EcoFasten Clickfit Manual de usuario
ECOFASTENSOLAR.COM
COMPLETE RAIL-BASED
RACKING SYSTEM
INSTALLATION GUIDE
VERSION: v3.0REVISION DATE: 12/02/22
VERSION: v3.0REVISION DATE: 12/2/22
INSTALLATION GUIDE
TABLE OF CONTENTS
PAGE
01
TABLE OF CONTENTS PAGE 01
FEATURES & BENEFITS PAGE 02
INTRODUCTION PAGE 03
OVERVIEW PAGE 04
COMPONENTS PAGE 05
RATINGS PAGE 06
ARRAY LAYOUT PAGE 07
INSTALLATION PAGE 08
GROUNDING PAGE 17
ACCESSORIES PAGE 21
CLAMP PART NUMBERS PAGE 29
COMPATIBLE MODULES PAGE 30
Clicking the page name will take you to that page
VERSION: v3.0REVISION DATE: 12/2/22
INSTALLATION GUIDE
FEATURES+ BENEFITS
PAGE
02
CLICKFIT
ClickFit conforms to UL 2703 and is one of the fastest installing rail-based systems in
the industry. Thanks to its Click-In Rail assembly, the rails can be connected to any of
EcoFasten’s composition shingle, tile, and metal roof mounts in seconds without the
need for fasteners or tools. The ClickFit system is made of robust materials, such as
aluminum and coated steel, to ensure corrosion resistance and longevity. ClickFit has
been tested in extreme weather conditions including wind, re, and snow.
FEATURES
• Tool and fastener free rail attachment
• Fully integrated bonding
• Click-on Mid & End Clamps
• Compatible with a variety of EcoFasten roof attachments
VERSION: v3.0REVISION DATE: 12/2/22
INSTALLATION GUIDE
INTRODUCTION
PAGE
03
INTRODUCTION
This manual describes the installation of the ClickFit mounting system for photovoltaic
modules on steep-slope roofs. Described within are details for composition shingle and tile,
attachments for ClickFit System. Other roof types as well as all other installation manuals
can be found for download at www.EcoFastenSolar.com.
GENERAL INSTALLATION CONDITIONS
Failure to observe the requirements in this document can lead to the exclusion of all
guarantees and product liability. EcoFasten Solar reserves the right to amend this document
without prior notice.
STABILITY & CONDITION OF THE ROOF
The roof must be in good condition and strong enough to support the weight of the modules,
including the additional equipment, wind and snow loads. When in doubt, consult with the
engineer of record, and/or the local building inspector.
APPLICATION RANGE OF CLICKFIT
Refer to Compatibility module list at the end of this document. Please refer to the Ecofasten
ClickFit span tables for system structural certication and allowable spans.
WARRANTY
Guarantee according to the warranty conditions and general terms and conditions of
EcoFasten Solar. These conditions can be found on the website at www.EcoFastenSolar.com.
LIABILITY
EcoFasten Solar cannot accept any liability whatsoever for damage or injury caused by
not taking adequate safety precautions or (accurately) following the instructions given, or
resulting from negligence during the installation of the product and any corresponding
accessories specied in this document.
VERSION: v3.0REVISION DATE: 12/2/22
INSTALLATION GUIDE
OVERVIEW
PAGE
04
OVERVIEW
The ClickFit mounting system consists of patented adjustable tile hooks and L feet, rails, and
the installation materials required for the mounting of photovoltaic modules on composition
shingle or tile roofs. For simplicity, tile hooks and L feet will be referred to as “attachments”.
ATTACHING TO THE ROOF
The attachments are fastened to the rafters. Attachments are height-adjustable to level the
system on uneven roof surfaces.
ATTACHING THE RAIL
The rail assembles to the attachments with a click-connector, or Clicker. The rail simply clicks
into place without the use of any tools.
ATTACHING THE MODULES
The modules are attached to the rails by means of mid clamps and end clamps.
Installer must review module and any 3rd party manufacturer’s documentation for
compatibility and compliance with warranty terms and conditions.
WARNING: This product must be installed and used according to this written instruction.
Any installation or use of this product not in accord with or not authorized by this written
instruction shall void any and all warranties, express or implied, on the product or the use
of the product and may cause failure, property damage and personal injury. EcoFasten is
not liable for any unauthorized use. Install and use only with other EcoFasten products to
ensure proper t and function.
