Ecler EWAMPBT+ Manual de usuario

eWAMPBT+

COMPACT AMPLIFIERS

Stereo wall amplifier with media player and BT connection

USER MANUAL

TABLE OF CONTENTS

1. IMPORTANT SAFETY INSTRUCTIONS...........................................3

2. KEY FEATURES............................................................................6

3. FRONT PANEL ............................................................................7

4. STARTUP....................................................................................8

4.1. FM ............................................................................................. 8

4.2. SD .............................................................................................. 8

4.3. USB............................................................................................ 9

4.4. BT CONNECTION ....................................................................... 9

4.5. AUX INPUT & AUX OUTPUT .................................................... 10

5. MECHANICAL DIAGRAMS .........................................................10

6. REMOTE CONTROL...................................................................11

7. TECHNICAL SPECIFICATIONS .....................................................12

8. REAR PANEL.............................................................................13

9. INSTALLATION .........................................................................14

10. PACKING LIST...........................................................................15

1. IMPORTANT SAFETY INSTRUCTIONS

•Read this instructions manual careful and follow all the

indications and safety warnings.

•Keep the instructions manual in an easily accessible place

for consulting at any time when needed.

•Do not handle the device or alter any of its parts, including

the electrical connection, mechanical fastening and external

structure.

•Keep the equipment away from sources of heat such as

radiators, stoves or heaters.

•Do not install or store the equipment in damp environments

or in places near to water.

•Do not insert any object of any kind through the ventilation

grilles on the device housing nor through any opening that

may contain the same. Failure to comply with these

guidelines may lead to a high risk of electrocution.

•Make sure not to cover the openings for heat dissipation

located in the metal body of the equipment. Also, avoid

build up of dust on the same.

•Prior to connecting the equipment, check that the power

supply input is in accordance with the voltage shown on the

label.

•This device needs to be earthed. At all times, make sure to

use the power supply cable supplied with the equipment

and to always connect the jack into an earthed plug.

•Do not pull on the power supply cable to unplug it.

•Do not use, connect or disconnect the equipment with wet

hands or feet.

•Immediately disconnect the equipment from the power

supply in the event of noting any kind of breakdown or

damage to the same that may be hazardous. Then contact

the authorized technical service.

•Clean the equipment with a dry cloth or with neutral soap

and a slightly damp cloth. Avoid using detergents, solvents

or any other type of abrasive substance.

•Make sure that the equipment is disconnected from the

power supply, or put the power in the off position before

handling any of the inputs or outputs on the equipment.

WARNING: This symbol indicates risk of electric shock

inside the device. Under no circumstance should the device

be opened while powered up.

WARNING: This symbol indicates that precautions should

be taken when handling and connecting the device.

Observing certain indications in the instructions manual is

required..

WARNING: This product must not be discarded, under any

circumstance, as unsorted urban waste. Take to the nearest

electrical and electronic waste treatment centre.

NEEC AUDIO BARCELONA, S.L. accepts no liability for any damage

that may be caused to people, animal or objects due to failure to

comply with the warnings above.

2. KEY FEATURES

Built-in 2x10 WRMS high efficient amplifier @ 8 ohm (min.

load)

LED screen

Multiple music connection modes, including FM, micro SD, USB,

Bluetooth, AUX input and AUX output

Supports MP3, WMA, WAV and FLAC

Adjustable sensitivity of auxiliary input

Stereo AUX output

Can store up to 20 FM radio channels. Support automatic and

manual search

Wide voltage input, suitable for 100~240VAC, 50/60Hz

Remote control included

Surface-mount installation box included

Play/pause

Volume down

Mode (source selection)

Volume up

Infrared receiver

Display

Micro SD

USB

Power ON

3. FRONT PANEL

WARNING: connect the AC terminals to electrical mains

supply before powering ON the device.

4. STARTUP

4.1. FM

Press Mkey to choose FM mode.

Automatic Search: long press to start the automatic channel search

and the system will automatically save the available radio stations.

Manual tuning mode: long press or to enter the manual tuning

mode; and then short press or to adjust the current channel.

After no key operation within 5 seconds, it will save the current

channel and leave manual tuning mode.

Mute: short press to mute FM playback.

Channel selection: short press or to navigate through saved

channels.

Volume control: short press +or -to increase or reduce the

current volume.

4.2. SD

Press Mkey to choose SD mode. If there is no SD card, the display will

show “NO” and flicker. If files are not supported or there are no files,

the display will show “----“.

Play control: to play/pause. Short press or to navigate

through songs. Long press to fast forward or fast reverse.

Volume control: short press +or -to increase or reduce the

current volume.

4.3. USB

Press Mkey to choose USB mode. If there is no USB device, the display

will show “NO” and flicker. If files are not supported or there are no

files, the display will show “----“.

Play control: to play/pause. Short press or to navigate

through songs. Long press to fast forward or fast reverse.

Volume control: short press +or -to increase or reduce the

current volume.

4.4. BT CONNECTION

Press Mkey to choose Bluetooth mode. If there is no connection, the

display will show “BT” and flicker. When the device is connected

successfully, “BT” will be always on. eWAMPBT+ is displayed in other

devices as ECLERXXXXXXXXX, where the last 9 digit numbers is the

device’s serial number. The password can be found in the rear side

label.

Play control: to play/pause. Short press or to navigate

through songs. Long press to fast forward or fast reverse.

Volume control: short press +or -to increase or reduce the

current volume.

86mm

38mm

10mm

4.5. AUX INPUT & AUX OUTPUT

Press Mkey to choose AUX1 input mode.

Play control: to play/mute. When it is muted, the display will

flicker.

Sensitivity adjustment: long press or to select S1 or S2

sensitivity adjustment. S1: input and output 500mV; S2: input

1000mV, output 500mV)

Volume control: short press +or -to increase or reduce the

current volume.

In addition, eWAMPBT+ features an aux audio output (AUX OUTPUT).

This stereo audio signal is identical to the powered signal, but with

LINE level (0dBV). Perfect to connecting an additional audio system

like a self-powered sub-woofer for bass reinforcement.

5. MECHANICAL DIAGRAMS
