eDAQ Quad Tc/mV Manual de usuario
e-corder
®
www.
eDAQ
.com
eDAQ Amp User Manual
Quad Tc/mV Amp
QQuad Amp
Tc/mV
150
Channel 1 Channel 2 Channel 3 Channel 4
On-line On-line On-line On-line
isolated
Cu
+
Cu
+
Cu
+
Cu
+
ii
This document was, as far as possible, accurate at
the time of printing. Changes may have been made
to the software and hardware it describes since
then: eDAQ Pty Ltd reserves the right to alter
specifications as required. Late-breaking information
may be supplied separately. Latest information and
software updates can be obtained from our web
site.
Trademarks of eDAQ
e-
corder
and PowerChrom are registered trademarks
of eDAQ Pty Ltd. Specific model names of data
recording units, such as
e-
corder
201, and
PowerChrom 280, are trademarks of eDAQ Pty Ltd.
Chart and Scope are trademarks of ADInstruments
Pty Ltd and are used under license by eDAQ.
EChem is a trademark of eDAQ Pty Ltd.
Other Trademarks
Mac OS, and Macintosh, are registered trademarks
of Apple Computer, Inc. Windows 98, Windows
Me, Windows 2000, and Windows XP are
trademarks of Microsoft Corporation.
PostScript, and Acrobat are registered trademarks of
Adobe Systems, Incorporated.
All other trademarks are the properties of their
respective owners.
Product: Quad Tc/mV Amp (EA150)
Document Number: U-EA150-0806
Copyright © August 2006
eDAQ Pty Ltd
6 Doig Avenue
Denistone East, NSW 2112
AUSTRALIA
http://www.eDAQ.com
email: [email protected]
All rights reserved. No part of this document may be
reproduced by any means without the prior written
permission of eDAQ Pty Ltd.
Quad Tc/mV Amp
iii
Contents
1
Overview
1
How to Use this Manual 2
Checking the Quad Tc/mV Amp 2
eDAQ Amps 2
2
The Quad Tc/mV Amp
5
The Front Panel 6
The Thermocouple Inputs 6
The On-line Indicators 6
The Back Panel 7
The Signal Outputs 7
I
2
C Connector 7
Connecting to the e-
corder 7
The Quad Tc/mV Amp Self Test 9
Using Chart software 9
Setting up the Quad Tc/mV Amp 9
Previewing the Signal 10
Calibration 12
Automatic Calibration 12
13
Manual Calibration 13
A
Technical Aspects
15
Quad Tc/mV Amp Operation 15
Technical Description 15
B
Troubleshooting
17
C
Specifications
19
Index
21
License & Warranty
23
Quad Amp
Tc/mV
150
Channel 1
On-line
isolated
Cu
+
iv
Quad
Tc/mV Amp
Quad pH/mV Amp
1
CHAPTER ONE
1
Overview
The eDAQ Quad Tc/mV Amp is designed to work with an
e-
corder
system, recording signals from up to four thermocouples (or other low
voltage sources) simultaneously.
2
Quad
pH/mV Amp
How to Use this Manual
This manual describes how to set up and begin using your Quad
Tc/mV Amp. The use of the pH/mV Amp with the Chart software
Thermocouple Calibration extension is discussed. The appendices
provide technical and troubleshooting information.
Checking the Quad Tc/mV Amp
Before you begin working with the Quad Tc/mV Amp, please check
that:
• all items described in the packing list are included; and that
• there are no signs of damage that may have occurred during
transit.
Contact your eDAQ distributor if you encounter a problem.
You should also become familiar with the basic features of your
e-
corder
system, which are discussed in the
e-
corder
Manual
which will
be installed on you hard disk.
eDAQ Amps
The Quad Tc/mV Amp is part of a family of preamplifiers known as
eDAQ Amps.
The Quad
Tc/mV Amp is designed for recording signals from up to four
pH and other potentiometric electrodes. As with other eDAQ Amps, it is
designed to be operated under full software control and is
automatically recognized by Chart or Scope software which controls its
gain range, signal filtering, and other settings.
Chapter 1 —
Overview
3
The range of eDAQ Amps includes the:
•
Quad pH/mV Amp
, suitable for connection of pH, ion selective,
and potentiometric (ORP) electrodes
•
Potentiostat
, a three–electrode potentiostat that can be used for
voltammetric and amperometric experiments. Gain ranges of 20 nA
to 100 mA in 1:2:5 steps.
• Picostat, a high sensitivity three–electrode potentiostat suitable for
use with carbon fibre and other microelectrodes. Current gain
ranges of 10 pA to 100 nA in 1:2:5 steps.
• QuadStat, a four channel, three electrode potentiostat suitable for
use with amperometric biosensors. Current gain ranges of 2 nA
to1 mA/channel in 1:2:5 steps.
• Bridge Amp, suitable for sensors requiring a low drift, high gain
differential amplifier. Also provides DC excitation
• GP Amp, suitable for high output sensors requiring a high
impedance single ended or differential amplifier. Also provides DC
excitation.
See our web site at www.eDAQ.com for more information.
4 Quad pH/mV Amp
Quad pH/mV Amp 5
CHAPTER TWO
2The Quad Tc/mV Amp
This chapter describes how to connect and use your eDAQ Quad
Tc/mV Amp.
IMPORTANT: Always make sure that the e-corder is turned off before
you connect or disconnect the Quad Tc/mV Amp. Failure to do this
may result in damage to the e-corder and/or the Quad Tc/mV Amp.
6 Quad pH/mV Amp
The Front Panel
The front panel of the Quad Tc/mV Amp is shown in Figure 2–1.
The Thermocouple Inputs
The miniature thermocouple input connectors marked ‘Cu’ and ‘+’ of the
Quad Tc/mV Amp provide connection for most types of thermocouple.
The On-line Indicators
When lit, these indicate that the Chart software has located and
initialized the Quad Tc/mV Amp. If the light does not go on when the
software is run, check that the Quad Tc/mV Amp is properly
connected.
Qua
ua
d Amp
d Amp
Tc/mV
/mV
150
Channel 1 Channel 2 Channel 3 Channel 4
On-line On-line On-line On-line
isolated
Cu +Cu +Cu +Cu +
On-line indicator
Thermocouple connector
Made in Australia by eDAQ Pty Ltd.
No user serviceable parts inside.
Refer servicing to qualified service personnel.
Input Output
I C
Bus
I C
2
Channel 4 Channel 3 Channel 2 Channel 1
Temperature signals, BNC connectors
DB–9 pin, I2C connectors
Chassis ground, 4 mm post
Figure 2–1
The Quad Tc/mV Amp
front panel
Figure 2–2
The Quad Tc/mV Amp
back panel
