Eaton Power Xpert Gateway Minislot Manual de programación

p/n: P-164000208

Revision 06

Package Contents

lPower Xpert Gateway Minislot (PXGMS) UPS Card

lUSB Cable

lQuick Start Instructions

Ident

Power

Act

100

PXGMS UPS

Restart TX RX

Setup

CMN

Status

DHCP EMP

Ethernet 10/100

Quick Start Instructions

Eaton®® Power Xpert®® Gateway Minislot (PXGMS) UPS Card

Eaton reserves the right to change specifications ithout prior notice. Eaton®, Po er Xpert®, and PredictPulseTM are registered

trademarks of Eaton or its subsidiaries and affiliates. Google Chrome is a trademark of Google Inc. Linux is a registered trademark of

Linus Torvalds. Microsoft, Internet Explorer, and Windo s are registered trademarks of Microsoft Corporation in the United States and in

other countries. Mozilla and Firefox are registered trademarks of the Mozilla Foundation. All other trademarks are property of their

respective companies.

express ritten approval of Eaton.

HHeellpp DDeesskk NNuummbbeerrss

United States 1-800-356-5737 or 1-800-843-9433

Canada 1-800-461-9166 ext 260

All Other Countries Call your local service representative

Web Site www.eaton.com/pxgms

NOTE On the Web site opening page, click Support and select the Customer Service

link for more information.

Eaton PXGMS Card Quick Start Instructions P-164000208—Rev 06 iii

TTaabbllee ooff CCoonntteennttss

EEaattoonn PPoowweerr XXppeerrtt GGaatteewwaayy MMiinniisslloott ((PPXXGGMMSS)) UUPPSS CCaarr QQuuiicckk SSttaarrtt IInnssttrruuccttiioonnss ................................................................................................11

Installation Checklist ........................................................................................................................................1

Install the Card................................................................................................................................................2

Connect the Card to the Computer ...................................................................................................................... 4

Install the US Driver Software ..........................................................................................................................6

Obtain a DHCP-Assigned IP Address ...................................................................................................................8

Assign an IP Address Manually......................................................................................................................... 11

Enable rowser Compatibility Mode .................................................................................................................. 13

Register a PredictPulse Subscription.................................................................................................................. 14

Verifying and Updating the Firmware Revision.................................................................................................. 14

Configuring the Connectivity Card for PredictPulse ............................................................................................ 16

PredictPulse Remote Monitoring Activation Completion Checklist ........................................................................... 20

iv Eaton PXGMS Card Quick Start Instructions P-164000208—Rev 06

Table of Contents

Eaton PXGMS Card Quick Start Instructions P-164000208—Rev 06 1

EEaattoonn PPoowweerr XXppeerrtt GGaatteewwaayy MMiinniisslloott ((PPXXGGMMSS)) UUPPSS CCaarr QQuuiicckk SSttaarrtt IInnssttrruuccttiioonnss

IInnssttaallllaattiioonn CChheecckklliisstt

1. Verify that the following items are available:

oPower Xpert Gateway Minislot (PXGMS) UPS Card package contents (card, cable, Quick Start

Instructions)

oPhillips®screwdriver

oAvailable US port on a computer running Microsoft®Windows®

oWeb browser (Microsoft Internet Explorer®version 11.0 and higher, Mozilla®Firefox®, or

Google Chrome™ are recommended)

2. If you are going to use Dynamic Host Configuration Protocol (DHCP), provide your local network

administrator with the card's MAC address. The MAC address is located on either the shipping box label or

the label on this card.

oMAC Address _______________________________________________

3. If you are not going to use DHCP to provide any of the settings listed below, contact your local network

administrator for the settings.

In the table below, check the DHCP check box or enter the values for manual configuration. This data is

referenced later in the procedure.

Item D CP* Manual Configuration

IPv4 oCard IP Address: _______________________________

Netmask: _____________________________________

Gate ay: _____________________________________

DNS – Name Servers oName Server #1:________________________________

Name Server #2:________________________________

Name Server #3:________________________________

DNS – Domain oDomain:_________________________________________

* The net ork administrator normally sets up the DHCP server to provide a static IP address each time the card makes a

DHCP request.

4. If you need e-mail functionality, obtain the SMTP mail server's IP address or host name. If using the SMTP

host name, verify that you also have the Name Server IP address (see Step 3).

oSMTP (mail server) IP Address

or Host Name

__________________________________________________________________________________

2 Eaton PXGMS Card Quick Start Instructions P-164000208—Rev 06

IInnssttaallll tthhee CCaarr

NOTE The hot-swappable PXGMS card can be installed without turning off the UPS or

disconnecting the load.

NOTE If your UPS is a 93PM, there may be a metal strip that prevents you from installing the

PXGMS card. If so, locate the metal strip bolted to the top of the UPS. Remove the

three bolts that attach the metal strip. Then, follow the procedure to install the PXGMS

card.

