Cummins 6.7L CM2100A CSP5

User Guide

EFILive, EFILive FlashScan and EFILive AutoCal are registered trademarks of EFILive Limited.

All other trademarks belong to their respective owners.

Cummins 6.7L CM2100A CSP5

User Guide

First published

14 August 2014

Revised

8 July 2021

Cummins 6.7L CM2100A CSP5UserGuide

support@efilive.com - 1 - www.efilive.com

Contents

............................................................................................................4

Prerequisites....................................................................................................................4

Intended Audience.......................................................................................................4

Computer Knowledge...................................................................................................4

Tuning Knowledge .......................................................................................................4

......................................................................................................5

Introduction......................................................................................................................5

What is EFILive?..........................................................................................................5

What is EFILive CSP5? ................................................................................................5

Software Version Overview..........................................................................................6

...............................................................................................................7

CSP5Upgrade.................................................................................................................7

CSP5Upgrade Checklist..............................................................................................7

Upgrade Operating System to CSP5............................................................................7

Tune Switch Password.................................................................................................9

CSP5Output Driver......................................................................................................9

CSP5Tune 6 - Switch via ECM Input.........................................................................10

CSP5CAN Tunes.......................................................................................................10

Supported Switching Methods ...................................................................................11

..........................................................................................................12

Cummins 6.7L CM2100A CSP5UserGuide

support@efilive.com - 2 - www.efilive.com

V8 Scan and Tune Scan................................................................................................12

Pass-Thru Data Logging............................................................................................12

Pass-Thru Licence and Flash a Controller.................................................................13

..........................................................................................................15

Configure FlashScan/AutoCal for BBX..........................................................................15

EDA Data Logging .....................................................................................................15

Configure Tuning........................................................................................................16

Tune File Switching....................................................................................................16

Configure DTCs .........................................................................................................16

Quick Setup ...............................................................................................................16

.............................................................................................................18

FlashScan Menu Navigation..........................................................................................18

FlashScan/AutoCal V3...............................................................................................18

Data Logging..........................................................................................................18

License and Flash a Controller...............................................................................18

Switch Tunes using FlashScan/AutoCal V3 ...........................................................19

FlashScan V2.............................................................................................................19

Data Logging..........................................................................................................19

License and Flash a Controller...............................................................................20

Switch Tunes using FlashScan V2.........................................................................20

.............................................................................................................22

Support..........................................................................................................................22

Trouble Shooting........................................................................................................22

Error Codes................................................................................................................22

Checksums ................................................................................................................22

Failed Flash Recovery Methods.................................................................................23

Cummins 6.7L CM2100A CSP5UserGuide

support@efilive.com - 3 - www.efilive.com

Flash Base with without tune file security restrictions.............................................23

ROM Boot Recovery...............................................................................................23

Test for Rogue Modules.............................................................................................23

Trace Files .................................................................................................................23

V8 Scan and Tune *.htx files ..................................................................................23

FlashScan/AutoCal V3 *.xalm files.........................................................................24

FlashScan V2 Trace Files ......................................................................................24

Knowledgebase..........................................................................................................24

EFILive Authorized Dealer.........................................................................................25

How to Tune?.............................................................................................................25

EFILive Service Desk.................................................................................................25

Cummins 6.7L CM2100A CSP5UserGuide

support@efilive.com - 4 - www.efilive.com

Prerequisites

Intended Audience

EFILive Customers using the V8 Scan and Tune Tool software.

Computer Knowledge

It is expected that readers have a basic understanding of:

The Windows operating system;

Starting and using Windows applications;

Navigating folders using Windows Explorer.

Tuning Knowledge

It is expected that readers have a basic understanding of:

Electronic Fuel Injection;

On Board Diagnostics.

Cummins 6.7L CM2100A CSP5UserGuide

support@efilive.com - 5 - www.efilive.com

Introduction

What is EFILive?

EFILive is tuning software and hardware - it is not a tune. Together the software

and hardware give users the tools to write tunes. EFILive does not provide tune

files, tuning advice or support, but do provide software support and hardware

support.

What is EFILive CSP5?

EFILive's CSP5 custom operating systems for Cummins controllers allows

customers to be able to switch 'on the fly' between multiple tunes, all stored in the

ECM's flash memory. Historically, Cummins Switchable Programming had 5 tune

positions; however as supported Cummins platforms have expanded this no

longer holds true. ECM memory now defines the number of tunes that are

available for switching for each ECM type as per the table below.

CSP Controller Matrix

CMB (CM849)

2006-2007 5.9L

CSP5

5 tunes accessible through CAN

bus switching, and a 6th tune that is

switched using an input on one of

the ECM connectors.

CMC (CM2100A)

2007-2009 6.7L

CSP5

CMD (CM2200)

Pick Up Trucks

2010-2012 6.7L

CSP5

5 Tunes accessible through CAN

bus switching.

CMD (CM2200)

Cab & Chassis

2010-2012 6.7L

CSP2

2 tunes accessible through CAN

bus switching.

CME (CM2350B)

2013-2018 6.7L

CSP4

4 tunes accessible through CAN

bus switching.

CMF (CM2450B)

2019+ 6.7L

CSP5

5 tunes accessible through CAN

bus switching.

Whilst different controllers contain different numbers of tunes, collectively this

feature is still referred to as CSP5.

