Echogear EGGA-DMAC1 Manual de usuario

#YourGearUpgraded

INSTRUCTION MANUAL

Model EGGA-DmAc1

Single Monitor

Desk Mount

WEIGHT RESTRICTIONS

For monitor (including accessories)

CANNOT EXCEED:

35 lbs.

(15.8 kg)

IMPORTANT SAFETY INSTRUCTIONS. READ ENTIRE MANUAL PRIOR TO quest. SAVE These INSTRUC

TIONS.

Before You EmBark on your Quest... just read it so you don’t get pwned!

Please read through these instructions completely and check your monitors' owner manual to see if there

are any special requirements for mounting your monitor.

If you do not understand these instructions, are a noob or have doubts about the safety of the

installation, assembly or use of this product, contact:

CAUTION: Manufacturer is not responsible for damage or injury caused by incorrect

assembly or use. To avoid any potential personal injuries, property damage or tipping:

►Your mounting surface must be stable and rugged enough to support the weight and motion of the

monitor and mount.

►Do not use this product for any purpose not explicitly speciﬁed by manufacturer.

“You even lift, Brah?....

Ok, even if you do... doooon’t do it.”

The Echogear Pros @ 1-855-428-2490 or www.echogear.com.

Contact The Echogear Pros:

1-855-428-2490

www.echogear.com

DESKTOP

THICKNESS

BFG

Yo Hands

Power up! Grab These Tools from Your arsenal

Size up Your Mounting Surface

Unsure?

UUUUHHH ?!?

Phillips

Screwdriver Apple

Required to Get the Job Done

Optional Based on Skill Level

"No snapin

pics for

twitter

til you're

done!"

Hex Keys

BOnus Loot!

FREE Inside Every Box

⁄

"collect the

whole set"

Mini-Nuke

Pump

Refreshment Saw

"Phil is

the boss"

0.8 in. — 2.6 in.

(20 mm — 66 mm)

We’re driven to give DIYers an awesome install experience. We stand

behind everything we make because you deserve the best entertainment

experience without sacriﬁcing quality and spending your whole paycheck.

Guess what? We’ll help you through the entire process, too.

Why? Because we like to help and it’s our passion to provide authentic

service. We won’t leave you hanging, no matter what.

Our U.S. based Echogear Pros answer the phone in all days ending in Y.

That means availability to try and stump our expert sta 7 days a week.

Call us if you…

1Have any questions before, during, or after install.

2Need dierent hardware to ﬁt your monitor model.

3Just need someone to chat with. We’re here for you.

Echogear Satisfaction Guarantee:

ONE MORE THING ...

WARNINGS:

DON'T ALLOW CHILDREN TO FEED ON CONTENTS AND NEVER USE DAMAGED GOODS!

►This product contains small items that are a choking hazard if swallowed.

►Before you start assembly, verify all parts are included and undamaged. If any parts are missing

or damaged, do not return the damaged item to your dealer; contact Customer Service.

Here's your Loadout

GEAR FOR LEVEL 1

1 Desk Mount 1 Knob

(Clamp Screw)

1 Mount Cover

(Attached) 1 Clamp 4

Gear FOR Level 3

2 Cable

Straps

Gear FOR Level 2

4 Screws

M4 X 12mm

4 Spacers

2.5 mm

4 Screws

M4 X 30mm

4 Spacers

5 mm

4 Spacers

22 mm

STAGE 1: Insert Knob into Mount and Attach Clamp

Level 1 Lock It Down! Assemble Clamp and Mount to Desk

"You spin me right round, baby

right round like a record, baby

right round round round...and

round and round and round..."

STAGE 2: Secure Clamp to Surface

"...and round and round

and round and round."

USE HEX KEY

TO SECURELY

CLAMP IT DOWN.

STAGE 3: Adjust Arm to Desired Height

TIP: ADJUST THE

ARM HEIGHT BEFORE

MONITOR IS ATTACHED.

OTHERWISE IT'S A TWO

PERSON JOB.

"Lefty"

"Righty"

to TIGHTEN

tension

to LOOSEN

tension

Level 2 Make The DROP! Attach Monitor to Mount

Select

Spacers

(if needed)

Flat Monitor

NEEDED FOR

NOT NEEDED

Select

Screws

Bracket

Short Screw

Spacer

Long Screw

Bracket

7/ 8 / 9

STAGE 1: Determine Screw Length and Spacer Size

Round

Monitor

Inset

Holes Cables

Flat

Monitor +
