E180-ZG120B-TB User Manual
Chengdu Ebyte Electronic Technology Co., Ltd. E180-ZG120B-TB User Manual
Copyright ©2012–2019，Chengdu Ebyte Electronic Technology Co., Ltd.
1
Content
1. Module introduction......................................................................................................................................... 2
2. Instruction......................................................................................................................................................... 2
3. Drive installation.............................................................................................................................................. 4
About us................................................................................................................................................................4
Chengdu Ebyte Electronic Technology Co., Ltd. E180-ZG120B-TB User Manual
Copyright ©2012–2019，Chengdu Ebyte Electronic Technology Co., Ltd.
2
1. Module introduction
E180-ZG120B-TB has been pre-welded for testing Chengdu Ebyte E180-ZG120B,please refer to the module
manual for detailed use.
All IO of E180 series wireless modules have been exported.
With CP2102G serial chip, serial communication can be developed.
With USB interface, can be directly plugged into the computer for use.
Users can access external power supply and serial port by themselves.
Stable work and easy to develop.
2. Instruction
2.
Chengdu Ebyte Electronic Technology Co., Ltd. E180-ZG120B-TB User Manual
Copyright ©2012–2019，Chengdu Ebyte Electronic Technology Co., Ltd.
3
Description：
No.
Pin
Description
1
AVDD
Module power port, 3.3V power
supply is recommended
2
3.3V
Baseboard LDO output 3.3V, can
supply power to the module
3
TXD
TXD of cp2102
4
RXD
RXD of cp2102
5
PA1
RXD of the module
6
PA0
TXD of the module
No.
Name
Direction
Function
1
GND
-
Ground, connected to power supply reference ground
2
GND
-
Ground, connected to power supply reference ground
3
PD13
Input
TOUCHLINK pin, which is continuously pulled lower than 3000ms,
will initiate a ZLL network establishment or join request
4
PD14
Input
WAKE pin is mainly used to wake up the sleep terminal. It is high level
when powered on. When the pin is pulled low externally, the sleep
terminal device will be woken
5
PA0(TX)
Output
Serial port transmission port TX
6
PA1(RX)
Input
Serial port receiving port RX
7
PA2
Input/Outp
ut
Reserve
8
PA4
Input/Outp
ut
Reserve
9
PB11
Input
Operating mode switching pin. When the pull-low time is longer than
500ms, the operating mode is switched.
10
PB12
Input
UART_BAUD_RESET pin is used to reset the device baud rate. The
power-on default is high level. In any mode, if this pin is pulled lower
for more than 1000ms, the serial port parameters of the module will be
restored to the default 115200.
11
PB13
Output
ACK pin is used to indicate the last user data transmission status. This
pin is pulled low before the transmission is started, and the pin is pulled
high after the transmission.
12
PB14(GPIO0)
Input/Outp
ut
GPIO Input/ Output port 0
13
3.3V
-
Module power supply positive reference voltage, voltage range
14
GND
-
Ground, connected to power supply reference ground
Chengdu Ebyte Electronic Technology Co., Ltd. E180-ZG120B-TB User Manual
Copyright ©2012–2019，Chengdu Ebyte Electronic Technology Co., Ltd.
4
15
PB15(GPIO1)
Input/Outp
ut
GPIO Input/ Output port 1
16
PA5
Input/Outp
ut
Reserve
17
PA3
Input/Outp
ut
Reserve
18
PD15
Output
AUX pin indicates the current working status of the device. When the
pin is low level, it indicates that the device is busy, and high level
indicates that the device is idle.
19
PC6(GPIO2)
Input/Outp
ut
GPIO Input/ Output port 2
20
PC7(GPIO3)
Input/Outp
ut
GPIO Input/ Output port 3
21
PC8(ADC1)
Input
ADC detection port 1
22
PC9(ADC2)
Input
ADC detection port 2
23
PC10(ADC3)
Input
ADC detection port 3
24
PC11(ADC4)
Input
ADC detection port 4
25
SWCLK
Input/Outp
ut
DBG_SWCLKTCK
26
SWDIO
Input/Outp
ut
DBG_SWDIOTMS
27
PF2(PWM0)
Output
PWM output port 0
28
PF4(PWM2)
Output
PWM output port 2
29
PF5(PWM3)
Output
PWM output port 3
30
PF7
Output
The LINK pin indicates the current network status of the module, output
high level meter has been added to the network.
31
PF6(PWM4)
Output
PWM output port 4
32
PF3(PWM1)
Output
PWM output port 1
33
PD12
Input/Outp
ut
Reserve
34
PD11
Input/Outp
ut
Reserve
35
PD10
Input/Outp
ut
Reserve
36
GND
Input/Outp
ut
Ground, connected to power supply reference ground
37
nRESET
Input
Reset pin
3. Drive installation
The CP2102 chip is used as the serial port. Please download and use the driver software provided by our company.
After installation, the serial port can be identified in the device manager.
About us
Sales hotline: 4000-330-990 Tel: 028-61399028
Support: support@cdebyte.com Website: www.ebyte.com
Address: Innovation Center B333~D347, 4# XI-XIN road, High-tech district (west), Chengdu, Sichuan,
China
