Edimax BR-6504n Manual de usuario

www.edimax.com EDIMAX TECHNOLOGY CO., LTD.

IEEE802.11nDraft2.0

WirelessBroadbandRouter

BR-6504n

U.K.

Edimax Technology (UK) Ltd.

TEL: +44-845-1238307

FAX: +44-845-1238306

[email protected]

Poland

Edimax Technology Europe

B.V. SP. Z O.O.

Tel: +48-22-6079-480

Fax: +48-22-6079-481

sales@edimax.pl

U.S.A.

Edimax Computer Company

TEL: +1-408-496-1105

FAX: +1-408-980-1530

sales@edimax.com

Latin America

TEL: +1-786-845-8099

FAX: +1-786-331-8490

sales_latinamerica@edimax.com

China

TEL: +86-10-6213-9288

FAX: +86-10-6213-9231

Russia

Edimax Technology Russia

Tel./Fax: +7-495-101-0239

sales@edimax.pl

Taiwan / Headquarters

Edimax Technology Co., LTD.

TEL: +886-2-7739-6888

FAX: +886-2-7739-6887

sales@edimax.com.tw

Europe

Edimax Technology Europe B.V.

TEL: +31-499-377344

FAX: +31-499-372647

sales@edimax.nl

Complies with IEEE802.11n Draft 2.0(2T3R)

BR-6504n complies with 802.11n draft 2.0, the next generation wireless

standard. With the advanced MIMO technology, it can support the data

transmission rate 6 times more (up to 300Mbps) and the coverage 3 times

more than IEEE 802.11g/b devices. BR-6504n stable wireless connection

and high bandwidth enable you enjoying the network applications without any

interruption.

Wi-Fi Protected Setup (WPS)

WPS function provides easy procedures to set up wireless security. Just press

the BR-6504n WPS button and you can simplify the security setting.

lP Sharing

The NAT/NAPT function lets you share the broadband connection to all the

network users (up to 253 users).

Supports Special Applications

You can set the trigger ports of application software (like Internet Gaming) so

BR-6504n will not block the communication with Internet of those applications.

Virtual Server and DMZ

The virtual server and DMZ function let you set up servers in the network which

can be accessed for the Internet users.

Detachable Antenna

BR-6504n three detachable 3dBi RP-SMA antennas allow you change to other

high gain antennas or use in combination with Edimax EA-MARS (antenna

relocator) to increase wireless coverage.

www.edimax.com EDIMAX TECHNOLOGY CO., LTD.

Features

•Complies with 2.4GHz IEEE802.11n Draft v2.0 and backward compatible

with IEEE 802.11b/g standards

•Supports NAT/NAPT IP sharing

•WAN Protocols: PPPoE/Static IP/PPTP/DHCP

•Supports advanced 2T3R MIMO technology to enhance the throughput

and coverage range significantly

•High speed data rate – up to 300Mbps.

•Supports Virtual Server and DMZ

•Supports Wi-Fi Protected Setup ( WPS ) with reset button

•Supports 64/128-bit WEP encryption and WPA-PSK, WPA2-PSK security

•Supports WMM function to meet the multimedia transmission requirement

•Supports WDS mode

•Supports Special Applications (Port Triggers)

•Supports DDNS (DynDNS, TZO), and QoS

•Supports VPN pass through (IPSec/PPTP)

•Supports MAC/IP filtering and URL blocking

•Supports DHCP server and Anti-Dos firewall

•Web user interface (remote configuration)

•System status and security log

•Firmware upgradeable

Specification：

Model NO. BR-6504n

Interface 1WAN + 4LAN 10/100Mbps UTP Ports

Flash 4 MB NOR Flash

RAM 16 MB SDRAM

Button WPS / Reset

Antenna RP-SMA Detachable 3dBi Antenna x 3

Power DC12V , 1A Switching Power Adapter

LED Indicators Power , WLAN , WAN

10/100Mbps and Link/Activity

Dimension 192 x 115 x 29 mm

Humidity 10~90% (Non-Condensing)

Temperature 0 ~ 45 ℃

Certifications CE, FCC