To install the PXGMS card:

1. On the PXGMS card, verify that all six DIP switches are in the OFF position (see Figure 1).

Figure 1. Verify DIP Switches are OFF

Ident

Power

Act

100

PXGMS UPS

Restart

Setup

CMN

Status

DHCP

EMP

Ethernet 10/100

13456

OFF

2. If not already done, record the MAC address from either the shipping box label or the label on this card for

future reference (see the Installation Checklist section).

3. Remove the mini-slot cover from the UPS. Retain the screws.

NOTE If another card is already installed with an attached communication cable, disconnect the

cable and then remove the card.

4. To prevent electrostatic discharge (ESD), place one hand on a metal surface, such as the UPS rear panel.

5. Slide the card into the open slot and secure it with the screws removed in Step 3 (see Figure 2).

Install the Card

Eaton PXGMS Card Quick Start Instructions P-164000208—Rev 06 3

Figure 2. Secure the PXGMS Card

Ident

Power

Act

100

PXGMS UPS

Restart TX RX

Setup

CMN

Status

DHCP EMP

Ethernet 10/100 +

6. From your laptop, go to www.eaton.com/pxgms.

7. On the esources tab, scroll down and expand the Software, firmware, and applications section to

download the Power Xpert Gateway USB Signed Windows Device Driver.

8. Save the driver configuration file (eaton-pxgms-firmware.zip) to the C: drive using the default location or a

folder you select. Note the path of the downloaded file on your computer.

NOTE Do not download the file to your desktop.

Install the Card

4 Eaton PXGMS Card Quick Start Instructions P-164000208—Rev 06

CCoonnnneecctt tthhee CCaarr ttoo tthhee CCoommppuutteerr

To connect the card to the computer:

1. Plug the small connector at the end of the supplied US configuration cable into the setup port on the card

(see Figure 3).

Figure 3. Install the USB Cable

Ident

Power

Act

100

PXGMS UPS

Restart TX RX

Setup

CMN

Status

DHCP EMP

Ethernet 10/100 +

2. Plug the other end of the US cable into the US port on the computer. The Windows operating system

detects new hardware.

NOTE If a message indicates that the device driver software was not successfully installed,

click Ignore.

NOTE You may see a pop-up message window that shows “Found new hardware.” This

indicates that the hardware installed successfully.

3. Connect an active Ethernet cable (not supplied) to the Ethernet 10/100 connector on the PXGMS card (see

Figure 4).

Connect the Card to the Computer

Eaton PXGMS Card Quick Start Instructions P-164000208—Rev 06 5

Figure 4. Install the Ethernet Cable

Ident

Power

Act

100

PXGMS UPS

Restart TX RX

Setup

CMN

Status

DHCP EMP

Ethernet 10/100 +

4. Wait for the power light and status light on the installed card to illuminate. This takes about two minutes.

5. Open a Web browser and type the default IP address (https://169.254.0.101 for firmware 2.6.0 or later,

http://192.168.200.101 for earlier firmware versions).

6. Did the Power Xpert Gateway software open to the PXGMS page?

• If yes, the driver has already been installed automatically. Either verify the IP address assigned

through DHCP or manually enter a static (fixed) IP address for the card’s network connection:

a. To verify the DHCP-assigned IP address, go to Step 12 of the

Obtain a DHCP-Assigned IP Address section.

b. To manually enter a fixed IP address, go to Assign an IP Address anually.

• If no, the driver has not been installed. Go to the Install the USB Driver Software section to confirm

that you have the most current US Driver software. If not, install or update the US Driver software.

Connect the Card to the Computer

6 Eaton PXGMS Card Quick Start Instructions P-164000208—Rev 06

IInnssttaallll tthhee UUSSBB DDrriivveerr SSooffttwwaarree

The steps you use to install the driver software depend on your operating system (OS). This procedure provides

instructions for installing driver software on a Windows OS.

NOTE You can use either the Device Manager path or the Devices and Printers path to browse

for the driver software and install it. This procedure uses the Device Manager.

To install the driver from the Device Manager:

1. Click Start in the Start bar. Type Device in the search box.

2. Select Device Manager from the list above the search box. The Device Manager displays (see Figure 5).

Figure 5. Device Manager

3. Expand the Network adapters and Ports (COM & LPT) sections as shown in Figure 5.

• Look for a US Serial Device with a COM port designation (COM4 in the example shown in Figure 5)

• Unplug the US connection to the card to verify the correct COM device in the Device Manager

4. Right-click the USB Serial Device (COM#) to display the menu and select Update Driver Software.

• If a pop-up message displays, “The best driver is already installed,” click Close and go to Step 10.

• Otherwise, go to Step 5.

5. Select Browse my computer for driver software (see Figure 6). Click Next. The next page displays.

Install the USB Driver Soft are
