LAUNAMNOITCURTSNI
HX100M
HDMI™ CAT6 Extender Series
CE labs can support many areas of your audio and video
distribution needs.
We manufacture:
• Digital Signage software and Media Players
• HD Matrix Switchers
• RF amplifiers
• HDMI and Component HD distribution amplifiers
• CAT 5 Signal Extenders
• VGA Extenders and Splitters
• and cables of all types.
See our full product line at www.celabs.net
WARRANTY
Document:
HX100M_manual.pdf
900-5065-10
3209 Wood Drive
Garland, TX 75041
Phone: (469) 429-9200
Toll free: (800) 767-6189
Fax: (469) 429-9205
www.celabs.net
Cable Electronics, Inc. warrants this product to be free from defects in
material and workmanship, under normal use and service, for a period of
one year from the purchase by the original purchaser. If this product is
defective or malfunctions, Cable Electronics will replace or repair this unit (at
their option) within a reasonable time. No expressed or implied warranty is
made for any defects caused by immersion or exposure to liquids, abuse,
neglect, improper operation of unit, excess wear and tear and defects
resulting from unauthorized disassembly and or modification.
HDMI™ Extra-Long Range CAT6 Extender uses only one
cost-effective CAT5E/6 cable to extend your HDTV display up to
328 feet at 1080p. With high-quality, uncompressed video to
deliver significant value to the entire home and commercial
entertainment system.
Features:
• Extends HDMI™ signal over one CAT5E/6 cable
• Uncompressed high definition video up to
1080p@ 60Hz@48bits and 3D capable
• Max data rate - 3.4Gbps.
• HDMI™ 1.3 and HDCP compliant
• Transmission range up to 328 feet at 1080p resolution
All manuals and user guides at all-guides.com
all-guides.com
PANEL VIEW & FUNCTION INSTALLATION VIEW
SPECIFICATIONS
Cable
Recommended: high-quality CAT5E, CAT6, CAT6A, CAT7 UTP/STP or FTP cable
Transmission Distance
The maximum transmission distance reaches up to 328 feet; using a lower
resolution will not extender longer distances.
RJ45 Pin Define
Video Link (TIA/EIA-568-B)
1. Orange-White DATA0+
2. Orange DATA0-
3. Green-White DATA1+
4. Blue DATA2+
5. Blue-White DATA2-
6. Green DATA1-
7. Brown-White DATA3+
8. Brown DATA3-
Caution
1. Keep cables away from any equipment with an electromagnetic wave, e.g.,
mobile phone, microwave, radio equipment, fluorescent lamp, high voltage power
lines...etc.
2. This device is not a network device, do not connect with a network to avoid
damages.
Package Contents
Transmitter x 1 piece
Receiver x 1 piece
Power adapter x 2 pieces
Manual
Screws
HX100M-T
HX100M-R
ITEM HX100M-T
Up to 1080p/60Hz/48bit
Type A
328 ft. (max)
Regulated 5V/2A
Operation 32-131°F, Storage: -4-185°F
Up to 95%
450mA (max)
Resolution
HDMI™ Connector
Link Cable Distance
Power Supply
Temperature
Humidity
1.9” x 3.6” x 1”
4.2 oz.
HX100M-R
950mA (max)
1.9” x 3.6” x 1”
4.8 oz.
Dimensions WxHxD
Weight
Power Consumption
PS3 HX100M-THX100M-R
100M (max)
Max. 328 ft.
Max. 15 ft. Max. 15 ft.
HX1T-3 HX1R-3Wall JackWall Jack
CAT5 Cable
