Instruction Manual
HCT-BTP01 series
ECLEAR LEANUP
For use in Japan only.
A customer who purchases outside Japan should refer to the
localized manuals in the country of purchase.
www.elecom.co.jp/global/download-list/manual/
Thank you for purchasing Eclear leanup.
This Instruction Manual features operating methods, as well as precautions for safe handling of
the product.
Be sure to read this Instruction Manual prior to using the product. Store this Instruction Manual
for safekeeping once you have finished reading.
Advantages of the product
Simple four-step operations via the app
※Ensure that the Bluetooth®on your smartphone/
laptop is set to ON
Step
1
Step
2
Step
3
Select " 引き締めた
い部分 (place(s) to
be toned)"
Select one or two
places for toning
Power ON
(long press)
※When
unconnected
to the main
unit, the pairing
settings
interface is
displayed.
※Due to continuous version upgrades, specifications are subject to change without notice
2
This product is an EMS product that supports Bluetooth®connection. You can install
the dedicated app on your smartphone or other device, and use this product via the
app for workout.
All recommended workout moves are displayed in the app and are easy to learn.
Contents
Step
4
Set the intensity and
timer, and then start
Workout app Preface
About the product ................................... 4
Safety precautions (Important) .............. 5
Precautions for cordless (Wireless)
security..................................................... 9
Package contents ................................. 10
Names of individual components ........ 11
Preparation
Charging................................................. 12
Attaching the gel pad............................ 14
Use
Basic operations ................................... 16
Using the dedicated app "ECLEAR
APP" ....................................................... 18
Examples for applying gel pads........... 23
After Use
Storing .................................................... 26
Maintenance .......................................... 27
How to store .......................................... 28
Others
Disposing ............................................... 29
Troubleshooting..................................... 30
Product specifications.......................... 33
3
Download here
ECLEAR APP
About this product
Do not use this product when you are exercising vigorously.
Moisture in sweat may cause skin inflammation or the gel pad to lose
adhesive strength.
CAUTION:
4
■What is EMS?
EMS, short for Electrical Muscle Stimulation, is a product that stimulates
mechanical movements of muscles through electrical stimulation to achieve a
workout result.
■What is deep layer frequency?
The deep layer frequency is a high frequency in the range of 2,000 to 5,000 Hz.
The higher the frequency, the more body parts where fat has accumulated can
be stimulated. The core muscles of the body that are normally hard to stimulate
can be stimulated.
■What is relaxation frequency?
The relaxation frequency is a low frequency in the range of 20 to 30 Hz. By
relaxing the muscles contracted by the deep layer frequency, you can train for
long hours without exhausting your muscles.
■Stretching
By using this product while your muscles are stretched, you can train
hard-to-stretch tendons and improve flexibility.
■Dedicated app
By pairing this product with a smartphone using Bluetooth®, you can use up to
two products with the dedicated app. This product can also be used without
the dedicated app.
■Recommended operating time
Use the gel pad on one place in one day, for about 30 minutes. Do not use this
product for a long time since it might cause injury.
Set the product timer. The product will automatically power off 15 minutes after
the workout started.
Preface
Safety precautions (Important)
To avoid injury and property damage to the user and other people, comply with the
following instructions:
■The categories of degree of damage or risk caused by failing to following these
instructions are as follows:
DANGER This symbol indicates a high probability of death or serious injury.
WARNING This symbol indicates a probability of death or serious injury.
CAUTION This symbol indicates the possibility of bodily harm or damage to
property.
This symbol indicates a prohibited action.
These images indicates "compulsory" items that must be performed.
DANGER
Never use this product together with the following medical equipment:
• Internally implanted electronic devices such as pacemakers
• Electrical life support devices such as artificial hearts and lungs
• Wearable medical electrical devices such as an ECG
If used with the product, these types of medical devices may malfunction and
endanger life.
WARNING
The following people must not use this product.