Having multiple tunes instantly accessible means changing tunes to suit different

driving conditions no longer requires the ECM to be reflashed each time you

choose to run a different tune. (E.g. racing, towing, or power limiting.) Simply build

multiple tunes to fill the CSP5slots, flash the ECM once and then select your

desired tune through your EFILive hardware (or other approved switching devices)

at any time.

CSP5delivers scanning enhancements to customers via Enhanced Data

Acquisition (EDA). EDA, EFILive’s custom scanning mode is the first of its kind

and aims to simplify the task of information sharing between users as every

individual data parameter has been selected with tuning feedback in mind. EDA

allows customers to log 45 individual data parameters specifically chosen to

Cummins 6.7L CM2100A CSP5UserGuide

support@efilive.com - 6 - www.efilive.com

complement tuning at up to 50 frames per second for V8 BBL & V7.5 pass through

logging.

EDA scanning is only available on CSP5upgraded ECM's.

Software Version Overview

This version of the Cummins 6.7L CM2100A CSP5User Guide migrates all

processes to EFILive V8 Scan and Tune software. Functionality is still available in

V7.5 software, however software support and bug fixes will cease in 2021.

FlashScan/AutoCal V3 and AutoCal V2 are not compatible with V7 software. V7

functions are only supported by FlashScan V2. The following is a brief view of the

activities that are performed with the different software versions:

Feature

Scanning

OBDII Diagnostics

Reading

Flashing

Tune Editing

VIN License Management

Firmware Management

Cummins 6.7L CM2100A CSP5UserGuide

support@efilive.com - 7 - www.efilive.com

CSP5 Upgrade

CSP5Upgrade Checklist

CSP5upgrades are only available on specific factory operating systems. Typically

these are based on the latest factory update (at time of development). If you have

a truck that has an OS not listed below, you will need to upgrade your base file

first.

Supported CSP5 operating systems are listed in the table below. These were the

latest factory updates as of early 2015; released 5 years after this ECM type was

introduced.

EFILive will not be offering CSP on older, obscure or obsolete OS's. No further

EFILive development is scheduled for the Dodge Cummins CMC platform.

CSP5Supported Operating Systems

11520902

11620606

11551031

11620807

11551032

11710806

11551035

11720604

11610805

11720606

11620604

11720809

Where a vehicle has been previously tuned with a product other than EFILive, the

conversion process may fail and render the ECM non-functional and not

recoverable.

EFILive recommends users source a good known base file for CSP5.

To upgrade to CSP5 exclusively in EFILive V8 Scan and Tune software you must

be running the following (or higher) software versions.

1. EFILive V8.3.8 or later.

2. FlashScan V3 / AutoCal V3 Firmware –V3.00.066.

3. FlashScan V2 / AutoCal V2 Firmware - V2.08.176.

The latest software versions are available for download from EFILive's website.

Upgrade Operating System to CSP5

1. Open V8 Scan and Tune software and your stock tune file.

2. Navigate to [F5: Edit].

3. Expand the Internal Flash -> Operating System Patches Folder and select CSP5

v1.02 Custom Operating System.

4. Select the [Apply Upgrade] button.

5. Select [Yes] to the “This operation cannot be undone, continue?” dialog box.

Cummins 6.7L CM2100A CSP5UserGuide

support@efilive.com - 8 - www.efilive.com

6. A message indicating “Upgrade applied successfully.” will now display.

7. Save the file with a new name using, File > Save As. Maybe something like...

'My Truck Base CSP5 Conversion.ctz’.

8. Close the tune file.

9. On the EFILive V8 Scan and Tune Recent Items list you will see your stock tune

and your upgraded CSP5tune. Confirm that the operating system number on the

base file is different to the upgraded CSP5converted file.

10.Reopen the tune file that was converted.

11.Navigate to [F5: Edit] and expand the EFILive Custom Calibrations folder.

Tabla de contenidos

Otros manuales de Accesorios para automóviles de EFILive

EFILive

EFILive CM2350B Manual de usuario

EFILive

EFILive AutoCal Manual de usuario

EFILive

EFILive Dodge Cummins Manual de usuario

Manuales populares de Accesorios para automóviles de otras marcas

James Baroud

James Baroud Odyssey Manual de usuario

Motorola

Motorola i50sx Manual de usuario

Yakima

Yakima 9MM STANDARD BIKE MOUNT Manual de usuario

Feniex

Feniex T3 Manual de usuario

Renault

Renault 77 11 423 180 Manual de usuario

Kia

Kia E8300-4D000 Manual de usuario

Brink

Brink 756843 Manual de usuario

Whispbar

Whispbar K085W Manual de usuario

v.link

v.link CI-VL2-PC-HSD Manual de usuario

Viking

Viking Stack-Rack Guía de configuración rápida

Aries

Aries 203015 Manual de usuario

Choetech

Choetech AT0005 Manual de usuario

ZZ2

ZZ2 ZZAIR-PRO Manual de usuario

Holman

Holman 4A80L Manual de usuario

Thule

Thule 2075 Manual de usuario

Motorola

Motorola T325 Manual de usuario

TAUBENREUTHER

TAUBENREUTHER 16-3950 Guía de instalación

DV8

DV8 FBJL-02 Manual de usuario
