USER MANUAL AUTOMATIC WEIGHING METER FOR EICKSORBER
T +49 7461 96 580 0 | F +49 7461 96 580 90 | export@eickemeyer.com | www.eickemeyer.com
2. SPECIFICATIONS
• Zeroing by one button only. Display provides real-time canister weight readings.
Max. Capacity: 2kg, Resolution: 1g, Accuracy: 5g.
• There are 3 alarm modes include alarm I, alarm II and Overweight alarm.
Remind anesthesiologist by alarm with sound and light.
– Alarm I (1.000g < reading of weight meter < 1.020g, be stable for 1 second):
Sound and light alarm, 0,5hz (1 time / s);
– Alarm II (1.020g < reading of weight meter < 1.500g, be stable for 1 second):
Sound and light alarm, 2hz (1 time / s);
– Overweight alarm (reading of weight meter > 1.500g, be stable for 1 second):
Sound and light alarm, indicator stays on, buzzer stays on
• Automatic recognition to the size of EICKEMEYER® EickSorber Anaesthetic Gas Filter
• Alternative duration of muting, pause alarm
– Press the mute button down briefl y, keep muting for 5min, then resume alarm
– Press and hold the mute button down for 3 seconds, keep muting for 30min, then resume alarm
• Power: Input: 100 – 240VAC, 50 / 60HZ, 0,5A; Output: DC 12V / 1A
• Weight: 1,4kg
3. UNPACKING, ASSEMBLING AND OPERATION
Unpacking and Assembling
Open the box and remove the instrument and accessories. Check the packing list (eg. Fig. 1.1). If there is damage or lack,
please contact EICKEMEYER® immediately.
Put the instrument onto a stable and safety platform. Insert the supporting metal rod and transfer hose. Switch on the power.
Put the instrument onto a stable and safety platform. Insert the supporting metal rod and transfer hose. Switch on the power.
Fig. 3.1: Assembling the product