• People suffering venous thrombosis or arterial thrombosis
• People who a doctor has instructed not to exercise
• Pregnant women
• People with telangiectasia due to prolonged use of steroid hormone drugs or
hepatic dysfunction
Do not use this product in the following cases.
• The skin near the gel pad(s) is painful • When drinking alcohol or smoking
• When you are extremely tired • During sleep or when taking a shower
Do not use the product for any other purpose than working out.
Otherwise, accidents and problems may occur.
5
WARNING
Do not let children use the device. Do not let children play or step on top device's
main unit or gel pads.
Doing so risks accidents or injuries.
Do not use this product on any of the following body parts:
•Chest and other parts near the heart; parts above the neck such as the head and face
• Mucosal surfaces such as wounds, eyes, mouth and genitals
• Areas where plastic surgery has been performed
• Where metal, plastic or silica gel is implanted
• Spine • Areas with tattoos • Abdomen (during menses)
• Parts where necklaces and watches are worn, or puncture sites
Turn off the power before connecting or removing the main unit and gel pads, and
before repasting or removing the gel pads.
Check for damage, chipping or deformation of the gel pad surface before use.
Otherwise, an accident, fault or malfunction may occur.
You must consult your doctor before using the product if any of the following
conditions apply:
• You are undergoing treatment or suffering a health condition
• Malignant cancer • Heart or cranial nerve abnormalities
• Your temperature is above 38℃ (fever)
※ Example 1: Acute onset of symptoms (e.g. fatigue, chills and blood pressure
fluctuation)
※Example 2: When feeling weak
• Infectious disease • Dermatological issues
• Acute pain, e.g., spinal fractures, contusions, or pulled muscle
• You are convalescing • Taking medication • Abnormal blood pressure
• Impaired mobility
• Impaired perceptual disability due to severe peripheral circulatory disorder caused by
diseases such as diabetes
• Low body temperature• Circulatory problems
• Your skin reacts badly to gel pads
• Epilepsy
Otherwise, accidents or discomfort may occur.
Do not disassemble, repair or modify the product.
Otherwise, a fire or electric shock may occur.
This product is intended for use by one person only. It cannot be used by multiple
people at a time.
Otherwise, an electric shock or accident may occur.
6
Do not
disassemble
Preface
CAUTION
Do not use or store the product in the locations described below.
•Areas exposed to direct sunlight
•Places near a heating device or other high-temperature unit
•Where humidity is high such as bathrooms
•Wet places •Dusty environments •On vibrating surfaces
Otherwise, fire, electric shock or malfunctions may occur.
Do not use while sleeping.
Doing so risks accidents or injuries.
Do not use immediately before driving or while driving.
Otherwise, accidents and problems may occur.
Do not leave the gel pads attached on the skin for a long time.
Otherwise, inflammation of the skin may occur.
Do not use a damp gel pad.
Otherwise, an electric shock may occur.
Use the gel pad in one place only on the same day. Do not use it for more than
30 minutes.
It may cause accidents or discomfort.
Ensure the main unit and gel pad are connected correctly and securely before use.
Do not use it on more than two locations at the same time.
It may cause accidents or discomfort.
Do not use the device until you are sure that all operation buttons are working
normally.
If you feel any discomfort or skin irritation such as eczema or redness or itching,
stop using the device immediately and consult a specialist.
It may cause accidents or discomfort.
When using the device for the first time or after storing a long time, follow the
instruction manual. Before use, check that the device is working.
Do not insert metal objects into the USB port.
This may cause heating and fire.
Do not touch the USB port with your hand, finger or any other body part.
Doing so may cause an electric shock, fault or malfunction.
7
CAUTION
Do not pull, bend or place a heavy object on top of a cable.
Otherwise, the cable may be damaged, and a fire or electric shock may occur.
The attached dedicated USB cable is for charging the main unit only.
The dedicated USB cable cannot be used for communications or charging
other devices.
Do not use a travel converter or other transformers to charge the product.
It may cause heating and fire.
