Edimax BR-6428nS V2 Manual de usuario
BR-6428nS V2
BR-6428nC
Quick Installation Guide
09-2013 / v1.1
1
PackageContents
Beforeyoustartusingthisproduct,pleasecheckifthereisanythingmissingin
thepackage,andcontactyourdealertoclaimthemissingitem(s):
BR‐6428nSV2
(5dBiAntennax2)
BR‐6428nC
(9dBiAntennax2)
PowerAdapter
EthernetCable QuickInstallationGuideCD‐ROM
or
2
Installation
1.Plugtheincludedpoweradapterintothedevice’s5VDCpowerportand
theotherendintoanelectricalsocket.
2.EnsurethatthepowerLEDislit.Ifnot,thedeviceisnotproperly
connected.
3.UseaWi‐Fidevice(e.g.computer,tablet,smartphone)tosearchforaWi‐Fi
networkwiththeSSID“edimax.setup”andconnecttoit.
iOS4orAndroid4andabovearerequiredforsetupona
smartphoneortablet.
4.Openawebbrowserandifyoudonotautomaticallyarriveatthe“Get
Started”screenshownbelow,entertheURLhttp://edimax.setupandclick
“GetStarted”tobeginthesetupprocess.
3
Ifyoucannotaccesshttp://edimax.setup,pleasemakesureyour
computerissettouseadynamicIPaddress.Thisisasimple
procedureandstep‐by‐stepinstructionscanbefoundintheuser
manual.
5.SelectamodeforyourBR‐6428nSV2/nCandclick“Next”tocontinue.
4
Wi‐FiRouterThedeviceconnectstoyourmodemandenables
Internet(wirelessandEthernet)accessonyour
networkdevices.
AccessPointThedeviceconnectstoanexistingroutervia
EthernetcableandprovidesInternet(wireless
andEthernet) accessforyournetworkdevices.
RangeExtenderThedeviceconnectswirelesslytoyourexisting
networkandrepeatsthewirelesssignal.
6.Followtheon‐screeninstructionstocompletesetup.Formoreinformation,
pleaserefertotheusermanual.
5
BrowserBasedConfigurationInterface
Aftersetupyoucanaccessthebrowserbasedconfigurationinterfaceto
configureorchangethesettingsoftheBR‐6428nSV2/nC.Toaccessthe
browserbasedconfigurationinterface,enterhttp://edimax.setupintothe
URLbarofawebbrowseronanetworkdevicewhichisconnectedtothe
BR‐6428nSV2/nC.
Ifyoucannotaccessedimax.setup,connecttheBR‐6428nSV2/nC
toacomputerusinganEthernetcableandtryagain.
Youwillbepromptedforausernameandpassword.Thedefaultusernameis
“admin”andthedefaultpasswordis“1234”.
Youwillarriveatthe“Status”screenshownbelow.Usethemenudownthe
leftsidetonavigate.Formoreinformation,refertotheusermanual.
6
Troubleshooting
1. Inrangeextendermode,howdoIconnecttoanetworkwhich
hasahiddenSSID?
a. DuringiQSetupselect“Setupextendermanually”asshownbelow.Manually
entertheSSIDofthehiddennetwork,anSSIDforyourdeviceandthe
encryptioninformationforthehiddennetwork.
SSID EntertheSSID(networkname)ofyourexisting,hidden
network.
DeviceSSIDEnteranSSIDfortheBR‐6428NsV2/nCorleaveitblankto
useadefaultwhichconsistsofyourexistingrouter’sSSID
(above)+"_2EX".
EncryptionEntertheencryptioninformationforyourexisting,hidden
network.
2. Ican’taccesstheInternet.
a. Ensurethatallcablesareconnectedproperly.TryadifferentEthernetcable.
b. Checkifyoucanaccessthewebbasedconfigurationinterface.Ifnot,please
ensureyourcomputerissettouseadynamicIPaddress.Refertotheuser
manualforguidanceifyouareunsurehowtodothis.
c. LogintothewebbasedconfigurationinterfaceandgotoInternet>WANSetup
andcheckthattheconnectiontypeiscorrect.Ifyouareunsurewhichinternet
connectiontypeyouhave,pleasecontactyourInternetServiceProvider(ISP).
