the separation between
the equipment and the receiver.
• Connect the equipment into an
outlet on a circuit different from
that to which the receiver is
connected.
• Consult the dealer or an
experienced radio/TV technician
for help.
Operation is subject to the following
two conditions: (1) this device may
not cause interference and; (2) this
device must accept any interference,
including interference that may cause
undesired operation of the device.
WARNING: Remote control
contains small batteries. Keep
away from children. If swallowed,
seek medical attention immedi-
ately.
WARNING: Do not install bat-
tery backwards, charge, put in re
or mix with used or other battery
types - may explode or leak caus-
ing injury.
!NOTE: Changes or modica-
tions not expressly approved by
the party responsible for compli-
ance could void user's authority to
operate the equipment.
7
Installation
Figure 1
Rear Support
Main Body
Mantel Top
Hardware
WARNING: Ensure the power
cord is not installed so that it is
pinched or against a sharp edge
and ensure that the power cord is
stored or secured to avoid tripping
or snagging to reduce the risk
of re, electric shock or injury to
persons.
WARNING: Construction
and electrical outlet wiring must
comply with local building codes
and other applicable regulations
to reduce the risk of re, electric
shock and injury to persons.
WARNING: Do not attempt
to wire your own new outlets or
circuits. To reduce the risk of re,
electric shock or injury to persons,
always use a licensed electrician.
WARNING: To reduce the risk
of re, do not store or use gaso-
line or other ammable vapors or
liquids in the vicinity of the heater.
CAUTION: High temperature,
risk of re, keep electrical cords,
drapery, furnishings, and other
combustibles at least 3 ft (0.9 m)
from the front of the heater.
!NOTE: A 15 Amp, 120 Volt
alternating current (VAC) circuit
is required. A dedicated circuit
is preferred but not essential in
all cases. A dedicated circuit will
be required if, after installation,
the circuit breaker trips or fuse
blows on a regular basis when the
heater is operating. Additional
appliances on the same circuit
may exceed the current rating of
the circuit breaker.
(No assembly required for the
at wall mantel)
Corner Mantel Assembly
1. Assemble the top of the man-
tel to the rear support using
the supplied hardware.
2. Using the supplied hardware
assemble the top and rear
support assembly to the main
replace body (Figure 1).
8 www.dimplex.com
Operation
WARNING: This electric
rebox must be properly installed
before it is used.
Manual Controls
To access the controls, swing
down the front cover panel
located on the lower front of the
replace. (Figure 2)
A. 3- Position Switch
The switch has two ON positions
marked with and “Manual”. The
“Manual“ position is for manual
operation. In this position the
built-in remote control is by-
passed.
The position is for operating the
unit with the provided remote con-
trol. When in position, the unit
is operated with the ON and OFF
buttons of the remote control.
When the switch is in the center
position the unit is off.
B. Heater ON/OFF Switch
The Heater ON/OFF Switch sup-
plies power to the heater fan and
the heater element. When the
Fireplace Installation
1. Make sure the unit’s 3-Posi-
tion switch is switched OFF
(refer to operating instruction
section).
2. Plug the unit into a 15 Amp,
120 VAC outlet.
Installation
L1
N
N
SWITCH OUT
CUTOUT THERMOSTAT
M
M
L
HEAT ON/OFF
SWITCH
LIGHT HARNESS
ASSEMBLY
FLICKER
MOTOR
CAPACITOR
BLOWER
MOTOR
ELEMENT
Wiring
9
Operation
Figure 2 AC B
switch is in the ON position the
heater operates if the thermostat
calls for heat.
!NOTE: The heater on your
replace may emit a slight,
harmless odor when rst used.
This odor is a normal condition
caused by the initial heating of
internal heater parts and will
not occur again.
C. Heater Thermostat Control
To adjust the temperature to your
individual requirements, turn the
thermostat control clockwise all
Figure 3
the way to turn on the heater.
When the room reaches the
desired temperature, turn the
thermostat knob counter clock-
wise until you hear a click. Leave
in this position to maintain the
room temperature at this setting.
For additional heat, turn clockwise
until you hear the click again and
the heater will turn on.
Resetting the Temperature
Cutoff Switch
Should the heater overheat, an
automatic cut out will turn the
heater off and it will not come
back on without being reset. It
can be reset by switching the
3-Position Switch to OFF and
waiting 5 minutes before switch-
ing the unit back on.
CAUTION: If you need to con-
tinuously reset the heater, unplug
the unit and call technical support
at 1-888-346-7539.
Remote Control (Figure 3)
The replace is supplied with an
Off
Button
On
Button
Battery
cover
Plastic
strip
10 www.dimplex.com
Operation
integrated on/off remote control.
!NOTE: Ensure that the re-
place 3 position switch is set to
the remote control setting (up
position).
To operate, push the ON button
to turn replace on, push the OFF
button to turn the replace off.
!NOTE: Before attempting any
operation with the remote, pull
the plastic insulator strip out
from between the remote cas-
ing and battery cover (Figure 3).
Remote Control Initialization/
Reprogramming
In the event that your remote
control ceases to operate your
replace, follow these steps to
re-initialize the remote control and
the remote control receiver in the
replace:
1. Place the 3-position switch
(Figure 2A) in the Off (“ O ”)
position.
2. Wait a minimum of ve sec-
onds and then place the
3-Position Switch in the Re-
mote Control (“ ”) position.
3. Within 10 seconds of chang-
ing the switch position, press
the ON button located on the
remote control (Figure 2).
This will synchronize the remote
control and the replace receiver.
!NOTE: You will have only 10
seconds to perform this last step.
Failure to do so will result in these
steps needing to be followed
again.
Battery Replacement
(Figure 3)
To replace the battery:
1. Slide battery cover open on
the remote control.
2. Correctly install one 12 Volt
(A23) battery in the battery
holder.
3. Close the battery cover.
Battery must be recycled
or disposed of properly.
Check with your Local
Authority or Retailer for recycling
advice in your area.
Otros manuales para Fireplace Compact
3
Tabla de contenidos
Otros manuales de Chimenea de interior de Electralog
Electralog
Electralog Fireplace Compact Manual de usuario
Electralog
Electralog Electric Fireplace Manual de usuario
Electralog
Electralog Fireplace Compact Manual de usuario
Electralog
Electralog CFP3913 Manual de usuario
Electralog
Electralog CFP3850E Manual de usuario
Electralog
Electralog DF2006 Manual de usuario
Electralog
Electralog ELECTRALOG DFP15-1131HO Manual de usuario
Electralog
Electralog Fireplace Compact Manual de usuario