Do not charge the device using a vehicle's cigarette lighter.
Otherwise, a fire, heating or electric shock may occur.
If you are charging it with a commercial charger using an AC power supply, read
the charger's instruction manual thoroughly and follow the safety instructions.
When charging, insert the dedicated USB cable all the way.
Otherwise, a fire or electric shock may occur.
Do not touch the special USB cable or gel pad with wet hands.
Otherwise, an electric shock, malfunction or accident may occur.
Do not use a special USB cable when it is damaged, or when the USB
connector insertion receptacle is loose.
Otherwise, a fire or electric shock may occur.
Do not pour water or any other liquid into the main unit. Do not let the main
unit get wet.
Otherwise, heating, cracks or fire may occur.
Keep the device away from children.
Otherwise, accidents may occur. If a child swallows the main unit, consult a
specialist immediately.
If any failures occur, stop using it immediately and turn it off. Contact the
distributor or our information center.
Follow local disposal requirements to dispose of the product.
Charge the product at least once every three months.
The product may not be able to charge if it is fully discharged.
Attach the gel pad onto the skin securely.
The main unit will automatically power off when the gel pad is removed from
the skin.
The gel pad cannot securely attach to body hair and doing so will age the gel pad.
8
No wet hands
Preface
Precautions for cordless (Wireless) security
This product is a radio device that uses the 2.4 GHz band, which does not
conflict with the frequency of detecting moving objects. FH-SS is adopted, and
the interference distance is 10 m.
Medical devices and WLAN devices under IEEE802.11b/11g/11n also use
2.4 GHz.
•Before using this product, ensure no other radios※are operating nearby.
•If a radio wave causes interference between this product and another
radio※, move to another location or stop using the product.
※Other radios include industrial, scientific, and medical devices that use 2.4 GHz;
other radio stations of the same type; internal radio stations used in assembly
lines; environments for detecting mobiles objects that require a license;
specific low-power radio stations that require no license; and amateur radio
stations.
WARNING
•Do not use this product on a machine that may have significant adverse
effects due to misoperation. This product may malfunction, slow down
or not react if it is interrupted by an external electromagnetic wave at
the same frequency or one generated by a mobile phone.
• Do not use this product in places where electromagnetic waves are
prohibited such as hospitals. The electromagnetic waves generated
from this product may affect electrical devices and medical equipment
such as pacemakers.
• This product cannot be used in an airplane cabin according to aviation
law, as it may compromise the safe running of the aircraft. Power off
the main unit before boarding. Do not use the product during a flight.
※
ELECOM assumes no liability for accidents and danger to the public
arising from product malfunctions.
9
Package contents
Make sure there are no missing parts before use. We've done everything
possible to ensure the quality of packaging. In case of missing components or
damaged packaging, please immediately contact the dealer or ELECOM
one-stop shop (P.35).
■Accessory
•Instruction Manual × 1
•Storage sheet × 1
•Storage bag × 1
•Dedicated USB
cable × 1
■Main unit × 2
(Ivory white/Gray)
•Core pad × 1 (consumable)
■Accessories (Sold Separately)
Inquire the retailer for details on separately sold accessories.
The following items are sold separately.
■Accessory
•Instruction Manual × 1•Storage sheet × 1
Used for HCT-P01 series gel pads only.
Twin pad (2 pieces) SN: HCT-P01G1
Core pad (1 piece) SN: HCT-P01G2
■Main unit type: HCT-BTP01
•Twin pad × 2 (consumable)
■Gel pad
■Accessory
•Instruction Manual × 1•Storage sheet × 1
■Twin pad × 2
(consumable)
■Core pad × 1
(consumable)
10
SN: HCT-BTP01G1
SN: HCT-BTP01G2
Twin pad (2 pieces)
Core pad (1 piece)
SN: HCT-BTP01G1
SN: HCT-BTP01G2
Este manual sirve para los siguientes modelos
2
Tabla de contenidos