VERSION: v3.0REVISION DATE: 12/2/22
INSTALLATION GUIDE
Refer to ClickFit Alternate Component Addendum for components not shown
COMPONENTS
PAGE
05
SYSTEM COMPONENTS REQUIRED
SYSTEM COMPONENTS ACCESSORIES
FRAME MLPE
MOUNT
MODULE JUMPER MLPE MOUNT WIRE MANAGEMENT
CLAMP
CLICKFIT RAIL RAIL SPLICE TILE HOOK
END CLAMP SIMPLEBLOCK-U
L-FOOT END CAP MID CLAMP
VERSION: v3.0REVISION DATE: 12/2/22
INSTALLATION GUIDE
RATINGS
PAGE
06
TORQUE SPECIFICATIONS
*Class A System re rating with Type 1, 2, and 29 PV modules with no skirt required. Class A System re rating with Type 4 and 5
modules with south edge skirt required. Any roof-to-module gap is permitted. This rating is applicable with any roof attachment.
**Class B System re rating with Type 4 and 5 modules, no skirt required. Any roof-to-module gap is permitted. This rating is
applicable with any roof attachment.
Fire Rating Class A* and B** System Fire Rating
Max System Voltage 1500 VDC
Max Fuse Rating 40A
Certication Conforms to UL STD 2703
Warranty 25 Year Material and Workmanship
UL 2703 Markings Product listing label is located on the rail end-caps
Roof Pitch 2:12 – 21:12
UL 2703 Allowable Design Load Rating 10 psf downward, 5 psf upward, and 5 psf lateral
Max Module Size 25.6 sqft
Module Orientation Portrait or Landscape
Multiple use Rated Components (Position Independent) Mid Clamp, Frame MLPE Mount and MLPE Mount
UL 2703 MARKING EXAMPLE:
Component Torque (in-lb) Notes
Lag Screw N/A Fully Seat. Use visual indicator of the black EPDM ring around the
bonded washer for torquing.
Mid-Clamp 144
End-Clamp 96
Rail Clicker Leveling Bolt 142 Pre-torqued upon delivery. Applies to Tile Hook and L-Foot/Clicker
Hook Height Bolt N/A Lightly clamp hook to ush with top of next tile row
Ground Lug N/A Refer to specic ground lug manufacturer’s installation manual
MLPE Clip 144
MLPE Mount 144
CLICKFIT
SYSTEM
MFG ID CODE: SSS-QQ-YYYY Conforms to UL STD 2703
XXXXXXX
RATINGS
VERSION: v3.0REVISION DATE: 12/2/22
INSTALLATION GUIDE
ARRAY LAYOUT
• Refer to span tables, local jurisdiction, or engineer of record specications when determining
setbacks from roof edges, attachment spans, etc.
• Mark the perimeter and corners of the array on the roof surface.
*Add 3/4” to account for the gap between modules in each direction*
• Draw or snap chalk lines where the rails will be installed,(refer to module manufacturer specs
to determine allowable mounting locations).
• Locate rafters within the area of the array. It may be necessary to shift
the array East or West on the roof in order to fall within the rail cantilever
specs (1/ 3 of span).
• Stagger rafters every row if required by the local jurisdiction, engineer of record, or company
policy.
PAGE
07
VERSION: v3.0REVISION DATE: 12/2/22
INSTALLATION GUIDE
INSTALLATION
PRE-INSTALLING RAIL SPLICES
1. Determine the number of rails required per row of modules.
2. Insert a rail splice into one rail. Do not push it past the center bump.
3. Slide the next rail onto the rail splice until the two rail ends meet.
4. Repeat steps 2 and 3 until the desired length is achieved.*
*This is usually easiest to do from the ground.
PAGE
08
VERSION: v3.0REVISION DATE: 12/2/22
INSTALLATION GUIDE
INSTALLATION
INSTALLATION OF FLASHING & L-FOOT
• ClickFit for comp shingle roofs uses EcoFasten GF-1 watertight
ashing system.
• Other roof types may use dierent EcoFasten Solar
attachments, visit ecofastensolar.com to learn about other
applications.
INSTALLATION STEPS:
1. Locate rafter lines.
2. Drill 7/32" pilot holes at all attachment points and back ll using roof-compatible sealant.
3. Separate shingles where ashing is to be installed. Insert the ashing so the top portion is under
the next row of shingles north of the pilot hole. Ensure the ashing is pushed to the third-course
of shingle to prevent water inltration through the vertical joints between shingles.
4. Align GF-1 ashing hole with pilot hole. Insert the lag bolt with pre-installed bonded washer
through the L foot and EPDM grommet. Tighten the lag bolt until fully seated. The EPDM Ring
visual indicator is the most eective way to ensure a watertight seal.
*Note the orientation of the L foot and clicker.
The clicker should be facing downslope
PAGE
09
1 2 3