7
d. Connectyourcomputerdirectlytoyourmodemandcheckifyoucanaccessthe
internet.Ifyoucan’t,pleasecontactyourInternetserviceproviderfor
assistance.
3. Ican’topenthewebbasedconfigurationinterface.
a. PleaseensureyourcomputerissettouseadynamicIPaddress.Refertothe
usermanualforguidanceifyouareunsurehowtodothis.
4. HowdoIresetmydevicetofactorydefaultsettings?
a. Toresetthedevicebacktoitsfactorydefaultsettings,pressandholdthe
WPS/Resetbuttonforover10seconds,untilthepowerLEDbeginstoflash.
Pleasewaitafewminutesfortheproducttorestart.Whenthedevicerestarts,
allsettingswillbereset.Defaultsettingsaredisplayedontheproductlabelon
thebackofthedevice,asshownbelow:
8
RouterLoginEnterthisURLinawebbrowsertoruniQSetupor
configureadvancedsettings.Youmustbe
connectedtothedevicebyWi‐FiorEthernet
cable.
Username/PasswordThisisthedefaultusernameandpasswordto
accessthebrowserbasedconfigurationinterface
whenyougotothe“RouterLogin”URL(above).
Wi‐FiNetwork
Name
ThisisthedefaultWi‐Finetworknameforthe
device.Searchforthisname(SSID)andconnectto
itinordertoaccessthe“RouterLogin”URL
(above).
MACAMACaddressisuniquetoeverydeviceandis
usedforidentificationwithinanetwork.Your
device’suniqueMACaddressisdisplayedhere.
PINCODEThisisyourdevice’sPINcodeforWi‐FiProtected
Setup(WPS).
5. Iforgotmypassword.
a. Resettheroutertoitsfactorydefaultsettingsandusethedefaultusername
adminanddefaultpassword1234.Defaultsettingsaredisplayedontheproduct
labelonthebackofthedevice,asshownabove.
6. MyBR‐6428nSV2/nChasaweakwirelesssignalinrange
extendermode.
a. Weaksignalsareusuallycausedbyinterferencefromotherdevicesorobstacles
blockingtheBR‐6428nSV2/nC’swirelesssignal:
b. Keepthedeviceawayfromotherradiodevicessuchasmicrowavesorwireless
telephones.
c. Donotputthedeviceinthecornerofaroomorunder/nearbymetal.
d. EnsurethereareasfewobstaclesaspossiblebetweentheBR‐6428nSV2/nCand
yourwirelessnetworkdevice.
Inrangeextendermode,theBR‐6428nSV2/nC’Sweakwirelesssignalmaybein
turncausedbyaweaksignalfromyourexistingrouter.It’simportanttochoosea
goodlocationfortheBR‐6428nSV2/nCinrelationtoyourexistingwirelessrouter.
Thebestlocationisroughlyinthemiddlebetweenyourexistingwirelessrouter
andtheareayouwouldliketobecoveredbytheBR‐6428nSV2/nC.Ifyouaretoo
farawayfromyourexistingrouter,thenitisdifficultfortheBR‐6428nSV2/nCto
receiveawirelesssignal.
9
7. DotheWANandLANportsworkthesamewhenthedeviceisin
differentmodes?
No,theWANandLANportshaveslightlydifferentfunctionsdependingonthe
operatingmodeofthedevice.
a. InWi‐Firoutermode,theWANportisforadirectconnectiontoyourxDSL
modem.TheLANportsareforwirednetworkclients.
b. Inaccesspointmode,theWANportisnotfunctional.Connectyourexisting
routertothedevice’sLANport,andtheotherLANportscanconnectwired
networkclients.
c. Inrangeextendermode,theWANportisnotfunctionalandtheLANportsare
forwirednetworkclients.Donotconnectyourexistingroutertothedevice’s
WANorLANports,asthiscancausethedevicetomalfunction.
