Eks E-light 2M Manual de usuario

0410001000101EV10-00 0410001000202EV10-00 0410001001111EV10-00

0410001001212EV10-00 0410001001313EV10-00 0410001003131EV10-00

0410001003333EV10-00 0410001003637EV10-00 0410001003535EV10-00

0410001005151EV10-00 0410001005353EV10-00 0410001005657EV10-00

0410001005555EV10-00

System

e-light 2M

6x10/100TX und 2x100FX

ManagedIndustrial EthernetSwitch

Version:EN_Manual_e-light-2M_v2.8.doc

Description and Manual

eks Engel GmbH&Co. KG

Schützenstraße2-4

DE-57482Wenden-Hillmicke

Tel:+49 (0)2762 93136

Fax:+49 (0)2762 9313-7906

E-Mail:info@eks-engel.de

Internet: www.eks-engel.de

Content

Introduction................................................................1

Characteristics..........................................................1

Packing content........................................................2

Viewof front panel....................................................3

Reset-button.............................................................4

DIP-switch................................................................4

LED Indications........................................................6

Ports.........................................................................8

Cabling...................................................................10

Connecting the differentialrelay.............................12

Mounting on DIN rail...............................................13

Portsand dimensions.............................................14

Hardware Installation...............................................15

Procedure:..............................................................15

Ring Function.........................................................17

Coupling Ring Application......................................18

DualHoming Application........................................19

Web-BasedManagement ........................................20

Preparations...........................................................20

SystemLogin..........................................................20

Port Status..............................................................22

Single PortInformation................................................... 22

Port Statistics.........................................................24

Port Control............................................................25

Switch Settings.......................................................26

Port Mirroring..........................................................27

VLAN Configuration................................................28

Port-BasedVLAN............................................................ 29

802.1QVLAN.................................................................. 31

Alerts......................................................................35

Configurationofemail alerts ........................................... 35

Event configuration......................................................... 36

Power alarmconfiguration.............................................. 38

IPConfiguration......................................................38

SNTPConfiguration ...............................................39

IPSecurity..............................................................42

RSTPConfiguration ...............................................43

Systemconfirguration..................................................... 43

Per PortConfiguration .................................................... 45

P-Ring....................................................................46

QoSConfiguration..................................................48

IGMP......................................................................51

SecurityManager...................................................52

SNMP Configuration...............................................53

CommunityStrings.......................................................... 54

Trap Manager................................................................. 55

Configuration Backup.............................................55

TFTPRestoreConfiguration........................................... 55

TFTPBackup Configuration............................................ 56

TFTPUpdate Firmware..........................................57

Factorysettings......................................................57

SystemReboot.......................................................58

Save the configuration............................................58

Bandwidth control...................................................58

SystemLog............................................................60

SystemLogConfiguration............................................... 60

Event configuration......................................................... 61

Trouble shooting......................................................63

Technical details......................................................64

STAND:EN_MANUAL_E-LIGHT-2M_V2.8.DOC

TECHNISCHE ÄNDERUNGEN VORBEHALTEN

SUBJECT TO TECHNICAL ALTERATIONS

SEITE :1

Introduction

e-Light2Misamanaged 6x10/100TXplus2x100FXIndustrialringswitch

especiallydesignedforindustrialapplications.AWeb GUIallowsthe very

easymanagementofe-light 2M.

Characteristics

nAccordingtoIEEE802.310Base-T,802.3u100Base-TX/100Base-FX

n6x10/100TX(RJ45)and2x100FX(POF, HCS, MM orSM)

nRJ-45 port supportsAutoMDI/MDI-Xfunction

nStore-and-forwardswitchingarchitecture

nredundant powersupply12-70VDC

nReversepolarityprotection

n2K MACadress tables

nWeb Management GUI

nEachport supports4priorityqueues

nIGMP

nIngress packetfilterandegress ratelimit

nSNTP/SMTP

nPort MirrorforTXorTXand RXpackets

nAlarmrelayoutput forsystemevents

nRingfunction

nPort basedVLAN/ 802.1Q TagVLAN

nIEEE 802.1pClass ofservicewithport base,tagbaseandprioritymethod

nDHCP client

nSNMP, web management, RMON

nTFTPfirmwareupdateand restoreaswell asbackupof systemconfiguration

STAND:EN_MANUAL_E-LIGHT-2M_V2.8.DOC

TECHNISCHE ÄNDERUNGEN VORBEHALTEN

SUBJECT TO TECHNICAL ALTERATIONS

SEITE :2

Packing content

Pleasecomparethepackingscontent withthelist below:

ne-light 2MRingManaged IndustrialSwitch

nManual

STAND:EN_MANUAL_E-LIGHT-2M_V2.8.DOC

TECHNISCHE ÄNDERUNGEN VORBEHALTEN

SUBJECT TO TECHNICAL ALTERATIONS

SEITE :3

Hardware description

Thissectioncontainsinformationaboutthehardware,the ports,thecabling

and theinstallation ofe-light 2M.

Viewof front panel

Front panelofe-Light2M

STAND:EN_MANUAL_E-LIGHT-2M_V2.8.DOC

TECHNISCHE ÄNDERUNGEN VORBEHALTEN

SUBJECT TO TECHNICAL ALTERATIONS

SEITE :4

Reset-button

Withthe resetbutton the switchcan fastandeasilybe resetandrestarted andthe

configurationcanbereset tothedefault value.

nRestart: Keepthe button pressed for2seconds.

nResettodefaultvalue: Keepthe button pressed for5

seconds.Theswitchresetsall configurationtothe default

value.

DIP-switch

Theswitchhasgota9-Dipswitchforthe configuration of the operation mode,

the alarmrelayand thefunction ofthe ringmaster.Thedefaultvalue ofthe

switchis OFF.

DIP SwitchNo Status Description

OFF Alarmof port 1switchedoff.

ON Alarmof port 1active.If theport’slink

fails, thefault LEDlightsup.

OFF Alarmof port 2switchedoff.

ON Alarmof port 2active.If theport’slink

fails, thefault LEDlightsup.

STAND:EN_MANUAL_E-LIGHT-2M_V2.8.DOC

TECHNISCHE ÄNDERUNGEN VORBEHALTEN

SUBJECT TO TECHNICAL ALTERATIONS

SEITE :5

OFF Alarmof port 3switchedoff.

ON Alarmof port 3active.If theport’slink

fails, thefault LEDlightsup.

OFF Alarmof port 4switchedoff.

ON Alarmof port 4active.If theport’slink

fails, thefault LEDlightsup.

OFF Alarmof port 5switchedoff.

ON Alarmof port 5active.If theport’slink

fails, thefault LEDlightsup.

OFF Alarmof port 6switchedoff.

ON Alarmof port 6active.If theport’slink

fails, thefault LEDlightsup.

OFF Alarmof port 7switchedoff.

ON Alarmof port 7active.If theport’slink

fails, thefault LEDlightsup.

OFF Alarmof port 8switchedoff.

ON Alarmof port 8active.If theport’slink

fails, thefault LEDlightsup.
